LMI Technologies Gocator 2320 User manual

USERMANUAL Gocator 2300 & 2880 Series
Document revision:C

Gocator 2300 & 2880 Series 2
Copyright
Copyright © 2015 by LMI Technologies, Inc. All rights reserved.
Proprietary
This document, submitted in confidence, contains proprietary information which shall not be
reproduced or transferred to other documents or disclosed to others or used for manufacturing or any
other purpose without prior written permission of LMI Technologies Inc.
No part of this publication may be copied, photocopied, reproduced, transmitted, transcribed, or
reduced to any electronic medium or machine readable form without prior written consent of LMI
Technologies, Inc.
Trademarks and Restrictions
Gocator™ is a registered trademark of LMI Technologies, Inc. Any other company or product names
mentioned herein may be trademarks of their respective owners.
Information contained within this manual is subject to change.
This product is designated for use solely as a component and as such it does not comply with the
standards relating to laser products specified in U.S. FDA CFR Title 21 Part 1040.
Contact Information
For more information, please contact LMI Technologies.
LMI Technologies, Inc. 1673 Cliveden Ave.
Delta, BC V3M 6V5
Canada
Telephone: [phone]
Facsimile: [phone]
www.lmi3D.com

Gocator 2300 & 2880 Series 3
Table of Contents
Copyright 2
Table of Contents 3
Introduction 9
Safety and Maintenance 10
Laser Safety 10
Laser Classes 11
Precautions and Responsibilities 12
Class 3B Responsibilities 12
Nominal Ocular Hazard Distance (NOHD) 13
Systems Sold or Used in the USA 14
Electrical Safety 14
Environment and Lighting 15
Sensor Maintenance 16
Getting Started 17
System Overview 17
Standalone System 17
Dual-Sensor System 17
Multi-Sensor System 18
Hardware Overview 20
Gocator 2300 &2880 Sensor 20
Gocator 2300 &2880 Cordsets 20
Master 100 21
Master 400/800 22
Master 1200/2400 22
Calibration Targets 23
Installation 25
Grounding - Gocator 25
Recommended Grounding Practices - Cordsets 25
Grounding - Master 400/800/1200/2400 26
Mounting 26
Orientations 27
Network Setup 30
Client Setup 30
Gocator Setup 32
Running a Standalone Sensor System 32
Running a Dual-Sensor System 33
Next Steps 36
Theory of Operation 38
3D Acquisition 38
Principle of 3D Acquisition 38
Resolution and Accuracy 39
X Resolution 39
Z Resolution 40
Z Linearity 40
Profile Output 41
Coordinate Systems 41
Sensor Coordinates 41
System Coordinates 41
Resampled and Uniform Spacing Profile
Format 42
Gocator Web Interface 43
User Interface Overview 43
Common Elements 44
Toolbar 44
Saving and Loading Settings 44
Managing Multiple Settings 45
Recording, Playback, and Measurement
Simulation 46
Downloading, Exporting, and Uploading
Recorded Data 48
Log 49
Metrics Area 50
Data Viewer 50
System Management and Maintenance 51
Manage Page Overview 51
Sensor System 52
Sensor Autostart 52
Dual-Sensor System Layout 52
Buddy Assignment 54
Exposure Multiplexing 55
Networking 55
Motion and Alignment 56
Alignment Reference 57
Encoder Resolution 57
Encoder Value and Frequency 58
Travel Speed 58
Jobs 58
Security 60
Maintenance 61
Sensor Backups and Factory Reset 62
Firmware Upgrade 63
Scan Setup and Alignment 65
Scan Page Overview 65

Gocator 2300 & 2880 Series 4
Scan Modes 66
Triggers 67
Trigger Examples 70
Trigger Settings 71
Sensor 72
Active Area 73
Tracking Window 74
Transformations 76
Exposure 76
Single Exposure 77
Dynamic Exposure 78
Multiple Exposure 79
Spacing 81
Sub-Sampling 82
Spacing Interval 82
Material 83
Alignment 85
Alignment States 85
Alignment Types 86
Alignment: With and Without Encoder
Calibration 86
Aligning Sensors 87
Clearing Alignment 89
Filters 90
Gap Filling 90
Median 91
Smoothing 92
Decimation 93
Surface Generation 93
Part Detection 95
Edge Filtering 98
Data Viewer 99
Data Viewer Controls 100
Video Mode 100
Exposure View 100
Spots and Dropouts 102
Profile Mode 103
Surface Mode 105
Height Map Color Scale 107
Region Definition 108
Intensity Output 109
Measurement 111
Measure Page Overview 111
Data Viewer 112
Tools Panel 112
Measurement Tool Management 112
Adding and Removing Tools 112
Enabling and Disabling Measurements 113
Editing a Tool or Measurement Name 115
Changing a Measurement ID 115
Common Measurement Settings 116
Source 116
Regions 117
Decisions 117
Filters 119
Measurement Anchoring 120
Profile Measurement 122
Feature Points 122
Fit Lines 124
Measurement Tools 125
Area 125
Circle 127
Dimension 128
Groove 130
Intersect 133
Line 135
Position 136
Panel 138
Gap 138
Flush 139
Strip 141
Tilt 146
Script 146
Surface Measurement 147
Measurement Tools 148
Bounding Box 148
Countersunk Hole 152
Ellipse 158
Hole 160
Measurement Region 164
Opening 165
Measurement Region 171
Plane 172
Position 174

Gocator 2300 & 2880 Series 5
Stud 176
Measurement Region 179
Volume 179
Script 181
Script Measurement 182
Built-in Functions 183
Output 187
Output Page Overview 187
Ethernet Output 188
Digital Output 192
Analog Output 194
Serial Output 196
Dashboard 198
Dashboard Page Overview 198
System Panel 198
Measurements 199
Gocator Device Files 201
Job Files 201
Configuration (Root) 201
Setup 201
Filters 202
XSmoothing 202
YSmoothing 203
XGapFilling 203
YGapFilling 203
XMedian 203
YMedian 203
XDecimation 204
YDecimation 204
Layout 204
Alignment 205
Disk 205
Bar 205
Plate 206
Devices / Device 206
Tracking 207
Material 207
SurfaceGeneration 209
FixedLength 209
VariableLength 210
Rotational 210
PartDetection 210
EdgeFiltering 211
Triggers 211
Tools 212
Profile Types 212
ProfileRegion2D 212
ProfileFeature 213
ProfileLine 213
SurfaceTypes 213
Region3D 213
SurfaceRegion2D 214
SurfaceFeature 214
ProfileArea 214
ProfileCircle 216
ProfileDimension 216
ProfileGroove 218
ProfileIntersect 219
ProfileLine 220
ProfilePanel 221
ProfilePosition 223
ProfileStrip 224
Script 226
SurfaceBoundingBox 226
SurfaceEllipse 227
SurfaceHole 228
SurfaceCsHole 230
SurfaceOpening 232
SurfacePlane 234
SurfacePosition 235
SurfaceStud 235
SurfaceVolume 237
SurfaceCsHole 238
Output 240
Ethernet 240
ASCII 242
EIP 242
Modbus 243
Digital0 and Digital1 243
Analog 243
Serial 244
Selcom 245
ASCII 245
Transformation File 246

Gocator 2300 & 2880 Series 6
Transform 247
Device 247
Protocols 248
Gocator Protocol 248
General 248
Modes 248
Buddy Communication Channels 248
States 249
Data Types 249
Status Codes 250
Discovery Commands 250
Get Address 250
Set Address 251
Control Commands 252
Protocol Version 252
Get Address 253
Set Address 253
Get System Info 254
Get States 255
Log In/Out 256
Change Password 256
Set Buddy 257
List Files 257
Copy File 258
Read File 258
Write File 258
Delete File 259
Get Default Job 259
Set Default Job 260
Get Loaded Job 260
Set Alignment Reference 260
Get Alignment Reference 261
Clear Alignment 261
Get Timestamp 261
Get Encoder 262
Reset Encoder 262
Start 262
Scheduled Start 263
Stop 263
Start Alignment 264
Start Exposure Auto-set 264
Software Trigger 264
Schedule Digital Output 265
Schedule Analog Output 265
Ping 266
Reset 266
Backup 267
Restore 267
Restore Factory 268
Set Recording Enabled 268
Get Recording Enabled 269
Clear Replay Data 269
Set Playback Source 269
Get Playback Source 270
Simulate 270
Seek Playback 271
Step Playback 271
Playback Position 272
Clear Measurement Stats 272
Simulate Unaligned 272
Acquire 273
Acquire Unaligned 273
Read File (Progressive) 273
Export CSV (Progressive) 274
Export Bitmap (Progressive) 274
Upgrade Commands 275
Get Protocol Version 275
Start Upgrade 276
Get Upgrade Status 276
Get Upgrade Log 277
Data Results 277
Stamp 278
Video 278
Profile 279
Resampled Profile 280
Profile Intensity 280
Surface 281
Surface Intensity 281
Measurement 282
Alignment Result 283
Exposure Calibration Result 283
Health Results 283
Modbus TCP Protocol 288
Concepts 288

Gocator 2300 & 2880 Series 7
Messages 288
Registers 289
Control Registers 290
Output Registers 291
State 291
Stamp 291
Measurement Registers 292
EtherNet/IP Protocol 294
Concepts 294
Basic Object 294
Identity Object (Class 0x01) 294
TCP/IP Object (Class 0xF5) 295
Ethernet Link Object (Class 0xF6) 295
Assembly Object (Class 0x04) 295
Command Assembly 296
Sensor State Assembly 296
Sample State Assembly 297
ASCII Protocol 300
Ethernet Communication 300
Asynchronous and Polling Operation 300
Command and Reply Format 300
Special Characters 301
Standard Result Format 301
Custom Result Format 302
Control Commands 302
Start 303
Stop 303
Trigger 303
Load Job 304
Stamp 304
Stationary Alignment 305
Moving Alignment 305
Clear Alignment 306
Data Commands 306
Get Result 306
Get Value 307
Get Decision 308
Health Commands 308
Get Health 308
Software Development Kit 310
Setup and Locations 310
Class Reference 310
Examples 310
Sample Project Environment Variable 311
Header Files 311
Class Hierarchy 311
GoSystem 311
GoSensor 312
GoSetup 312
GoLayout 312
GoTools 312
GoTransform 312
GoOutput 312
Data Types 312
Value Types 312
Output Types 313
GoDataSet Type 313
MeasurementValues and Decisions 314
Operation Workflow 314
Initialize GoSdk APIObject 315
Discover Sensors 316
Connect Sensors 316
Configure Sensors 316
Enable Data Channels 316
Perform Operations 316
Limiting Flash Memory Write Operations 318
Tools and Native Drivers 319
Sensor Recovery Tool 319
GenTL Driver 321
16-bit RGB Image 322
16-bit Grey Scale Image 323
Registers 324
XMLSettings File 326
CSV Converter Tool 326
Troubleshooting 328
Specifications 330
Gocator 2300 Series 331
Gocator 2320 333
Gocator 2330 334
Gocator 2340 336
Gocator 2350 337
Gocator 2370 339
Gocator 2375 342
Gocator 2380 345

Gocator 2300 & 2880 Series 8
Gocator 2880 Sensor 348
Gocator 2880 349
Gocator Power/LAN Connector 352
Grounding Shield 352
Power 353
Laser Safety Input 353
Gocator 2300 &2880 I/O Connector 354
Grounding Shield 354
Digital Outputs 355
Inverting Outputs 355
Digital Inputs 355
Encoder Input 356
Serial Output 357
Analog Output 357
Master 100 359
Master 100 Dimensions 360
Master 400/800 361
Master 400/800 Electrical Specifications 362
Master 400/800 Dimensions 363
Master 1200/2400 364
Master 1200/2400 Electrical Specifications 365
Master 1200/2400 Dimensions 366
Parts and Accessories 367
Return Policy 369
Software Licenses 370
Support 376
Contact 377

Gocator 2300 & 2880 Series 9
Introduction
The Gocator 2300 series of laser profiling sensors is designed for 3D measurement and control
applications. Gocator sensors are configured using a web browser and can be connected to a variety of
input and output devices.
This documentation describes how to connect, configure, and use a Gocator. It also contains reference
information on the device's protocols and job files.
Notational Conventions
This guide uses the following notational conventions:
Follow these safety guidelines to avoid potential injury or property damage.
Consider this information in order to make best use of the product.

Gocator 2300 & 2880 Series 10
Safety and Maintenance
The following sections describe the safe use and maintenance of Gocator sensors.
Laser Safety
Gocator sensors contain
semiconductor lasers that emit visible
or invisible light and are designated as
Class 2M, Class 3R, or Class 3B,
depending on the chosen laser option.
Gocator sensors are referred to as
components, indicating that they are
sold only to qualified customers for
incorporation into their own
equipment. These sensors do not
incorporate safety items that the
customer may be required to provide
in their own equipment (e.g., remote
interlocks, key control; refer to
references for detailed information).
As such, these sensors do not fully
comply with the standards relating to
laser products specified in IEC 60825-1
and FDA CFR Title 21 Part 1040.
Use of controls or adjustments or performance of procedures other than those specified herein
may result in hazardous radiation exposure.
References
1. International standard IEC 60825-1 (2001-08) consolidated edition, Safety of laser products – Part 1:
Equipment classification, requirements and user's guide.
2. Technical report 60825-10, Safety of laser products – Part 10. Application guidelines and explanatory
notes to IEC 60825-1.
3. Laser Notice No. 50, FDA and CDRH http://www.fda.gov/cdrh/rad-health.html

Gocator 2300 & 2880 Series Safety and Maintenance • Laser Safety • 11
Laser Classes
Class 2M laser components
Class 2M laser components would not cause
permanent damage to the eye under
reasonably foreseeable conditions of operation,
provided that any exposure can be terminated
by the blink reflex (assumed to take 0.25
seconds). Because classification assumes the
blink reflex, the wavelength of light must be in
the visible range (400 nm to 700 nm). The
Maximum Permissible Exposure (MPE) for
visible radiation for 0.25 seconds is 25 watts per
square meter, which is equivalent to 1 mW
entering an aperture of 7 mm diameter (the
assumed size of the pupil).
Class 3R laser components
Class 3R laser products emit radiation where
direct intrabeam viewing is potentially
hazardous, but the risk is lower with 3R lasers
than for 3B lasers. Fewer manufacturing
requirements and control measures for 3R laser
users apply than for 3B lasers.
Class 3B laser components
Class 3B components are unsafe for eye
exposure. Usually only ocular protection will be
required. Diffuse reflections are safe if viewed
for less than 10 seconds.
Labels reprinted here are examples only. For accurate specifications, refer to the label on your
sensor.

Gocator 2300 & 2880 Series Safety and Maintenance • Laser Safety • 12
Precautions and Responsibilities
Precautions specified in IEC 60825-1 and FDA CFR Title 21 Part 1040 are as follows:
Requirement Class 2M Class 3R Class 3B
Remote interlock Not required Not required Required*
Key control Not required Not required Required – cannot remove
key when in use*
Power-on delays Not required Not required Required*
Beam attenuator Not required Not required Required*
Emission indicator Not required Not required Required*
Warning signs Not required Not required Required*
Beam path Not required Terminate beam at useful
length
Terminate beam at useful
length
Specular reflection Not required Prevent unintentional
reflections
Prevent unintentional
reflections
Eye protection Not required Not required Required under special
conditions
Laser safety officer Not required Not required Required
Training Not required Required for operator and
maintenance personnel
Required for operator and
maintenance personnel
*LMI Class 3B laser components do not incorporate these laser safety items. These items must be added and completed by customers
in their system design.
Class 3B Responsibilities
LMI Technologies has filed reports with the FDA to assist customers in achieving certification of laser
products. These reports can be referenced by an accession number, provided upon request. Detailed
descriptions of the safety items that must be added to the system design are listed below.
Remote Interlock
A remote interlock connection must be present in Class 3B laser systems. This permits remote switches
to be attached in serial with the keylock switch on the controls. The deactivation of any remote switches
must prevent power from being supplied to any lasers.
Key Control
A key operated master control to the lasers is required that prevents any power from being supplied to
the lasers while in the OFF position. The key can be removed in the OFF position but the switch must not
allow the key to be removed from the lock while in the ON position.
Power-On Delays
A delay circuit is required that illuminates warning indicators for a short period of time before supplying
power to the lasers.

Gocator 2300 & 2880 Series Safety and Maintenance • Laser Safety • 13
Beam Attenuators
A permanently attached method of preventing human access to laser radiation other than switches,
power connectors or key control must be employed. On some LMI laser sensors, the beam attenuator is
supplied with the sensor as an integrated mechanical shutter.
Emission Indicator
It is required that the controls that operate the sensors incorporate a visible or audible indicator when
power is applied and the lasers are operating. If the distance between the sensor and controls is more
than 2 meters, or mounting of sensors intervenes with observation of these indicators, then a second
power-on indicator should be mounted at some readily-observable position. When mounting the
warning indicators, it is important not to mount them in a location that would require human exposure
to the laser emissions. User must ensure that the emission indicator, if supplied by OEM, is visible when
viewed through protective eyewear.
Warning Signs
Laser warning signs must be located in the vicinity of the sensor such that they will be readily observed.
Examples of laser warning signs are as follows:
FDA warning sign example IEC warning sign example
Nominal Ocular Hazard Distance (NOHD)
This is the distance from the source at which the intensity or the energy per surface unit becomes lower
than the Maximum Permissible Exposure (MPE) on the cornea and on the skin. The laser beam is
considered dangerous if the operator is closer from the source than the NOHD.
The following table shows the estimated NOHD for each Gocator model and laser class, assuming
continuous operation of the laser. As a configurable device the Gocator allows the user to set the laser
exposure (laser on-time) independently of the frame period (total cycle time for data acquisition).
Continuous operation of the laser means that the laser exposure is configured to be identical to the
frame period, which is also referred to as 100% duty cycle. However, in many applications the laser
exposure can be smaller than the frame period (less than 100% duty cycle) thereby reducing the NOHD.
The table therefore shows the worst-case NOHD.

Gocator 2300 & 2880 Series Safety and Maintenance • Electrical Safety • 14
Model Laser Class Line Fan Angle NOHD (mm)
2x20 2M 28 259
2x30 2M 28 259
3R 28 900
3B 28 5759
2x40 2M 28 259
3R 28 900
3B 28 5759
2x50 2M 28 259
3R 28 900
3B 28 5759
2x70 2M 43 251
3R 43 875
3B 43 3645
2x80 2M 57 245
3R 57 859
3B 57 2645
Systems Sold or Used in the USA
Systems that incorporate laser components or laser products manufactured by LMI Technologies
require certification by the FDA.
Customers are responsible for achieving and maintaining this certification.
Customers are advised to obtain the information booklet Regulations for the Administration and
Enforcement of the Radiation Control for Health and Safety Act of 1968: HHS Publication FDA 88-8035.
This publication, containing the full details of laser safety requirements, can be obtained directly from
the FDA, or downloaded from their web site at http://www.fda.gov/cdrh.
Electrical Safety
Failure to follow the guidelines described in this section may result in electrical shock or
equipment damage.
Sensors should be connected to earth ground
All sensors should be connected to earth ground through their housing. All sensors should be mounted
on an earth grounded frame using electrically conductive hardware to ensure the housing of the sensor
is connected to earth ground. Use a multi-meter to check the continuity between the sensor connector
and earth ground to ensure a proper connection.

Gocator 2300 & 2880 Series Safety and Maintenance • Environment and Lighting • 15
Minimize voltage potential between system ground and sensor ground
Care should be taken to minimize the voltage potential between system ground (ground reference for
I/O signals) and sensor ground. This voltage potential can be determined by measuring the voltage
between Analog_out- and system ground. The maximum permissible voltage potential is 12 V but should
be kept below 10 V to avoid damage to the serial and encoder connections.
See Gocator 2300 &2880 I/O Connector (page 354) for a description of connector pins used with Gocator
2300 series sensors.
Use a suitable power supply
The +24 to +48 VDC power supply used with Gocator sensors should be an isolated supply with inrush
current protection or be able to handle a high capacitive load.
Use care when handling powered devices
Wires connecting to the sensor should not be handled while the sensor is powered. Doing so may cause
electrical shock to the user or damage to the equipment.
Environment and Lighting
Avoid strong ambient light sources
The imager used in this product is highly sensitive to ambient light hence stray light may have adverse
effects on measurement. Do not operate this device near windows or lighting fixtures that could
influence measurement. If the unit must be installed in an environment with high ambient light levels, a
lighting shield or similar device may need to be installed to prevent light from affecting measurement.
Avoid installing sensors in hazardous environments
To ensure reliable operation and to prevent damage to Gocator sensors, avoid installing the sensor in
locations
lthat are humid, dusty, or poorly ventilated;
lwith a high temperature, such as places exposed to direct sunlight;
lwhere there are flammable or corrosive gases;
lwhere the unit may be directly subjected to harsh vibration or impact;
lwhere water, oil, or chemicals may splash onto the unit;
lwhere static electricity is easily generated.
Ensure that ambient conditions are within specifications
Gocator sensors are suitable for operation between 0–50° C and 25–85% relative humidity (non-
condensing). Measurement error due to temperature is limited to 0.015% of full scale per degree C.
The Master 400/800/1200/2400 is similarly rated for operation between 0–50° C.
The storage temperature is -30–70° C.
The sensor must be heat-sunk through the frame it is mounted to. When a sensor is properly
heat sunk, the difference between ambient temperature and the temperature reported in the
sensor's health channel is less
than 15° C.

Gocator 2300 & 2880 Series Safety and Maintenance • Sensor Maintenance • 16
Gocator sensors are high-accuracy devices, and the temperature of all of its components must
therefore be in equilibrium. When the sensor is powered up, a warm-up time of at least one
hour is required to reach a consistent spread of temperature in the sensor.
Sensor Maintenance
Keep sensor windows clean
Gocator sensors are high-precision optical instruments. To ensure the highest accuracy is achieved in all
measurements, the windows on the front of the sensor should be kept clean and clear of debris.
Use care when cleaning sensor windows
Use dry, clean air to remove dust or other dirt particles. If dirt remains, clean the windows carefully with
a soft, lint-free cloth and non-streaking glass cleaner or isopropyl alcohol. Ensure that no residue is left
on the windows after cleaning.
Turn off lasers when not in use
LMI Technologies uses semiconductor lasers in 3D measurement sensors. To maximize the lifespan of
the sensor, turn off the laser when not in use.
Avoid excessive modifications to files stored on the sensor
Settings for Gocator sensors are stored in flash memory inside the sensor. Flash memory has an
expected lifetime of 100,000 writes. To maximize lifetime, avoid frequent or unnecessary file save
operations.

Gocator 2300 & 2880 Series 17
Getting Started
The following sections provide system and hardware overviews, in addition to installation and setup
procedures.
System Overview
Gocator sensors can be installed and used in a variety of scenarios. Sensors can be connected as
standalone devices, dual-sensor systems, or multi-sensor systems.
Standalone System
Standalone systems are typically used when only a single Gocator sensor is required. The sensor can be
connected to a computer's Ethernet port for setup and can also be connected to devices such as
encoders, photocells, or PLCs.
Dual-Sensor System
In a dual-sensor system, two Gocator sensors work together to perform profiling and output the
combined results. The controlling sensor is referred to as the Main sensor, and the other sensor is
referred to as the Buddy sensor. Gocator's software recognizes three installation orientations: Opposite,
Wide, and Reverse.

Gocator 2300 & 2880 Series Getting Started • System Overview • 18
A Master 400/800/1200/2400 must be used to connect two sensors in a dual-sensor system. Gocator
Power and Ethernet to Master cordsets are used to connect sensors to the Master.
Multi-Sensor System
Master 400/800/1200/2400 networking hardware can be used to connect two or more sensors into a
multi-sensor system. Gocator Master cordsets are used to connect the sensors to a Master. The Master
provides a single point of connection for power, safety, encoder, and digital inputs. A Master
400/800/1200/2400 can be used to ensure that the scan timing is precisely synchronized across
sensors. Sensors and client computers communicate viaan Ethernet switch (1 Gigabit/s recommended).
Master 400/800/1200/2400 networking hardware does not support digital, serial, or analog output.

Gocator 2300 & 2880 Series Getting Started • System Overview • 19

Gocator 2300 & 2880 Series Getting Started • Hardware Overview • 20
Hardware Overview
The following sections describe Gocator and its associated hardware.
Gocator 2300 &2880 Sensor
Gocator 2330
Item Description
Camera Observes laser light reflected from target surfaces.
Laser Emitter Emits structured light for laser profiling.
I/O Connector Accepts input and output signals.
Power / LAN Connector Accepts power and laser safety signals and connects to 1000 Mbit/s Ethernet network.
Power Indicator Illuminates when power is applied (blue).
Range Indicator Illuminates when camera detects laser light and is within the target range (green).
Laser Indicator Illuminates when laser safety input is active (amber).
Serial Number Unique sensor serial number.
Gocator 2300 &2880 Cordsets
Gocator 2300 and 2880 sensors use two types of cordsets.
The Power & Ethernet cordset provides power, laser safety interlock to the sensor. It is also used for
sensor communication via 1000 Mbit/s Ethernet with a standard RJ45 connector. The Master version of
the Power & Ethernet cordset provides direct connection between the sensor and a Master
400/800/1200/2400.
The Gocator I/O cordset provides digital I/O connections, an encoder interface, RS-485 serial connection,
and an analog output.
