LockTech AccuReader YM63-OP User manual

YM63-OP
by
www.accureader.com
[email protected]
Thank you for purchasing the AccuReader
wafer reading system by LockTech. This system will
allow you to read the YM63-OP ignition completely
and accurately without the removal of the ignition.
Following a few simple steps it takes only minutes to
read the depths for each cut in each position for a
complete key.
The AccuReader works on the process of
elimination to decipher the correct depths of the lock.
By checking the deepest cut first you eliminate what
the cuts are not. Therefore it is essential to always
read depth slide #4 first.
The AccuReader key is designed to be used
for wafer positions 1-7 for a complete key. The
YM63-OP was developed for Yamaha’s new ignition
that features opposing wafers. It is important to
use the correct set of slides for the lock being
read. The ignition uses the slides marked OP and all
other locks use the slides marked AUX.
Please take the time to familiarize yourself
with the tools and verify all pieces are accounted for
from the list of contents below:
Package Contents:
1-AccuReader key
1-insertion/release slide
1-depth slide #4 OP
1-depth slide #3 OP
1-depth slide #2 OP
1-depth slide #4 AUX
1-depth slide #3 AUX
1-depth slide #2 AUX
1-Tube storage container
1-Tube Cap
USING THE ACCU-READER
1) Always thoroughly clean the lock with an
electronics safe cleaner to free any potentially stuck
wafers.
2) Use the alignment holes through the AccuReader
key to assist in judging the distance from one wafer
position to the next.
3) Place the insertion/release slide in the slot on the
AccuReader. Fully insert the AccuReader key into
the ignition and remove the slide. The AccuReader
key is now ready to read the #7 wafer. (Note: If the
AccuReader comes out a full position before
trapping a wafer, remove it, flip it, and reinsert it
fully into the lock again. The AccuReader should
now have wafer position 7 trapped.)(Odd wafers
will be read on one side of the lock and even
wafers will be read on the opposite side of the
ignition.)
4) Always start reading with the #4 depth slide
tool, then proceed to #3, then #2 IF necessary.
Fully insert the depth slide into the AccuReader key.
The alignment mark on the depth slide will line up
with the (Y) Yes mark or it will line up with the (N)No
mark.
a) If the #4 depth slide lines up with the Y
then the depth for the #7 wafer is a 4. If the depth
slide lines up with a N, then you must proceed to the
#3 depth slide.
b) If the #3 depth slide lines up with the Y
then the depth for the #7 wafer is a 3. If the depth
slide lines up with a N, then you must proceed to the
#2 depth slide.
c) If the #2 depth slide lines up with the Y
then the depth for the #7 wafer is a 2. If the depth
slide lines up with a N, then the depth for wafer #7 is
a 1.
d) Repeat steps a) through c) for each wafer
position until you have recorded the depth for wafer
positions 7, 5, 3, & 1.
e) Using the insertion/release slide remove
the AccuReader key from the keyway and flip it over.
Fully insert the insertion/removal back into the
keyway. Remove the release tool and slowly pull
outward until wafer position 6 traps.
f) Repeat steps a) through c) for each wafer
position until you have recorded the depth for wafer
positions 6, 4, & 2.
g) You now have recorded all the positions to

make a complete key.
TIPS& SUGGESTIONS
1) Always clean the keyway thoroughly before starting.
2) Watch the demonstration video online at: www.accureader.com
3) While holding the AccuReader key straight, keep slight upward pressure on the slide to ensure the tip is resting
along the bottom of the slide track.
Currently found on
MAKE
MODEL
YEARS
Yamaha
Z07
2015+
Please email us for any corrections or additions at [e-mail] rev. 5-27-17
