LOFTNESS FertiLogix F1210 User manual

Model Number:
Serial Number:
Date of Purchase:
F1210 Fertilizer Spreader
Owner’s Manual and Parts Book
(Originating w/Serial Number 90-101)
L1230 Lime Spreader
Owner’s Manual and Parts Book
(Originating w/Serial Number 91-101)
Chassis for Both Models
Originating w/Serial Number 89-101
05.06.19206260 Rev. A

LOFTNESS SPECIALIZED EQUIPMENT, INC.
LIMITED WARRANTY POLICY
The limited warranty policy begins upon delivery of the unit to the original customers.
All Loftness products have a one (1) year limited warranty. The XLB10 Grain Bag Loader has a two (2) year limited warranty.
If any Loftness product is used as rental equipment, or in a commercial application, the limited warranty period is for only 30 days
from the delivery date to the original customers.
Loftness Specialized Equipment, hereinafter referred to as LOFTNESS, a manufacturer of quality machinery since 1956, warrants
new LOFTNESS machinery and/or attachments at the time of delivery to the original purchaser, to be free from defects in material and
workmanship when properly set up and operated in accordance with the recommendations set forth in the LOFTNESS Operator’s
Manual.
LOFTNESS’ liability for any defect with respect to accepted goods shall be limited to repairing the goods at an authorized dealer or
other LOFTNESS designated location, or replacing them as LOFTNESS shall elect. The above shall be in accordance with
LOFTNESS warranty adjustment policies.
WARRANTY REQUIREMENTS
.smialcytnarrawllaetadilavottnempiuqEdezilaicepSssentfoLotdenruterdnatuodellifebtsummrofnoitartsigerytnarraW
To receive a warranty claim, a return authorization from LOFTNESS must be obtained. The failed part may then be returned in an
.gnicivresrofyrenihcamgninruternehwderrucnisegrahcyreviledrothgierfedulcnitonseodytnarrawsihT.sutatsderepmatnu
Dealer mileage, service calls and pick-up/delivery charges are the customer’s responsibility.
LIMITATIONS OF WARRANTY
LOFTNESS products are designed to provide years of dependable service when proper use and maintenance is adhered to. The
potential for misuse in many applications exists; therefore, a limited warranty is provided as follows.
This warranty shall not apply to any machine or attachment which shall have been repaired or altered outside the LOFTNESS factory
or authorized LOFTNESS dealership or in any way so as in LOFTNESS’ judgment, to affect its stability or reliability, nor which has
been subject to misuse, negligence or accident, nor to any machine or attachment which shall not have been operated in accordance
with LOFTNESS’ printed instructions or beyond the company recommended machine rated capacity. LOFTNESS may elect to have
an area representative evaluate the condition of the machine before warranty is considered.
In addition, this limited warranty provides no coverage for general wear or maintenance items, misuse, environmental conditions and/
or contamination for which they were not designed or not intended, including but not limited to the following items:
•Use of machine beyond its rated capacity;
•Improper knife replacement;
•Missing knives;
•Striking foreign objects
•Lack of lubrication
•Failures caused by running in an “out-of-balance” condition;
•Tires;
•Conveyors;
•Auger wear;
•Saw blades; and
•Brakes and brake pads.
EXCLUSIONS OF WARRANTY
Except as otherwise expressly stated herein, LOFTNESS makes no representation or warranty of any kind, expressed or implied. The
implied warranty of merchantability and fitness for a particular purpose are excluded from this limited warranty. The
remedies set forth in this warranty are the only remedies available to any person under this warranty. LOFTNESS shall have no
liability to any person for incidental, consequential or special damages of any description, whether arising out of express or implied
warranty or any other contract, negligence, or other tort or otherwise. This exclusion of consequential, incidental and special damages
is independent from and shall survive any finding that the exclusive remedy failed of its essential purpose. Upon purchase, the buyer
assumes all liability, all personal injury and property damage resulting from the handling, possession or use of the goods by the buyer.
No agent, employee or representative of LOFTNESS has any authority to bind LOFTNESS to any affirmation, representation or
warranty concerning its machinery and/or attachments except as specifically set forth herein.
April 2017

12 Ton Spreader OM
Table of Contents
Warranty
Table of Contents
Ordering Code
Ordering Code......................................................................1
12 Ton Spreader (Example).........................................................1
Introduction
Owner Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Warranty Policy .....................................................................3
Serial Number Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
F1210 .........................................................................3
L1230 .........................................................................3
Manual Storage.....................................................................4
F1210 Features .....................................................................5
F1210 Options......................................................................5
L1230 Features .....................................................................6
L1230 Options......................................................................6
Safety Instructions
Safety First ........................................................................7
Owner’s Responsibility ...............................................................7
Safety Rules .......................................................................8
Operating Safety .................................................................8
Transporting Safety ...............................................................8
Maintenance Safety ..............................................................8
Hydraulic Safety .................................................................9
Chemical Fertilizer Safety ..........................................................9
California Proposition 65 Warning.......................................................9
F1210 Fertilizer Spreader Identification .................................................10
L1230 Lime Spreader Identification ....................................................11
Safety Decal Locations ..............................................................12
F1210 ........................................................................12
L1230 ........................................................................12
F1210 and L1230 ...............................................................13
Set-up and Operation
Preparation for Use .................................................................15
Adjusting Track Width ...............................................................15
Dual Wheels ......................................................................16
Repositioning Breakaway Lights.......................................................16
Monitors/Controllers ................................................................16
Connecting to Tractor ...............................................................17
Controller/Monitor Connections ....................................................17
Scale Set-up and Calibration ...................................................17
Wiring Connections..............................................................17
Hydraulic Connections ...........................................................17

12 Ton Spreader OM
Table of Contents
Set-up and Operation (Cont’d)
Setting Tractor Hydraulics............................................................17
For Spinners and Apron Drive......................................................17
F1210 ........................................................................18
One Section Model ...........................................................18
Two Section Model ...........................................................18
L1230 ........................................................................18
Determining Product Density .........................................................19
Scale Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Setting the Metering Gate Opening ....................................................19
F1210 ........................................................................20
L1230 ........................................................................20
Calibrate Spreader Constant. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Catch Test .....................................................................20
Engaging the Apron(s)...............................................................21
Spreading Speed and Interval.........................................................21
Speed ........................................................................21
Driving Interval .................................................................21
Calibration ........................................................................22
Spreader Constants/Rate Chart .......................................................23
Hydraulic (Variable Rate Ready) ....................................................23
Spread Pattern Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Machine Preparation.............................................................24
Course Set-up..................................................................24
Spread Pattern Course ........................................................25
Spread Procedure ...............................................................25
Spread Pattern Test Results Sheet ..................................................26
Spread Pattern Recording ........................................................27
Graphing the Test Results.........................................................27
Acceptable Patterns ..........................................................28
Unacceptable Patterns ........................................................28
Spread Pattern Adjustments..........................................................29
Spinner Blade Positions ..........................................................29
Rear Deflector Adjustment ........................................................29
Spinner RPM...................................................................29
For Hydraulic Spinner Drive (HSD) ...............................................30
For Controlled Spinner Drive (CSD) ..............................................30
Steerable Hitch (Optional) ............................................................31
One Section and Two Section Spreading (F1210 Models Only) ...............................31
Transporting (Towing with Truck).......................................................32
Maintenance
General Maintenance ...............................................................33
Maintenance Schedule ..............................................................33
Fluids And Lubricants ...............................................................33
Lubrication .......................................................................34
Grease Points ..................................................................34
Wheel Bearing Maintenance ..........................................................35
Tire Inflation.......................................................................36

12 Ton Spreader OM
Table of Contents
Maintenance (Cont’d)
Roller Chain Maintenance ............................................................36
Chain Lubrication ...............................................................36
Adjusting Chain Tension ..........................................................37
F1210 ........................................................................37
L1230 ........................................................................37
Tightening/Loosening Apron..........................................................37
F1210 ........................................................................37
L1230 ........................................................................38
Hitch Turnbuckle Adjustment (No-Scale Models Only)......................................38
Removing the Rear End .............................................................38
Cleaning .........................................................................39
Storage ..........................................................................39
For Short-term Storage: ..........................................................39
For Long-term or End of Season Storage: ............................................39
Troubleshooting....................................................................40
Parts Identification
12 Ton Spreader Chassis - Model F1210 and L1230 .......................................44
Axles and Tires, 10 on 11.25" Bolt Center - Model F1210 and L1230 ..........................46
Axles and Tires, 10 on 13.189" Bolt Center - Dual Wheel Extension and
Configuration - Model F1210 and L1230 ................................................47
Breakaway Lights; Electrical - Model F1210 and L1230.....................................48
Hydraulics, Chassis (Spinner and Apron Drive) - Model F1210 and L1230 ......................50
Steerable Hitch (206273) - Model F1210 and L1230 .......................................51
Mounts, No-Scale (204333) - Model F1210 and L1230 .....................................52
Turnbuckle, Non-Steerable Hitch (206275) - Model F1210 and L1230 .........................52
Scale System (204171) - Model F1210 and L1230.........................................53
Spinner Mount and Drive (CSD - 206271; HSD - 204140) - Model F1210 and L1230 ..............54
Manifold, Spinner Motor - Hydraulic Spinner Drive (HSD) (N113478) Model F1210 and L1230 ......56
Manifold, Spinner Motor - Controlled Spinner Drive (CSD) (N141475) Model F1210 and L1230......57
F1210 Hopper, and Apron Components - Model F1210. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
L1230 Hopper - Model L1230.........................................................60
L1230 Apron Roller, Front - Model L1230................................................61
L1230 Apron Roller, Rear; Apron Drive; Metering Gate - Model L1230 .........................62
Apron Drive, One Section (204322) - Model F1210 ........................................63
Apron Drive, Two Section - Model F1210 ................................................64
Apron Drive Motor and Valve Assembly (204235) - Model F1210 One Section, and L1230 .........65
Apron Drive Motor and Valve Assembly (204247) - Two Section; Right Side - Model F1210.........66
Motor and Valve Assembly - Two Section; Left Side (204248) - Model F1210....................67
Manual Holder - Model F1210 and L1230 ...............................................68
Density Scale - Model F1210 and L1230 ................................................68
Roll Tarp - Model F1210 and L1230 ....................................................69
Raven 660 Controller (N89543) - Model F1210 and L1230 ..................................70
ISO Controller (204386) - Model F1210 and L1230 ........................................71
Machine Decals and Signs ...........................................................72

12 Ton Spreader OM
Table of Contents
Appendix
Control Harness Schematic ..........................................................74
Product Harness Schematic (204366, 204367) ...........................................75
Specifications .....................................................................76
F1210 Fertilizer Spreader .........................................................76
L1230 Lime Spreader ............................................................77
Dimensions .......................................................................78
F1210 Fertilizer Spreader .........................................................78
L1230 Lime Spreader ............................................................79
Torque Specifications ...............................................................80
Inches Hardware and Lock Nuts....................................................80
Metric Hardware and Lock Nuts ....................................................81

112 Ton Spreader OM
Ordering Code
Ordering Code
12 Ton Spreader (Example)
The ordering code will consist of a letter with four numbers (Model), one number or letter (Spread Width), one letter or
number (Tire Size), one letter (Apron Drive), one letter (Spinner Drive), one number or letter (Wheel Struts, Steering, and
Scale Options), and one letter (Machine Options). An example of a fertilizer spreader ordering code is shown below.
MODEL
F1210 = Row Crop Spreader
L1230 = Lime/Material
SPREAD WIDTH
4 = 40 ft. Driving Interval
5 = 50 ft. Driving Interval
6 = 60 ft. Driving Interval
8 = 80 ft. Driving Interval
A = 88 ft. Driving Interval
9 = 90 ft. Driving Interval
TIRE SIZE
B = 380/90R46 (14.9R46) Lugged Tire; 10 on 11.25 in. Bolt Circle
C = 480/80R42 (18.4R42) Lugged Tire; 10 on 11.25 in. Bolt Circle
D = 320/90R50 (12.4R50) Lugged Tire; 10 on 11.25 in. Bolt Circle
N = No Tires; 10 on 11.25 in. Bolt Circle
2 = 380/90R46 (14.9R46) Lugged Tire; 10 on 13.189 in. Bolt Circle
4 = 320/90R50 (12.4R50) Lugged Tire; 10 on 13.189 in. Bolt Circle
H = No Tires; 10 on 13.189 in. Bolt Circle
APRON DRIVE
W = Hydraulic Drive Raven 22 pin - Variable Rate Ready (VRR), requires HSD, not available on CSD
X = Hydraulic Drive Raven 37 pin - Variable Rate Ready (VRR)
Y = Hydraulic Drive Raven 37 pin - Variable Rate Ready (VRR) (Two Section)
T = Hydraulic Drive ISO Ready pin - Variable Rate Ready (VRR)
U = Hydraulic Drive ISO Ready pin - Variable Rate Ready (VRR) (Two Section)
SPINNER DRIVE
H = Hydraulic Spinner Drive (HSD) - Fixed Speed
C = Controlled Spinner Drive (CSD) - Compensated Speed - Includes Speed Sensor
WHEEL STRUTS, STEERING & SCALE OPTIONS (NO BRAKES)
8 = 80 in. - 120 in. Tread on center - Non-steerable
9 = 80 in. - 120 in. Tread on center - Non-steerable, w/Scale (monitor is optional)
C = 80 in. - 120 in. Tread on center - Steerable
D = 80 in. - 120 in. Tread on center - Steerable, w/Scale (monitor is optional)
A = 90 in. - 152 in. Tread on center - Non-steerable
B = 90 in. - 152 in. Tread on center - Non-steerabler, w/Scale (monitor is optional)
E = 90 in. - 152 in. Tread on center - Steerable
F = 90 in. - 152 in. Tread on center - Steerable, w/Scale (monitor is optional)
OPTIONS
T = Tarp, installed
I = Raven ISO CAN Node (requires 37 pin)
R = Raven SCS660 Controller (requires 22 pin) (includes harness to spreader)
G = GPS Speed Sensor
S = Spinner RPM Sensor (Requires HSD) (included in CSD)
M = Scale Monitor - Digistar GT 400 (requires scale)
F12104BWH8.TRSM
Example:
A
A
B
C
D
E
F
G
B C D E F G

212 Ton Spreader OM

312 Ton Spreader OM
Owner Information
To ensure maximum performance of this product, it is
mandatory that you thoroughly study the owner’s manual
and follow its recommendations. Proper operation and
maintenance are essential to prevent injury or damage
and to maximize machine life.
NOTE: This manual provides setup, operation, and
maintenance instructions for two Loftness
spreader models - the F1210 Fertilizer Spreader,
and the L1230 Lime Spreader. The instructions
and information provided in this manual apply to
both models unless specified by model number.
Given the similarity between the two models,
some images or drawings in the manual may
portray one model, but pertain to both. In this
case a note will be placed in the image showing
which model is being shown to help clarify.
Operate and maintain this machine in a safe manner and
in accordance with all applicable local, state, and federal
codes, regulations and/or laws, and in compliance with
on-product labeling and these instructions.
Make sure that all personnel have read this owner’s
manual and thoroughly understand safe and correct
operating, installation, and maintenance procedures.
Continuous improvement and advancement of Loftness
products may result in changes to your equipment
that may not be reflected in this publication. Loftness
reserves the right to make product improvements to the
machine at any time. Although great care has been taken
to ensure the accuracy of this publication, Loftness does
not assume any liability for errors or omissions.
Loftness is not responsible for costs or damages
caused by misapplication of fertilizers. It is the
responsibility of the operator to assure that the
fertilizer is applied uniformly and correctly over the
application area.
Warranty Policy
Be sure to read and understand the Warranty Policy at
the beginning of this manual. It is also important that you
fill out the Warranty Registration form(s) completely and
return to Loftness so as not to void the warranty.
Serial Number Location
Always use your model and serial number when
requesting information or when ordering parts.
The images below show where the serial number tags for
each model are located.
NOTE: Serial numbers are also stamped into the
spreader near the serial tag.
F1210
F1210 serial number tag (1).
Chassis serial number tag (2).
L1230
L1230 serial number tag (3).
L1230 serial number tag (4).
Introduction

412 Ton Spreader OM
Manual Storage
Keep the owner’s manual and the entire documentation
packet in the storage compartment provided with your
fertilizer spreader. The owner’s manual must be available
to all operators.
The manual holder (1) is located on the rear left of the
hopper frame on both the F1210 model and the L1230
model
Introduction

512 Ton Spreader OM
F1210 Features
Hopper and Chassis
• Separate chassis, hopper, and drive
• Obstruction-free hopper interior
• Minimal flat surfaces
• 41 in. frame clearance
• Hopper and components 409 stainless
• Frame 1/4 in. channel-formed steel
• Single bearing design
• Adjustable height hitch; 1/4 in. channel-formed
steel
Axles (adjustable)
• 80 in. (203.2 cm) to 120 in. (304.8 cm) track setting
Tires and Wheels
• Standard tires - 380/90R46 (14.9R46)
Integral Lights
• Sealed and rubber isolated lights; adjustable with
breakaway feature; chassis-mounted
• Compliant with ASABE standard (S279.14)
Apron
• Hydraulic Drive, variable rate ready (VRR) - single
section option
• Hydraulic Drive, variable rate ready (VRR) - two
section option
• Apron Chain 304 Stainless Steel
• Dual Apron Chains
Spinners
• Hydraulic driven:
- Hydraulic Spinner Drive (HSD)
- Controlled Spinner Drive (CSD)
• Dual stainless steel spinners deliver a spread
pattern of 40-90 ft. using a 100% overlapping
triangular pattern.
• Spread patterns up to 90 ft. with a trapezoidal
pattern.
Introduction
F1210 Options
Integral Scale Option
• Four point scale system
Steerable Hitch
• Hydraulically-controlled; turnbuckle - standard
Axle Extensions
• Axle extensions for 90 in. (228.6 cm) to 152 in.
(386.1 cm) track setting.
Tires and Wheel Options
• Single tires - 480/80R42 (18.4R42); or 320/90R50
(12.4R50)
• Dual tires - 380/90R46 (14.9R46); or 320/90R50
(12.4R50) - 20 in., 22 in., or 30 in. spacing
Roll Tarp
• Optional (Contact your dealer for a hopper roll tarp.)
Shur-Co.®or Agri-Cover®(Specify Loftness model).

612 Ton Spreader OM
L1230 Features
Hopper and Chassis
• Separate chassis, hopper, and drive
• Obstruction-free hopper interior
• Minimal flat surfaces
• 41 in. frame clearance
• Hopper and components 409 stainless
• Frame 1/4 in. channel-formed steel
• Single bearing design
• Adjustable height hitch; 1/4 in. channel formed steel
Axles (adjustable)
• 80 in. (203.2 cm) to 120 in. (304.8 cm) track setting
Tires and Wheels
• Standard tires - 380/90R46 (14.9R46)
Integral Lights
• Sealed and rubber isolated lights; adjustable with
breakaway feature; chassis-mounted
• Compliant with ASABE standard (S279.14)
Apron
• Hydraulic Drive, variable rate ready (VRR)
• 24 in. belt over 88C chain
Spinners
• Hydraulic driven:
- Hydraulic Spinner Drive (HSD)
- Controlled Spinner Drive (CSD)
• Dual stainless steel spinners; Lime spread pattern
of 20-60 ft.; Fertilizer spread pattern of 40-90 ft.;
using a 100% overlapping triangular pattern.
• Spread patterns up to 90 ft. with a trapezoidal
pattern.
L1230 Options
Integral Scale Option
• Four point scale system
Steerable Hitch
• Hydraulically-controlled; turnbuckle - standard
Axle Extensions
• Axle extensions for 90 in. (228.6 cm) to 152 in.
(386.1 cm) track setting.
Tires and Wheel Options
• Single tires - 480/80R42 (18.4R42); or 320/90R50
(12.4R50)
• Dual tires - 380/90R46 (14.9R46); or 320/90R50
(12.4R50) - 20 in., 22 in., or 30 in. spacing
Roll Tarp
• Optional (Contact your dealer for a hopper roll tarp.)
Shur-Co.®or Agri-Cover®(Specify Loftness model).
Introduction

712 Ton Spreader OM
Safety First
Accidents can be prevented by recognizing the causes or
hazards before an accident occurs and doing something
about them. Regardless of the care used in the design
and construction of this machine, there are some areas
that cannot be safeguarded without interfering with
accessibility and efficient operation.
In the owner’s manual and on decals used on the
machine the words DANGER, WARNING, CAUTION,
IMPORTANT, and NOTE are used to indicate the
following:
DANGER: This word warns of immediate hazards which,
if not avoided, will result in severe personal injury or
death. The color associated with Danger is RED.
WARNING: This word refers to a potentially hazardous
situation which, if not avoided, could result in severe
personal injury or death. The color associated with
Warning is ORANGE.
CAUTION: This word refers to a potentially hazardous or
unsafe situation that, if not avoided, may result in minor
or moderate injury. It may also be used to alert against
unsafe practices. The color associated with Caution is
YELLOW.
IMPORTANT: Highlights information that must be
heeded.
NOTE: A reminder of other related information that needs
to be considered.
Safety Alert Symbol
This message alert symbol identifies
important safety messages on the machine
and in the owner’s manual. When you see this
symbol, be alert to the possibility of personal
injury and carefully read the message that
follows.
If Safety Decals on this machine are ISO two panel
pictorial, decals are defined as follows:
• The first panel indicates the nature of the hazard.
• The second panel indicates the appropriate
avoidance of the hazard.
• Background color is YELLOW.
• Prohibition symbols such as and STOP if used,
are RED.
Be certain all machine operators are aware of the
dangers indicated by safety decals applied to the
machine, and be certain they follow all safety decal
instructions. Contact Loftness for safety decal
replacement.
Loftness cannot anticipate every possible
circumstance that may involve a potential hazard. The
warnings in this owner’s manual are not all inclusive.
Owner’s Responsibility
Operate and maintain this machine in a safe manner and
in accordance with all applicable local, state, and federal
codes, regulations and/or laws and in compliance with
on-product labeling and this owner’s manual instructions.
Make sure that all personnel have read this owner’s
manual, and thoroughly understand safe and correct
installation, operation and maintenance procedures.
Make sure the machine is assembled and installed
correctly before being placed in service. At regular
intervals thereafter, the machine should be serviced in
accordance with procedures outlined in this owner’s
manual.
Fulfill all warranty obligations so as not to void the
warranties. The warranty policy included in this manual
outlines the warranty policy of Loftness.
Safety Instructions

812 Ton Spreader OM
Safety Rules
These are general safety considerations. Additional
precautions may be necessary to operate your
machine in a safe manner. Be certain you are operating
your machine in accordance with all safety codes,
OSHA rules and regulations, insurance requirements
and local, state, and federal laws.
Operating Safety
• Do not allow anyone to operate the machine until he
or she has read the owner’s manual and is completely
familiar with all safety precautions.
• Do not allow inexperienced persons unfamiliar with
the machine, or unfamiliar with safe operating and
maintenance procedures, to operate or maintain the
machine.
• Do not allow persons under the influence of alcohol,
medications, or other drugs that can impair judgment
or cause drowsiness to operate or maintain the
machine.
• Keep children, bystanders and other workers away
from the machine while it is operating. No riders
allowed.
• The machine requires an operator at all times. Never
leave the machine running and unattended.
• Do not wear loose hanging clothes, neckties or
jewelry. Long hair is to be placed under a cap
or hat. These precautions will help prevent you
from becoming caught in any moving parts on the
machine.
• Do wear safety glasses, ear protection, respirators,
gloves, hard hats, safety shoes and other protective
clothing when required.
• The spreader should not be used to handle materials
other than those which were specified as part of
its design. It is the operator’s responsibility to be
aware of the specifications and operate the spreader
accordingly.
• It is the operator’s responsibility to be aware of
machine operation and work area hazards at all
times.
• Operators are responsible to know the location and
function of all guards and shields including but not
limited to chain drives, aprons/conveyors, spinners
and are responsible to make certain that all guards
are in place when operating the machine.
• Operators are responsible to be aware of safety
hazard areas and follow instructions on warning,
caution, or danger decals applied to the machine.
• Know the area before operating the machine. Be
aware of power lines or other equipment. Watch for
adequate overhead clearance.
• Always have an operator in the tractor while the
machine is in operation.
Transporting Safety
• Be sure the machine is in the transport position
before transporting on a roadway.
• Do not exceed speed rating (30 mph) on the factory
provided tires. Refer also to “Tire Inflation” on page
36 for tire pressure(s) while transporting.
• Machine has high center of gravity. Exercise caution
when pulling on slopes. Reduce speed while turning.
Maintenance Safety
• Do not allow inexperienced persons unfamiliar with
the machine, or unfamiliar with safe operating and
maintenance procedures, to operate or maintain the
machine.
• Do not allow persons under the influence of alcohol,
medications, or other drugs that can impair judgment
or cause drowsiness to operate or maintain the
machine.
• Make sure the operator’s area is clear of any
distracting objects. Keep work areas clean and free
of grease and oil to avoid slipping or falling.
• Periodically check all guards, shields and structural
members. Replace or repair anything that could
cause a potential hazard.
• Periodically check all hoses, hose connections and
electrical wiring. Replace or repair anything that
could cause a potential hazard.
• Do not replace components or parts with other than
factory-recommended service parts. To do so may
decrease the effectiveness of the machine.
Safety Instructions

912 Ton Spreader OM
Safety Rules (Cont’d)
Maintenance Safety (Cont’d)
• Do not lubricate parts while the machine is running.
• Do not smoke while servicing the machine.
• Never attempt to make any adjustments while the
tractor engine is running or the key is in the “ON”
position in the tractor. Before leaving the operator’s
position, disengage power to the machine and
remove ignition key.
Hydraulic Safety
• The hydraulic system is under high pressure. Make
sure all lines and fittings are tight and in good
condition. These fluids escaping under high pressure
can have sufficient force to penetrate skin and cause
serious injury.
• Never check for leaks by using any part of your body
to feel for escaping fluid.
• Always use a piece of wood to check for leaks.
WARNING: Contact with high pressure
fluids may cause fluid penetration and burn
hazards. Fluid that is under pressure can
penetrate body tissue. Fluid penetration can
cause serious injury and possible death. If
fluid is injected into the skin, seek medical
attention immediately!
Chemical Fertilizer Safety
• Always read the label before using chemical
fertilizers. Follow manufacturer’s instructions for
use and handling. Also follow label directions and
recommendations on keeping fertilizer residue on
edible parts of plants within limits permitted by law.
• Wear personal protective equipment (PPE) when
handling chemical fertilizers, such as safety glasses
or face shield, respirators, proper clothing, and
rubber gloves.
• Wash hands, face, and clothing after handling and
spreading.
Safety Instructions
• Do not spill chemical fertilizers on skin or clothing.
In case of a spill, remove contaminated clothing and
wash skin and clothing thoroughly with soap and
water.
• Avoid inhaling chemical fertilizers.
• Do not smoke when handling chemical fertilizers.
• Cover food and water containers when spreading
around livestock or pet areas.
• Keep bystanders away while spreading fertilizer.
• The spreader should be completely emptied of
chemical fertilizer, all residue removed, and washed
with clean water before servicing.
• If symptoms of illness occur during or after handling
and/or spreading chemical fertilizers, contact a
physician immediately.
• Store chemical fertilizer in a locked, secure space
away from food and animal feed. Do not store inside
of the home.
• Keep chemical fertilizers away from children, pets,
and unauthorized personnel.
• Store chemical fertilizers in their original containers
and securely closed. Be sure to read fertilizer
manufacturers storage recommendations.
• Dispose of empty fertilizer containers according to
manufacturer’s instructions.
California Proposition 65 Warning
WARNING: This product can expose you to
Mineral Oil, which is known to the State of
California to cause cancer. For more
information, go to www.p65warnings.ca.gov.
A decal with this warning statement is adhered to the
machine. If the decal should become worn or missing,
replace immediately.

10 12 Ton Spreader OM
Safety Instructions
F1210 Fertilizer Spreader Identification

1112 Ton Spreader OM
Safety Instructions
L1230 Lime Spreader Identification

12 12 Ton Spreader OM
Safety Instructions
Safety Decal Locations
Check and replace any worn, torn, hard to read or
missing safety decals on your machine.
NOTE: This section shows where safety-related decals
are applied on the machine. For all machine
decals see “Machine Decals and Signs” on page
72.
F1210
L1230
Part No. N35391
Part No. N35380
WARNING
N35391
Disengage all
power before
servicing
or adjusting.
WARNING
N35380
Stay clear.
Wear eye
protection.
2
1
