logitrans LOGIFLEX ELFR User manual

LOGIFLEX ELFR / ELFSR - ROTATOR

D142-2
01.04.2016
EU DECLARATION CONFORMANCE
Manufacturer: Logitrans A/S
Hillerupvej 35
DK-6760 Ribe
Danmark
It is hereby declared that:
Machine: Productgroup:  LogiexwithRotator
   Type:   ELFR/ELFSR
   Yearofmanufacture/
   SerialNo:
a)  Hasbeenmanufacturedinconformancewiththestipulationsofthe:
• Directive no. 2006/42/EC
• Directive no. 2004/108/EC
• Directive no. 2006/95/EC
b) Hasbeenmanufacturedinconformancewiththestipulationsofthestandard:
• EN ISO 3691-5
Name:  Gitte K. Berg
Position: CEO
Company: Logitrans A/S
Product type declaration of:
Signature:    
Distributor:

3
Contents
1.0 Before the first lift... ............................................................................................. 4
2.0 Functions and identifications.......................................................................... 5
3.0 How to operate the Rotator.............................................................................. 7
3.1 Handling of pallets............................................................................................................... 7
3.2UseoftheRotator ............................................................................................................... 8
3.3 Adjusting of stop .................................................................................................................. 9
3.4Settingthespeed................................................................................................................. 9
3.5Reset ................................................................................................................................... 9
4.0 Optimum safety ..................................................................................................... 10
4.1 Avoid overloads ................................................................................................................. 10
4.2 Avoid offset loads ...............................................................................................................11
4.3Rotationrange................................................................................................................... 12
4.4Safetyregulations.............................................................................................................. 14
4.5 Driving loaded.................................................................................................................... 15
4.6Rotationwithload.............................................................................................................. 15
4.7 Emergency braking and Emergency stop.......................................................................... 16
5.0 There must be a current supply... ................................................................17
5.1 Fuses - replacement.......................................................................................................... 17
5.2 Wiring connections ............................................................................................................ 17
6.0 Long live the Rotator .......................................................................................... 18
6.1 Lubrication and hydraulic oil.............................................................................................. 18
6.2 Oil change ......................................................................................................................... 18
6.3 Fork adjustment................................................................................................................. 19
6.4 Adjustment of lifting chain.................................................................................................. 19
6.5Adjustmentofsteeringwheelchains ................................................................................. 20
6.6 The hydraulic pump and gear motor.................................................................................. 20
6.7 Cleaning ............................................................................................................................ 20
6.8 Adjustment of side play...................................................................................................... 21
7.0 Adjusting the Rotator ......................................................................................... 22
7.1 Tensioning the chains ........................................................................................................ 22
7.2Adjustingtheswitch........................................................................................................... 23
7.3 Lubrication......................................................................................................................... 23
8.0 Fault location key................................................................................................. 24
9.0 Good service after purchase ......................................................................... 26
9.1 Ordering spare parts.......................................................................................................... 26
9.2Warranty/Compensation.................................................................................................... 26
9.3Serviceandrepair ............................................................................................................. 26
9.4 Warranty ............................................................................................................................ 26
9.5Liabilityexemption............................................................................................................. 26

4
TheRotatorismanufacturedinaccordancewithsafetydirectives.
AmongthesubjectsdealtwithinthisInstruction Manual are:
- Proper application
- Physical limitations of the product
- Risks with improper use
- Therefore please read this Instruction Manual carefully!
1.0 Before the first lift...

5
Lifting/Lowering
Emergency stop
Instrument board
- Battery indicator
- Type plate
- Charging plug
 (internalorexternalcharger)
- Plugforextraequipment,
 12Vmaximum15Amp
Released position
Braked position
Remote control
Theremotecontrolisusedwhen:
• Rotatingtheforks
• Settingtiltstopinbothdirections:Seeparagraph3.3.
• Settingrotationspeed:Seeparagraph3.4.
Boxholder
withoutclamps
Boxholderwithclamps
Clockwise/
counter-
clockwise
2.0 Functions and identifications
To release the brake:
1. Pull
2. Push

6
A
Long, 620 - 950
Short, 620 - 870
Long, 425 - 715
Short, 385 - 635
Long, 620 - 950
Short, 620 - 870
Long, 425 - 715
Short, 385 - 635
Box holder
TheRotatorcanbeequippedwithoneortwosetsofboxholders,
adjustedfordifferentboxsizes.Whenlooseningthescrew(A),
theboxholdercanbemovedbetweenthetwodifferentpositions.
NOTE! Thescrewhastobetightened,beforeusingtheproduct.
Setting of distance between box holders
• Fork span 560 mm:
Distancebetweenboxholdersof840,890,1000or
1040mm,forboxwidthsof800,850,950or1000mm.
• Fork span 680 mm: Distancebetweenboxholdersof1040,1090,1200or
1240mm,forboxwidthsof1000,1050,1150or1200mm .
Setting of height
Theboxholderscanbeplacedintwodifferentheights
• Itisimportantthattheboxholdersareplacedapprox.ontheleveloforabove
the load centre of the load.
• Ifpossible,usetwoboxholdersineachside:
1)Whentheweightoftheloadisbetween500and1000kg.
2)Forhighboxesorwhenthematerialoftheboxisunstable,e.g.cardboard
NOTE! Iftheboxholdershavenoclamps,theloadisnotallowedtobetiltedmore
than 60º to each side.
Box holders with clamps
Iftheboxcanfalloff,orifithastobetiltedmorethan60º,boxholderswithclamps
have to be used.
Boxholderswithclampscangrip,holdandrotateboxeswithdifferentheights.
Theclampsaretobetightenedwhentheboxisliftedfromthefloor.
Box holder with clamps
– upper position
Box holder with clamps
– lower position
2.0 Functions and identifications

7
ELF
ELFS
Forproperoperation,
stand behind the handle.
Push/pull-raise/lower
When handling closed pallets
-usetheRotatorwithstraddlelegs!
3.1 Pallet handling
TheRotatorfunctionsasanordinarystacker,whentheforksareplacedin
horizontalposition.
3.0 How to operate the Rotator

8
3.2 Use of the Rotator
Condition: Theupperedgeoftheforksisliftedbetween400and900mm.
Theloadcanberotated355ºwithoneadjustablestopineveryside.
Note! Tocontinuethetiltfunctionfromthehorizontalposition,thetiltswitchhas
 tobereleasedandactivatedintherequestedtiltdirection.
Tolowertheforksfullyortolifthigherthan900mm,theforkshavetobeplacedin
horizontalposition.
Soft acceleration / deceleration
TheRotatorhassoftacceleration/decelerationwiththefollowingbenets:
• The rotation stops precisely
• Thegearisprotected,becausesuddenstart/stopareminimised.
NOTE!
The load has to be supported
sideways before tilting.
3.0 How to operate the Rotator

9
A
3.3 Adjusting of stop
Theforksarefactory-settostopin45º.Ifanothersettingisrequired,theRotator
can be set electronically to stop in different angles.
1)Theforksareplacedinhorizontalposition.
2)ShortpressureontheswitchAactivatesthesetting
 procedure.Thecontrollergivesasignal(onebeep).
3)Theforksareplacedintherequestedangle.
4)Whentheforkshavereachedtherequestedangle,
 thecontrollerwillgivesignalafterthreeseconds
 (onebeep),whenthepositionhasbeenstored.
The procedure is repeated to set stop in the opposite
side.
3.4 Setting the speed
1)Theforksareplacedinhorizontalposition.
2)Theswitch(A)ispressedthreeseconds,andtwo
 shortbeepswillbegiven.Theswitchisreleased
and the speed is set by activating the remote
control.
Clockwise: Increasing the speed
Counter-clockwise:Reducingthespeed
Note:Maximumtilttime(0-355º):1minute.
3)Whentherequestedspeedhasbeenreached,
 thecontrollerwillgivesignalafterthreeseconds   (two
beeps),whenthepositionhasbeenstored.
3.5 Reset the settings
1)Theforksareplacedinhorizontalposition.
2)PressswitchA,untilvebeepsaregiven.Theswitchisreleasedandthe
 controllerissettomaximumspeedandstopsat45°.
Plug from
remote control
SwitchA
Signal
3.0 How to operate the Rotator

10
A
C
B
4.1 Avoid overloads
Themaximumloadmustnotbeexceeded.Remember,thattheRotatorisdesigned
forevenlydistributedload,-goodsonpalletsetc.
Iftheforksarepoint-loadedononeside,thereisariskofbending.
NOTE! Whendrivingwiththetruck,theforksshouldbeplacedinhorizontalposition.
Max.capacityoftheRotator/Multi-purposecarriage:1000kg/700Nm(seeload
diagram).
Load diagram
Whentheforksaretilted,thespatialpositionoftheloadchanges.Thismeansthat
theloadcapacitythatcanbetiltedisreduced,thelargerthedistanceisbetween
load centre of the load and rotation centre.
Inordertousetheloaddiagram,thefollowingthreefactshavetobeknown:
• Thedistancefromtheupperedgeoftheforks/belowedge of the Multi-purpose
carrige to the load centre
• Requestedtiltdegree
• Weight of the load
Example:
- Theloadcentreisplaced120mm(A)overtheforks/belowedgeMulti-purpose
carrige
- Tiltdegree:90º(B)
- Weight of the load: 400 kg
It appears from the load diagram
thatthemaximumallowed
loadis425kg(C).
NOTE! Iftheloadcentreexceedsthealloweddistanceshownintheloaddiagram,
thereisariskthattheRotatorwillturnover,whenrotating.
Load centre distance from
upper edge of the
forks/belowedgeMulti-
purpose carriage.
Upperedgeforks/below
edge Multi-purpose carriage.
4.0 Optimum safety

11
Marking
The mast lifting capacity and the corresponding centre of gravity
distance are given by the pictogram on the side of the mast.
Theliftingcapacityofthemastisthesameasthemax.lifting
capacity of the product.
Max.liftingcapacityissetonthesafetyvalveoftheproduct.
4.2 Avoid offset loads
Theloadmustbeevenlydistributed.Themaximumcentreofgravitydistancefrom
thefrontoftheforkmast(givenonthetruck)mustnotbeexceeded.Agreater
distance reduces the level of safety and increases the risk of toppling.
Goodsonpallets,etc.mustbeproperlysecured,sothattheycannotfalloffduring
transport,whenthetruckislifted,orwhenthetruckmustremainliftedforatime.
4.0 Optimum safety

12
4.3 Rotation range
Standard version
Theloadcanberotated,whentheupperedgeoftheforksareliftedbetween400
and900mm.Outsidethisrange,thestackerfunctionsasastandardstacker.
Bottom stop
Indicates that the forks are lifted 400 mm above
theoor.
Top stop
Indicates that the forks are lifted 900 mm above
theoor.
NOTE:Topstopisonlyplacedonstackerswith
 liftingheights,beinghigherthan:
 920mmELFR
 890mmELFSR
4.0 Optimum safety

13
400
900
1450
1880
Upper
edge forks
Max.sideways
moment
ELFR560x1250
Max.sideways
moment
ELFR680x1250
Max.sideways
moment
ELFSR560x1250with
850 mm straddle legs
Rangeofmaximumload1000kg/700Nm
of stacker in special version
Normalrangeforthemaximumload1000kg/700Nm,
fork height 400-900 mm.
Special version
Thetopstopcanbesettootherintervalsthanbetween400-900mm.
Theheightofthetopstopdependsonthewidthofthestacker,asawidestackercan
managealargersidewaysmovement.
E.g.
Onastackerwith850mmstraddlelegs,thestopcanbeplacedatamaximumfork
height of 1880 mm.
4.0 Optimum safety

14
ATTENTION
Moving parts
4.4 Safety regulations
• Neverwalkunderaraisedload!
• Beforeloweringtheforks,makecertainthatnoforeign
elementscanhinderthefreeloweringoftheforks
• The Rotatorisdesignedforuseonanevenandleveloor
• During transport the forks shall be raised as little as possible
• Transportwithraisedforksshouldbemadeovertheshortestpossible
distancesandatlowspeed
• Checkthatthechainsliftequally.Theyshallbeequallytightwhentheforks
are loaded
• Chains and chain bolts must not be damaged. Chains that have become
permanentlystretched(max.2%oforiginallength)mustbescrapped.
4.0 Optimum safety

15
4.5 Driving loaded
TheRotatorisdesignedforuseonevenandleveloor.Duringtransporttheforks
shallberaisedaslittleaspossible.Transportwithraisedforksshouldbemadeover
theshortestpossibledistancesandatlowspeed.
4.6 Rotation with load
Theloadcentreisnotallowedtobeplacedontheoutsideofthelegsofthestacker,
asthiswillcauseariskofturningover.
NOTE!Rotationisonlyallowedtotakeplace,ifthestackerisplacedonanequal
oor.
BE CAREFUL!
Whenrotatingboxes,theoperatorneedsafulloverviewofthewholeworkingarea,
sothattherotationmovementcanbestoppedbeforetheboxtouchestheoor,the
itemsorpersonsintheworkingarea.
4.0 Optimum safety

16

!


If it becomes necessary to use the load as a brake to prevent the Rotator from
runningaway,activatetheDOWNbuttonquickly,untiltheloadreachestheground.
4.7 Emergency braking and Emergency stop
The product has an emergency stop. When activating
theemergencystop,themaincurrentsupplyisswitchedoff.
Themovementoftheforksstopsimmediatelywhenactivating
the emergency stop.
4.0 Optimum safety

17
5A1
5A1
0A80A40A
10A 20A 20A 100A 40A
5.0 There must be a current supply...
5.1 Fuses - replacement
There are five fuses in the electrical circuit.
100 Amp fuse in the main supply from battery
10 Amp fuse in the control current circuit
20Ampfuse(plugforextraequipmentontheinstrumentboard)
20 Amp fuse for built-in charger
40AmpfuseforRotator
Replacement:
Theoldfuseistoberemovedandreplacedbyanewoneofthesamesize.
Find out why the fuses blow!
Many operational disturbances are caused by bad
connections in the elctrical circuit. Make sure that the
connections are in order.
Check connections regularly for damage at insulating caps or
bad connections at plugs etc. Verdigris must be removed from
cableplugs.Keepallscrew/nutconnectionstight.
5.2 Wirring connections

18
Regularinspectionandthereplacementofwornordefectivepartsingoodtimewill
prolongthelifeoftheRotator.“Preventionisbetterthanrepair”,thereforeensure:
• Check battery every 14 cycles
• Correct usage
• Regularcleaning
• Periodic safety and service inspection
• Forsafetyreasonspleasecheckthebelowevery3month:
- Tightenloosescrewandnuts
 - Checkthattherearenocracks,fracturesanddeformationsin
the bearing construction
 - Wearingparts,suchasbrakes,wheelsandbearings,areadjustedand 
  exchangedcontinuously
6.1 Lubrication and hydraulic oil
UndernormaloperationconditionstheRotatorrequiresnolubrication.
Allballbearingsaresealedandlubricatedforlife,andmovingparts
haveself-lubricatingbearingsoraretreatedwithgrease.
Thehydraulicsystemislledwithhydraulicoilofviscosityclass
ISOVG15.Anadditiveisaddedtotheoil.Theconcentratereduces
frictionandwearandprotectsagainstcorrosion.Pre-mixedhydraulicoilwithadditive
is available from the dealer. The oil is suitable for use in the temperature range
-10to+50°C.Athinneroilisrecommendedfortemperatureslowerthan-10°C(if
necessary,contactyourdealer).
6.2 Oil change
Draining the oil:
1. Bringtheunloadedforksdowntothelowestposition.
2. Mostoftheoilcanbedrainedbylooseningthehydraulichoseunionandbriey
 activatingthehydraulicpumpwiththeswitch.
3. Theremainingoilcanbedrainedfromtheoiltankbytakingoffthetwelveclips
on the pump and removing the tank.
Oil lling:
4. Filloilthroughthellingholeonthetank.
5. Oilquantity:ELFR920&ELFSR 890 approx1,5 liter
   ELFR1200&ELFSR1170 approx 3 liter
   ELFR1400&ELFSR1370 approx 3liter
   ELFR1600&ELFSR1570 approx 3 liter
   ELFR1910&ELFSR1880 approx 4liter
6.Retthellingcapandbleedthesystem(6.6).
6.0 Long live the Rotator

19
18
6.3 Fork adjustment
Twooftherollersontheforkbracketare
mountedoneccentricpins,sothattheycanbe
adjusted. The adjustable rollers are at the top.
1. Loosenscrew(pos.91)(keywidth5mm).
2. Eccentricpins(pos.56)(keywidth8mm)
 cannowbeturnedtogivethenecessary
fork adjustment.
3. Adjustment must be made on both sides
to ensure uniform loading of the rollers.
6.4 Adjustment of lifting chain
The chains shall be adjusted so that
• theyliftequally
• theyareequallytight
• Theliftingmovementhastostopinthecylinder,
before the mast rolls touch the top stop.
 Afteradjusting,pleasecheck:
a: Fork bracket: the forks have to be placed above
 thewheels
b: Adjustable carriage: the forks are to be
 keptclearoftheoor
Thenuts(pos.18)aretobeadjusted
(nutM12,keywidth19mm).
6.0 Long live the Rotator

20
6.5 Adjustment of steering wheel
chains
- Setthehandleinitsmiddleposition.
- Adjustthenuts(1,2,3and4)andbring
 thewheelsintoparallel.
6.6 The hydraulic pump and the gear motor
ThehydraulicpumphasaS3“periodicintermittentduty”of10%.Thismeansthat
thepumpintotalisallowedtooperate1minuteforaperiodof10minutes.Ifthe
pumpoperatesmorethan10%,themotorwillbedamagedduetosuperheating.
Bleeding the hydraulic system
Withaloadof50-100kg,theforksmustberaisedandloweredtotopandbottom
position 2-3 times.
Gear motor of Rotator
Thegearmotorhasa”shorttimeunderconstantload”of10minutes
(S2=10minutes).Thismeansthatthemotorisallowedtooperatewiththe
maximumloadfor10minutes.Hereafterithastobecooleddowntonormal
temperature.
NOTE!Themotorwillbedamagedbysuperheating,ifitoperatesforalonger
timeorifitisnotcooleddown.
6.7 Cleaning
WhencleaningtheRotator,donotdirectthejetontobearingsand
seals.Otherwisethegreasewillbewashedoutandthelifeofthe
equipmentshortened.
Cleaning of the plastic screen (polycarbonate)
Thescreenistobewashedwithslightlywarmwateraddedaneutralcleaning
material,andafterwardswashedwithcleanwater.
Useasoftsponge,awoollenclothorawashleather.
Never use sharp objects or
solvent cleaners when cleaning.
6.0 Long live the Rotator
