Ltech V3 User manual

2.4G RGB ControllerLED
RGB
Main Characteristics
Dimensions
1
V3 Holder R4-3AR4-5A/R4-CC
www.ltech-led.com
R4-3A CV Receiver
Input Voltage:
Max Current Load:
Max Output Power:
Working Temperature:
Package Size:
Weight(G.W.):
5~24Vdc
3A
60W/144W/288W(5V/12V/24V)
-30℃~55℃
L127×W35×H24(mm)
60g
× 4CH Max. 12A
R4-5A CV Receiver
Input Voltage:
Max Current Load:
Max Output Power:
Working Temperature:
Package Size:
Weight(G.W.):
5~24Vdc
5A
100W/240W/480W(5V/12V/24V)
-30℃~55℃
L178×W48×H33(mm)
150g
× 4CH Max. 20A
R4-CC CC Receiver
Input Voltage:
Output Voltage:
Output Current:
Output Power:
Working Temperature:
Package Size:
Weight(G.W.):
12~48Vdc
3~46Vdc
CC 350/700/1050mA×4CH
1.05W~48.3W×4CH Max 193.2W
-30℃~55℃
L178×W48×H33(mm)
165g
Note: Receiver is sold separately.
Remote Option:
orking Voltage
Wireless Frequency:
Working Temperature:
Package Size:
Weight(G.W.):
W :
RGB
2.4GHz
-30℃~55℃
L150×W46×H18(mm)
85g
3Vdc (Battery CR2032）
RF RGB Remote Control
V3

RGB
The Changing Mode
Operating Instruction for Remote:
Wiring Diagram :
Operating Instruction for Receiver:
Current selection switch
LED lamp
connection
LED lamp
connection
The running light
The running light
ID learning button
ID learning button
12~48Vdc
CV power supply
5~24Vdc
CV power supply
Operation table
Match/Clear code between remotes
Match/Clear code between remote and receiver
Match code:
Match code:
Clear code:
Clear code:
Receiver
Long press “ID learning button” on receiver for
5 seconds, If the running light flicker several
times, deactivate the matching successfully.
1. 2. 3.
Assuming that B
match up with A.
Then press any key
on A in 5 seconds.
When the indicator
light of B turns off,
match successfully.
Press the bottom
two keys of B
simultaneously until
the indicator light
keeps on .
Press the bottom two keys of B simultaneously
(about 6 seconds), the indicator light keeps
on, deactivated matching successfully.
Press any key on the remote, the running
light on the receiver flicker several times,
match successfully.
Short press the ID learning button on the
receiver, the running light keeps on.
1.
2.
Receiver
ID learning
button
ID learning
button
2
Short press: play.
Long press: save.
On/Off
Speed
Brightness+/-
+/-
Scene Keys
Mode Key
Indicator Light
R-R+
G-G+
B-B+
1 2
Red+/-
Green+/-
Blue+/-
1. Static Red
2. Static Green
3. Static Blue
4. Static Yellow
5. Static Purple
6. Static Cyan
7. Static White
8. RGB Skipping
9. 7 Colors Skipping
10. RGB Smooth
11. 7 Colors Smooth
CV Power Supply
5~24Vdc
CV Power Supply
5~24Vdc
CV Power Supply
5~24Vdc
www.ltech-led.com Update time:2016-09-29
Attention:
Please replace the battery if the remote becomes insensitive or control distance is shortened.
Please take out the battery for long time unused.
