LUCCI Air METT User manual

V2.0 (09/2022)
METT IP EXHAUST FAN
⚫INSTALLATION
⚫OPERATION
⚫MAINTENANCE
⚫WARRANTY INFORMATION
CAUTION
READ INSTRUCTIONS CAREFULLY FOR SAFE
INSTALLATION AND FAN OPERATION.

Mett Exhaust Fan Installation Instructions
2 | P a g e
THANK YOU FOR PURCHASING
Thank you for purchasing this quality Lucci product. To ensure correct function and safety, please read and
follow all instructions carefully before assembly, installation and use of this exhaust fan. Please keep
instructions for future reference.
WARRANTY
•This exhaust fan is covered by a 2 year warranty. The warranty is from date of purchase, not the date
of installation.
•Please retain proof of purchase for any warranty enquires.
•Warranty will be void if there is any damage due to improper usage or modification to the exhaust fan.
•Failure to comply with the instructions in this manual may increase the risk of damage or injury and will
void warranty.
SAFETY PRECAUTIONS
•Always ensure the power is OFF and the exhaust fan has cooled down before performing any
maintenance, cleaning or making any adjustment to the exhaust fan.
•Ensure that the exhaust fan is switched off from the supply mains before removing the fascia.
•This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
•Children should be supervised to ensure that they do not play with the appliance.
•WARNING: If unusual oscillating movement is observed, immediately stop using the product and contact
the manufacturer, its service agent or suitably qualified persons.
•Do not allow any foreign object to enter the grille opening as which may damage the product.
•The supply cord cannot be replaced. If the cord is damaged the appliance should be scrapped.

Mett Exhaust Fan Installation Instructions
3 | P a g e
INSTALLATION REQUIREMENT
•A licensed electrician is required to install this unit to the mains supply.
•Before installation, check the installation location in the ceiling has access to a socket outlet which is
connected to a wall switch. If it does not, please contact a licensed electrician to arrange installation of the
socket outlet and wall switch before continuing. Refer to the circuit diagram section for more information.
(Fig.4)
•All wiring and installation of the exhaust fan must adhere to the local council regulation and latest local
and national wiringrules, eg. AS/NZS 3000electrical installations. If unsure, contact a licensed electrician.
•This is a Class I product and must be earthed.
•This product is suitable for indoor use only.
•This product must be installed at least 2.1 m above the floor level.
•Before cutting a hole in the ceiling, check that there are no ceiling joists, etc. or electrical wiring above the
desired mounting location.
•The mounting point must be able to support at least 2 times the weight of the exhaust fan.
•Ensure all the clearance values to the structural building element are maintained according to the
clearance diagram in Figure 2.
•Do not install the exhaust fan in canopies over stoves etc., as excessive heat will damage the product.
•This product is designed for installation in the flat ceiling only. Do not mount it on a sloping ceiling or a
vertical wall.
•Any duct (not included) attached to the product must be installed horizontally in the ceiling and with the
same height or lower than the exhaust fan.
•Ensure the duct (not included) is not bent otherwise the performance will be reduced.
•Where applicable, precautions must be taken to avoid the back-flow of gases into the room from the open
flue of gas or other fuel-burning appliances.
•Do not allow any thermal insulation to cover any part of the rear of the appliance.
•Ensure the thermal insulation does not obstruct the airflow.
•There must be an adequate source of external air to ensure the rated performance.
•For exhaust fan optimum performance, volume of air being extracted should be equal to the amount of air
entering the room. Air is drawn mostly from under a door, or an open window. If the bathroom or room is
air tight (door and windows shut), the exhaust will not perform well.

Mett Exhaust Fan Installation Instructions
4 | P a g e
PARTS LIST
•Unpack your fan carefully. Remove all parts and hardware.
•Lay out all the components on a smooth surface and make sure there are no components missing before
assembling. If parts are missing, return the complete product to the place of purchase for inspection or
replacement.
•Check whether the exhaust fan has been damaged during transport. Do not operate/install any product
which appears damaged in any way. Return the complete product to the place of purchase for inspection,
repair or replacement.
•Examine all parts, which should include the following:
1
Fascia x 1
2
Fan motor assembly x 1
3
Outlet nozzle x 1
CLEARANCE REQUIREMENT
Before installation, please plan and check the ceiling space to make sure that there are no obstructions such
as ceiling joists and there is sufficient height clearance for the motor housing. Refer to the figure 2 for the
clearance requirement.
Fig. 1
Fig. 2
DO NOT COVER WITH THERMAL INSULATION!

Mett Exhaust Fan Installation Instructions
5 | P a g e
INSTALLATION DIRECTION
NOTE: Before installation, plug the exhaust fan into a socket outlet to ensure the product is working
correctly. Switch off the main power before commencing the below installation.
1. Cut an installation hole into the ceiling according to cut-out size specified in the specification section.
2. Remove the fixing screw of the outlet nozzle.
3. Slide and push the outlet nozzle in position.
4. Retighten the screw to fix the outlet nozzle.
5. Attach the outlet duct (not included) to the outlet and install the exhaust fan into the cut-out hole.
6. Push the three mounting clips outwards then tighten the screws until the mounting clips are clamped to
the ceiling tightly.
7. Install the fascia onto the exhaust fan body.
8. Switch on the power to test the exhaust fan.
Fig. 3

Mett Exhaust Fan Installation Instructions
6 | P a g e
CIRCUIT DIAGRAM
NOTE: The appliance is provided with flex cord and plug. Check the installation location in the
ceiling has access to a socket outlet which is connected to a wall switch. If it does not, please
contact a licensed electrician to arrange installation of the socket outlet and wall switch.
CARE & CLEANING
NOTE: Always turn OFF the power at the mains switch before performing any maintenance or
attempting to clean your fan.
•Clean the fascia and blades regularly. To clean, wipe with a damp clean cloth with NO organic solvents
or cleaners.
•Do not soak or immerse your fan in the water or other liquids. It could damage the product and create the
possibility of an electrical shock.
Specifications
SKU #
209038
209039
Colour
Matte Black
Matte White
Insulation class
Class I
IP rating
IP24 after installation
Rated voltage
220-240V~, 50Hz
Rated wattage
45W
Max. Airflow
290 M3/H
Overall dimensions
H: 175mm W: 275mm L: 195mm Fascia: Φ 275mm
Cut-out size
Φ 240mm
Exhaust outlet
Φ125mm
Weight
1.9kg
Fig. 4

Mett Exhaust Fan Installation Instructions
7 | P a g e
LUCCI CEILING FAN WARRANTY DETAIL
LUCCI FAN WARRANTY CONTACT INFORMATION:
Online Warranty Form: https://www.beaconlighting.com.au/warranty-claims
Email: [e-mail]
Lucci Fan Warranty Hotline: (Free Call) 1800 602 243
THIS WARRANTY IS VALID IN AUSTRALIA ONLY
In the event of service being required, please call the Lucci Fan Warranty Hotline on 1800 602 243 between 9am & 5pm
(EST) Monday to Friday. Please make sure you have all the fan details filled out at the end of the manual before making
the call.
Every Lucci fan is thoroughly inspected and tested before being released for sale. In addition to any warranty rights or
conditions under statutory regulations, Lucci warrants all of its fans against defective workmanship and faulty materials
for twenty four (24) months from the date of purchase. Lucci undertakes, at its option, to repair or replace, free of charge,
each product or part thereof on condition that;
1. The fan or relevant part has not been subjected to misuse, neglect, or been involved in an accident.
2. The repairs are not required as a result of normal wear and tear.
3. The product was installed by a licensed electrical contractor.
4. A copy of the original receipt of purchase is presented.
5. 12 month warranty applies when used in any non-domestic applications.
6. This warranty does not cover stains, scratch and scuff marks, or dents if the product is purchased through a
factory outlet or to refurbished items.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You
are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does
not amount to a major failure.
Lucci Design cannot be held responsible for any repair other than those carried out by it or one of its Authorised
Service Agents. Please keep this warranty information in a safe place. This information must be produced in the
event of service being required.
Distributed by:
Beacon Lighting
140 Fulton Drive
Derrimut, Victoria, 3026
Australia
Ph [phone]
Email: [e-mail]

Mett Exhaust Fan Installation Instructions
8 | P a g e
CEILING FAN WARRANTY INFORMATION
LUCCI FAN WARRANTY CONTACT INFORMATION:
Online Warranty Form: https://www.beaconlighting.com.au/warranty-claims
Email: [e-mail]
Lucci Fan Warranty Hotline: (Free Call) 1800 602 243
Complete and retain this form for your personal records and warranty purposes.
NAME…………………………………………………………………………………
ADDRESS……………………………………………………………………………
……………………………………………………POSTCODE……………………
MODEL NUMBER……………………………………………………………………
(PO# + DATECODE Sticker here)
PO NUMBER or DATECODE ………………………………………………………
DATE OF PURCHASE………………………………………………………………
INSTALLING LICENSED ELECTRICIAN……………………………………………
…………………………………………………………………………………………
LICENCE No…………………………………………………………………………
ATTACH PROOF OF PURCHASE HERE
THIS COMPLETED DETAIL PAGE SHOULD BE PRODUCED AND SENT TO THE
WHOLESALER OR THEIR AUTHORISED AGENTS BEFORE OBTAINING
WARRANTY SERVICE
