Lucent Technologies Lineage 2000 ECS Battery Plant User manual

Product Manual
H569-403
Select Code 167-790-041
Comcode 106577646
Issue 4
February 1997
Lucent Technologies
Lineage®2000
600-Ampere, +24-Volt
ECS Battery Plant
Notice:
Every effort was made to ensure that the information in this
document was complete and accurate at the time of printing.
However, information is subject to change.
© Lucent Technologies 1997
All Rights Reserved
Printed in U.S.A.

Lucent Technologies Lineage®2000 ECS Battery Plant H569-403
Issue 4 February 1997 Table of Contents - 1
Table of Contents
1 Introduction
General Information 1 - 1
Technical Support 1 - 2
USA, Canada, Puerto Rico, and the US Virgin Islands 1 - 2
Central and South America 1 - 2
Europe, Middle East, and Africa 1 - 2
Asia Pacific Region 1 - 2
Product Repair and Return 1 - 2
USA, Canada, Puerto Rico, and the US Virgin Islands 1 - 2
Central and South America 1 - 3
Europe, Middle East, and Africa 1 - 3
Asia Pacific Region 1 - 3
Customer Service 1 - 3
2 Product Description
Plant Specifications 2 - 1
Typical Battery Plant Description 2 - 3
Battery Plant Subsystems 2 - 3
ECS Battery Plant Physical Description 2 - 5
Introduction 2 - 5
Initial Bay 2 - 6
ECS Battery Plant Subsystems 2 - 6
Rectifier 2 - 6
Batteries 2 - 7
Controller 2 - 7
DC-DC Converter 2 - 8
DC Distribution 2 - 8
ECS DC Distribution Panel 2 - 9
Plant Bus Bars 2 - 13
Plant Shunt 2 - 13
Low Voltage Battery Disconnect/
Reconnect (LVD/R) Feature 2 - 13
3 Engineering, Planning, and Ordering
General Engineering Calculations 3 - 1

Lucent Technologies Lineage®2000 ECS Battery Plant H569-403
2 - Table of Contents Issue 4 February 1997
Load Equipment Voltage 3 - 2
Battery Voltage 3 - 2
Load Drain and Growth 3 - 4
Reserve Capacity 3 - 8
Charge Capacity and Recharge Time 3 - 9
Battery String Voltage Drop and Balancing 3 - 10
Battery Size versus Voltage Drop 3 - 11
Calculating Voltage Drop 3 - 13
Conductor Ampacity 3 - 13
Overcurrent Protection 3 - 14
Lineage® 2000 Engineering Specifics 3 - 15
Rectifier Sizing 3 - 15
Battery Sizing 3 - 16
Cable and Load Breaker Sizing 3 - 17
Low-Voltage Disconnect/Reconnect Feature 3 - 22
Controller Options 3 - 22
Alarm System Interface 3 - 23
Planning 3 - 23
Floor Plan Data 3 - 23
Grounding 3 - 24
Growth 3 - 24
Ordering Reference Material 3 - 25
Coding and Terminology 3 - 25
J-drawings 3 - 26
T-drawings 3 - 30
SD-drawings 3 - 31
Documentation References 3 - 32
Ordering Information 3 - 34
4 Installation
General 4 - 1
Installation Tools and Test Equipment 4 - 1
Suggested Installation Sequence 4 - 2
General Information 4 - 2
Sequence of Tasks 4 - 3
Unpacking, Handling, and Frame Installation 4 - 3
Battery Stand Assembly 4 - 6
Initial Charge 4 - 6
Cable Support and Ground System 4 - 6
Controller and LVD Set-up 4 - 7
AC Wiring, Rectifier Installation and Test 4 - 8
Load Wiring 4 - 8
Battery Connections, Disconnect Installation, and Test 4 - 9
Controller Test 4 - 9
Load Turn-up 4 - 10

Lucent Technologies Lineage®2000 ECS Battery Plant H569-403
Issue 4 February 1997 Table of Contents - 3
Installation Procedures for Plant Growth 4 - 10
Adding a Load Circuit 4 - 10
5 Maintenance
Controls and Indicators 5 - 1
Controller LEDs and Switches 5 - 1
Rectifier LEDs and Switches 5 - 1
CP5 Fuse Board LEDs and Fuses 5 - 1
DC Circuit Breakers/Fuses 5 - 2
Troubleshooting 5 - 2
Open Distribution Breaker 5 - 4
Red LVD OPEN LED Lit 5 - 4
Yellow LVD FAIL LED Lit 5 - 4
Repair and Replacement 5 - 5
Load Circuit Breaker or Fuse Replacement 5 - 5
LVD/R Contactor Replacement 5 - 6
LVD/Fuse Board (CP5) Replacement 5 - 7
Spare Parts 5 - 8
6 Product Warranty

Lucent Technologies Lineage®2000 ECS Battery Plant H569-403
Issue 4 February 1997 List of Figures - 1
List of Figures
Figure 1-1: Lineage®2000 ECS Battery Plant (Model
H569-403) 1 - 4
Figure 2-1: Block Diagram of Typical Battery Plant 2 - 4
Figure 2-2: ECS Battery Plant Block Diagram 2 - 5
Figure 2-3: Group 20 (10 to 100A) Circuit Breaker Panel 2-11
Figure 2-4: Group 43 Meter and Fuse Panel
(3-Inch Cover Removed) 2 - 11
Figure 2-5: Plant Bus Bars with Optional Group 2
Low Voltage Disconnect 2 - 12
Figure 2-6: ECS DC Distribution Panel (Front View) 2 - 12
Figure 3-1: Bay Dimensions and Clearances 3 - 36
Figure 3-2: Frame Ground Adapter Assembly 3 - 37
Figure 3-3: Typical J-Drawing A-Sheet 3 - 37
Figure 4-1: Typical Floor Mounting Detail 4 - 5
Figure 4-2: Floor Mounting Template
(All Dimensions Are Given in Inches) 4 - 6
Figure 4-3: LVD/Fuse Board (CP5) Jumper Locations 4 - 7

Lucent Technologies Lineage®2000 ECS Battery Plant H569-403
Issue 4 February 1997 List of Tables - 1
List of Tables
Table 2-A: Lineage®2000 Battery Plant Specifications
(Model H569-403) 2 - 1
Table 2-B: H569-403, Group 20 Lineage®2000
ECS Battery Plant Breaker Panel 2 - 9
Table 2-C: H569-403 Group 43 Fuse Options 2 - 10
Table 3-A: Initial Load Drain Information 3 - 6
Table 3-B: Anticipated Future Load Drain Information 3 - 7
Table 3-C: Reserve Capacity 3 - 8
Table 3-D: Double Hole Terminal Lugs 3 - 19
Table 3-E: Single Hole Terminal Lugs 3 - 20
Table 3-F: Load Feeder Wire and Fuse/Breaker Size 3 - 21
Table 3-G: Minimum Wire Gauge
(Ampacity) - All Strings 3 - 22
Table 3-H: Ordering Guide, H569-403 ECS
600-Ampere +24-Volt Battery Plant 3 - 35
Table 4-A: Minimum Torque for All Electrical
Connections (e.g., Bus Bars) 4 - 4
Table 4-B: Torque for All Non-Electrical
Connections
(e.g., Floor Anchors) 4 - 5
Table 5-A: Troubleshooting 5 - 3

Lucent Technologies Lineage®2000 ECS Battery Plant H569-403
Issue 4 February 1997 Introduction 1 - 1
1 Introduction
General
Information This product manual (Select Code 167-790-041) describes the
H569-403 ECSBatteryPlant,which isshown inFigure 1-1.This
member of the ECS family of battery plants operates from a
nominal 208/240 volt ac, 50/60 Hz source. It offers a
600-amperetotal plantcapacity with a nominal 24-volt dc output
in a totally integrated energy system.
The basic plant consists of charge and discharge bus bars with
optional low voltage disconnect, a circuit breaker panel for
24-volt distribution requirements, an ECS controller, two
rectifier shelf assemblies which can connect up to six Lineage®
2000 SR Series +24-volt, 100-ampere rectifiers, and space for
four 24-volt to 48-volt, 10-ampere dc to dc converters and a fuse
panel for 48-volt distribution needs.
The plant's modular front-access design facilitates installation
and growth. Growth in plant output current capacity is achieved
by adding Lineage®2000 100-ampere, +24-volt rectifiers to
rectifier shelf assemblies. Adding functionality to the basic
controller is achieved through two optional circuit packs, one to
add microprocessor-based features and the second to add a
datalogger.
The ECS Battery Plant is compatible with virtually all
valve-regulated batteries that float within the range of 24
through 29 volts. In addition, the ECS plant is capable of
operating in a batteryless mode, making it suitable for those
applications where battery backup is not necessary or is
achieved through the use of an uninterrupted power supply
(UPS).

Lucent Technologies Lineage®2000 ECS Battery Plant H569-403
1 - 2 Introduction Issue 4 February 1997
Technical
Support Technical support for Lucent Technologies equipment is
available to customers around the world.
USA, Canada,
Puerto Rico, and
the US Virgin
Islands
Onapost-salebasis,duringtheProductWarrantyperiod,our
Technical Support telephone number 1-800-CAL RTAC
(1-800-225-7822) provides coverage during normal business
hours. Product Specialists are available to answer your technical
questions and assist in troubleshooting problems. For
out-of-hours EMERGENCIES, the 800 number will put you in
touch with a Regional Technical Assistance Center Engineer via
our 24 hour a day, 7 day per week Help Desk.
When Technical Support is required in the Post-Warranty
Period, the service may be billable unless you hold an extended
warranty or contractual agreement.
Central and
South America If you need product technical support, contact your local Field Support/Regional Technical Assistance Center or contact your
sales representative who will be happy to discuss your specific
needs.
Europe, Middle
East, and Africa If you need product technical support, contact your local Field Support/Regional Technical Assistance Center or contact your
sales representative who will be happy to discuss your specific
needs.
Asia Pacific
Region If you need product technical support, contact your local Field Support/Regional Technical Assistance Center or contact your
sales representative who will be happy to discuss your specific
needs.
Product Repair
and Return Repair and return service for Lucent Technologies equipment is
available to customers around the world.
USA, Canada,
Puerto Rico, and
the US Virgin
Islands
For information on returning of products for repair, customers
may call 1-800-255-1402 for assistance.

Lucent Technologies Lineage®2000 ECS Battery Plant H569-403
Issue 4 February 1997 Introduction 1 - 3
Central and
South America If you need to return a product for repair, your sales representative will be happy to discuss your individual situation.
Europe, Middle
East, and Africa If you need to return a product for repair, your sales representative will be happy to discuss your individual situation.
Asia Pacific
Region If you need to return a product for repair, your sales representative will be happy to discuss your individual situation.
Customer
Service For customer service, any other product or service information,
or for additional copies of this manual or other Lucent
Technologies documents, call 1-800-THE-1PWR
(1-800-843-1797). Specify the select code number for manuals,
or drawing number for drawings. Contact your regional
customer service organization or sales representative for
information regarding spare parts.

Lucent Technologies Lineage®2000 ECS Battery Plant H569-403
1 - 4 Introduction Issue 4 February 1997
Figure 1-1: Lineage®2000 ECS Battery Plant (Model H569-403)
Lucent

Lucent Technologies Lineage®2000 ECS Battery Plant H569-403
Issue 4 February 1997 Product Description 2 - 1
2 Product Description
Plant
Specifications
Table 2-A: Lineage®2000 Battery Plant Specifications
(Model H569-403)
Input Voltage 180-264 Vac (208/240 Vac nominal)
Input Frequency 47-63 Hz (50/60 Hz nominal)
Operating Voltage 20-30 Vdc (24 Vdc nominal)
Float Voltage 24-29 Vdc (24 Vdc nominal)
Plant Current Rating 600 amperes
Plant Shunt 600 amperes maximum at 50 millivolts
LVD/R Voltage Settings 20.25 or 21.25 Vdc
Controller Basic: 113B Microprocessor option circuit pack: CP2
Datalogger option circuit pack: CP3
Rectifier Shelf Assembly 2 maximum, each mounts 3 rectifiers
Rectifiers Type: Lineage®2000 SR100/+24
Rating: +24 volts nominal, 100 amperes
6 maximum
Converter Shelf Assembly 2 maximum, each mounts 2 converters
Converters Type: KS23832 Rating: -48 volts, 10 amperes
4 maximum

Lucent Technologies Lineage®2000 ECS Battery Plant H569-403
2 - 2 Product Description Issue 4 February 1997
Circuit Breakers
Type: KS22010
Available ratings: 10, 20, 30, 45, 60, 100
amperes
18 maximum
Fuses Type: 74, KS-19870 Available ratings: 1-30 amperes
8 maximum
Temperature 32-122°F (0-50°C)
Altitude
-200 to 13,000 feet (-61 to 3962 meters)
For altitudes of 5000 to 13,000 feet,
derate maximum temperature by 3.6°F
per 1000 feet above 5000 feet.
For altitudes of 1524 to 3962 meters,
derate maximum temperature by 0.656°C
per 100 meters above 1524 meters.
Framework
Type: 7-foot Central Office Framework
(standard 26-inch width)
Vertical mounting centers:1.00 inch (25
mm)
Horizontal mounting centers: 24.32
inches (618 mm)
Dimensions Height: 84 inches (2134 mm) Width: 26 inches (660 mm)
Depth: 18.0 inches (457 mm)
Weight (Includes 6 rectifiers): 450 pounds (204
kilograms)
Earthquake (See Note 1)
Heat Dissipation
Full load: 3254 watts (11,093
BTU/hr)(See Note 2)
Half load: 1640 watts (5590 BTU/hr)
Rectifier, full load: 538 watts (1834
BTU/hr)
Controller, basic and options: 26 watts
(89 BTU/hr)
Converter, full load: 135 watts (460
BTU/hr)
Humidity rating 10% to 95% noncondensing
Table 2-A: Lineage®2000 Battery Plant Specifications
(Model H569-403)

Lucent Technologies Lineage®2000 ECS Battery Plant H569-403
Issue 4 February 1997 Product Description 2 - 3
Typical Battery
Plant
Description
A basic block diagram of a typical dc battery plant is shown in
Figure2-1.The batteryplantacceptsalternatingcurrentfromthe
commercial utility or a standby ac power source and rectifies it
to produce dc power for the using equipment. Control and alarm
functions are provided by the plant to interact with the rectifiers
and the office. In addition, the plant provides overcurrent
protection, charge, discharge, and distribution facilities. Battery
reserve automatically provides a source of dc power if the
commercial or standby ac fails. This battery reserve is
engineered to supply dc power for a specific period of time. In
normal practice, battery capacity is sized to provide three to
eight hours of reserve time.
Battery Plant
Subsystems Figure 2-2 illustrates the arrangement and interconnections of the typical ECS dc battery plant subsystems from the ac input to
the dc output. These subsystems are defined as follows:
AC Distribution: Connects the commercial and/or standby ac
power sources to the rectifiers within the plant and provides
overcurrent protection. This subsystem is usually supplied by
the customer.
Rectifiers: Convert an ac source voltage into the dc voltage
level required to charge and float the batteries and to power the
using equipment.
Audible noise 68 dBa (See Note 3)
Electrostatic discharge IEC 801-2 Level 5 (15 KV) at 40%
relative humidity
Electromagnetic immunity 10V/m over the range of 20 to 2000MHz
Note 1: Earthquake testing has not been conducted on this bay. However, the bay's
components and architecture are very similar to J85500G-2, which has passed
Zone 4.
Note 2: Specified at 27.25 Vdc, 600 amperes output, and nominal input voltages and
frequencies.
Note 3: Measured at 2 feet (0.6 meter) from the rectifiers installed in plant (six rectifiers
in initial bay).
Table 2-A: Lineage®2000 Battery Plant Specifications
(Model H569-403)

Lucent Technologies Lineage®2000 ECS Battery Plant H569-403
2 - 4 Product Description Issue 4 February 1997
Controller: Provides the local and remote control, monitor and
diagnostic functions required to administer the battery plant.
Batteries: Provide energy storage for an uninterrupted power
feed to the using equipment during loss of ac input or rectifier
failure.
DC Distribution: Provides overcurrent protection, connection
points for the using equipment, and bus barsused to interconnect
the rectifiers, batteries, plant shunt, and dc distribution.
Figure 2-1: Block Diagram of Typical Battery Plant

Lucent Technologies Lineage®2000 ECS Battery Plant H569-403
Issue 4 February 1997 Product Description 2 - 5
ECS Battery
Plant Physical
Description
Introduction The Lineage®2000 Evolutionary ControlSystem(ECS) Battery
Plant Model H569-403 is shown in Figure 1-1. The ECS battery
plant provides power for the using equipment, as well as float
and recharge capability for the battery reserve. The plant
operates from a nominal 208/240 Vac,50/60 Hz source.It offers
a 600-ampere total plant capacity with a nominal +24 Vdc
output. The ECS battery plant is compatible with virtually all
flooded and valve regulated batteries. In addition, the ECS plant
is capable of operating in a batteryless mode, making it suitable
for those applications where battery backup is not necessary or
is achieved through the use of an uninterruptible power supply
(UPS).
Figure 2-2: ECS Battery Plant Block Diagram
Lucent

Lucent Technologies Lineage®2000 ECS Battery Plant H569-403
2 - 6 Product Description Issue 4 February 1997
The ECS battery plant is designed as a totally integrated energy
system package. It is a compact and complete system containing
a controller, rectifiers, circuit breaker distribution panel, and an
automatic battery disconnect/reconnect (LVD/R) feature that
can all be configured in one standard equipment bay. The plant
is a modular front-access design for ease of installation, growth,
and maintenance. This power system is ideal for use in confined
areas and allows efficient use of valuable floor space.
Initial Bay The initial bay will accommodate up to six Lineage®2000 SR
Series +24-volt, 100-ampere rectifiers, a Lineage®2000 ECS
controller, a distribution panel accepting breakers from 10-100
amperes,alowvoltage battery disconnect/reconnectfeature,and
space for four +24-volt to -48-volt dc-dc 10-ampere converters
and an associated meter and fuse panel for 48-volt distribution.
ECS Battery
Plant
Subsystems
Figure 2-2 illustrates the arrangement and interconnections of
the ECS Battery Plant subsystems from the ac input to the dc
output. These subsystems are described below:
Rectifier TheLineage®2000SR Seriesrectifiers are designed specifically
for applications where small size, low weight and ease of
installation are of overriding importance. The rectifiers utilize a
combinationof switchmode technology and forcedair cooling to
achieve a significant reduction in size and weight over
conventional ferroresonant rectifiers. The plug-in,
connectorized design oftherectifiersreduces installationtimeto
minutes, permitting easy growth and maintenance without
service interruption.
TheLineage®2000SRSeries 100-ampere rectifiersoperateover
208/220/240 Vac 50/60 Hz nominal single phase input range
without any necessary tap changes. A power factor correction
circuit incorporated in the design insures a power factor of 90
percent or greater for loads above 50 percent of the full load
rating. The rectifiers provide the ECS controller with a full
complement of status and alarm signals. The SR Series
100-ampere rectifier is both UL recognized and CSA certified.
The rectifier status and alarm signals, ac input, and dc output are
all connectorized. The rectifiers plug into a rectifier shelf
assembly that accommodates a maximum of three individual

Lucent Technologies Lineage®2000 ECS Battery Plant H569-403
Issue 4 February 1997 Product Description 2 - 7
100-ampere rectifiers. The ECS plant is equipped with two
rectifier shelf assemblies for a total capacity of six SR Series 100
ampere rectifiers. (See the rectifier product manual for
additional information on the shelf and rectifier.)
Batteries The ECS battery plant is compatible with virtually all flooded
and valve regulated batteries. The Lineage®2000 VR Series
battery is designed specifically for use in the ECS battery plant.
Selection of the VR Series battery enables one to maximize
space efficiency and fully realize the benefits of front access,
modular growth, and ease of installation and maintenance
offered by the ECS battery plant system design.
The Lineage®2000 VR Series battery is a valve-regulated
design incorporating many of the same technologically
advancedfeaturesasthehighlyacclaimedLineage®2000Round
Cell battery. It isa compact, totally front access, modular battery
based on a unit cell architecture. The VR Series battery is
currently available in a 2 volt, 375 ampere-hour configuration
for use in the ECS plant. The compact physical dimensions of
the VR battery permit the installation of up to 1500
ampere-hours of 24-volt battery reserve in a single framework
space. (See the battery product manual for additional
information.)
Controller The ECS controller performs the centralized monitoring,
control, and reporting functions for the ECS battery plant. In the
H569-403, the basic ECS controller monitors and controls a
maximum of six SR 100/+24V rectifiers. The controller,
however, is capable of monitoring up to twelve rectifiers. It also
provides a single interface point for power alarm and status
reporting.
Two optional expansion circuit packs are available to upgrade
the ECS controller: a microcomputer board equipped with a
powerful 16-bit microprocessor, and a datalogger board. The
microcomputer board adds sophisticated firmware features such
as remote communications, alarm history, and statistics. This
board is available as Group 5 or 7 on H569-403. Group 7 is the
same as Group 5, with the addition of a voice response feature.
The datalogger board may be used in conjunction with the
microcomputer option to provide general purpose ac and dc
voltage and current monitoring and control. This board is
available as Group 8 or 9 on H569-403. Group 9 is the same as

Lucent Technologies Lineage®2000 ECS Battery Plant H569-403
2 - 8 Product Description Issue 4 February 1997
Group 8, with the addition of a remote termination panel
allowing external connection to the board from outside the
controller. (See the ECS controller manual for further
information.)
DC-DC Converter The Lineage®2000 KS2383224-volt to -48-volt dc-dc converter
system utilizes 50KHz technology to provide a reliable and
economical means of obtaining closely regulated and filtered
-48-volt dc power when only one primary source of +24-volt dc
power is available.
The dc-dcconvertersystem consists ofKS23832 convertershelf
assemblies equipped with one or two KS23832 10-ampere
+24-volt to -48-volt converters. Amaximum of two shelves with
four converters may be equipped per bay. Group 41 provides a
converter shelf equipped with two converters and Group 42
provides a converter shelf equipped with one converter.
Converters should be sized with n+1 redundancy. This extra
reserve not only provides backup to your operating converter but
also provides the necessary energy required to operate fuses.
Distribution to the -48-volt load is provided via a meter and fuse
panel.
The converter shelf assembly has mounting brackets for
standard 26-inch relay rack mounting. Each converter module
contains a blocking diode, low input voltage shutdown, current
limiting, and high voltage shutdown with automatic restart. The
converter shelf assembly is equipped with major and minor
alarms. The converter shelf assembly has two Form C contacts,
one for converter major and one for converter minor. When one
converter fails, the converter minor relay will operate and when
two converters fail, the converter major relay will operate. For
more details, refer to the KS23832 converter product manual.
DC Distribution The ECS H569-403 distribution includes the plant charge and
discharge bus bars, plant shunt, LVD/R contactor, and
associated circuitry. Space below these items accommodates
circuit breaker panel for 24-volt distribution. A meter and fuse
panel is also available for 48-volt loads when the plant is
equipped with 24-volt to -48-volt converters. A complete
discussion of the ECS dc distribution is presented in the
following section of this manual.

Lucent Technologies Lineage®2000 ECS Battery Plant H569-403
Issue 4 February 1997 Product Description 2 - 9
ECS DC
Distribution
Panel
Both circuit breaker and fuse protected distribution panels are
available with the ECS Battery Plant. They are orderable as
Group 20 and Group 43, respectively. An alarm connection is
provided with each panel to indicate an open fuse or tripped
circuit breaker and is transmitted to the ECS Controller as a
Major Fuse Alarm, MJF (FAJ).
Circuit Breaker Panel (Group 20)
Distribution to the +24-volt loads is provided with the
ED83182-30 G7 circuit breaker panel. This panel
accommodates up to eighteen 10- to 100-ampere circuit
breakers. A hinged front cover panel allows easy access to the
breakers for connecting load leads or adding circuit breakers.
When dc-dc converters are required, the first four mounting
positions should be reserved for 45-ampere circuit breakers (one
for each converter). Figure 2-3 shows the circuit breaker panel
and Table 2-B describes the circuit breaker options and ordering
information.
Table 2-B: H569-403, Group 20 Lineage®2000
ECS Battery Plant Breaker Panel
Circuit breakers operate and provide an alarm during
electrical or manual trip. The Group 20 panel contains 18
positions for circuit breakers. The panel bus bar is sized for
600-ampere capacity.
Circuit Breaker Specifications
Capacity (Amps) Type Heinemann Order Information
H569-403, G20*
10
20
30
45
60
100
KS22010
G-AA
G-AB
G-AC
G-AD
G-AE
G-AF
* One breaker provided per lettered group. Specify breaker positions 1 to
18, left to right.

Lucent Technologies Lineage®2000 ECS Battery Plant H569-403
2 - 10 Product Description Issue 4 February 1997
Meter and Fuse Panel (Group 43)
Distributionto the-48-voltloads is providedwiththe J85501C-1
L5 meter and fuse panel. This panel includes a fuse block that
accommodates eight 1- to 30-ampere distribution fuses and
associated alarm fuses, an ammeter (0-50A), voltmeter (0-60V)
and distribution bus bars. The analog meters monitor the total
current and voltage delivered by the converters. Load lead
connections to the fuse block and discharge return are front
accessible via a removable 3-inch coverpanel. Figure 2-4 shows
the meter and fuse panel and Table 2-C describes the load fuse
options.
Table 2-C: H569-403 Group 43 Fuse Options
The Group 43 panel contains a fuse block which accommodates
8 load fuses. Refer below for fuse specifications. Load fuses are
ordered on a job basis, separately from the battery plant order.
Load Fuse
Size Type Range
(Amps) Order Information for a Fuse Panel
9/32 x 1-1/4 inch 74
KS-19870 1.25-20 2-30 H569-403, G-43
