Lucent Technologies Lineage 2000 J85503C-3 User manual

Lineage®2000
400-Ampere, 60-Hertz
Ferroresonant Rectifier
J85503C-3
Product Manual
Select Code 169-790-132
Comcode 107239915
Issue 10
July 2000
© 2000 Lucent Technologies

Product Manual
Select Code 169-790-132
Comcode 107239915
Issue 10
July 2000
Lucent Technologies
Lineage®2000
400-Ampere, 60-Hertz
Ferroresonant Rectifier
J85503C-3
Notice:
The information, specifications, and procedures in this manual
are subject to change without notice. Lucent Technologies
assumes no responsibility for any errors that may appear in this
document.
© 2000 Lucent Technologies
All Rights Reserved
Printed in U.S.A.

Lucent Technologies Lineage®2000 400A, 60Hz Ferroresonant Rectifier J85503C-3
Issue 10 July 2000 Table of Contents - 1
Table of Contents
1 Introduction
J85503C-3 1 - 1
Customer Service Contacts 1 - 2
Customer Training 1 - 2
Customer Service 1 - 2
Technical Support 1 - 2
Product Repair and Return 1 - 2
Warranty Service 1 - 3
On-Line Power Systems Product Manuals 1 - 3
2 Product Description
Function 2 - 1
Benefits 2 - 1
Features 2 - 2
Output Current “Walk-in” 2 - 2
Electronic Current Limit 2 - 2
Backup Current Limit 2 - 2
Selective High Voltage Shutdown 2 - 2
Internal Selective High Voltage Shutdown (ISHVSD) 2 - 3
Backup High Voltage Shutdown (BUHVSD) 2 - 3
Dynamic Response 2 - 3
Forced Electronic Load Sharing 2 - 3
Safety Interlocks 2 - 3
Restart Circuit 2 - 3
Output Circuit Breaker 2 - 3
Output Fuse and Fuse Alarm Switch 2 - 4
Output Current Indication 2 - 4
Output Voltage Adjustment Range 2 - 4
Float/Equalize/Boost 2 - 4
Equalize Acknowledge 2 - 4
Remote Sense Leads 2 - 4
Local Sense 2 - 4
Remote Shutdown 2 - 5
Remote Control Circuit 2 - 5
Output Noise 2 - 5
Rectifier Failure Alarm (RFA) Test 2 - 5

Lucent Technologies Lineage®2000 400A, 60Hz Ferroresonant Rectifier J85503C-3
2 - Table of Contents Issue 10 July 2000
Electromagnetic Compatibility (EMC) 2 - 5
Alarms 2 - 6
Load Share Fail (LSF) 2 - 6
Fuse Alarms (FA) 2 - 6
Rectifier Failure Alarm (RFA) 2 - 6
Auxiliary RFA Alarm 2 - 6
Charger Fail Alarm (RFA/CFA) 2 - 7
Manual Alarm (MAN) 2 - 7
AC Fail (ACF) 2 - 7
Circuit Breaker Alarm (CB)/Output Fuse Alarm Switch 2 - 7
Phase Monitor Circuit (PHA) 2 - 7
Unbalance Alarm Circuit 2 - 7
Low Current Alarm (LCA) 2 - 7
Front Panel Controls and Indicators 2 - 8
Output Meter 2 - 8
Rect V 2 - 8
Power Switch 2 - 8
LEDs 2 - 9
Rect Test Switch 2 - 9
Rect + and - Test Jacks 2 - 9
Plant + and - Test Jacks 2 - 9
Float Adj 2 - 9
FLT/EQ 2 - 10
Equal Adj 2 - 10
Circuit Breaker 2 - 10
Output Fuse Alarm Switch 2 - 10
Circuit Modules 2 - 12
CM1 (329A Fuse Board) 2 - 12
CM2 (208F Control Board) 2 - 13
CM3 (323D Digital Meter Board) 2 - 13
CM4 (330B Interface Board) 2 - 13
CM5/CM6 (ED83156-30 G3) 2 - 13
CM7 (425C/D/E/F Transformer Boards) 2 - 13
Alarm and Control Flow 2 - 14
Specifications 2 - 15
3 Engineering and Ordering
Rectifier Sizing 3 - 1
Sizing Considerations 3 - 1
Redundant and Non-Redundant Systems 3 - 2
Sizing Example 3 - 3
Ordering 3 - 4
List Structure 3 - 4
Notes 3 - 5
Sample Order 3 - 10

Lucent Technologies Lineage®2000 400A, 60Hz Ferroresonant Rectifier J85503C-3
Issue 10 July 2000 Table of Contents - 3
4 Safety
Safety Precautions 4 - 1
ESD Precautions 4 - 3
Warning Statements and Safety Symbols 4 - 4
5 Installation
Introduction 5 - 1
Tools 5 - 1
Guidelines 5 - 2
Floor Mounting 5 - 2
Heat Dissipation 5 - 3
AC Input Power 5 - 4
DC Output Power 5 - 7
Handling Equipment 5 - 9
Unpacking 5 - 9
Installing or Adding a Rectifier 5 - 10
Locate and Anchor the Rectifier 5 - 10
AC Power Cables 5 - 11
DC Power Cables 5 - 12
Supplemental Central Office (CO) Ground 5 - 13
Plant Control Cable Assembly (Lucent Technologies
Controller) 5 - 13
Plant Control Cable Assembly (External Alarm/Control Bay) 5 - 16
DIP Switch Settings 5 - 17
208F Control Board (CM2) 5 - 17
323D Digital Meter Board (CM3) 5 - 20
329A Fuse Board (CM1) 5 - 20
330C Interface Board (CM4) 5 - 20
Converting AC Voltage 5 - 20
Initial Battery Charging 5 - 21
6 Testing
Overview 6 - 1
Precautions 6 - 1
Tools and Test Equipment 6 - 2
Battery Plant Simulator Test Set 6 - 2
Test Load Connection 6 - 3
Initial Conditions for Testing Off Line 6 - 4
Testing Off Line 6 - 8
Startup 6 - 8
Regulation (NL/FL) Test 6 - 8
Rectifier Failure Alarm Test 6 - 9
Current Limit Test 6 - 9

Lucent Technologies Lineage®2000 400A, 60Hz Ferroresonant Rectifier J85503C-3
4 - Table of Contents Issue 10 July 2000
Phase Failure Alarm (PHA) Test 6 - 10
Backup High Voltage Shutdown (HVSD) Test 6 - 10
Control (TR) Test 6 - 11
Selective High Voltage Shutdown (SHVSD) and Restart 6 - 11
Float/Equalize Test 6 - 11
Local Equalize Control Test 6 - 12
Low Current Alarm (LCA) Test 6 - 12
Load Share Fail (LSF) Test 6 - 12
Meter Test 6 - 13
Off-line Test Completion 6 - 13
Bringing a Rectifier On Line 6 - 14
Testing On Line 6 - 15
Regulation (NL/FL) Test 6 - 15
Rectifier Failure Alarm/Fuse Alarm Test 6 - 16
Current Limit Test 6 - 16
Isolated Current Measuring (VI) Test 6 - 17
Phase Failure Test 6 - 18
Backup High Voltage Shutdown (HVSD) Test 6 - 18
Control (TR) Test 6 - 19
Selective High Voltage Shutdown (SHVSD) and Restart 6 - 20
AC Fail Test 6 - 20
RFA Circuit Verification RFA Test 6 - 20
Meter Test (On Line) 6 - 21
Adjust Rectifiers to Float Voltage 6 - 22
Individually 6 - 22
As a Group 6 - 23
Enable and Test Load Share 6 - 24
Special Application Load Share (NLS) 6 - 25
7 Troubleshooting and Adjustments
Introduction 7 - 1
Remove Rectifier From Service 7 - 2
Diagnostics 7 - 3
Front Panel Conditions 7 - 6
Adjustments 7 - 12
Clear Rectifier Failure Alarm (RFA) 7 - 12
Clear Fuse Alarm (FA) 7 - 13
Calibrate CM3 Digital Meter 7 - 13
Adjust Current Limit 7 - 16
ISHVSD in Plants Without a Controller 7 - 16
Restore Rectifier to Service 7 - 17
Preventive Maintenance 7 - 18

Lucent Technologies Lineage®2000 400A, 60Hz Ferroresonant Rectifier J85503C-3
Issue 10 July 2000 Table of Contents - 5
8 Spare Parts and Replacement Procedures
Introduction 8 - 1
Circuit Modules 8 - 2
Ordering 8 - 2
Handling 8 - 2
Fuses 8 - 4
Electrical Parts 8 - 5
Replacing Circuit Packs 8 - 6
CM1 Fuse Board 8 - 6
CM2 Control Board 8 - 7
CM3 Digital Meter Board 8 - 8
CM4 Interface Board 8 - 9
CM5 or CM6 Snubber Board 8 - 9
CM7 Transformer Board 8 - 10
Replacing Components 8 - 11
Guidelines 8 - 11
Torquing Requirements 8 - 12
Thyristors (Q1, Q2) 8 - 15
Diode Heat Sink Assemblies 8 - 15
DC Capacitors (C7 through C12) 8 - 16
CB1 Circuit Breaker 8 - 16
F7 Fuse and SW1 Switch Assembly 8 - 17
DC Inductor (L3, L4) 8 - 17
Contactor Relay (K1) 8 - 18
AC Inductors (L1, L2) 8 - 18
AC Capacitors (C1 - C6, C13 and C14) 8 - 18
Main Transformers (T1, T2) 8 - 18
Disconnecting a Rectifier 8 - 19
9 Product Warranty

Lucent Technologies Lineage®2000 400A, 60Hz Ferroresonant Rectifier J85503C-3
Issue 10 July 2000 List of Figures - 1
List of Figures
Figure 2-1: J85503C-3 Control Panel 2 - 8
Figure 2-2: J85503C-3 Rectifier With Door Open 2 - 11
Figure 2-3: Signal Flow Rectifier/Galaxy Controller 2 - 14
Figure 3-1: Recharge Time vs. Recharge Factor 3 - 2
Figure 5-1: Floor Mounting Detail 5 - 2
Figure 5-2: Floor Anchoring 5 - 3
Figure 5-3: AC and DC Termination Points 5 - 6
Figure 5-4: Top View of the J85503C-3 Rectifier 5 - 6
Figure 5-5: DC Output Cables in Cable Rack 5 - 8
Figure 5-6: CM4 Interface Board 5 - 13
Figure 5-7: Top Half of DIP Switch Label 5 - 18
Figure 5-8: Bottom Half of DIP Switch Label 5 - 19
Figure 6-1: Battery Plant Simulator Test Set 6 - 2
Figure 6-2: CM1 Fuse Board With Clip Connections 6 - 6
Figure 6-3: CM2 Board With Clip Connections 6 - 7
Figure 7-1: Adjustment Potentiometer on CM3 7 - 15
Figure 8-1: Component Locations 8 - 14

Lucent Technologies Lineage®2000 400A, 60Hz Ferroresonant Rectifier J85503C-3
Issue 10 July 2000 List of Tables - 1
List of Tables
Table 2-A: Circuit Packs in the J85503C-3 Rectifier 2 - 12
Table 2-B: J85503C-3 Specifications 2 - 15
Table 3-A: J85503C-3 Ordering Information 3 - 5
Table 3-B: Hardware 3 - 7
Table 3-C: Shims 3 - 8
Table 3-D: Circuit Packs in the J85503C-3 Rectifier 3 - 9
Table 5-A: AC Input Requirements 5 - 5
Table 5-B: DC Output Options 5 - 7
Table 5-C: Rack Widths for 350KCMIL Cables 5 - 8
Table 5-D: Controller Connectors 5 - 14
Table 5-E: Control Settings for Initial Battery Charge 5 - 21
Table 6-A: Test Set Connections 6 - 3
Table 6-B: Rectifier Control Settings for Testing Off Line 6 - 4
Table 6-C: Rectifier Control Settings for Testing On Line 6 - 14
Table 6-D: Rectifier Controls for Meter Test On Line 6 - 21
Table 7-A: Troubleshooting 7 - 3
Table 7-B: Front Panel Conditions and Indications 7 - 6
Table 7-C: Alarms on TB1/TB2 of CM4 7 - 8
Table 7-D: Controls on TB1/TB2 of CM4 7 - 9
Table 7-E: Signals on TB3 of CM4 7 - 10
Table 7-F: Additional Conditions/Indications on the J85503C-3 7 - 11
Table 7-G: Digital Meter Tolerance 7 - 14

Lucent Technologies Lineage®2000 400A, 60Hz Ferroresonant Rectifier J85503C-3
2 - List of Tables Issue 10 July 2000
Table 7-H: Control Settings Prior to Restoring a Rectifier
to Service 7 - 17
Table 8-A: Circuit Packs in the J85503C-3 Rectifier 8 - 2
Table 8-B: Spare Fuse Information 8 - 4
Table 8-C: Spare Electrical Parts 8 - 5
Table 8-D: Minimum Torque for Electrical Connections 8 - 13
Table 8-E: Torque and Minimum Yield Strength Values
for Mechanical Connections (Using Hex Head Cap Screws) 8 - 13

Lucent Technologies Lineage®2000 400A, 60Hz Ferroresonant Rectifier J85503C-3
Issue 10 July 2000 Introduction 1 - 1
1 Introduction
J85503C-3 This product manual (Select Code 169-790-132) describes the
J85503C-3, 3-phase, 400-ampere, 60-Hertz, -48-volt, floor-mounted
rectifier.
The J85503C-3 rectifier is a member of the Lucent Technologies family
of Lineage® 2000 rectifiers. Like all Lineage® 2000 rectifiers, it
represents a significant advancement in efficiency, space savings, and
serviceability. The rectifier uses the electronically controlled,
closed-loop, ferroresonant technology developed by Lucent
Technologies Bell Laboratories. This technology provides excellent
output regulation in spite of variations in the incoming commercial line
voltage and frequency, and the outgoing current or load.
The J85503C-3 rectifier converts commercial 416-volt ac input power
at 60 Hertz into highly regulated and filtered, low-noise, -48-volt dc
output power for telecommunications equipment loads. Central offices
usually obtain electrical power from potentially noisy commercial ac
lines and/or emergency generators during commercial power failures.
The J85503C-3 rectifier provides the high quality dc power required for
proper operation of telecommunications equipment.
Lucent Technologies developed the J85503C-3 rectifier to support large
central office applications where high reliability, low maintenance, long
life, and fault tolerance are critical.
The J85503C-3 rectifier can be used with a Lineage®2000 battery plant
or any commercial battery plant. It can boost charge batteries and
equalize batteries off-line to 65 volts as well as operate without
batteries. The rectifier works with Lucent Technologies controllers to
provide control and alarm functions. An interface board is available to
access these functions with commercial controllers.

Lucent Technologies Lineage®2000 400A, 60Hz Ferroresonant Rectifier J85503C-3
1 - 2 Introduction Issue 10 July 2000
Customer
Service
Contacts
Customer Training Lucent Technologies offers customer training on many Power Systems
products. For information call 1-972-284-2163. This number is
answered from 8:00 a.m. until 4:30 p.m., Central Time Zone (Zone 6),
Monday through Friday.
Customer Service For customers in the United States, Canada, Puerto Rico, and the US
Virgin Islands, call 1-800-THE-1PWR (1-800-843-1797). Services
provided through this contact include initiating the spare parts
procurement process for out of service emergencies, ordering Lucent
Technologies documents, and providing other product and service
information.
For other customers worldwide, call 001-972-840-0382. This number is
answered from 8:00 a.m. until 4:30 p.m., Central Time Zone (Zone 6),
Monday through Friday.
Technical Support Technical support for Lucent Technologies customers is available
around the world during the normal product warranty period and also
while specific contractual agreements extend this service.
For customers in the United States, Canada, Puerto Rico, and the US
Virgin Islands, call 1-800-CAL-RTAC (1-800-225-7822) to contact a
product specialist to answer your technical questions and assist in
troubleshooting problems.
For other customers worldwide, contact your local field support center
or your sales representative to discuss your specific needs.
ProductRepairand
Return Repair and return service is provided for Lucent Technologies
customers around the world.
For customers in the United States, Canada, Puerto Rico, and the US
Virgin Islands, call 1-800-255-1402 for information on returning of
products for repair.
For other customers worldwide, contact your sales representative to
discuss your particular circumstances.

Lucent Technologies Lineage®2000 400A, 60Hz Ferroresonant Rectifier J85503C-3
Issue 10 July 2000 Introduction 1 - 3
Warranty Service For domestic warranty service, contact your Warranty Service Manager
(WSM). For international warranty service, contact your sales
representative.
On-Line Power
Systems Product
Manuals
For Lucent Technologies users logging in from inside the corporate
firewall, the address of the “Power Systems On-Line Product Manuals”
page is http://www.cic.lucent.com/lineage.html.
For customers logging in from outside the firewall, the address is
http://www.lucent8.com/lineage.html. The annual subscription fee for
access to this site is $25. To obtain a password, follow the instructions
on-line or call 1-888-Lucent8 (1-888-582-3688). When prompted for an
order number, enter or say “167-790-010.”

Lucent Technologies Lineage®2000 400A, 60Hz Ferroresonant Rectifier J85503C-3
Issue 10 July 2000 Product Description 2 - 1
2 Product Description
Function In most telecommunications applications, the output of the rectifier
system is electrically connected in parallel with the batteries. The
rectifiers provide boththe power to thetelephone equipment through the
plant distribution and the charging and float current to the batteries. In
the event of commercial power failure, the batteries supply the required
dc power tothetelephone equipment. Thistransition needs no switching
because of the parallel connection of the rectifiers and batteries.
Benefits The J85503C-3, 400-ampere, 60-Hertz rectifier offers you the following
benefits:
• Eliminates internal switching transients typically associated with
older technologies.
• Reduces noise and transients from the commercial ac source. As the
interface between commercial power and telephone equipment, the
ferroresonant rectifier significantly attenuates noise and lightning
surges from commercial lines.
• Introduces far less noise into closely coupled telephone lines due to
lower harmonic components in the input current waveshape.
• Provides highly efficient power conversion.
• Ferroresonant technology and the rectifier's physical design
features combine to provide reliable service, easy maintenance, and
greater cost effectiveness.
• All components in the rectifier meet Lucent Technologies' strict
specifications and reliability standards. The rectifier uses an
extremely efficient, free-convection cooling system that keeps
components operating at temperatures well below the
recommended maximum, resulting in high reliability.

Lucent Technologies Lineage®2000 400A, 60Hz Ferroresonant Rectifier J85503C-3
2 - 2 Product Description Issue 10 July 2000
• All circuits for power control, alarms, voltage regulation, current
limiting, restart, plant interface, and remote monitoring/control are
mounted on replaceable circuit modules. Front access to the circuit
modules simplifies replacement or adjustment, if required.
Standardized modules simplify parts inventory, resulting in lower
costs and better equipment availability.
• The rectifier can be used in a plant with or without batteries and
with or without a controller. The load share feature, equalize
feature, noise filtering, and interface board adapt the rectifier to
practically any application.
Features The J85503C-3, 400 ampere rectifier offers the following standard
features.
Output Current
“Walk-in” This circuit controls the time required for the rectifier to reach its rated output voltage after it is turned on. Initially, the output voltage is about
80 percent of normal, and gradually increases to the required value in
approximately 10 seconds. As the output voltage “walks in,” so does
output current. This feature minimizes the starting surge on the
customer's power source and is especially important with a more limited
power source, such as an engine driven alternator.
Electronic Current
Limit The rectifier provides a constant output voltage up to its rated output current, at which pointitprovides constantcurrent.Thiscurrent limitset
point is adjustable from 30 to 110 percent of the rectifier rating, 120-440
amperes. When the output current tends to increase above the current
limit setting, the current limit circuit overrides the voltage regulating
signal and limits the output current of the rectifier.
Backup Current
Limit In addition to the electronic current limit, the ferroresonant transformers are naturally current limiting to 125-175 percent of full load, or 500-700
amperes.
Selective High
Voltage Shutdown If the battery voltage goes too high, a Lineage®2000 controller signals all of the connected rectifiers. This signal causes the rectifier(s)
delivering morethan10 percent offull load to shutdown. The remaining
rectifiers continue to operate. The J85503C-3, 400 ampere also accepts
a selective high voltage shutdown (HVSD) signal from any external
source via the interface board.
