Lucent Technologies Lineage 2000 J85503B-2 User manual

Lineage®2000
200-Ampere, 60-Hertz
Ferroresonant Rectifier
J85503B-2
Product Manual
Select Code 169-790-128
Comcode 107666356
Issue 8
January 1999
©1999 Lucent Technologies

Product Manual
J85503B-2
Select Code 169-790-128
Comcode 107666356
Issue 8
January 1999
Lucent Technologies
Lineage®2000
200-Ampere, 60-Hertz
Ferroresonant Rectifier
Notice:
Every effort was made to ensure that the information in this
document was complete and accurate at the time of printing.
However, information is subject to change.
©1999 Lucent Technologies
All Rights Reserved
Printed in U.S.A.

Lucent Technologies Lineage®2000 200A Ferroresonant Rectifier J85503B-2
Issue 8 January 1999 Table of Contents - 1
Table of Contents
1 Introduction
General 1 - 1
Applications 1 - 1
Features 1 - 2
Benefits 1 - 2
Customer Service 1 - 3
Technical Support 1 - 3
Product Repair and Return 1 - 3
2 Product Description
General 2 - 1
Typical Battery Plant 2 - 1
Battery Plant Subsystems 2 - 1
Features 2 - 2
Output Current “Walk-in” 2 - 2
Electronic Current Limit 2 - 3
Backup Current Limit 2 - 3
Selective High Voltage Shutdown 2 - 3
Internal Selective High Voltage Shutdown (ISHVSD) 2 - 3
Backup High Voltage Shutdown (BUHVSD) 2 - 3
Dynamic Response 2 - 3
Forced Electronic Load Sharing 2 - 4
Safety Interlocks 2 - 4
Restart Circuit 2 - 4
Output Circuit Breaker 2 - 4
Output Current Indication 2 - 4
Output Voltage Adjustment Range 2 - 4
Float/Equalize/Boost 2 - 4
Equalize Acknowledge 2 - 5
Remote Sense Leads 2 - 5
Local Sense 2 - 5
Remote Shutdown 2 - 5
Remote Control Circuit 2 - 5
Output Noise 2 - 6
Rectifier Failure Alarm (RFA) Test 2 - 6
Electromagnetic Compatibility (EMC) 2 - 6

Lucent Technologies Lineage®2000 200A Ferroresonant Rectifier J85503B-2
2 - Table of Contents Issue 8 January 1999
Alarms 2 - 6
Load Share Fail (LSF) 2 - 6
Fuse Alarms (FA) 2 - 6
Rectifier Failure Alarm (RFA) 2 - 6
Auxiliary RFA Alarm 2 - 7
Charger Fail Alarm (RFA/CFA) 2 - 7
Manual Alarm (MAN) 2 - 7
AC Fail (ACF) 2 - 7
Circuit Breaker Alarm (CB) 2 - 7
Phase Monitor Circuit (PHA) 2 - 7
Unbalance Alarm Circuit 2 - 8
Low Current Alarm (LCA) 2 - 8
Front Panel Controls And Indicators 2 - 8
Output Meter 2 - 8
Rect V 2 - 9
Power Switch 2 - 9
Alarms 2 - 9
Rect Test Switch 2 - 9
Rect + and - Test Jacks 2 - 10
Plant + and -Test Jacks 2 - 10
Float Adj 2 - 10
FLT/EQ 2 - 10
Equal Adj 2 - 10
Circuit Breaker 2 - 10
Circuit Modules 2 - 10
CM1 2 - 11
CM2 2 - 11
CM3 2 - 11
CM4 2 - 11
CM5/CM6 2 - 11
CM7 2 - 11
Alarm and Control Flow 2 - 12
Specifications 2 - 14
3 Engineering and Ordering
Rectifier Sizing 3 - 1
Sizing Considerations 3 - 1
Sizing Example 3 - 3
Ordering Information 3 - 4
Rectifier 3 - 5
Hardware 3 - 6
Shims 3 - 7
Junction Plates 3 - 8
Spare Parts 3 - 8
Sample Order 3 - 10

Lucent Technologies Lineage®2000 200A Ferroresonant Rectifier J85503B-2
Issue 8 January 1999 Table of Contents - 3
Documentation References 3 - 10
4Safety
Safety Precautions 4 - 1
ESD Precautions 4 - 3
5 Installation
General 5 - 1
Preparing for Installation 5 - 1
Floor Mounting 5 - 1
Heat Dissipation 5 - 2
AC Input Power 5 - 3
DC Output Power 5 - 4
DC Power Cables 5 - 6
Handling Equipment 5 - 7
Installation 5 - 8
Unpacking 5 - 8
Installing or Adding a Rectifier 5 - 9
Locate and Anchor the Rectifier 5 - 9
AC Power Cables 5 - 10
DC Power Cables 5 - 10
Supplemental Central Office (CO) Ground 5 - 11
Plant Control Cable Assembly (Lucent Controller) 5 - 11
Plant Control Cable Assembly (External
Alarm/Control Bay) 5 - 15
DIP Switch Settings 5 - 16
208F Control Board (CM2) 5 - 16
323D Digital Meter Board (CM3) 5 - 19
329A Fuse Board (CM1) 5 - 19
330C Interface Board (CM4) 5 - 19
Converting AC Voltage 5 - 20
Initial Battery Charging 5 - 20
6 Testing
General 6 - 1
Precautions 6 - 1
Tools and Test Equipment 6 - 2
Battery Plant Simulator Test Set 6 - 2
Test Load Connection 6 - 3
Initial Conditions for Testing Off Line 6 - 5
Testing Off Line 6 - 8
Startup 6 - 8
Regulation (NL/FL) Test 6 - 8

Lucent Technologies Lineage®2000 200A Ferroresonant Rectifier J85503B-2
4 - Table of Contents Issue 8 January 1999
Rectifier Failure Alarm Test 6 - 8
Current Limit Test 6 - 9
Phase Failure Alarm (PHA) Test 6 - 9
Backup High Voltage Shutdown (HVSD) Test 6 - 10
Control (TR) Test 6 - 11
Selective High Voltage Shutdown (SHVSD)
and Restart 6 - 11
Float/Equalize Test 6 - 11
Local Equalize Control Test 6 - 12
Low Current Alarm (LCA) Test (48V only) 6 - 12
Load Share Fail (LSF) Test (48V only) 6 - 12
Meter Test 6 - 12
Off Line Test Completion 6 - 13
Bringing a Rectifier On Line 6 - 13
Testing On Line 6 - 15
Regulation (NL/FL) Test 6 - 15
Rectifier Failure Alarm/Fuse Alarm Test 6 - 15
Current Limit Test 6 - 16
Isolated Current Measuring (VI) Test 6 - 16
Phase Failure Test 6 - 18
Backup High Voltage Shutdown (BUHVSD) Test 6 - 18
Control (TR) Test 6 - 19
Selective High Voltage Shutdown (SHVSD)
and Restart 6 - 20
AC Fail Test 6 - 20
RFA Circuit Verification RFA Test 6 - 21
Meter Test (on line) 6 - 21
Adjust Rectifiers to Float Voltage 6 - 22
Adjust Rectifiers Individually 6 - 22
Adjust Rectifiers as a Group 6 - 23
Enable and Test Load Share 6 - 24
Special Application Load Share (NLS) 6 - 25
7 Troubleshooting and Adjustments
General 7 - 1
Disconnecting a Rectifier 7 - 1
Diagnostics 7 - 3
Front Panel Conditions 7 - 6
Adjustments 7 - 12
Clear Rectifier Failure Alarm (RFA) 7 - 12
Clear Fuse Alarm (FA) 7 - 13
Calibrate CM3 Digital Meter 7 - 14
Adjust Current Limit 7 - 15
ISHVSD in Plants Without a Controller 7 - 16
Restore Rectifier to Service 7 - 18

Lucent Technologies Lineage®2000 200A Ferroresonant Rectifier J85503B-2
Issue 8 January 1999 Table of Contents - 5
Preventive Maintenance 7 - 19
8 Replacing Components and Circuit
Modules
General Considerations for Replacing Components 8 - 1
Replacing Components 8 - 4
Thyristors (Q1, Q2) 8 - 5
Diode Heat Sink Assemblies 8 - 6
DC Capacitors (C7 through C12) 8 - 6
CB1 Circuit Breaker 8 - 7
DC Inductor (L3, L4) 8 - 7
Contactor Relay (K1) 8 - 8
AC Inductors (L1, L2) 8 - 8
AC Capacitors (C1 - C6, C13 and C14) 8 - 8
Main Transformers (T1, T2) 8 - 8
Handling Circuit Modules 8 - 9
Replacing Circuit Modules 8 - 10
CM1 Fuse Board 8 - 10
CM2 Control Board 8 - 11
CM3 Digital Meter Board 8 - 12
CM4 Interface Board 8 - 13
CM5 or CM6 Snubber Board 8 - 14
CM7 Transformer Board 8 - 14
9 Product Warranty

Lucent Technologies Lineage®2000 200A Ferroresonant Rectifier J85503B-2
6 - Table of Contents Issue 8 January 1999

Lucent Technologies Lineage®2000 200A Ferroresonant Rectifier J85503B-2
Issue 8 January 1999 List of Figures - 1
List of Figures
Figure 2-1: Block Diagram of a Typical Battery Plant 2 - 2
Figure 2-2: J85503B-2 Control Panel 2 - 8
Figure 2-3: J85503B-2 Rectifier with Door Open 2 - 13
Figure 2-4: Signal Flow Rectifier/Galaxy Controller 2 - 14
Figure 3-1: Recharge Time vs. Recharge Factor 3 - 2
Figure 5-1: Floor Mounting Detail 5 - 2
Figure 5-2: Floor Anchoring 5 - 2
Figure 5-3: AC and DC Termination Points 5 - 5
Figure 5-4: Top View of the J85503B-2 Rectifier 5 - 6
Figure 5-5: DC Output Cables in Cable Rack 5 - 7
Figure 5-6: CM4 Interface Board (330C) 5 - 14
Figure 5-7: 48V DIP Switch Label 5 - 17
Figure 5-8: 24V DIP Switch Label 5 - 18
Figure 6-1: Battery Plant Simulator Test Set 6 - 4
Figure 6-2: CM1 Fuse Board with Clip Connections
(Older version of CM1 on the left) 6 - 6
Figure 6-3: CM2 Board with Clip Connections 6 - 7
Figure 7-1: Adjustment Potentiometer on CM3 7 - 15
Figure 8-1: Component Locations 8 - 5

Lucent Technologies Lineage®2000 200A Ferroresonant Rectifier J85503B-2
2 - List of Figures Issue 8 January 1999

Lucent Technologies Lineage®2000 200A Ferroresonant Rectifier J85503B-2
Issue 8 January 1999 List of Tables - 1
List of Tables
Table 2-A: CM2 Circuits 2 - 11
Table 2-B: J85503B-2 Rectifier Specifications 2 - 14
Table 3-A: J85503B-2 Ordering Information 3 - 5
Table 3-B: Hardware Ordering Information 3 - 7
Table 3-C: Shims Ordering Information 3 - 8
Table 3-D: Junction Plates Ordering Information 3 - 8
Table 3-E: Circuit Modules in the J85503B-2 Rectifier 3 - 9
Table 3-F: Spare Fuse Information 3 - 9
Table 3-G: Spare Electrical Parts 3 - 9
Table 5-A: AC Input Requirements 5 - 3
Table 5-B: DC Output Options 5 - 5
Table 5-C: Rack Widths for 350KCMIL Cables 5 - 7
Table 5-D: Controller Connectors 5 - 12
Table 5-E: Control Settings for Initial Battery Charge 5 - 20
Table 6-A: Test Set Connections 6 - 2
Table 6-B: Rectifier Control Settings for Testing Off Line 6 - 5
Table 6-C: Rectifier Control Settings for Testing On Line 6 - 14
Table 6-D: Rectifier Controls for Meter Test On Line 6 - 21
Table 7-A: Troubleshooting 7 - 3
Table 7-B: Front Panel Conditions and Indications 7 - 6
Table 7-C: Alarms on TB1/TB2 of CM4 7 - 8
Table 7-D: Controls on TB1/TB2 of CM4 7 - 9

Lucent Technologies Lineage®2000 200A Ferroresonant Rectifier J85503B-2
2 - List of Tables Issue 8 January 1999
Table 7-E: Signals on TB3 of CM4 7 - 10
Table 7-F: Additional Conditions/Indications on the
J85503B-2 7 - 11
Table 7-G: Digital Meter Tolerance 7 - 14
Table 7-H: Control Settings Prior to Restoring
a Rectifier to Service 7 - 18
Table 8-A: Minimum Torque for Electrical Connections 8 - 3
Table 8-B: Torque and Minimum Yield Strength Values
for Mechanical Connections (Using Hex Head
Cap Screws) 8 - 4

Lucent Technologies Lineage®2000 200A Ferroresonant Rectifier J85503B-2
Issue 8 January 1999 Introduction 1 - 1
1 Introduction
General This product manual describes the J85503B-2, 3-phase,
200-ampere, 60-hertz, -48 and ±24 volt, floor-mounted
ferroresonant rectifier. The manual covers rectifier technology,
features and specifications, installation and testing, and
operation and maintenance.
The J85503B-2 rectifier is a member of theLucent Technologies
family of Lineage®2000 rectifiers. Like all Lineage®2000
rectifiers, it represents a significant advancement in efficiency,
space savings, and serviceability. The rectifier uses the
electronically controlled, closed-loop, ferroresonant technology
developed by Bell Laboratories. This technology provides
excellent output regulation in spite of variations in the incoming
commercial line voltage and frequency and the outgoing current
or load.
The J85503B-2 rectifier converts commercial 208/240/480-volt
ac input power at 60 hertz into highly regulated and filtered,
low-noise, -48 and ±24 volt dc output power for
telecommunications equipment loads. Central offices usually
obtain electrical power from potentially noisy commercial ac
lines and/or emergency generators during commercial power
failures. The J85503B-2 rectifier provides the high quality dc
power required for proper operation of telecommunications
equipment.
Applications Lucent developed the J85503B-2 rectifier to support large
central office applications where high reliability, low
maintenance, long life, and fault tolerance are critical.

Lucent Technologies Lineage®2000 200A Ferroresonant Rectifier J85503B-2
1 - 2 Introduction Issue 8 January 1999
Features The J85503B-2 rectifier can be used with a Lineage®2000
batteryplant oranycommercialbatteryplant.Itcanboostcharge
batteries and equalize batteries off-line to 65 volts (for -48-volt
plants) or to ±32 volts (for ±24 volt plants), as well as operate
without batteries. The rectifier works with Lucent Technologies
controllers to provide control and alarm functions. An interface
board is available to access these functions with commercial
controllers.
Benefits The J85503B-2 rectifier offers you the following:
• Eliminates internal switching transients typically associated
with older technologies.
• Reduces noise and transients from the commercial ac
source. As the interface between commercial power and
telephone equipment, the ferroresonant rectifier
significantly attenuates noise and lightning surges from
commercial lines.
• Introduces far less noise into closely coupled telephone
lines due to lower harmonic components in the input current
waveshape.
• Provides highly efficient power conversion.
Ferroresonant technology and the rectifier’s physical design
features combine to provide reliable service, easy maintenance,
and greater cost-effectiveness.
High reliability: All components in the rectifier meet Lucent
Technologies’strict specifications and reliability standards. The
rectifier uses an extremely efficient, free-convection cooling
system that keeps components operating at temperatures well
below the recommended maximum, which results in high
reliability.
Easier maintenance: All circuits for power control, alarms,
voltage regulation, current limiting, restart, plant interface, and
remote monitoring/control are mounted on replaceable circuit
modules. Front access to the circuit modules simplifies
replacement or adjustment, if required. Standardized modules
simplify parts inventory, resulting in lower costs and better
equipment availability.
Wide versatility: The rectifier can be used in a plant with or
withoutbatteries and with or without a controller. The loadshare

Lucent Technologies Lineage®2000 200A Ferroresonant Rectifier J85503B-2
Issue 8 January 1999 Introduction 1 - 3
feature, equalize feature, noise filtering, and interface board
adapt the rectifier to practically any application.
Customer
Service For customers in the United States, Puerto Rico, the U.S. Virgin
Islands, and Canada, call 1-800-THE-1PWR (1-800-843-1797).
Customer service specialists at this number can initiate the spare
parts procurement process, order Lucent Technologies
documents, and provide other product and service information.
Other customers world-wide may call 001-972-840-0382.
This number is answered from 8:00 am until 4:30 pm,
Central Time (Zone 6), Monday through Friday.
Technical
Support Technical support for Lucent Technologies equipment is
available to customers around the world.
Technical support for Lucent Technology customers is available
around the world during thenormal product warranty period and
also while specific contractualarrangements extend this service.
For customers in the United States, Puerto Rico, the U.S. Virgin
Islands, and Canada, call our Technical Support telephone
number 1-800-CAL RTAC (1-800-225-7822) to contact a
Product Specialist to answer your technical questions and assist
in troubleshooting problems. For out-of-hours emergencies, the
800 number will put you in touch with a Regional Technical
Assistance Center Engineer via our 24 hour a day, 7 day per
week Help Desk.
For other customers world-wide, contact your local field support
center or your sales representative to discussyour specific needs.
Product Repair
and Return Repair and return service for Lucent Technologies equipment is
available to customers around the world. For customers in the
United States, Puerto Rico, the U.S. Virgin Islands, and Canada,
call 1-800-255-1402 for information on returning products for
repair.
For other customers world-wide, contact your local field support
center or your sales representative to discussyour specific needs.

Lucent Technologies Lineage®2000 200A Ferroresonant Rectifier J85503B-2
1 - 4 Introduction Issue 8 January 1999

Lucent Technologies Lineage®2000 200A Ferroresonant Rectifier J85503B-2
Issue 8 January 1999 Product Description 2 - 1
2 Product Description
General In most telecommunications applications, the output of the
rectifier system is electrically connected in parallel with the
batteries. The rectifiers provide both the power to the telephone
equipment through the plant distribution and the charging and
float current to the batteries. In the event of commercial power
failure, the batteries supply the required dc power to the
telephone equipment. This transition needs no switching
because of the parallel connection of the rectifiers and batteries.
Typical Battery
Plant Figure 2-1 shows a basic block diagram of a typical dc battery
plant. The battery plant accepts alternating current from the
commercial utility or a standby ac power source and rectifies it
toproduce dc power for the using equipment.The plant’s control
and alarm functions interact with the rectifiers and the office. In
addition, the plant provides overcurrent protection, charge,
discharge, and distribution facilities. Battery reserve
automatically provides a source of dc power if the commercial
or standby ac fails. This battery reserve is engineered to supply
dc powerfor a specific periodof time. In normalpractice, battery
capacity is sized to provide 3 to 8 hours of reserve time.
Battery Plant
Subsystems AC Input: connects the commercial and/or standby ac power
sources to the rectifiers within the plant and provides
overcurrent protection. This subsystem is usually supplied by
the customer.
Rectifiers: convert an ac source voltageinto the dc voltagelevel
required to charge and float the batteries and to power the using
equipment.

Lucent Technologies Lineage®2000 200A Ferroresonant Rectifier J85503B-2
2 - 2 Product Description Issue 8 January 1999
Controller: provides the local and remote control, monitor and
diagnostic functions required to administer the battery plant.
Batteries: provide energy storage for an uninterrupted power
feed to the using equipment during loss of ac input or rectifier
failure.
DC Distribution: provides overcurrent protection, connection
points forthe using equipment,and bus barsused to interconnect
the rectifiers, batteries, plant shunt, and dc distribution.
Converters: transform -48 volt source voltages into regulated,
low-noise 24 volt dc power sources for use with
telecommunications loads.
Features The J85503B-2 rectifier offers the following standard features.
Output Current
“Walk-in” This circuit controls the time required for the rectifier to reach its
rated output voltage after it is turned on. Initially, the output
voltage is about 80percent of normal, and gradually increases to
the required value in approximately 10 seconds. As the output
voltage “walks in,” so does output current. This feature
minimizes thestarting surgeon thecustomer’spower source and
is especially important with a more limited power source, such
as an engine driven alternator.
Figure 2-1: Block Diagram of a Typical Battery Plant
