Lineage®2000
125-Ampere, 60-Hertz
Ferroresonant Rectifier
J85502C-1
Product Manual
Select Code 169-790-121
Comcode 107044992
Issue 8
July 1999
© 1999LucentTechnologies

Product Manual
Select Code 169-790-121
Comcode 107044992
Issue 8
July 1999
Linea
g
e®2000
125-Am
p
ere, 60-Hertz
Ferroresonant Recti
f
ier
J85502C-1
Notice:
Every effort was made to ensure that the information in this
document was complete and accurate at the time of printing.
However, information is subject to change.
© 1999 Lucent Technologies
All Rights Reserved
Printed in U.S.A.

Lucent Technologies Lineage®2000 125A Ferroresonant Rectifier J85502C-1
Issue 8 July 1999 - 1
Table of Contents
1Introduction
General Information 1 - 1
Customer Training 1 - 1
Customer Service 1 - 1
Technical Support 1 - 2
Product Repair and Return 1 - 2
Warranty Service 1 - 2
On-Line Power Systems Product Manuals 1 - 2
2Product Description
Overview 2 - 1
Ferroresonant Technology 2 - 2
Standard Features 2 - 2
Additional Features 2 - 5
Circuit Modules 2 - 5
Front Panel Controls and Indicators 2 - 7
Alarm and Control Flow 2 - 10
Physical, Thermal, and Electrical Specifications 2 - 11
3Ordering Information
Equipment Lists 3 - 1
Documentation 3 - 2
4Safety
Admonishments 4 - 1
Safety Statements 4 - 1
Precautions 4 - 2
Warning Statements and Safety Symbols 4 - 4
5Installation
Introduction 5 - 1
Safety 5 - 1
Preparing for Installation 5 - 1

Lucent Technologies Lineage®2000 125A Ferroresonant Rectifier J85502C-1
2 - Issue 8 July 1999
Handling Equipment 5 - 1
Bay Mounting 5 - 2
Heat Dissipation 5 - 2
AC Input Power 5 - 2
DC Output Power 5 - 3
Installation Tools 5 - 7
Unpacking 5 - 8
Installing or Adding a Rectifier 5 - 9
Installing AC Power Cables 5 - 9
Installing DC Power Cables 5 - 10
Installing Plant Control Cable Assembly for a Lucent
Technologies Controller 5 - 11
Converting AC Voltage (Optional) 5 - 12
Converting DC Output Polarity (Optional) 5 - 13
Initial Battery Charging (Optional) 5 - 15
6Testing
Introduction 6 - 1
Precautions 6 - 1
Tools and Test Equipment 6 - 2
Battery Plant Simulator Test Set 6 - 2
Test Load Connection 6 - 2
Preparation for Testing Off Line 6 - 4
Testing Off Line 6 - 9
Startup 6 - 9
Regulation (NL/FL) Test (Off Line) 6 - 10
Rectifier Failure Alarm/Fuse Alarm Test (Off Line) 6 - 10
Current Limit Test (Off Line) 6 - 10
Backup High Voltage Shutdown (HVSD) Test (Off
Line) 6 - 11
Control (TR) Test 6 - 12
Selective High Voltage Shutdown (SHVSD) and
Restart 6 - 12
Meter Calibration Test (Off Line) 6 - 13
Float Equalize Setup and Test - Optional (Off Line) 6 - 13
Test for 434A or 434B Circuit Module 6 - 14
Off-Line Test Completion 6 - 14
Bringing the Rectifier On Line 6 - 15
Testing On Line 6 - 16
Regulation (NL/FL) Test (On Line) 6 - 17
Rectifier Failure Alarm/Fuse Alarm Test (On Line) 6 - 17
Current Limit Test (On Line) 6 - 18
Isolated Current Measuring (VI) Test (MCS or Galaxy
Controller) 6 - 18

Lucent Technologies Lineage®2000 125A Ferroresonant Rectifier J85502C-1
Issue 8 July 1999 - 3
Backup High Voltage Shutdown (HVSD) Test (On
Line) 6 - 20
Meter Calibration Test (On Line) 6 - 21
Float Equalize Test - Optional (On Line) 6 - 22
Adjusting Rectifiers to Float Voltage 6 - 22
Adjusting Rectifiers Individually 6 - 23
Adjusting Rectifiers as a Group 6 - 23
7Troubleshooting and
Ad
j
ustments
Introduction 7 - 1
Removing a Rectifier from Service 7 - 1
Diagnostics and Troubleshooting 7 - 2
Adjustments 7 - 4
Clear Rectifier Failure Alarm (RFA) 7 - 4
Clear Fuse Alarm (FA) 7 - 6
Calibrate CM3 Digital Meter 7 - 6
Adjust Isolated Current Measuring Circuit (VI) 7 - 10
Adjust Internal Selective HVSD (Battery Plant
Without Controller) 7 - 11
Adjust Current Limit 7 - 11
Restoring a Rectifier to Service 7 - 12
8S
p
are Parts and Re
p
lacement Procedures
Introduction 8 - 1
Ordering Circuit Modules 8 - 1
Handling Circuit Modules 8 - 2
Electrostatic Discharge 8 - 2
Modifying the CM1 Option Board 8 - 4
Spare Fuses 8 - 5
Replacing Circuit Modules 8 - 5
Replacing CM1 Option Board 8 - 5
Replacing CM2 Control Board 8 - 6
Replacing CM3 Digital Meter Board 8 - 8
General Information on Replacing Components 8 - 9
Replacing Components 8 - 13
Volts Adjust Potentiometers: Output Volts (R4) and
Equalize Volts (R5) 8 - 14
CBA1 Bracket Assembly 8 - 14
DC Output Circuit Breaker (CBA1) 8 - 15
DC Inductor (L2) 8 - 15
DC Filter Capacitors (C1-C8) 8 - 15
Diode Heat Sink Assembly 8 - 16

Lucent Technologies Lineage®2000 125A Ferroresonant Rectifier J85502C-1
4 - Issue 8 July 1999
AC Inductor (L1) 8 - 17
AC Capacitors (C10 or C11) 8 - 18
Thyristor (Q1) 8 - 19
Relay (K2) 8 - 19
Contactor Relay (K1) 8 - 19
Transformer (T2) 8 - 20
Main Transformer (T1) 8 - 20
Rectifier Diode Test and/or Replacement 8 - 22
Heat Shrink Removal 8 - 23
Disconnecting a Rectifier 8 - 24
9Product Warrant
y

Lucent Technologies Lineage®2000 125A Ferroresonant Rectifier J85502C-1
Issue 8 July 1999 - 1
List of Figures
Figure 2-1: Control Panel on the J85502C-1 2 - 9
Figure 2-2: Signal Flow Between Rectifier and Lucent
Technologies Controller 2 - 10
Figure 5-1: Four Views of the J85502C-1 125-ampere
Rectifier 5 - 5
Figure 5-2: Terminal Block 1 (TB1) Where Ac Input
Voltage Is Converted on J85502C-1 Rectifier 5 - 6
Figure 5-3: Typical J85502C-1 125-ampere Rectifier
With Door Open and Diode Heat Sink Removed 5 - 7
Figure 5-4: Output Polarity Conversion and Bus Bar
Assembly of J85502C-1 Rectifier 5 - 15
Figure 6-1: Battery Plant Simulator Test Set 6 - 4
Figure 6-2: CM1 Option Board Showing Test Clip
Connections and Movable Straps 6 - 7
Figure 6-3: CM2 Control Board Showing Test Clip
Connections and Other Component Detail 6 - 8
Figure 7-1: Bus Bar Assembly with Output Capacitor
Fusing on 125-ampere Rectifiers with List C Option 7 - 5
Figure 7-2: Partial Sketch of CM3 Digital Meter Boards 7 - 8
Figure 8-1: Typical J85502C-1 125-ampere Rectifier
with Door Open and Diode Heat Sink Removed 8 - 14

Lucent Technologies Lineage®2000 125A Ferroresonant Rectifier J85502C-1
Issue 8 July 1999 - 1
List of Tables
Table 2-A: Digital Meter Accuracy 2 - 8
Table 2-B: Physical and Thermal Specifications of the
J85502C-1 Rectifier 2 - 11
Table 2-C: Input Specifications for the J85502C-1
Rectifier 2 - 11
Table 2-D: Output Specifications for the J85502C-1
Rectifier 2 - 12
Table 3-A: Equipment Lists for the J85502C-1 Rectifier 3 - 1
Table 3-B: Document References 3 - 2
Table 5-A: AC Input Requirements 5 - 3
Table 5-B: DC Output Requirements 5 - 4
Table 5-C: Rectifier Control Settings for Initial Battery
Charge 5 - 16
Table 6-A: Rectifier Control Settings for Testing Off Line 6 - 4
Table 6-B: Test Set Connections 6 - 6
Table 6-C: Rectifier Control Settings Prior to Testing
On Line 6 - 15
Table 6-D: Controls for Meter Calibration Test On Line 6 - 21
Table 7-A: Troubleshooting 7 - 3
Table 7-B: Digital Meter Tolerance 7 - 9
Table 7-C: Control Settings Prior to Restoring Rectifier
to Service 7 - 12
Table 8-A: Spare Circuit Modules 8 - 2
Table 8-B: Modifications for the CM1 Option Board 8 - 4
Table 8-C: Spare Fuse Information 8 - 5

Lucent Technologies Lineage®2000 125A Ferroresonant Rectifier J85502C-1
2 - Issue 8 July 1999
Table 8-D: Torque and Minimum Yield Strength
for Mechanical Connections (Using Hex Head
Cap Screws) 8 - 11
Table 8-E: Minimum Torque for all Electrical
Connections 8 - 12

Lucent Technologies Lineage®2000 125A Ferroresonant Rectifier J85502C-1
Issue 8 July 1999 Introduction 1 - 1
1 Introduction
General
Information This product manual (Select Code 169-790-121) describes the
J85502C-1 125-ampere rectifier. The J85502C-1 rectifier
converts commercial 208 or 240 volts ac input power at 60 Hz
into highly regulated and filtered, low-noise, ±24 or –48-volt dc
output power for telecommunications equipment loads. Since
central offices usually obtain their electrical power from
potentially noisy commercial ac lines (and emergency
generators during commercial power failures), and since high
qualitydc power is required inorderforthe equipment to operate
correctly, the J85502C-1 rectifier is an excellent choice for any
telecommunications battery plant.
The J85502C-1 rectifier can be used with a Lineage® 2000
battery plant, older vintage Lucent Technologies battery plants,
or any commercialbattery plant. With certain options, itcan also
operate off battery.
Customer
Training Lucent Technologies offers customer training on many Power
Systems products. For information call 1-972-284-2163. This
numberis answeredfrom8:00a.m.until 4:30p.m.,CentralTime
Zone (Zone 6), Monday through Friday.
Customer
Service Forcustomers in the United States, Canada, Puerto Rico, and the
US Virgin Islands, call 1-800-THE-1PWR (1-800-843-1797).
Services provided through this contact include initiating the
spare parts procurement process for out of service emergencies,
ordering Lucent Technologies documents, and providing other
product and service information.

Lucent Technologies Lineage®2000 125A Ferroresonant Rectifier J85502C-1
1 - 2 Introduction Issue 8 July 1999
For other customers worldwide, call 001-972-840-0382. This
numberis answeredfrom8:00a.m.until 4:30p.m.,CentralTime
Zone (Zone 6), Monday through Friday.
Technical
Support Technical support for Lucent Technologies customers is
available around the world during the normal product warranty
period and also while specific contractual agreements extend
this service.
For customers in the United States, Canada, Puerto Rico, and the
US Virgin Islands, call 1-800-CAL-RTAC (1-800-225-7822) to
contact a product specialist to answer your technical questions
and assist in troubleshooting problems.
For other customers worldwide, contact your local field support
center or your sales representative to discuss your specific needs.
Product Repair
and Return Repair and return service is provided for Lucent Technologies
customers around the world.
For customers in the United States, Canada, Puerto Rico, and
the US Virgin Islands, call 1-800-255-1402 for information on
returning of products for repair.
For other customers worldwide, contact your sales
representative to discuss your particular circumstances.
Warranty
Service For warranty service worldwide, contact your Warranty Service
Manager (WSM). The WSM serves specific customer-groups,
who have taken ownership of the product. For product
conformance issues prior to customer ownership, contact your
local customer service.
On-Line Power
Systems Product
Manuals
For Lucent Technologies users logging in from inside the
corporate firewall, the address of the “Power Systems On-Line
Product Manuals” page is
http://www.cic.lucent.com/lineage.html.
For customers logging in from outside the firewall, the address is
http://www.lucent8.com/lineage.html. The annual subscription
fee for access to this siteis $25. To obtaina password,follow the
instructions on-line or call 1-888-Lucent8 (1-888-582-3688).

Lucent Technologies Lineage®2000 125A Ferroresonant Rectifier J85502C-1
Issue 8 July 1999 Introduction 1 - 3
When prompted for an order number, enter or say
“167-790-010.”

Lucent Technologies Lineage®2000 125A Ferroresonant Rectifier J85502C-1
Issue 8 July 1999 Product Description 2 - 1
2 Product Description
Overview In most telecommunications applications, the output of the
rectifier system is electrically connected in parallel with the
batteries. The rectifiers provide both the power to the telephone
equipment through the plant distribution and the charging and
float current to the batteries. In the event of commercial power
failure, the batteries supply the required dc power to the
telephone equipment. This transition needs no switching
because of the parallel connection of the rectifiers and batteries.
The rectifier provides alarms and accepts control signals from an
external source. It is Underwriters Laboratory (UL) listed and
Canadian Standards Association (CSA) certified. The rectifier
uses controlled ferroresonant technology, which reduces noise
and transients from commercial lines.
All components in the rectifier meet Lucent Technologies’ strict
specifications and reliability standards. The rectifier uses an
extremely efficient free-convection cooling system that keeps
components operating at temperatures well below the
recommended maximum, resulting in high reliability.
Allcircuitsforpower control,alarms,voltage regulation, current
limiting, restart, plant interface, and remote monitoring/control
are mounted on replaceable circuit modules. Front access to the
circuit modules simplifies replacement or adjustment, if
required. Standardized modules simplify parts inventory,
resulting in lower costs and better equipment availability.
The rectifier can be used in a plant with or without batteries and
with orwithout a controller. One each of twoinput voltages, two
output voltages, and either negative or positive polarity may be
ordered. Optional noise filtering can be added. Each option

Lucent Technologies Lineage®2000 125A Ferroresonant Rectifier J85502C-1
2 - 2 Product Description Issue 8 July 1999
requires different equipment which Lucent Technologies has
organized into numbered lists to simplify ordering.
Ferroresonant
Technology The J85502C-1 rectifier isa member of the Lucent Technologies
family of Lineage®2000 rectifiers. Like all the rectifiers in the
family, it represents a significant advancement in efficiency,
space savings, and serviceability. The rectifier uses the
electronically controlled, closed-loop, ferroresonant technology
developed by Lucent Technologies Bell Laboratories. This
technology provides excellent output regulation in spite of
variations in the incoming commercial line voltage and
frequency, and the outgoing current or “load.”
Ferroresonant technology and the rectifier’s physical design
features combine to provide reliable service, easy maintenance,
and greater cost-effectiveness on a dollars-per-output-ampere
basis.
Ferroresonant technology also:
• Eliminates internal switching transients typically associated
with other technologies.
• Reduces noise and transients from commercial lines. As the
interface between commercial power and telephone
equipment, the ferroresonant rectifier significantly
attenuates noise and lightning surges from commercial
lines.
• Introduces far less noise into closely coupled telephone
lines due to lower harmonic components in the input current
waveshape compared to other technologies.
• Provides highly efficient power conversion.
Standard
Features The J85502C-1,125-ampere rectifier has the following standard
features.
•Output current “walk-in”: This circuit controls the time
required for the rectifier to reach its rated output voltage
after it is turned on. Initially, the output voltage is about 80
percent of normal, and gradually increases to the required
value in approximately 10 seconds. As the output voltage
“walks in,” so does output current. This feature minimizes

Lucent Technologies Lineage®2000 125A Ferroresonant Rectifier J85502C-1
Issue 8 July 1999 Product Description 2 - 3
the starting surge on the customer’s power source and is
especially important with amore limited power source, such
as an emergency generator set.
•Internal selective high voltage shutdown: If the rectifier
voltage goes too high, and it is delivering at least 10 percent
of its rated output current, the rectifier shuts down. If the
rectifier is connected to a Lineage®2000 controller, this
feature is deactivated and the controller furnishes the
external selective high voltage shutdown (HVSD).
•External Selective high voltage shutdown: If the battery
voltage goes too high, the Lineage®2000 controllers signal
all of the connected rectifiers. This signal causes the
rectifier(s) delivering at least 10 percent of rated output
current to shut down. The remaining rectifiers continue
operating. Straps on the CM1 option board must be set for
List WB. See Table 8-B.
•Backup high voltage shutdown: This circuit prevents
damage to the rectifier in the event of high battery voltage.
Each rectifier senses its own output voltage and when this
voltage exceeds a preset value, it shuts down. This circuit
operates if the external selective HVSD fails to operate.
This backup HVSD operates from an independent voltage
source per Bellcore standards.
•Voltage monitor circuit module: This circuit monitors the
± 5 and ± 12 biased dc supply voltages on the 205A1
control board. The circuit shuts down the rectifier and issues
an RFA alarm when these voltages fall below acceptable
levels.
•Output current limit: The rectifier provides a constant
output voltage up to its rated output current, at which point
it provides constant current. When the output current tends
to increase above the rated output, the current limit circuit
overrides the voltage regulating signal and limits the output
current of the rectifier.
•Back-up current limit: In addition to the output current
limit, the ferroresonant transformers self-limit current
output between 125-175 percent of full load, or 156-219
amperes.

Lucent Technologies Lineage®2000 125A Ferroresonant Rectifier J85502C-1
2 - 4 Product Description Issue 8 July 1999
•Isolated output current indication: When used with a
Microprocessor Controlled System controller, the rectifier
provides an isolated 2- to 10-volt signal, corresponding to a
range of no-load to 125 percent of rated output load, which
is used to indicate the rectifier drain on the controller.
•Safety interlocks: A series-loop circuit electrically
interconnects the control circuit modules and prevents
rectifier operation if an open circuit is detected.
•Fuse alarm circuit: The low-power control functions shut
the rectifier down if a fuse alarm (FA) occurs. One fuse
alarm protects each of the regulation leads. When any FA
occurs, a Rectifier Failure Alarm (RFA) LED lights on the
front panel and an RFA signal is generated. The FA LED
also lights.
•Man alarm: This alarm indicates that either the rectifier
has been turned off manually or has lost commercial input
power.
•Restart circuit: The rectifier has an automatic restart
feature that is compatible with the Lineage®2000
controllers and most other controllers. If a rectifier shuts
down due to the external selective HVSD, most controllers
try at least once to restart it automatically.
•Remote sense leads: These leads permit remote regulation
of the rectifier if it is installed with a compatible controller
and straps on CM1 option board are set for List WA. See
Table 8-B.
•TR: This signal remotely shuts down the rectifier.
•AC voltage monitor circuit: This circuit monitors the ac
input voltage and shuts the rectifier down if the ac goes
below the following voltages:
Input Low
208 170
240 195
•LOA: The limited output alarm (LOA) signals a controller
that the rectifier has lost input voltage.
