Lumex RJ4200A Installation guide

LIFETIME LIMITED WARRANTY
Quality is the hallmark of all Lumex®products.
Trusted by healthcare professionals and end-users
for over 50 years, Lumex features a full line of
patient aids and specialty healthcare seating.
Lumex products are designed and built to precise
standards and are carefully inspected prior to shipment.
We are dedicated to providing products that will give
our customers years of dependable service.
This Lumex product is warranted to be free of defects in
materials and workmanship for the lifetime of the original
consumer purchaser.
This warranty does not cover product failures due to
normal wear and tear or device misuse. The warranty
does not extend to non-durable components, such as
rubber accessories, which aresubject to normal wear
and require periodic replacement.
Should a product defect that is covered by this warranty
arise, we will, at our option, repair or replace the product.
For additional information on this Lumex product or this warranty,
please contact an authorized Graham-Field Health Products Dealer.
All illustrations and specifications in this manual are based on the latest product information available
at the time of publication. Graham-Field reserves the right to make changes at anytime, without notice.
©2005, Graham-Field Health Products, 2935 Northeast Parkway, Atlanta, Georgia 30360.
Printed in China. Doc Number: RJ4200A 03/04
INSTRUCTIONS
&WARRANTY
INFORMATION
Deluxe Four Wheeled Rollator
RJ4200A
IMPORTANT: READ BEFORE USE
RJ4200A-HangTag2 1/13/06 11:46 AM Page 1

INSTRUCTIONS FOR USE –
PLEASE READ ALL INSTRUCTIONS BEFORE USE.
Please consult a healthcare professional for the proper adjustment.
SAFETY GUIDELINES –
PLEASE READ BEFORE USE
1. This product should not be used without proper
instruction from a healthcare professional.
2. This product has a maximum user weight limitation of 500 lb.
3. Graham-Field Health Products assumes no responsibility for
any damage or injury caused by improper installation,
assembly or use of this product.
4. If components are damaged or missing, contact your
dealer immediately. DO NOT use substitute parts.
5. Before use, ensure that all assembled parts are secure
and all hardware is tightened.
6. Always use caution when using this product on wet
or slippery surfaces. Do not use Rollator on stairs or
steep inclines.
7. Inspect Rollator weekly for proper function and wear.
If any component is not in proper working order or
appears worn, contact your Graham-Field Health Products
dealer for repair and/or appropriate replacement parts.
8. Assemble Rollator as instructed to ensure safe use.
9. If the hand brakes fail to stop the Rollator, contact
your Graham-Field Health Products dealer immediately
for adjustment.
HEIGHT ADJUSTMENT
1. Remove Rollator from case.
2. Cut plastic ties to remove basket.
3. Unfold frame; spread front and back legs apart.
4. Flip down black locking mechanism to secure back legs.
Ensure that black locking mechanism is resting firmly on back crossbar.
5. Remove the gray plastic end caps from the frame and discard them.
6. Insert chrome tube sections of left and right handle bars into their
respective vertical frame sections.
7. Adjust handle bars to user’s height. DO NOT extend the handle bars
beyond the security mark. Tighten adjustment knobs on both vertical
frame sections until handle bars are secure.
OPERATION
HAND BRAKE: Squeeze hand brakes to stop; release hand brakes to walk.
Ensure that both hand brakes are squeezed at the same time to ensure proper
braking. If only one hand brake is squeezed, only one wheel will brake.
TO LOCK: Push hand brakes down to lock. Ensure that both left and right hand
brakes are locked. Always lock hand brakes when user is immobile; never sit on
rest seat if hand brakes are not locked.
TO UNLOCK: Lift hand brakes up to unlock.
FOLDING ROLLATOR: Remove any attached accessories, such as the
wire shopping basket and food tray. Flip up black locking mechanism.
Press legs together.
ATTACH ACCESSORIES
SHOPPING BASKET: Attach wire shopping basket hooks to front side of
Rollator top crossbar on both sides of rest seat
FOOD TRAY: Place food tray on rest seat; ensure that food tray is firmly seated.
Carry Basket
Detachable
WireBasket
Handgrip
Locking
Hand Brake
8" Wheel
Hand Bar
(Vertical Frame Section)
Rest Seat
Detachable (Clear
Plastic Food Tray)
Handle Bar(Chrome
Tube Section)
Adjustment
Knob
Rear Leg
Black Locking
Mechanism
Back Crossbar
MAINTENANCE
• For dust and dirt, wipe Rollator gently with damp, softy cloth.
• Use a mild soap and water solution to clean, rinse with clear water,
then dry with a soft cloth.
• Never use organic solvents, abrasive cleaners or scouring pads on
any part of Rollator or food tray
• Check fit and tightness of all nuts, bolts and knobs weekly to ensure
that Rollator is safe to use.
• To guarantee the best service from your Rollator, always specify
Lumex replacement parts, available from your Lumex dealer.
