LYSON W20970 OP R User manual

INSTRUCTIONS MANUAL
Manual Wax Extruder
Przedsiębiorstwo Pszczelarskie Tomasz Łysoń
Spółka z o.o. Spółka Komandytowa
34-125 Sułkowice, ul. Racławicka 162, Polska
www.lyson.com.pl, email; [email protected]
tel. [phone]
Headquarters: Klecza Dolna 148, 34-124 Klecza Górna

The manual covers following devices (codes):
W20970_OP_R
Table of contents
1. General safety instructions
1.1. Intended use
1.2. Operation safety
2. Instructions for use
2.1. General instructions – preparation for use
3. Product description
3.1.Technical specifications
4. Storage
5. Maintenance and cleaning
6. Warranty

1. General safety instructions
Before first use read the manual carefully and follow the
instructions contained therein. The manufacturer is not liable
for damage caused by equipment used inappropriately or by
incorrect handling.
1.1. Intended use
1. The device’s purpose is to extrude any remaining
honey from wax cappings
2. Before use the device must be thoroughly cleaned
using detergents allowed in food industry using a soft
cloth. After cleaning rinse the device and allow it to dry
thoroughly
1.2. Bezpieczeństwo użytkowania
a) Set the device on a surface that allows full stability!
b) Do not put your hands or fingers into the feeding funnel
while turning the crank
c) The device is not intended for use by persons (including
children) with limited physical, sensory or mental abilities,
or by inexperienced users, unless under supervision or
with instructions given by an accountable party. This
device is not a toy, and shouldn’t be used as one. Children
should not to play with it.
2. Instructions for use
The machine is designed to separate honey and to
mechanically compress the wax cappings. This process takes
place inside a perforated cylinder, where a rotating press-
screw module presses the honey out, which then escapes
through the perforations into the container placed underneath.
The remaining wax is moved and pressed by the screw and is
then pushed out and into a separate container. The wax is now
ready to be melted.
IMPORTANT !!!
When filling up make an extra care should be taken
to ensure that no hard objects (stones, metal) get
into the extruder which could damage the perforated
cylinder.
2.1. General instructions – preparation for use
An additional technical check should be carried out before the
start of the pollen harvesting season, and if any defects are
found, please contact the manufacturer.
Clean and dry thoroughly before use.
3. Product description:
1. Manual drive system
2. Powder coated steel frame
3. Stainless steel feeder funnel
4. Press screw
5. Honey container
Fig.1
1 2 3 4 5
3.1. Technical specifications
•Acid resistant stainless steel body
•Powder coated steel frame
•Poliamide PA6 press-screw
•length - 900mm.
•width - 700mm.
•height - 1100mm.
•weight – 34 kg.
4. Storage
Clean and dry the unit thoroughly after use.
An additional technical check should be carried out
periodically, and if any defects are found, please contact the
manufacturer.

5. Cleaning and maintenance
IMPORTANT!
Before first use the equipment must be thoroughly cleaned and
dried.
Clean with hot water using detergents allowed in food industry
using a soft cloth.
After cleaning rinse the device and allow it to dry thoroughly.
Store the device in a dry room.
Do not use any chemical agents to protect the devices
elements.
In order to thoroughly wash the extruder after the end of the
season, it is recommended to remove the perforated element
together with the funnel. To do this, unscrew the four screws
fixing this element’s flange to the frame.
Mounting screws (4 pcs)
6. Warranty
The product purchased from the Lyson Company is covered by
a manufacturer's warranty. The warranty period is 24 months
from the date of purchase.
All purchased products come with receipts or VAT invoices.
Warranty details at:
www.lyson.com.pl
