M-Elec ML-2820 User manual

RF wireless wall mounted 240V RGB/W controller
Parameter
ML-2820
Product Size
Installation
Button introduction
Part No. Iuput Voltage Remarks
Current
ML-1009FAWi 12-36VDC Constant voltage
4x(60-180)W
4x5A
Output
Remote
Part No. Operation Voltage DIMENSIONS
ø/h (mm)
Operation
Frequency
ML-2820 100-240VAC 120x75x29.1
434MHz
Receiver(purchased separately)
Remarks
Touch Sensor
Wiring diagram
1)Sender DiagramConnection
110V-230VAC N
L
1 zone
Save 3 Scenes
Sensitive Glass Touch Panel
Feature
RF Signal
White&black
North American Size
120.0
75.0
29.1
Color Wheel:
Touch to choose color
Brightness Color Running Button:
Short touch to start or Pause color
running mode;
Long touch to adjust speed (10 built-in
color running mode)
Warm white & Cold White &
Natural White, mixed by RGB
Switch: Short to switch on/offtouch
Save Color:
Long Touch S1/S2/S3 to save your
favorite colors
Short touch to choose the color R.G.B.W
Long touch to dim brightness of R.G.B.W
NC N
ML-2820
NLL
5

2)Receiver Connection Diagram for Single Unit
Operation
1. Do wiring according to connection diagram
2. Learning process
a.Wake up the panel by touching ON/OFF button.
b. Press at learning button on receiver.
c. Then touch color wheel.
d.Connected LED light will blink to confirm zone designation.
e . Press at learning button on receiver over 5 seconds until LED light flash, then delete the learned ID.
3.how to save color or mode
buttons can save the color from mode or save color when you touch color wheel or touch
buttons.
In " " button, it saved "R/ G/ B" 3 colors in default. But with your operation, you can save another 3
colors replace those R/G/B colors.
Press button ,mode runs, see favorite mode---> press or or button over 3 seconds until connected
light flashes. Then it saved successful ly.
Touch color wheel or touch color temperature button or touch any buttons----> see favorite color--->
press button over 3 seconds until connected light flashes. Then it saved successfully
How to recall color or mode?
Touch S1/S2/S3 directly. .
Power Supply
12-36VDC
LN
110V-230VAC
RGB/W or CDW LED strip
ML-10 09FAW i
Made i n China
PRI :
Uin =12- 36VDC
Iin =20. 5A
SEC :
Uou t=4x (12-3 6)VD C
Iou t=4x 5A
Pou t=4x (60-1 80)W
TEM P RANGE: -20℃-+5 0℃
12- 36VD C
W
Safety & Warnings
1) The product shall be installed and serviced by a qualified person.
2) IP20. Please avoid the sun and rain. When installed outdoors, please ensure it is mounted in a water proof
enclosure.
3) Always be sure to mount this unit in an area with proper ventilation to avoid overheating.
4) Please check if the output voltage of any LED power supplies used complies with the working voltage of the
product.
5) Never connect any cables while power is on and always assure correct connections to avoid short circuits
before switching on.
6) Please ensure that the cable is secured tightly to the connector.
7) For latest information please visit our website www.melec.com.au.
Warranty Agreement
1) We provide lifelong technical assistance with this product:
5 year warranty. Every product has printed date on, for example: 1125 means year 2011, week 25.The warranty
is for free repair or replacement and covers manufacturing faults only. For faults beyond the 5-year warranty we
reserve the right to charge for time and parts.
2) Warranty is void if:
Any defects are caused by wrong operation.
Any damages are caused by unauthorized removal, maintenance, modifying, incorrect connection and
replacement of components.
Any damages are due to transportation, vibration etc. after purchase.
Any damages are caused by earthquake, fire, lightning, pollution and abnormal voltage.
Any damages are caused by negligence, inappropriate storing at high temperatures and humidity or near
harmful chemicals.
Product has been updated or changed.
3) Repair or replacement as provided under this warranty is the exclusive remedy to the customer.
