M-system R3-RS8 User manual

R3-RS8
P. 1 / 3 EM-8365 Rev.3
BEFORE USE ....
Thank you for choosing M-System. Before use, please check
the contents of the package you received as outlined below.
If you have any problems or questions with the product,
please contact M-System’s Sales Office or representatives.
■ PACKAGE INCLUDES:
RTD input module ...................................................... (1)
■ MODEL NO.
Check that model No. described on the specification label is
exactly what you ordered.
■ INSTRUCTION MANUAL
This manual describes necessary points of caution when you
use this product, including installation, connection and basic
maintenance procedures.
INSTRUCTION MANUAL
MODEL R3-RS8
RTD INPUT MODULE
(8 points, isolated)
POINTS OF CAUTION
■ CONFORMITY WITH EC DIRECTIVES
• The equipment must be mounted inside the instrument
panel of a metal enclosure.
• The actual installation environments such as panel con-
figurations, connected devices and connected wires may
affect the protection level of this unit when it is integrated in
a panel system. The user may have to review the CE
requirements in regard to the whole system and employ
additional protective measures to ensure CE conformity.
■ HOT INSERTION/REMOVAL OF MODULES
Removing or replacing modules does not affect other modules
on the same backplane. It is possible to replace them without
removing the power supply. However, replacing multiple
modules at once may greatly change line voltage levels. We
recommend that you replace them one by one.
■ ENVIRONMENT
• Indoor use
• When heavy dust or metal particles are present in the air,
install the unit inside proper housing with sufficient ventila-
tion.
• Do not install the unit where it is subjected to continuous
vibration. Do not subject the unit to physical impact.
• Environmental temperature must be within -10 to +55°C
(14 to 131°F) with relative humidity within 30 to 90% RH in
order to ensure adequate life span and operation.
■ WIRING
• Do not install cables (power supply, input and output) close
to noise sources (relay drive cable, high frequency line, etc.).
• Do not bind these cables together with those in which noises
are present. Do not install them in the same duct.
■ AND ....
• The unit is designed to function as soon as power is
supplied, however, a warm up for 10 minutes is required for
satisfying complete performance described in the data sheet.
INSTALLATION
Use the Installation Base (model: R3-BSx).

R3-RS8
P. 2 / 3 EM-8365 Rev.3
COMPONENT IDENTIFICATION
■SIDE DIP SW
•RTD Type: SW1, SW2 (selectable per 4 channels)
SW3-1 BURNOUT
OFF Upscale (*)
ON Downscale
SW3-2 SW3-3 TEMP. UNIT
OFF OFF °C (*)
ON OFF °F
OFF ON
(Absolute Temp)
SW3-4 CONV. RATE
OFF 250 msec. (*)
ON 1 sec.
(*) Factory setting
SW2SW1
ON
1
2
3
4
5
6
7
8
ON
ON
1
2
3
4
5
6
7
8
SW3
1
2
3
4
5
19
20
21
22
15
16
17
18
23
24
25
26
27
28
6
7
8
9
10
11
12
13
14
1
2
3
4
■FRONT VIEW
ERR LED
RUN LED
■SIDE VIEW
Input 1-4 (SW1)
or
Input 5-8 (SW2)
RTD
Conv.
Rate
Temp.
Unit
Burnout
INPUT 1 through INPUT 4 (SW1)
INPUT 5 through INPUT 8 (SW2) RTD
1234
OFF OFF OFF OFF Pt 100 (*)
(JIS ’97, IEC)
ON OFF OFF OFF Pt 100
(JIS ’89)
OFF ON OFF OFF JPt 100
ON ON OFF OFF Pt 50Ω
OFF OFF ON OFF Ni 100
ON OFF ON OFF
Cu 10 (25°C)
OFF OFF OFF ON Cu 50
TERMINAL CONNECTIONS
Connect the unit as in the diagram below.
■ DIMENSIONS mm (inch)
TERMINAL
COVER
5
19
20
21
22
15
16
17
18
23
24
25
26
27
28
6
7
8
9
10
11
12
13
14
1
2
3
4
130 (5.12)
27.5 (1.08) 109 (4.29) POSITIONING
GUIDE
28–M3
SCREW
6.2
(.24)
■STATUS INDICATOR LED
RUN indicator: Bi-color (red/green) LED;
Red when the bus A operates normally;
Green when the bus B operates normally;
Amber when both buses operate normally.
ERR indicator: Bi-color (red/green) LED;
Red with burnout;
Green in normal operating conditions.
•Burnout: SW3
•Temperature Unit: SW3
•Conversion Rate: SW3

R3-RS8
P. 3 / 3 EM-8365 Rev.3
■ CONNECTION DIAGRAM
