M-system R7C-EC16B/UL User manual

EM-7801-K Rev.5 P. 1 / 7
INSTRUCTION MANUAL
PNP TRANSISTOR OUTPUT EXTENSION MODULE, 16 points
(CC-Link V.1.10) MODEL
R7C-EC16B
BEFORE USE ....
Thank you for choosing M-System. Before use, please check
contents of the package you received as outlined below.
If you have any problems or questions with the product,
please contact M-System’s Sales Office or representatives.
■PACKAGE INCLUDES:
Discrete output extension module......................................(1)
■MODEL NO.
Confirm Model No. marking on the product to be exactly
what you ordered.
■INSTRUCTION MANUAL
This manual describes necessary points of caution when
you use this product, including installation, connection and
basic maintenance procedures.
POINTS OF CAUTION
■NONINCENDIVE APPROVAL OPTION
• This equipment is suitable for use in Class I, Division 2,
Groups A, B, C, D or Non-Hazardous Locations only.
• WARNING! – Explosion Hazard –
Substitution of any component may impair suitability for
Class I, Division 2.
• WARNING! – Explosion Hazard –
DO NOT disconnect while the circuit is live or unless the
area is known to be free of ignitable concentrations.
• Temperature Code of this equipment is T5 and the Max-
imum Ambient Temperature is 55°C (Surrounding Tem-
perature inside the fire enclosure).
■CONFORMITY WITH UL APPROVAL
• This equipment is suitable for use in Installation Catego-
ry II and in a Pollution Degree 2 environment.
• Altitude up to 2000 meters.
• This equipment must be mounted inside a suitable fire
enclosure.
• This equipment is to be supplied by a Class 2 power sup-
ply.
■CONFORMITY WITH EU DIRECTIVES
• The equipment must be mounted inside the instrument
panel of a metal enclosure.
• The actual installation environments such as panel con-
figurations, connected devices, connected wires, may af-
fect the protection level of this unit when it is integrated
in a panel system. The user may have to review the CE
requirements in regard to the whole system and employ
additional protective measures to ensure the CE conform-
ity.
■POWER INPUT RATING & OPERATIONAL RANGE
• Locate the power input rating marked on the product and
confirm its operational range as indicated below:
24V DC rating: 24V ±10%, approx. 20mA
■GENERAL PRECAUTIONS
• Before you remove the unit or mount it, turn off the power
supply and output signal for safety.
■ENVIRONMENT
• Indoor use.
• When heavy dust or metal particles are present in the
air, install the unit inside proper housing with sufficient
ventilation.
• Do not install the unit where it is subjected to continuous
vibration. Do not subject the unit to physical impact.
• Environmental temperature must be within -10 to +55°C
(14 to 131°F) with relative humidity within 30 to 90% RH
in order to ensure adequate life span and operation.
■WIRING
• Do not install cables close to noise sources (relay drive
cable, high frequency line, etc.).
• Do not bind these cables together with those in which
noises are present. Do not install them in the same duct.
■AND ....
• The unit is designed to function as soon as power is sup-
plied, however, a warm up for 10 minutes is required for
satisfying complete performance described in the data
sheet.
056 222 38 18 [e-mail] www.sentronic.com
SENTRONIC AG

R7C-EC16B
EM-7801-K Rev.5 P. 2 / 7
COMPONENT IDENTIFICATION
0123456789ABCDEF
10 11 12 13
2341
15 16 17 18
7896
14
5
Discrete Output Status Indicator LED
Output Terminals
■DISCRETE OUTPUT STATUS INDICATOR LED
LED indicators show the signal status.
ON : LED ON
OFF : LED OFF
■OUTPUT TERMINAL ASSIGNMENT
10
+24V
11
Y1
12
Y3
1
0V
2
Y0
3
Y2
13
Y5
4
Y4
14
Y7
5
Y6
15
Y9
6
Y8
16
YB
7
YA
17
YD
8
YC
9
YE
18
YF
NO. ID FUNCTION NO. ID FUNCTION
1 0V 0V 10 +24V
24V DC (common)
2 Y0 Output 0 11 Y1 Output 1
3 Y2 Output 2 12 Y3 Output 3
4 Y4 Output 4 13 Y5 Output 5
5 Y6 Output 6 14 Y7 Output 7
6 Y8 Output 8 15 Y9 Output 9
7YA Output 10 16 YB Output 11
8 YC Output 12 17 YD Output 13
9 YE Output 14 18 YF Output 15
CONNECTING THE EXTENSION MODULE
1) Remove the extension connector cover located at the side
of the basic module.
2) Connect the extension module.
3) Mount the combined module on a DIN rail.
TERMINAL CONNECTIONS
Connect the unit as in the diagram below.
■EXTERNAL DIMENSIONS unit: mm (inch)
11.5
(.45)
10 11 12 13
2341
15 16 17 18
789 6
14
5
94 (3.70)
30 (1.18) [5 (.20)]
DIN RAIL
35mm wide
54 (2.13)
17 (.66)
18–M3 SCREW
TERMINALS
for OUTPUT
6 (.24)
3 (.12)5.5 (.22) 50 (1.97) 18.5 (.73)
056 222 38 18 [e-mail] www.sentronic.com
SENTRONIC AG

R7C-EC16B
EM-7801-K Rev.5 P. 3 / 7
■CONNECTION DIAGRAM
EXTENSION CONNECTOR
10
17
18
1
YD
16
YB
0V
YF
15
Y9
14
Y7
13
Y5
12
Y3
11
Y1
9YE
8YC
7YA
6Y8
5Y6
4Y4
3Y2
+24V
Y0
2
■
Output Connection Example
10
1
2
Y0
0V
+24V –
+
18
YF
WIRING INSTRUCTIONS
■SCREW TERMINAL
Torque: 0.5 N·m
■SOLDERLESS TERMINAL
Refer to the drawing below for recommended ring tongue
terminal size. Spade tongue type is also applicable.
Applicable wire size: 0.25 to 1.65 mm2(AWG 22 to 16)
Recommended manufacturer: Japan Solderless Terminal
MFG. Co., Ltd, Nichifu Co., Ltd
6 (.24) max
3.3 (.13) max
mm (inch)
056 222 38 18 [e-mail] www.sentronic.com
SENTRONIC AG

R7C-EC16B
EM-7801-K Rev.5 P. 4 / 7
CONFORMITY WITH CE MARKING
■CE MARKING
CE marking requires to integrate safety regulations existed in each country in EU territory and to secure smooth distribution
of products of which safety is guaranteed. It is mandatory by law that products distributed and sold in EU territory to have
CE mark which shows that the product conforms with the requirements of EU Directive. Each EU Directive describes the
scope of apparatuses to which that EU Directive is applied. M-System’s R7C must conform with EMC Directive.
Each Directive states only basic requirements. In order to mark the CE on an assembled machinery equipment, its manufac-
turer needs to check the overall conformity with Directives applicable to it.
■WARNINGS AND CAUTIONS WHEN INSTALLING THE R7C
The R7C needs to be installed in a control panel. This is effective not only to ensure general safety but also to contain noise
emissions by the R7C inside the control panel. We conduct a series of testing to see that the product conforms to EMC Direc-
tive while it is installed in the control panel.
Warning and cautions when installing R7C are stated below.
• Use control panels with an internal panel plate, both made of metal, when installing the R7C.
• Make sure to adequately ground the control panel and the internal panel plate with a thick cable to maintain low imped-
ance at high frequency.
• Use shielded cables for the signals taken out of the control panel.
• Choose a thick and short cable to ground the FG terminal of the R7C module to the internal panel plate of the control panel.
Note: If electromagnetic radiation disturbance increases by grounding the FG terminal, remove the grounding.
• When painting the internal plate of the control panel, apply masking to expose metal surface to secure conductivity at the
sections where the following parts are attached:
- Bolts attaching the internal panel to the control panel
- Ground for the FG of the R7C module
- Earth clamp on the shielded cable
• Noise emissions inside the control panel might leak through its openings. Design them as small as possible. Recommended
diameter is 10 cm or less.
Supplement:
Additional measures may be taken depending upon actual installation sites. These points of cautions are illustrated in the
next page.
• Prevent noise leakage by wrapping cables using shield covers, shield tubes and flexible conduits etc. if noise leaks through
the cable outlet.
• Use an electromagnetic shield gasket and block up the gap between the control panel cabinet and its cover, if noise leaks
through it.
• Connecting the internal panel plate and the cover of the control panel to the main cabinet using an earth strap may be
effective to strengthen the grounding.
• Electromagnetically shielded control panel cabinet is effective for shielding.
056 222 38 18 [e-mail] www.sentronic.com
SENTRONIC AG

R7C-EC16B
EM-7801-K Rev.5 P. 5 / 7
Use (e.g.) a shield cover
when noise leaks through
the opening.
To external apparatus
Keep the opening
for cabling as small as
possible.
Install an electromagnetically
shielded gasket when
noise leaks through
the opening. Shielding is strengthened
by using an electro-
magnetically shielded
control panel.
By connecting the
internal panel plate
and the panel cover with
an earth strap, grounding
may be strengthened and
EMC may be improved.
Ground the control panel
at low impedance using
(e.g.) braided wires.
Keep the opening for
ventilation as small as
posible.
Attach an electro-
magnetically shielded
filter when noise leaks
through the opening.
Install the R7C Series inside
a control panel.
Attachment part of earth
clamp should be fixed with
screw in conduction with the
internal panel plate.
• Points of cautions applicable when installing the R7C Series
056 222 38 18 [e-mail] www.sentronic.com
SENTRONIC AG

R7C-EC16B
EM-7801-K Rev.5 P. 6 / 7
■WARNINGS AND CAUTIONS WHEN LAYING CABLES
Signal cables connected to the R7C contain high-frequency components. Since these cables has the same effect as an anten-
na, they emit these high-frequency components to the external space as noise or overlaps noise from the external space on
themselves.
Cables with shielding should be used for the signal line due to the above reason.
EMC conformance test is conducted in the condition that shielded cables and earth clamps are used with the R7C.
Warning and cautions when laying cables are stated below. These points of cautions are illustrated in the next page.
• Use shielded cables for those signal cables installed out of the control panel and for thermocouple and RTD extension wires.
• All the network cables connected to R7C should be shielded.
• Use exclusively designed cables for the CC-Link.
• Expose the shield at a part of the cable cover, clip it with an earth clamp, and ground it to the internal panel of the control
panel. A drain wire connected to the panel in a pig-tail form cannot maintain low impedance against high-frequency noise,
thus grounding (noise shielding) in this form will not be effective.
Supplement:
Additional measures may be taken depending upon actual installation sites. These points of cautions are illustrated in the
next page.
• Keep cables as short as possible. It prevents noise emissions from the cables and noise overlapping to the cables.
• Attach a ferrite core to reduce noise impact to the signal cables susceptible to the noise. Ferrite core can be attached close
to the cable outlet of the control panel or close to the I/O terminal or connector, whichever is more effective. Also, the impact
might be reduced by winding the cable around the ferrite core for extra turns or attaching multiple ferrite cores.
• Keep cables which are easily affected by noise away from those which can be a noise source.
Motor Drive
Cable
Power Supply
Cable
DC Signal Cable
Network Cable
Analog Signal
Cable
Often being a noise source Often subject to noise interference.
In the following are examples of effective ways to lay cables separately:
• Keeping physical distance (farther than 20 cm from motor drive cables, farther than 10 cm for other groups).
• Dividing off by a grounded metal plate
• Grouping into separate grounded metal pipes or cable shields.
Wires on each side of a filter should not be too close to each other. Noise could ride onto the other side of cable.
Extra attention needs to be paid at the following parts.
• Noise filter that is enclosed in power cables.
• Ferrite core that is attached to signal cables.
• Noise limiting circuit (surge quenching circuit, transient absorber circuit, etc.) that is enclosed in signal cables.
056 222 38 18 [e-mail] www.sentronic.com
SENTRONIC AG

R7C-EC16B
EM-7801-K Rev.5 P. 7 / 7
Noise
Filter
Motor
Drive Cable Maintain distance between
cables and noise sources.
Grounding in pig tail form
is not effective.
• Points of cautions applicable when wiring the R7C Series
To external apparatus
Keep the cable as
short as possible.
To external apparatus
Shielded
Cable
Earth
Clamp
Remove a part of the shielded
cable cover and ground it
to the internal panel
plate using an earth
clamp.
To connect with
apparatuses outside
the control panel via
CC-Link, ground the
cable shield using
an earth clamp.
Keep the wires away from
each other at both ends of
the filter.
056 222 38 18 [e-mail] www.sentronic.com
SENTRONIC AG
