MadgeTech QuadRT User manual

QuadRTD and OctRTD
Red 485
Dark Blue Pantone 289
Light Blue 58% of Pantone 289
To view the full MadgeTech product line,
visit our website at www.madgetech.com.
Red 485
Dark Blue Pantone 289
Light Blue 58% of Pantone 289
Battery Warning
WARNING: FIRE, EXPLOSION, AND SEVERE BURN HAZARD. DO NOT SHORT CIRCUIT, CHARGE,
FORCE OVER DISCHARGE, DISASSEMBLE, CRUSH, PENETRATE OR INCINERATE. BATTERY MAY
LEAK OR EXPLODE IF HEATED ABOVE 60 °C (140 °F).
Specifications subject to change.
See MadgeTech’s terms and conditions at www.madgetech.com
MadgeTech, Inc.
6 Warner Road lWarner, NH 03278
Phone [phone] lFax 603.456.2012
www.madgetech.com l[email protected]
DOC-1005035-00 REV 12 08.07.2017
QuadRTD
4-Channel, 100 Ω RTD Based Temperature Data Logger
OctRTD
8-Channel, 100 Ω RTD Based Temperature Data Logger
Description QuadRTD OctRTD
Temperature Sensor External: 2, 3 or 4 wire 100 Ω platinum RTD
Temperature Range -200 °C to +850 °C (-328 °F to +1562 °F)
Temperature Resolution 0.01 °C (0.018 °F)
Calibrated Accuracy +0.1 °C
Memory 21,845/channel 10,922/channel
Reading Rate 1 reading every 2 seconds up to 1 reading every 12 hours
Channels 4 8
LED Indicator None
Required Interface Package IFC200
Baud Rate 2,400
Battery Type 9V lithium or alkaline battery included, user replaceable
Typical Battery Life 1 year
Operating Environment -20 °C to +60 °C (-4 °F to +140 °F),
0 %RH to 95 %RH (non–condensing)
Material Anodized aluminum
Weight 11.9 oz (335 g) 15.9 oz (450 g)
Dimensions 3.5 in x 4.4 in x 1.0 in
(89 mm x 112 mm x 26 mm)
3.5 in x 4.4 in x 1.5 in
(89 mm x 112 mm x 39 mm)
Product User Guide

Wiring the Data Logger
Wiring Options
For 4-wire RTD probes, connect the four lead wires to your RTD logger as shown in the
figures below.
For 3-wire RTD probes, short inputs 3
and 4 together, then connect the lead
wires to inputs 1, 2 and 3.
For 2-wire RTD probes, short inputs
3 and 4 together and inputs 1 and 2
together, then connect the RTD lead
wires to inputs 2 and 3.
Warning: Note the polarity instructions. Do not attach wires to the wrong terminals. 100 Ω, 2 or 4 wire RTD probes are
recommended for the most accurate performance. Most 100 Ω, 3 wire RTD probes will work, but MadgeTech cannot guarantee the
accuracy. To determine whether or not the 3-wire RTD probe will work, the resistance between the two same colored wires should be
less than 1 Ω. (Note: Please contact the manufacturer of the RTD probe for questions on the resistance)
Installation Guide
Installing the Interface cable
- IFC200
Insert the device into a USB port. The drivers will install automatically.
- USB-1 or USB-101
Install the USB drivers from the CD provided in the kit, then plug the USB cable into the
computer and the serial cable into the serial port.
Installing the software
The Software can be downloaded from the MadgeTech website at the following link: www.
madgetech.com/software-download. Follow the instructions provided in the Installation
Wizard.
Device Operation
Connecting and starting the data logger
- Once the software is installed and running, plug the interface cable into the data logger.
- Connect the USB end of the interface cable into an open USB port on the computer.
- The device will appear in the Connected Devices list, highlight the desired data logger.
- For most applications, select “Custom Start” from the menu bar and choose the desired
start method, reading rate and other parameters appropriate for the data logging
application and click “Start”. (“Quick Start” applies the most recent custom start options,
“Batch Start” is used for managing multiple loggers at once, “Real Time Start” stores the
QuadRTD and OctRTD Product User Guide
dataset as it records while connected to the logger.)
- The status of the device will change to “Running”, “Waiting to Start” or “Waiting to
Manual Start”, depending upon your start method.
- Disconnect the data logger from the interface cable and place it in the environment to
measure.
Note: The device will stop recording data when the end of memory is reached or the device is stopped. At this point the device
cannot be restarted until it has been re-armed by the computer.
Downloading data from a data logger
- Connect the logger to the interface cable.
- Highlight the data logger in the Connected Devices list. Click “Stop” on the menu bar.
- Once the data logger is stopped, with the logger highlighted, click “Download”. You will
be prompted to name your report.
- Downloading will offload and save all the recorded data to the PC.
Device Maintenance
Battery Replacement
Materials:
3/32” HEX Driver (Allen Key)
Replacement Battery (U9VL-J)
- Remove the cover from the device by unscrewing the four screws.
- Remove the battery from its compartment and unsnap it from the connector.
- Snap the new battery into the terminals and verify it is secure.
- Replace the cover taking care not to pinch the wires. Screw the enclosure back together
securely.
Note: Be sure not to over tighten the screws or strip the threads.
Recalibration
The QuadRTD or OctRTD standard calibration is at two points, 50 Ω and 15 0 Ω .
Additional Services:
Custom calibration and verification point options available, please call for pricing.
Call for custom calibration options to accommodate specific application needs.
Prices and specifications subject to change. See MadgeTech’s terms and conditions at www.madgetech.com
To send devices to MadgeTech for calibration, service or repair, please use the MadgeTech RMA Process by visiting
www.madgetech.com, then under the services tab, select RMA Process.
3-Red
4-Red or Short to 3
1-Black or Short to 2
2-Black
Connector for 100
Ohm PtRTD
Connector for interface cable
3
4
1
2
3
4
1
2
KEY
4- Excitation Current Out (+)
3- Measurement (+) Input
2- Measurement(-) Input
1- Ground (-)
