Mainstays MS18-D2-1011-08 User manual

THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2018-03-13 Rev. 0001-A Factory: CHEGRE
Arris 4 Shelf Tower Book Shelf
Stock # MS18-D2-1011-08
ADULT ASSEMBLY REQUIRED
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store
where it was purchased. Please call our customer service number and have your instructions and parts list
ready to provide the model name, part name or factory number:
866-942-5362
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or visit our web site 24 hours a day, 7 days a week for product assistance at
www.whalenstyle.com
Or e-mail your request to [e-mail]
LOT NUMBER:
DATE PURCHASED: / /

2
MANUFACTURER: Whalen Furniture Manufacturing
CATALOG: Arris 4 Shelf Tower Book Shelf
MODEL # MS18-D2-1011-08
MADE IN CHINA
1. Please read the Assembly Instructions prior to assembling the unit.
2. To avoid damage, assemble the unit on a sturdy, level and non-abrasive surface.
3. Keep all hardware part out of reach of children.
4. Please wait until all steps are completed before tightening bolts.
5. Make sure all bolts are tightly fastened before the unit is used.
M A X I M U M R E C O M M E N D E D W E I G H T L O A D S
MAXIMUM LOAD 50 lb. (22.7 kg)
THIS UNIT IS INTENDED ONLY FOR USE WITHIN THE
MAXIMUM WEIGHTS INDICATED. USE WITH HEAVIER THAN THE MAXIMUM
WEIGHTS INDICATED MAY RESULT IN INSTABILITY CAUSING POSSIBLE INJURY.
G E N E R A L I N F O R M A T I O N , T I P S
A N D
T R I C K S

3
Parts and Hardware List
Please read completely through the instructions and verify that all listed parts and hardware are present
before beginning assembly.
A- Side Frame (Qty. 2) B- Top Shelf (Qty. 1)
E- Lower Middle Shelf (Qty. 1) F- Bottom Shelf (Qty. 1)
(1) 1” Bolt (Qty. 16+1 extra) (2) 1-3/4” Bolt (Qty. 4+1 extra)
(3) Lock Washer (Qty. 4+1 extra) (4) Flat Washer (Qty. 4+1 extra)
Hex Wrench (Qty. 1) Touch-up Pen (Qty. 1) Tipping Restraint Hardware Kit (Qty.1)
(Inside Plastic Bag)
Tools required: Hex wrench (provided) and Phillips screwdriver (not provided).
C- Upper Middle Shelf (Qty. 1) D- Middle Shelf (Qty. 1)

4
Assembly Instructions
NOTE: Please do not fully tighten all bolts until you finish assembling all parts. Once assembled, go back
and fully tighten all bolts. This will make the assembly easier.
1. Unpack the unit and confirm that you have all the hardware and required parts.
2. Locate one Side Frame (A) on a level and protected surface with the threaded holes facing up.
3. Attached Top Shelf (B) to the top rail of the Side Frame (A) with two 1-3/4” Bolts (2) and two Washers
(3 and 4).
4. Attach the Lower Shelves (C, D, E and F) to the Side Frame (A) with eight 1” Bolts (1).
Lock Washer
(2 used in this step)
③
Flat Washer
(2 used in this step)
④
C
D
E
F
A
F
1
A
2
3
4B
1” Bolt
(8 used in this step)
①
1-3/4” Bolt
(2 used in this step)
②

5
Assembly Instructions
5. Repeat the same procedure to attach the other Side Frame (A) at the opposite side.
A
B
C
D
E
F
A
F
1
2
3
4
B
A
Lock Washer
(2 used in this step)
③
Flat Washer
(2 used in this step)
④
1-3/4” Bolt
(2 used in this step)
②
1” Bolt
(8 used in this step)
①

6
Assembly Instructions
Tools required (not provided): Phillips screwdriver, stud finder, power drill and 3 mm/0.1 in drill bit.
6. Ask for assistance to lift the unit upright and position it at the desired location against a wall. If
necessary, adjust the pre-attached floor levelers at the bottom of the Side Frames (A) to level the unit.
7. Follow the instructions printed on the plastic bag containing the Tipping Restraint Hardware to attach
the tip-over restraints to the unit and the wall.
NOTE: The tipping restraint hardware included is for wooden stud wall construction. It must be
attached to a wall stud. Depending upon your wall construction, different anchor hardware maybe
required. Please contact your local hardware store for assistance. Young children can be seriously
injured by tipping furniture. You must install the Tipping Restraint Hardware with the unit to
prevent the unit from tipping, causing any accidents or damage. The tipping restraints are intended
only as a deterrent, they are not a substitute for proper adult supervision. The tipping restraints are
not earthquake restraints. If you wish to add the extra security of earthquake restraints, they must be
purchased and installed separately.
8. The book shelf is now ready for use.
A
A A

7
Care and Maintenance
 Use a soft, clean cloth that will not scratch the surface when dusting.
 Use of furniture polish is not necessary. Should you choose to use polish, test first in an inconspicuous area.
 Using solvents of any kind on your furniture may damage the finish.
 Never use water to clean your furniture as it may cause damage to the finish.
 Always use coasters under beverage glasses and flowerpots.
 Liquid spills should be removed immediately. Using a soft, clean cloth, blot the spill gently. Avoid rubbing.
 Always use protective pads under hot dishes and plates. Heat can cause chemical changes that may create
spotting within the furniture finish.
 In the event that your furniture is stained or otherwise damaged during use, we recommend that you call a
professional to repair your furniture.
 Check bolts/screws periodically and tighten them if necessary.
Further Advice about Furniture Care
It is best to keep your furniture in a climate-controlled environment. Extreme temperature and humidity
changes can cause fading, warping, shrinking and splitting of wood. It is advised to keep furniture away from
direct sunlight as sun may damage the finish.
Proper care and cleaning at home will extend the life of your purchase. Follow these important and helpful tips
that will enhance your furniture as it ages.
A touch-up pen has been provided to minimize the small nicks or scratches that may occur during
assembly or shipping.
We hope you enjoy your purchase for many years.
Thank you for your purchase!
QUALITY GUARANTEE
We are confident that you will be delighted with your Whalen Furniture purchase.
Should this product be defective in workmanship or materials or fail under normal use, we will repair
or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is
designed to meet your highest expectations. We guarantee that you will immediately see the value of
our fine furniture.
This warranty gives you specific legal rights and you may also have other rights which vary from
State to State.
Customer Service: 866-942-5362
8:30 a.m. - 4:30 p.m., PST, Monday to Friday
www.whalenstyle.com
