Makita 4114 Manual

Model No.
Description
PRODUCT
CONCEPT AND MAIN APPLICATIONS
P 1 / 6
Specification
Standard equipment
Optional accessories
Continuous Rating (W)
Voltage (V) Cycle (Hz) Input Output Max. Output (W)
120
No load speed: min.-1= rpm
Wheel size: mm (")
Clutch
Soft start
Socket wrench 17 ................................... 1 pc.
Model 4114
Diameter
Hole diameter
15 AC/ DC 1,650 800 3,000
Current (A)
Continuous Rating (W)
Voltage (V) Cycle (Hz) Input Output Max. Output (W)
110
Model 4114S
23 50 / 60 2,400 1,500 2,750
230 11 50 / 60 2,400*11,600 3,700
Current (A)
Dimensions: mm (")
Width (W)
Height (H)
Length (L) 673 (26-1/2)
240 (9-1/2)
329 (13)
Note: The standard equipment for the tool shown above may differ by country.
3,500
355 (14)
Yes
(SJS - Super Joint System)
No
25.4 (1)
Thickness 2.6 (1/8)
Specifications Model 4114
Protection against electric shock Double insulation
Cord length: m (ft) 2.5 (8.2)
Net weight*2: kg (lbs) 10.8 (23.8)
Yes
4114S
10.9 (24.0)
*2: Without wheel and cord
*1: Switzerland =2,300W, Brazil (127V)=1,900W
Assorted diamond wheels
Assorted abrasive cut off wheels
Base set
Elbow joint 32 (for connecting to vacuum cleaner)
Ring 20
4114, 4114S
Angle Cutter 355mm (14")
Model 4114S is the 355mm (14") version of the current
4112S 305mm (12") Angle cutter, having the following
same benefits as 4112S;
High torque delivered at low motor speed of 3,500rpm
"SJS - Super Joint System" that provides smooth
approach and long service life of gear section
Soft start to minimize startup shock
Model 4114 features the same benefits as 4112S except for
soft start function.
Model 4114 for North American countries feature AC/DC switch.
TECHNICAL INFORMATION

P 2 / 6
Repair
[2] LUBRICATION
Apply Makita grease N. No.1 to the following portions designated by black triangle to protect parts and product from
unusual abrasion.
Bearing extractor (Makita Part No.1R269), Retaining ring S and R pliers (Makita Part No.No.1R291),
Water pump pliers
[3] DISASSEMBLY/ASSEMBLY
[3] -1. Removing Base and Wheel Cover
Fig. 2 Fig. 3
[1] NECESSARY REPAIRING TOOLS
CAUTION: Remove the wheel from the machine for safety before repair/ maintenance !
1) Remove Base by unscrewing an M8x20 Wing bolt and two M6 Shoulder hex bolts. (Fig. 2)
2) Remove Pressure plate by unscrewing three M5x14 Hex bolts. (Fig. 3)
Pressure plate
Hex bolt M5x14
(3pcs)
Fig. 4
3) Remove two M8x20 Hex bolts. The Wheel cover section can now be removed. (Fig. 4)
Note: Be careful not to lose Plate B.
Shoulder hex bolt M6 (2pcs) Base
Spring washer 8
Flat washer 8
Wing bolt M8x20
Hex bolt M8x20 (2pcs)
Plate B
Fig.1
Gear room in Gear housing (Item No. 32): 40g
The grease protects the gear teeth of Spiral bevel gear 57.
The outer periphery of
Lock spring 24 (Item No. 26): 1g
The installed part of
Spindle complete (Item No. 17)
into Spiral gear 57: 1g
(Spiral bevel gear 57)

P 3 / 6
Repair
Fig. 5 Fig. 6
[3] -2. Disassembling/ Assembling Gear Section and SJS (Clutch) Mechanism
1) Apply Makita grease SG. No.0 to the spring when assembling Lock spring 24 to Spiral bevel gear 57.
2) Tilt and place Lock spring 24 on Spiral bevel gear 57. Press down the portion A (the highest portion) of the spring
using arbor press. While turning the gear counterclockwise, press down the portions B, C, D sequentially.
After one turn of of the gear, the top surface of the spring will be almost flat. Lock spring 24 can now be fit on
Spiral bevel gear 57 by pressing down the entire top surface of the spring. (Fig. 5)
3) Assemble Lock sleeve to Spiral bevel gear 57 by doing the same way as you did to install Lock spring 24. (Fig. 6)
4) Do the reverse of the disassembling steps.
ASSEMBLING
Lock spring 24
Spiral bevel
gear 57
Arbor press
Lock sleeve
[3] -3. Replacing Armature
1) Separate Base and Wheel cover. (Refer to [3] -1. of page 2.)
2) Remove Brush holder cap and Carbon brush. Separate the Gear housing section from Motor housing by unscrewing
four M5x40 Hex bolts.
3) Armature can now be removed from Gear housing by tapping the end surface of Gear housing with plastic hammer.
Ball bearing 6202DDW still remains in Gear housing in this step.
4) In order to remove Ball bearing 6202DDW;
Remove Retaining ring R-40 and Flat washer 30. Insert the removed Armature lightly into the ball bearing again.
While swaying the commutator end of the armature, pull out the ball bearing with the inserted armature. (Fig. 7)
5) Tighten four M5x40 Hex bolts to the recommended torque of 7.4 - 15Nm when fastening the Gear housing section to
Motor housing.
Fig. 7
Flat washer 30
Retaining ring R-40
Ball bearing 6202DDW
Ball bearing
6202DDW

P 4 / 6
Repair
Fig. 8 Fig. 9 Fig. 10
[3] -2. Disassembling/ Assembling Gear Section and SJS (Clutch) Mechanism
Retaining ring S-15
Flat washer 15
1) Remove the Gear section by unscrewing four M5x14 Hex bolts. (Fig. 8)
2) Remove Ball bearing 6000LLB using Ball bearing extractor (Makita Part No.1R269). (Fig. 9)
3) Remove Retaining ring S-15 using Retaining ring S and R pliers (Makita Part No.1R291). Flat washer 15 can now be
removed. (Fig. 10)
4) See Fig. 11. Remove Spindle by pressing down from the Spiral bevel gear installation side using arbor press and Round
bar for arbor: Use a Round bar of 14mm or smaller.
Important: Be careful not to damage the Labyrinth ring 25 (The component of Spindle complete) in this step.
5) Remove the assembly of Spiral bevel gear 57 and Lock sleeve from Bearing box. (Fig. 12)
Fig. 11 Fig. 12
6) While turning Lock sleeve clockwise with water pump pliers, Lock sleeve can be separated from Spiral bevel gear 57
by pulling the gear. (Fig. 13)
7) While turning Lock spring 24 clockwise with water pump pliers, Lock spring 24 can be separated from Spiral bevel
gear 57 by pulling the gear . (Fig. 14)
Important: Wrap Lock spring 24 with soft cloth or the like in order not to damage with the pliers.
Water pump pliers Water pump pliersLock sleeve
Fig. 13
Lock spring 24
Fig. 14
Soft cloth
Hex bolt M5x14 (4pcs)
Gear section
No.1R269
Ball bearing 6000LLB
No.1R291
Round bar for arbor
Spindle complete
Spiral bevel gear 57
Lock sleeve
Labyrinth ring 25
(The component of Spindle complete) Bearing box
Spiral bevel gear 57Spiral bevel gear 57
DISASSEMBLING

P 5 / 6
Circuit diagram
Wiring diagram
Color index of lead wires
Black
White
Orange
Purple
Route the following lead
wires through the hook:
* Field lead wire (black)
* Field lead wire (orange)
Route the following lead
wires through the hook:
* Field lead wire (black)
* Field lead wire (purple)
* Connecting lead wire
(orange) from Brush holder
[1] Wiring in Motor Housing for 4114 and 4114S
Insulated
receptacle
Noise
suppressor Insulated
connector
Insulated
connector
Switch
Field
Brush holder
(left) Brush holder
(right)
Brush holder
(left)
Brush holder
(right)
Power supply cord
Field lead wire (purple)
Field lead wire (orange)
Field lead wire (black)
Connecting lead wire (purple)
from Brush holder
Connecting lead wire (orange)
from Brush holder
Hook
Hook
4114
4114S
Insulated receptacle
Soft start
circuit Noise
suppressor
(If used.)
Insulated
connector
Insulated
connector
Switch
Field
Brush holder
(left) Brush holder
(right)
Line filter
(If used.)
Power supply cord
red or orange
white or blue
black or brown
black or brown
white
or blue

P 6 / 6
[3] Wiring in Handle for 4114S
Be sure to connect so that all slits
of the four Insulated receptacles
face the same direction as illustrated
below.
Insulated receptacle
(viewed from the wheel installation side)
Terminal of Switch
Terminal
Slit in Terminal
Insulator
Switch
Insulated receptacle
Connecting Insulated Receptacles
with Terminals of Switch
Fix the following lead wires
with this lead wire holder:
*2 Field lead wires (black)
*Lead wire of Soft start circuit (white)
*Lead wire of Soft start circuit (orange or red)
Rib
Pin
If Line filter is used,
guide two Field lead
wires (black) through it,
and put in this space.
Fix the following lead wires with this lead
wire holder, and put in this space:
*2 Field lead wires (purple, orange)
*2 Connecting lead wires (purple, orange)
from Brush holder
Put Soft start circuit
in this space.
Put Noise suppressor
in this space if used.
Switch
[Correct] [Wrong]
[2] Wiring in Handle for 4114
Switch
Fix the following lead wires
with this lead wire holder:
*2 Field lead wires (black)
*Lead wire of Soft start circuit (white)
*Lead wire of Soft start circuit (orange or red)
Do not put the lead wires
of Power supply cord on
this rib.
Avoid this pin to route
the lead wires of Power
supply cord.
Fix the following lead wires with this lead
wire holder, and put in this space:
*2 Field lead wires (purple, orange)
*2 Connecting lead wires (purple, orange)
from Brush holder
Put Noise suppressor
in this space if used.
Wiring diagram
