ECHNICAL INFORMATION
Current part New part NoteQ'ty
Item No. I/CQ'ty
Subject
For Models
Country
Description
Note
Implementation
Interchangeability(I/C)
T
Modifications on Tool Holder
HM0810, HM810B, HM0810T, HM0811, HM0821
All countries
Tool Holder Three Bond 1342
(on three spots)
Flat Washer 43
(color; gold, material; brass) O Ring 38 Barrel Complete
Where Flat Washer 43 Is Placed and Three Bond 1342 Is Applied
As illustrated below;
1) Flat Washer 43 (Part No.267203-1) has been added as illustrated below in order to
fasten Tool Holer on Barrel Complete straightly with further accuracy.
2) The adhesive, Three Bond 1342 has been added on three spots of the thread of Tool Holder
as illustrated below to prevent Tool Holder from loosening.
3) In accordance with the modifications of 1) and 2), Tool Holders / Tool Holder Assemblies
for repairing of the subject Models have been changed to Tool Holder Sets.
These Tool Holder Sets additionally include each one piece of Flat Washer 43 (Part No.267203-1)
and O ring 38 (Part No.213508-7), which might necessarily be replaced whenever Tool Holders
/ Tool Holder Assemblies are replaced in repairing.
See the column of Interchangeability for Part Nos. of Tool Holder Sets.
Three Bond 1342(50g)
045017-6A
Flat Washer 43
267203-1
Tool Holder
323790-1
Tool Holder
322594-8
Tool Holder Ass'y
125070-9
Tool Holder Ass'y
134716-6
Tool Holder Set
193005-8
Tool Holder Set
193003-2
Tool Holder Set
193004-0
Tool Holder Set
193010-5
Interchangeability mark ; means that the new part is substituted for the current.
HM0810: 093
HM0810B: 086
HM0810T: 081
HM0811: 095
HM0821: 090
HM0810, HM0811
HM0821
HM0810T: 032
HM0810B: 031
HM0810, HM0811,
HM0821: 500
HM0810: 034
HM0811: 036
HM0821: 034
For all Models
For all Models
HM0810T
HM0810B
1
1
1
1
1
1
1
1
1
0.1g
HM0810 : From serial No.405169E (May,1999)
HM0810B : From serial No.37902E (May,1999)
HM0810T : From serial No.57443E (May,1999)
HM0811 : Discontinued since Apr.,1989
HM0821 : Discontinued since June,1991
Note)
See the next page for "Service Manual for Tool Holders of Models HM0810/HM0810B/HM0810T" that we have
newly issued, taking these modifications into account.

1) How to Remove Tool Holder
(a) Hold the machine tightly with a vise as in Fig.(1).
(b) Insert a hex.wrench (size: 17mm between
the opposite sides) into the hex. socket of
Tool Holder, and loosen it with a pipe of
one meter long.
(Notes)
1.When the hex. socket of Tool Holder is broken,
use a pipe wrench to grip Tool Holder directly
and to loosen it.
2.When Tool Holder cannot be loosened,
heat it with a gasburner .
In case of damaging O Ring 38 and/or X Ring
at the time, sure to replace them with new ones.
pipe of
1m long
loosened
appropriate wood
to stabilize the machine
Vise
Hex.Wrench
(17mm between
the opposite sides)
17mm
Copper Plates
(Part No.1R041)
(Motor side
of machine)
Fig.(1)
(Illustrated is Model HM0810T.)
Service Manual for Tool Holders of Models HM0810/ HM0810B/ HM0810T
When re-securing Tool Holder in repairing, always take the steps of procedure as described below.
2) How to Fasten Tool Holder on Barrel Complete
(a) As illustrated in the former page, set Flat Washer 43 (Part No.267203-1) in place and apply adhesive
on the three spots on the thread of Tool Holder.
And then, secure Tool Holder by taking the reverse steps of procedure of Removing as described above.
(Notes)
1.Replace Flat washer 43 with new one in every repairing because the washer is pressed and deformed
every time Tool Holder is secured.
2.Although the recommendable adhesive is Three Bond 1342 (Part No.045017-6A),
you may also use any type of adhesive that is available for oily surface.
(b) Fasten Tool Holder on Barrel Complete with torque of
250Nm or over - that is, as in Fig.(2), give weight of 25kg
or over to the end of one meter pipe after securing Tool Holder
till the pipe comes to the horizontal position.
(c) How to Adjust the Position of Tool Holer;
HM0810 - to see Fig.(3);
Secure Tool Holder till the side plate of Tool Retainer comes
parallel with the side of square foot of Barrel Complete.
HM0810B - to see Fig.(4);
Secure Tool Holder till the end side of Bolt-type of Tool Retainer
comes parallel with the side of square foot of Barrel Complete.
HM0810T - to see Fig.(5);
Secure Tool Holder till two opposite sides of the hex. socket of
Tool Holder comes parallel with the two sides of square foot of
Barrel Complete as in the right illustration of Fig.(5).
At this time, Tool Holder should be secured till "Z" comes to "A"
as in the left illustration of Fig.(5).
However, when "Z" has already passed "A", sure to secure
Tool Holder till "Y" comes to "A".
25kg or over
1m
Fig.(2)
Fig.(5) Model HM0810T
Fig.(3) HM0810 Fig.(4) HM0810B
Tool Retainer
Tool Retainer
A
Y
Z
