Makita CL002G User manual

CL002G
EN Cordless Cleaner INSTRUCTION MANUAL 9
SL Brezžični čistilnik NAVODILA ZA UPORABO 18
SQ Pastruesi me bateri MANUALI I PËRDORIMIT 27
BG Акумулаторна
прахосмукачка РЪКОВОДСТВО ЗА ЕКСПЛОАТАЦИЯ 36
HR Bežični usisavač PRIRUČNIK S UPUTAMA 46
МК Безжична правосмукалка УПАТСТВО ЗА УПОТРЕБА 55
SR Бежични чистач УПУТСТВО ЗА УПОТРЕБУ 65
RO Aspirator cu acumulator MANUAL DE INSTRUCŢIUNI 75
UK Бездротовий пилосос ІНСТРУКЦІЯ З
ЕКСПЛУАТАЦІЇ 85
RU Аккумуляторный пылесос РУКОВОДСТВО ПО
ЭКСПЛУАТАЦИИ 95

2
Fig.1
3
11
2
Fig.2
1
2
Fig.3
4
1
3
2
2
1
Fig.4
3
2
1
Fig.5
Fig.6
1
2
Fig.7
1
23
Fig.8

3
1
Fig.9
Fig.10
Fig.11
Fig.12
1
Fig.13
1
2
Fig.14
Fig.15
1
23
Fig.16

4
1
Fig.17
Fig.18
Fig.19
Fig.20
1
Fig.21
3
2
1
Fig.22
1
2
Fig.23
Fig.24

5
1
Fig.25
3
2
1
Fig.26
1
2
Fig.27
1
2
Fig.28
1
2
3
Fig.29
Fig.30
1
Fig.31
2
1
Fig.32

6
1
Fig.33
1
2
Fig.34
1
2
Fig.35
1
2
Fig.36
Fig.37
Fig.38
Fig.39
1
Fig.40

7
1
Fig.41
1
Fig.42
1
Fig.43
3
4
1
2
5
Fig.44
23
1
4
Fig.45
2
1
Fig.46

8
2
1
Fig.47
1
2
Fig.48
1
2
3
Fig.49

9ENGLISH
ENGLISH (Original instructions)
WARNING
• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sen-
sory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruc-
tion concerning use of the appliance in a safe way and understand the hazards involved.
• Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children with-
out supervision.
• See the chapter “SPECIFICATIONS” for the type reference of the battery.
• See the section “Installing or removing battery cartridge” for how to remove or install the battery.
• When disposing the battery cartridge, remove it from the tool and dispose of it in a safe place. Follow your local
regulations relating to disposal of battery.
• If the tool is not used for a long period of time, the battery must be removed from the tool.
• Do not short the battery cartridge.
• See the chapter “MAINTENANCE” for the appropriate details of precautions during user maintenance.
SPECIFICATIONS
Model: CL002G
Capacity with dust bag 500 mL
with paper lter 330 mL
Continuous use
(with battery BL4025)
1 (Quiet mode) Approx. 80 min
2 (Normal speed mode) Approx. 40 min
3 (High speed mode) Approx. 25 min
4 (Max speed mode) Approx. 16 min
Overall length (with pipe, nozzle, and battery BL4025) 1,066 mm
Rated voltage D.C. 36 V - 40 V max
Net weight 1.8 - 2.4 kg
• Due to our continuing program of research and development, the specications herein are subject to change
without notice.
• Specications may di󰀨er from country to country.
• The weight does not include accessories but battery cartridge(s). The lightest and heaviest combination weight
of the appliance and battery cartridge(s) are shown in the table.
Applicable battery cartridge and charger
Battery cartridge BL4020* / BL4025* / BL4040* / BL4050F
* : Recommended battery
Charger DC40RA / DC40RB / DC40RC
• Some of the battery cartridges and chargers listed above may not be available depending on your region of
residence.
WARNING: Only use the battery cartridges and chargers listed above. Use of any other battery cartridges
and chargers may cause injury and/or re.
Symbols
The followings show the symbols which may be used
for the equipment. Be sure that you understand their
meaning before use.
Read the instruction manual.
A representative battery applicable to this
product.

10 ENGLISH
Ni-MH
Li-ion
Only for EU countries
Due to the presence of hazardous com-
ponents in the equipment, waste electrical
and electronic equipment, accumulators
and batteries may have a negative impact
on the environment and human health.
Do not dispose of electrical and electronic
appliances or batteries with household waste!
In accordance with the European Directive
on waste electrical and electronic equipment
and on accumulators and batteries and
waste accumulators and batteries, as well as
their adaptation to national law, waste elec-
trical equipment, batteries and accumulators
should be stored separately and delivered
to a separate collection point for municipal
waste, operating in accordance with the
regulations on environmental protection.
This is indicated by the symbol of the
crossed-out wheeled bin placed on the
equipment.
Intended use
The tool is intended for collecting dry dust.
SAFETY WARNINGS
Cordless cleaner safety warnings
WARNING: IMPORTANT! READ CAREFULLY
all safety warnings and all instructions BEFORE
USE. Failure to follow the warnings and instructions
may result in electric shock, re and/or serious injury.
1. Do not expose to rain. Store indoors.
2. Do not allow to be used as a toy. Close
attention is necessary when used by or near
children.
3. Use only as described in this manual. Use only
manufacturer's recommended attachments.
4. Do not use with damaged battery. If appliance
is not working as it should, has been dropped,
damaged, left outdoors, or dropped into water,
return it to a service center.
5. Do not handle appliance with wet hands.
6. Do not put any object into openings. Do not
use with any opening blocked; keep free of
dust, lint, hair, and anything that may reduce
air ow.
7. Keep hair, loose clothing, ngers, and all parts
of body away from openings and moving parts.
8.
Turn o󰀨 all controls before removing the battery.
9. Use extra care when cleaning on stairs.
10. Do not use to pick up ammable or combusti-
ble liquids, such as gasoline, or use in areas
where they may be present.
11. Use only the charger supplied by the manufac-
turer to recharge.
12.
Do not pick up anything that is burning or smok-
ing, such as cigarettes, matches, or hot ashes.
13. Do not use without dust bag and/or lters in
place.
14. Do not charge the battery outdoors.
15. Recharge only with the charger specied by
the manufacturer. A charger that is suitable for
one type of battery pack may create a risk of re
when used with another battery pack.
16. Use appliances only with specically desig-
nated battery packs. Use of any other battery
packs may create a risk of injury and re.
17. When (the) battery pack is not in use, keep
it away from other metal objects, like paper
clips, coins, keys, nails, screws or other small
metal objects, that can make a connection
from one terminal to another.
18. Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If con-
tact accidentally occurs, ush with water.
19. Do not use a battery pack or appliance that
is damaged or modied. Damaged or modied
batteries may exhibit unpredictable behaviour
resulting in re, explosion or risk of injury.
20. Do not expose a battery pack or appliance
to re or excessive temperature. Exposure
to re or temperature above 130 °C may cause
explosion.
21. Follow all charging instructions and do not
charge the battery pack or appliance outside
the temperature range specied in the instruc-
tions. Charging improperly or at temperatures
outside the specied range may damage the
battery and increase the risk of re.
SAVE THESE INSTRUCTIONS.
ADDITIONAL SAFETY RULES
This appliance is intended for household use.
1. Read this instruction manual and the charger
instruction manual carefully before use.
2. Do not pick up the following materials:
— Hot materials such as lit cigarettes or
spark/metal dust generated by grinding/
cutting metal
— Flammable materials such as gasoline,
thinner, benzine, kerosene or paint
— Explosive materials like nitroglycerin
— Ignitable materials such as Aluminum,
zinc, magnesium, titanium, phosphorus
or celluloid
— Wet dirt, water, oil or the like
— Hard pieces with sharp edges, such as
wood chips, metals, stones, glasses,
nails, pins or razors
— Powder to clot such as cement or toner
— Conductive dust such as metal or carbon
— Fine particle like concrete dust
Such action may cause re, injury and/or prop-
erty damage.
3. Stop operation immediately if you notice any-
thing abnormal.
4. If you drop or strike the cleaner, check it care-
fully for cracks or damage before operation.
5.
Do not bring close to stoves or other heat sources.
6. Do not block the intake hole or vent holes.
SAVE THESE INSTRUCTIONS.

11 ENGLISH
Important safety instructions for
battery cartridge
1. Before using battery cartridge, read all instruc-
tions and cautionary markings on (1) battery
charger, (2) battery, and (3) product using
battery.
2. Do not disassemble or tamper with the battery
cartridge. It may result in a re, excessive heat,
or explosion.
3. If operating time has become excessively
shorter, stop operating immediately. It may
result in a risk of overheating, possible burns
and even an explosion.
4. If electrolyte gets into your eyes, rinse them
out with clear water and seek medical atten-
tion right away. It may result in loss of your
eyesight.
5. Do not short the battery cartridge:
(1) Do not touch the terminals with any con-
ductive material.
(2) Avoid storing battery cartridge in a con-
tainer with other metal objects such as
nails, coins, etc.
(3) Do not expose battery cartridge to water
or rain.
A battery short can cause a large current
ow, overheating, possible burns and even a
breakdown.
6. Do not store and use the tool and battery car-
tridge in locations where the temperature may
reach or exceed 50 °C (122 °F).
7. Do not incinerate the battery cartridge even if
it is severely damaged or is completely worn
out. The battery cartridge can explode in a re.
8. Do not nail, cut, crush, throw, drop the battery
cartridge, or hit against a hard object to the
battery cartridge. Such conduct may result in a
re, excessive heat, or explosion.
9. Do not use a damaged battery.
10. The contained lithium-ion batteries are subject
to the Dangerous Goods Legislation require-
ments.
For commercial transports e.g. by third parties,
forwarding agents, special requirement on pack-
aging and labeling must be observed.
For preparation of the item being shipped, consult-
ing an expert for hazardous material is required.
Please also observe possibly more detailed
national regulations.
Tape or mask o󰀨 open contacts and pack up the
battery in such a manner that it cannot move
around in the packaging.
11. When disposing the battery cartridge, remove
it from the tool and dispose of it in a safe
place. Follow your local regulations relating to
disposal of battery.
12. Use the batteries only with the products
specied by Makita. Installing the batteries to
non-compliant products may result in a re, exces-
sive heat, explosion, or leak of electrolyte.
13. If the tool is not used for a long period of time,
the battery must be removed from the tool.
14. During and after use, the battery cartridge may
take on heat which can cause burns or low
temperature burns. Pay attention to the han-
dling of hot battery cartridges.
15. Do not touch the terminal of the tool imme-
diately after use as it may get hot enough to
cause burns.
16. Do not allow chips, dust, or soil stuck into the
terminals, holes, and grooves of the battery
cartridge. It may cause heating, catching re,
burst and malfunction of the tool or battery car-
tridge, resulting in burns or personal injury.
17. Unless the tool supports the use near
high-voltage electrical power lines, do not use
the battery cartridge near a high-voltage elec-
trical power lines. It may result in a malfunction
or breakdown of the tool or battery cartridge.
18. Keep the battery away from children.
SAVE THESE INSTRUCTIONS.
CAUTION: Only use genuine Makita batteries.
Use of non-genuine Makita batteries, or batteries that
have been altered, may result in the battery bursting
causing res, personal injury and damage. It will
also void the Makita warranty for the Makita tool and
charger.
Tips for maintaining maximum
battery life
1. Charge the battery cartridge before completely
discharged. Always stop tool operation and
charge the battery cartridge when you notice
less tool power.
2. Never recharge a fully charged battery car-
tridge. Overcharging shortens the battery
service life.
3. Charge the battery cartridge with room tem-
perature at 10 °C - 40 °C (50 °F - 104 °F). Let
a hot battery cartridge cool down before
charging it.
4. When not using the battery cartridge, remove
it from the tool or the charger.
5. Charge the battery cartridge if you do not use
it for a long period (more than six months).

12 ENGLISH
FUNCTIONAL
DESCRIPTION
CAUTION: Always be sure that the tool is
switched o󰀨 and the battery cartridge is removed
before adjusting or checking function on the tool.
CAUTION: Take care not to trap nger(s)
between cleaner and battery as shown in diagram
when loading battery. Trapping nger(s) may cause
injury.
► Fig.1
Installing or removing battery
cartridge
CAUTION: Always switch o󰀨 the tool before
installing or removing of the battery cartridge.
CAUTION: Hold the tool and the battery car-
tridge rmly when installing or removing battery
cartridge. Failure to hold the tool and the battery
cartridge rmly may cause them to slip o󰀨 your hands
and result in damage to the tool and battery cartridge
and a personal injury.
► Fig.2: 1. Red indicator 2. Button 3. Battery cartridge
To remove the battery cartridge, slide it from the tool
while sliding the button on the front of the cartridge.
To install the battery cartridge, align the tongue on the
battery cartridge with the groove in the housing and slip
it into place. Insert it all the way until it locks in place
with a little click. If you can see the red indicator as
shown in the gure, it is not locked completely.
CAUTION: Always install the battery cartridge
fully until the red indicator cannot be seen. If not,
it may accidentally fall out of the tool, causing injury to
you or someone around you.
CAUTION: Do not install the battery cartridge
forcibly. If the cartridge does not slide in easily, it is
not being inserted correctly.
Battery protection system
The tool is equipped with a tool/battery protection sys-
tem. This system automatically cuts o󰀨 power to the
motor to extend tool and battery life. The tool will auto-
matically stop during operation if the tool or battery is
placed under one of the following conditions.
Overloaded:
The tool/battery is operated in a manner that causes it
to draw an abnormally high current.
In this situation, turn the tool o󰀨 and stop the application
that caused the tool to become overloaded. Then turn
the tool on to restart.
If the tool does not start, the battery is overheated. In this
situation, let the battery cool before turning the tool on again.
Low battery voltage:
The remaining battery capacity is too low and the tool
will not operate. In this situation, remove and recharge
the battery.
Protections against other causes:
Protection system is also designed for other causes
that could damage the tool and allows the tool to stop
automatically. Take all the following steps to clear the
causes, when the tool has been brought to a temporary
halt or stop in operation.
1.
Turn the tool o󰀨, and then turn it on again to restart.
2. Charge the battery(ies) or replace it/them with
recharged battery(ies).
3. Let the tool and battery(ies) cool down.
If no improvement can be found by restoring protection
system, then contact your local Makita Service Center.
Indicating the remaining battery capacity
Press the check button on the battery cartridge to indi-
cate the remaining battery capacity. The indicator lamps
light up for a few seconds.
► Fig.3: 1. Indicator lamps 2. Check button
Indicator lamps Remaining
capacity
Lighted O󰀨 Blinking
75% to 100%
50% to 75%
25% to 50%
0% to 25%
Charge the
battery.
The battery
may have
malfunctioned.
NOTE: Depending on the conditions of use and the
ambient temperature, the indication may di󰀨er slightly
from the actual capacity.
NOTE: The rst (far left) indicator lamp will blink when
the battery protection system works.
Switch action
► Fig.4: 1. Suction power change button 2. ON/OFF button
To start the cleaner, simply push the ON/OFF button. To
switch o󰀨, push the ON/OFF button again.
You can change the suction power of the cleaner in
four steps by pushing the suction power change button.
Each push on this button repeats the Quiet/Normal/
High/Max mode in a cycle.
Level Indication Mode
1Quiet mode
2
Normal speed mode
3High speed mode
4Max speed mode

13 ENGLISH
NOTE: You can change the suction power before
turning on the cleaner.
NOTE: The cleaner starts the operation with the
same suction power as the last operation.
Lighting up the lamp
CAUTION: Do not look in the light or see the
source of light directly.
To turn on the lamp, push the suction power change
button. The lamp goes o󰀨 in approximately 10 seconds.
While the cleaner is running, the lamp turns on.
The lamp goes out approximately 10 seconds after
stopping operation.
NOTE: When the remaining battery capacity gets low,
the lamp starts blinking. The timing, at which the lamp
starts blinking depends on the temperature at work
place and the battery cartridge conditions.
► Fig.5: 1. Suction power change button 2. ON/OFF
button 3. Lamp
ASSEMBLY
CAUTION: Always be sure that the tool is
switched o󰀨 and the battery cartridge is removed
before carrying out any work on the tool.
Dust bag and paper lter
Install either dust bag or paper lter before using cleaner.
Use the dust stopper when installing either dust bag or paper lter.
Dust bag are usable many times repeatedly by cleaning it out.
Paper lter is a throw-away type. Throw away the entire
paper lter without emptying when it has become full.
NOTICE: To prevent dust from getting into the
motor:
• Make sure that the dust bag or paper lter is
installed before use.
• Insert the dust stopper together with the
dust bag or paper lter all the way into the
slots when installing them.
• Do not use a broken or ripped bag.
Otherwise the motor may be broken.
NOTICE: Do not fold the cardboard at its open-
ing when installing the paper lter.
NOTICE: Never throw away the dust stopper
because it needs to be used repeatedly whenever
either the dust bag or the paper lter is used.
NOTICE: The paper lter for the cleaner is an
important component for maintaining the tool
performance. Using other than the genuine paper
lter may cause smokes or ignition.
NOTE: When the dust bag or the paper lter is not
installed in the cleaner, the front cover does not close
completely.
► Fig.6
Installing dust bag
Use the dust stopper when installing dust bag. Be
careful not to take the upper side for the lower side by
mistake because they are di󰀨erent each other.
► Fig.7: 1. Upper side of dust stopper 2. Lower side of
dust stopper
1. Insert the protrusion of the dust bag into the lower
groove on the dust stopper as shown in the gure.
► Fig.8: 1. Dust stopper 2. Lower groove 3. Dust bag
There is no distinction between the upper and lower
sides of the dust bag. You may insert its protrusion of
either side into the lower groove of the dust stopper.
► Fig.9: 1. Lower groove
2. Overlap the frame of dust stopper with that of the
dust bag.
► Fig.10
3. Place the dust stopper and the dust bag together
into the cleaner cavity in the same direction of arrow on
the dust stopper. Insert them all the way into the slots in
the cleaner cavity.
► Fig.11
4.
Spread the cloth part of the dust bag inside the cleaner.
► Fig.12
5. Close the front cover completely.
► Fig.13: 1. Front cover
Installing the paper lter
Use the dust stopper also when installing paper lter.
Be careful not to take the upper side for the lower side
by mistake because they are di󰀨erent each other.
► Fig.14: 1. Upper side of dust stopper 2. Lower side
of dust stopper
1. Unfold the entrance of the paper lter before
setting it on the dust stopper.
► Fig.15
2. Insert the protrusion of the paper lter into the
lower groove on the dust stopper as shown in the gure.
► Fig.16:
1. Dust stopper 2. Lower groove 3. Paper lter
There is no distinction between the upper and lower
sides of the paper lter. You may insert its protrusion of
any side into the lower groove of the dust stopper.
► Fig.17: 1. Lower groove
3. Overlap the frame of dust stopper with that of the
paper lter.
► Fig.18
4. Place the dust stopper and the paper lter
together into the cleaner cavity in the same direction of
arrow on the dust stopper. Insert them all the way into
the slots in the cleaner cavity.
► Fig.19
5. Spread the container part of the paper lter inside
the cleaner.
► Fig.20
6. Close the front cover completely.
► Fig.21: 1. Front cover

14 ENGLISH
OPERATION
CAUTION: Do not move your face close to
the air vent when operating the cleaner. If foreign
objects are blown into eyes, it may result in personal
injury.
Installing and removing cleaner
attachments
CAUTION: After installing attachments, check
if they are securely installed. If the attachments are
installed imperfectly, they may come o󰀨 and cause
personal injury.
CAUTION: Be careful not to hit your hand on
the wall etc. when removing the attachments.
When using attachment with lock
function
To install attachment, insert it to the suction inlet of the
cleaner until it clicks. Make sure that the attachment is
locked.
► Fig.22: 1. Suction inlet 2. Attachment with lock
function 3. Hook
NOTICE: When installing the attachment with
lock function, be sure to align the release button
on the cleaner with the hook on the attachment. If
they are not aligned, the attachment will not be locked
and may come o󰀨 from the cleaner.
To remove, pull the attachment while pushing the
release button.
► Fig.23: 1. Release button 2. Attachment with lock
function
When using attachment without lock
function
NOTICE: To connect attachment without lock
function, twist and insert it securely into the suc-
tion inlet of the cleaner. To disconnect the attach-
ment, pull it away while twisting.
► Fig.24
Cleaning (Suction)
Nozzle
Attach the nozzle to clean o󰀨 tables, desks, furniture,
etc. The nozzle slips on easily.
► Fig.25: 1. Nozzle
Nozzle + Extension wand (Straight
pipe)
The extension wand ts in between the nozzle and the
cleaner itself. This arrangement is convenient for clean-
ing a oor in a standing position.
► Fig.26: 1. Cleaner body 2. Extension wand
3. Nozzle
Corner nozzle
Fit on the corner nozzle for cleaning corners and crev-
ices of a car or furniture.
► Fig.27: 1. Corner nozzle 2. Cleaner body
You can store the corner nozzle in the nozzle holder.
► Fig.28: 1. Nozzle holder 2. Corner nozzle
CAUTION: Be careful not to trap nger(s)
between the corner nozzle and the nozzle holder.
Trapping nger(s) may cause injury.
Corner nozzle + Extension wand
(Straight pipe)
In tight quarters where the cleaner itself cannot
squeeze in, or in high places hard to reach, use this
arrangement.
► Fig.29: 1. Corner nozzle 2. Extension wand
3. Cleaner body
Cleaning without nozzle
You can pick up powder and dust without nozzle.
► Fig.30
For picking up dust on a oor in a standing position, it is
convenient to attach the extension wand (straight pipe)
to the cleaner.
► Fig.31: 1. Extension wand (Straight pipe)
Disposing of dust
CAUTION: Empty the cleaner before it
becomes too full, or the suction force weakens.
CAUTION: When closing the front cover, be
careful not to pinch your ngers.
NOTICE: Never throw away the dust stopper
because it should be used whenever either the
dust bag or the paper lter is used.
NOTICE: When the dust bag/paper lter is not
inside of the cleaner, the front cover does not
close completely. Do not force to close the front
cover. It may result in deforming or breakage of
the tool.
NOTICE: When disposing of dust, also clean the
room for the dust bag/paper lter. The remaining
dust and dirt in the room may cause the sponge lter
to be clogged or the motor to be damaged.
1. Push the button to open the front cover. Opening
it until a click is heard allows a positive stop at that
position.
► Fig.32: 1. Front cover 2. Button
2. Pull out both the orange-colored dust stopper and
dust bag/paper lter together at the same time.
► Fig.33: 1. Dust stopper

15 ENGLISH
3. Perform the procedures below depending on the
dust container type:
When using the dust bag
Remove the dust stopper and empty the dust bag.
► Fig.34: 1. Dust stopper 2. Dust bag
When using the paper lter
Remove the dust stopper and dispose of the paper lter.
► Fig.35: 1. Dust stopper 2. Paper lter
4. Place the dust bag/new paper lter and dust stop-
per together into the cleaner and close the front cover.
NOTE: The cleaner is constructed in such a way that
the front cover comes o󰀨 when trying to force the
front cover open at the angle of more than 90°. If the
front cover comes o󰀨, insert it into the front cover joint
in place.
► Fig.36: 1. Front cover 2. Front cover joint
MAINTENANCE
CAUTION: Always be sure that the tool is
switched o󰀨 and the battery cartridge is removed
before attempting to perform inspection or
maintenance.
To maintain product SAFETY and RELIABILITY,
repairs, any other maintenance or adjustment should
be performed by Makita Authorized or Factory Service
Centers, always using Makita replacement parts.
After use
CAUTION: Putting the cleaner against the
wall without any other support may cause the
cleaner to fall down, resulting in personal injury
or damage to the cleaner.
► Fig.37
Cleaning
CAUTION: Clean dust bags and lters when
they become clogged. Continued use in the clogged
condition may result in heating or re.
NOTICE: Never use gasoline, benzine, thinner,
alcohol or the like. Discoloration, deformation or
cracks may result.
NOTICE: Do not blow dust sticking on the
cleaner and lters by air duster. It brings dust into
the housing and causes failure.
NOTICE: After washing dust bags and
sponge lters, dry them thoroughly before use.
Insu󰀩ciently dried lters may cause poor suction and
shorten the service life of the motor.
NOTICE: After cleaning dust bags and sponge
lters, be sure to re-install them before use. If
you use the cleaner without dust bags and sponge
lters, dust comes into the motor housing and cause
malfunction.
Cleaner body
From time to time wipe o󰀨 the outside (cleaner body) of
the cleaner using a cloth dampened in soapy water.
Clean out also the suction opening, dust bag/paper lter
mounting area and the dust stopper.
► Fig.38
Dust bag
Wash the dust bag in soapy water when it is clogged
with dust and the cleaner power becomes weak. Dry it
out thoroughly before use. An insu󰀩ciently dried lter
may cause poor suction and shorten the service life of
the motor.
► Fig.39
NOTE: Paper lter is a throw-away type.
Dust stopper
Wipe dust o󰀨 from the dust stopper.
Remove dust and dirt on the sponge part by lightly
tapping it.
► Fig.40: 1. Sponge part
Removing and installing the sponge
lter
CAUTION: After cleaning sponge lter, be
sure to install it on the cleaner. If washed in water,
dry it up before installing. An insu󰀩ciently dried
sponge lter may shorten the service life of the motor.
When the sponge lter is clogged with dust, remove it
from the cleaner and then wipe it o󰀨 or wash in water.
To remove the sponge lter, remove the dust bag or
paper lter and then pinch and take the sponge lter
out.
► Fig.41: 1. Sponge lter
Press in the whole edge of the sponge lter against the
recessed wall inside the dust bag/paper lter mounting
area.
► Fig.42: 1. Recessed wall
Wall mount for cordless cleaner
Optional accessory
NOTE: The screw to mount the holder is not included.
Prepare a screw which ts with the material to screw
into.
Attach the wall mount for cordless cleaner to a hard
wooden wall, beam or column, where the wall mount
for cordless cleaner can be rmly secured. Always be
sure that the wall mount for cordless cleaner is securely
attached before hanging the cleaner.
► Fig.43: 1. Wall mount for cordless cleaner
CAUTION: Do not hang the cleaner to the wall
mount violently or hang other appliances than the
cleaner.

16 ENGLISH
Troubleshooting
Before asking for repairs, check the following points.
Symptom Area to be investigated Fixing method
Weak suction power
Is dust bag or paper lter full of dust? Empty dust bag or paper lter.
Is dust bag or sponge lter clogged? Dust down or wash dust bag and sponge
lter.
Is paper lter clogged? Replace paper lter.
Is battery cartridge discharged? Charge battery cartridge.
Not working Is battery cartridge discharged? Charge battery cartridge.
Abnormal noise and vibration come
out
Is dust bag or sponge lter clogged? Dust down or wash dust bag and sponge
lter.
Is paper lter clogged? Replace paper lter.
Anything to block openings or holes? Clean any dust and objects out of nozzles,
pipes and air openings.
Is suction inlet of nozzle or pipe closed? Uncover and open suction inlet of nozzle
and pipe.
Dust case cover does not close Is dust bag or paper lter set? Set dust bag or paper lter.
CAUTION: Do not attempt to repair the cleaner by yourself.
OPTIONAL
ACCESSORIES
CAUTION: These accessories or attachments
are recommended for use with your Makita tool
specied in this manual. The use of any other
accessories or attachments might present a risk of
injury to persons. Only use accessory or attachment
for its stated purpose.
If you need any assistance for more details regard-
ing these accessories, ask your local Makita Service
Center.
• Extension wand (Straight pipe)
• Nozzle
• Nozzle for carpet
• Shelf brush
• Corner nozzle
• Round brush
• Flexible hose
• Dust bag
• Paper lter
• Free nozzle
• Seat nozzle
• Crevice nozzle
• Wall mount for cordless cleaner
• Cyclone attachment
• Tool bag
• Makita genuine battery and charger
NOTE: Some items in the list may be included in the
tool package as standard accessories. They may
di󰀨er from country to country.
Cyclone attachment
► Fig.44: 1. Release button 2. Hook 3. Extension
wand (Straight pipe) 4. Cyclone attachment
5. Suction inlet
About the cyclone attachment
Using the cleaner with the cyclone attachment installed
reduces the amount of dust that enters the dust bag,
which helps to prevent the suction force from weaken-
ing. In addition, cleaning after use is also simple.
CAUTION: Always be sure that the tool is
switched o󰀨 and the battery cartridge is removed
before carrying out any work on the tool. If the
battery cartridge is left inserted, the cleaner may start
unexpectedly and result in injury.
CAUTION: Clean the mesh lter of the
cyclone attachment and the dust bag of the
cleaner unit when they become clogged.
Continued use in the clogged condition may result in
heating or smoke.
NOTICE: When the cyclone attachment is
attached, do not use the cleaner in the horizontal
or upward facing condition. Doing so may cause
the mesh lter to become clogged.
NOTICE: Always use the cleaner with the dust
bag installed, even when using the cyclone
attachment. Using the cleaner without the dust bag
installed may result in a motor malfunction.

17 ENGLISH
NOTE: Check that the cyclone attachment, cleaner,
and extension wand (straight pipe) are locked prop-
erly before use.
NOTE: Empty the dust case of the cyclone attach-
ment and the dust bag of the cleaner when dust has
accumulated. Continued use will result in weakened
suction force.
NOTE: You can also use the cyclone attachment with-
out lock function.
NOTE: To install or remove the cyclone attachment,
refer to the section "Installing and removing cleaner
attachments".
Disposing of dust
When dust has accumulated up to the full line of the
dust case, follow the procedure below and dispose of
the dust.
1. Hold the dust case rmly, press and hold the two
buttons, and remove the dust case.
► Fig.45: 1. Full line 2. Dust case 3. Button (two
locations) 4. Mesh lter
2. Dispose of the dust inside the dust case and
remove any dust and powder adhered to the surface of
the mesh lter.
3. Insert the dust case all the way until the two but-
tons lock with a click.
► Fig.46: 1. Dust case 2. Button (two locations)
CAUTION: When reassembling the dust case,
be careful not to pinch your ngers.
NOTE: Check that the cyclone attachment, cleaner,
and extension wand (straight pipe) are locked prop-
erly before restarting operation.
NOTE: If the suction force does not recover even
after disposing of the dust and cleaning the mesh
lter, check whether dust has accumulated in the dust
bag of the cleaner or clogging has occurred.
NOTE: The dust may y up when disposing from the
cyclone attachment. Be careful not to let dust get into
your eyes.
Cleaning
CAUTION: After washing the cyclone attach-
ment, dry it thoroughly before use. Insu󰀩ciently
dried components may cause an electrical shock or
damage to the appliance.
When the dust case becomes dirty or the mesh lter is
clogged, remove and wash them with water. (Refer to
“Disposing of dust” for the removal procedure.)
Dry the parts thoroughly before reinstallation and use.
► Fig.47: 1. Dust case 2. Mesh lter
When the mesh lter gets dirty badly, clean it in the
following procedures.
1. Turn the mesh lter counterclockwise and remove
it while the hooks are unlocked.
► Fig.48: 1. Mesh lter 2. Hook
2. Remove the dust on the mesh lter and then wash
it with water. After that, dry it thoroughly.
3. Insert the mesh lter into the base while the hooks
are aligned with the port. Turn the mesh lter clockwise
until the hooks are locked with a click. Make sure that
the mesh lter is installed securely.
► Fig.49: 1. Mesh lter 2. Hook 3. Port

18 SLOVENŠČINA
SLOVENŠČINA (Originalna navodila)
OPOZORILO
• To napravo lahko na varen način, če razumejo vključena tveganja, uporabljajo otroci, stari 8 let in več ter osebe
z zmanjšanimi zičnimi, čutilnimi ali psihičnimi sposobnostmi ter s pomanjkanjem izkušenj in znanja, če so pod
ustreznim nadzorom ali so prejeli navodila v zvezi z uporabo naprave.
• Otroci se z napravo ne smejo igrati. Otroci brez nadzora ne smejo izvajati čiščenja in uporabniškega
vzdrževanja.
• Glejte poglavje „TEHNIČNI PODATKI“ za vrsto baterije.
• Za navodila o nameščanju ali odstranjevanju baterije glejte razdelek „Nameščanje ali odstranjevanje akumula-
torske baterije“.
• Ko želite akumulatorsko baterijo zavreči, jo vzemite iz orodja in odložite med odpadke na varno mesto.
Upoštevajte lokalne uredbe glede odlaganja baterije.
• Če orodja ne boste uporabljali dalj časa, morate odstraniti baterijo.
• Ne povzročite kratkega stika akumulatorske baterije.
• Za primerne podrobnosti o previdnostnih ukrepih med vzdrževanjem glejte poglavje „VZDRŽEVANJE“.
TEHNIČNI PODATKI
Model: CL002G
Zmogljivost z vrečko za prah 500 mL
s papirnatim ltrom 330 mL
Neprekinjena uporaba
(z akumulatorjem BL4025) 1 (tihi način) Pribl. 80 min
2 (način z običajno hitrostjo) Pribl. 40 min
3 (način z visoko hitrostjo) Pribl. 25 min
4 (način z največjo hitrostjo) Pribl. 16 min
Celotna dolžina (s cevjo, šobo in baterijo BL4025) 1.066 mm
Nazivna napetost D.C. največ 36 V – 40 V
Neto teža 1,8 – 2,4 kg
• Ker nenehno opravljamo raziskave in razvijamo svoje izdelke, se lahko tehnični podatki v tem dokumentu
spremenijo brez obvestila.
• Tehnični podatki se lahko razlikujejo od države do države.
• Teža ne vključuje pripomočkov, vključuje pa akumulatorske baterije. Najlažja in najtežja kombinacija teže
naprave in akumulatorskih baterij sta prikazani v tabeli.
Uporabna akumulatorska baterija in polnilnik
Baterijski vložek BL4020* / BL4025* / BL4040* / BL4050F
* : Priporočeni akumulator
Polnilnik DC40RA / DC40RB / DC40RC
• Nekatere zgoraj navedene akumulatorske baterije in polnilniki morda v vaši državi prebivališča niso na voljo.
OPOZORILO: Uporabljajte le zgoraj navedene akumulatorske baterije in polnilnike. Uporaba drugih
akumulatorskih baterij in polnilnikov lahko povzroči telesne poškodbe in/ali požar.
Simboli
Naslednji simboli se lahko uporabljajo v povezavi s
strojem. Pred uporabo izdelka se obvezno seznanite z
njihovim pomenom.
Preberite navodila za uporabo.
Vzorec baterije, ki se uporablja za ta
izdelek.

19 SLOVENŠČINA
Ni-MH
Li-ion
Samo za države EU
Zaradi prisotnosti nevarnih komponent v
opremi imajo lahko uporabljena električna
in elektronska oprema, akumulatorji in
baterije negativen vpliv na okolje in zdravje
ljudi.
Električnih in elektronskih naprav ali baterij
ne odlagajte med gospodinjske odpadke!
Skladno z evropsko Direktivo o odpadni
električni in elektronski opremi, o akumula-
torjih in baterijah ter odpadnih akumulator-
jih in baterijah ter njeno uporabo v državnih
zakonih morate rabljeno električno in
elektronsko opremo, baterije in akumula-
torje zbirati ločeno ter dostaviti na posebno
zbiralno mesto za komunalne odpadke, ki
deluje skladno s predpisi za zaščito okolja.
To nakazuje simbol prečrtanega smetnjaka
s kolesi, ki je natisnjen na opremi.
Predvidena uporaba
Orodje je namenjeno za zbiranje suhega prahu.
VARNOSTNA
OPOZORILA
Varnostna opozorila za brezžični
čistilnik
OPOZORILO: POMEMBNO! POZORNO
PREBERITE vsa varnostna opozorila in navodila
pred uporabo. Zaradi neupoštevanja opozoril in
navodil lahko pride do električnega šoka, požara in/ali
hudih telesnih poškodb.
1. Ne izpostavljajte dežju. Hranite v notranjih
prostorih.
2. Ne dovolite igranja z napravo. Potrebna je
posebna pozornost, kadar napravo uporabljajo
otroci ali se uporablja v njihovi bližini.
3. Uporabljajte le v skladu z opisi v tem priroč-
niku. Uporabljajte le priključke, ki jih priporoča
proizvajalec.
4.
Ne uporabljajte naprave s poškodovanim aku-
mulatorjem. Če naprava ne deluje, kot bi morala,
je padla, je poškodovana, pozabljena na prostem
ali je padla v vodo, jo odnesite v servis.
5. Ne rokujte z napravo z mokrimi rokami.
6. Ne vstavljajte predmetov v odprtine. Ne upo-
rabljajte z zamašenimi odprtinami; odstranite
prah, vlakna, lase in vse, kar bi lahko zmanj-
šalo pretok zraka.
7. Las, ohlapnih oblačil, prstov in nobenih delov
telesa ne približujte odprtinam in premikajočim
se delom.
8. Preden odstranite akumulator, izklopite vse
upravljalne elemente.
9. Med čiščenjem na stopnicah bodite izjemno
previdni.
10. Ne uporabljajte za pobiranje vnetljivih ali gor-
ljivih tekočin, kot je bencin, in ne uporabljajte v
območjih, kjer so lahko prisotne.
11. Za polnjenje uporabljajte samo polnilnik, ki ga
dobavlja proizvajalec.
12. Ne pobirajte ničesar, kar gori ali iz česar se vije
dim, kot so cigarete, vžigalice ali vroč pepel.
13. Ne uporabljajte brez vrečke za prah in/ali
nameščenih ltrov.
14. Akumulatorja ne polnite na prostem.
15. Orodje polnite samo s polnilnikom, ki ga je
določil proizvajalec. Polnilnik, ki je primeren za
eno vrsto akumulatorskega sklopa, lahko pomeni
nevarnost požara, če ga uporabljate z drugim
akumulatorskim sklopom.
16.
Naprave uporabljajte samo s predpisano vrsto aku-
mulatorskih sklopov. Pri uporabi drugih akumulator-
skih sklopov lahko pride do telesnih poškodb in požara.
17. Ko akumulatorskega sklopa ne uporabljate,
ga ne hranite ob kovinskih predmetih, kot so
sponke za papir, kovanci, ključi, žeblji, vijaki ali
drugi manjši kovinski predmeti, ki lahko pove-
žejo oba terminala.
18. V neprimernih pogojih lahko iz akumulatorja
uhaja tekočina; izogibajte se stiku. Če pride do
nenamernega stika, sperite z vodo.
19. Ne uporabljajte akumulatorskega sklopa ali
naprave, ki je poškodovana ali spremenjena.
Delovanje poškodovanih ali spremenjenih baterij
je nepredvidljivo in lahko povzroči požar, eksplo-
zijo ali telesne poškodbe.
20. Akumulatorskega sklopa oziroma naprave
ne izpostavljajte ognju ali previsoki tempera-
turi. Izpostavljenost ognju ali temperaturam nad
130 °C lahko povzroči eksplozijo.
21.
Upoštevajte vsa navodila glede polnjenja in
akumulatorskega sklopa oziroma naprave ne
polnite zunaj določenega temperaturnega raz-
pona. Nepravilno polnjenje ali polnjenje pri tempe-
raturah zunaj določenega razpona lahko povzroči
poškodbe baterije in poveča nevarnost požara.
SHRANITE TA NAVODILA.
DODATNA VARNOSTNA PRAVILA
Ta naprava je namenjena le za domačo uporabo.
1. Pred uporabo pozorno preberite ta navodila za
uporabo in navodila za uporabo polnilnika.
2. Ne pobirajte naslednjih materialov:
— vročega materiala, kot so prižgane ciga-
rete ali iskre/kovinski prah, ki nastane
zaradi brušenja/rezanja kovin
— vnetljivih materialov, kot je bencin,
razredčilo, kerozin ali barva
— eksplozivnih materialov, npr. nitroglicerin
— vnetljivih materialov, kot je aluminij, cink,
magnezij, titan, fosfor ali celuloid
— mokre zemlje, vode olja ipd.
— trdih predmetov z ostrimi robovi, kot
so lesni ostružki, kovine, kamni, steklo,
žeblji, bucike ali britvice
— prahu, ki se strdi, kot je cement ali toner
— prevodnega prahu, kot je kovina ali ogljik
— nih delcev, kot je betonski prah
Takšna dejanja lahko povzročijo požar, telesne
poškodbe in/ali materialno škodo.

20 SLOVENŠČINA
3. Če opazite karkoli neobičajnega, takoj prene-
hajte uporabljati orodje.
4. Če vam čistilnik pade iz rok ali če z njim kam
udarite, ga pred uporabo skrbno preglejte, da
preverite, ali je razpokan ali poškodovan.
5. Ne približujte ga pečicam ali drugim virom
vročine.
6. Ne zamašite vhodne odprtine ali odprtin za
prezračevanje.
SHRANITE TA NAVODILA.
Pomembna varnostna navodila za
akumulatorsko baterijo
1. Pred uporabo baterijskega vložka preberite
vsa navodila in opozorilne oznake na (1) pol-
nilniku akumulatorja, (2) akumulatorju in (3)
izdelku, ki uporablja akumulator.
2. Ne razstavljajte ali spreminjajte akumulatorske
baterije. S tem lahko povzročite požar, preko-
merno vročino ali eksplozijo.
3. Če se je čas delovanja občutno skrajšal, takoj
prenehajte uporabljati orodje. V nasprotnem
primeru lahko pride do pregretja, morebitnih
opeklin in celo eksplozije.
4. Če pride elektrolit v stik z očmi, jih sperite s
čisto vodo in takoj poiščite zdravniško pomoč.
Posledica je lahko izguba vida.
5.
Ne povzročite kratkega stika baterijskega vložka:
(1) Ne dotikajte se priključkov s kakršnim
koli prevodnim materialom.
(2) Izogibajte se shranjevanju baterijskega
vložka v vsebniku z drugimi kovinskimi
predmeti kot so žeblji, kovanci itn.
(3) Ne izpostavljajte baterijskega vložka vodi
ali dežju.
Kratek stik akumulatorja lahko povzroči velik
električni tok, pregrevanje, morebitne opekline
in celo okvaro.
6. Ne shranjujte in uporabljajte orodja in akumu-
latorske baterije na mestih, kjer lahko tempera-
tura doseže ali preseže 50 °C (122 °F).
7. Ne sežigajte baterijskega vložka, tudi če je
hudo poškodovan ali v celoti izpraznjen.
Baterijski vložek lahko v ognju eksplodira.
8. Ne pribijajte, režite, drobite, mečite, spuščajte
akumulatorske baterije oziroma ne udarjajte
z akumulatorsko baterijo po trdem predmetu.
Takšno ravnanje lahko povzroči požar, preko-
merno vročino ali eksplozijo.
9. Ne uporabljajte poškodovanih akumulatorjev.
10. Priložene litij-ionske baterije ustrezajo zahte-
vam zakonodaje v zvezi z nevarnim blagom.
Za komercialne prevoze, npr. tiste, ki jih opravljajo
tretje stranke in carinski posredniki, je treba upo-
števati posebne zahteve v zvezi z embalažo in
označevanjem.
Med postopkom priprave na odpremo izdelka se
je treba posvetovati s strokovnjakom za nevarne
snovi. Pri tem upoštevajte tudi podrobnejše nacio-
nalne predpise.
Odprte stike oblepite z lepilnim trakom ali jih dru-
gače zaščitite, baterijo pa zapakirajte tako, da se v
embalaži ne more premikati.
11. Ko odstranjujete akumulatorsko baterijo, jo
vzemite iz orodja in varno zavrzite. Upoštevajte
lokalne uredbe glede odlaganja baterije.
12. Baterije uporabljajte le z izdelki, ki jih določi
Makita. Če namestite baterije v neskladne izdelke,
lahko pride do požara, pregrevanja, eksplozije ali
puščanja elektrolita.
13. Če orodja dlje časa ne uporabljate, morate iz
njega odstraniti baterijo.
14. Med uporabo in po uporabi lahko akumu-
latorska baterija postane vroča in povzroči
opekline. Z vročimi akumulatorskimi baterijami
ravnajte pazljivo.
15. Ne dotikajte se priključka orodja takoj po upo-
rabi, ker se lahko dovolj segreje, da povzroči
opekline.
16. Ne dovolite, da bi se v priključke, odprtine in
utore akumulatorske baterije zlepili ostružki,
prah ali zemlja. To lahko povzroči pregrevanje,
požar, razpočenje in okvaro orodja ali akumula-
torske baterije ter privede do opeklin ali drugih
telesnih poškodb.
17. Razen če orodje podpira uporabo v bližini
visokonapetostnih električnih vodov, akumula-
torske baterije ne uporabljajte v bližini visoko-
napetostnih električnih vodov. Takšna uporaba
lahko povzroči motnje v delovanju ali okvaro
orodja oziroma akumulatorske baterije.
18. Baterijo hranite izven dosega otrok.
SHRANITE TA NAVODILA.
POZOR: Uporabljajte le originalne baterije
Makita. Če uporabljate neoriginalne baterije Makita
ali baterije, ki so bile spremenjene, lahko pride do
eksplozije baterije in posledično do požara, telesnih
poškodb ali materialne škode. S takšno uporabo
boste tudi razveljavili garancijo Makita za orodje in
polnilnik Makita.
Nasveti za ohranjanje največje
zmogljivosti akumulatorja
1. Napolnite baterijski vložek, preden se v celoti
izprazni. Ko opazite, da ima orodje manjšo
moč, vedno ustavite delovanje orodja in napol-
nite baterijski vložek.
2. Nikoli znova ne polnite popolnoma napol-
njenega baterijskega vložka. Prenapolnjenje
skrajša življenjsko dobo akumulatorja.
3. Baterijski vložek s sobno temperaturo pol-
nite pri temperaturi okolja od 10 °C do 40 °C.
Počakajte, da se vroč baterijski vložek pred
polnjenjem ohladi.
4. Ko akumulatorske baterije ne uporabljate, jo
odstranite iz orodja ali polnilnika.
5. Če baterijskega vložka ne uporabljate dalj časa
(več kot 6 mesecev), ga napolnite.
