Manrose M200P User manual

INSTALLATION
INSTRUCTIONS
Location
1. When installing fan through an external wall,
an external wall grille must be fitted at all
times.
2. For best results this Extractor Fan should
be fitted as high on the wall as possible, or
if preferred, on the ceiling. Note: Pullcord
models should not be installed in a ceiling.
3. Do not install the unit within a shower
cubicle or anywhere else where there is a
risk of being sprayed with water (Please
see our range of showerfans for these
installations.).
4. If the fan is installed in a room containing
a fuel burning appliance, the installer must
ensure that the air replacement is adequate
for both the fan and the fuel burning
appliance.
Wiring
1. Switch off mains supply before making
electrical connections. If in any doubt contact
a qualified electrician.
2. These units are for fixed wiring only. A flexible
cord must not be used. All wiring must be
fixed securely and the cable to the fan should
be a minimum of 1mm2in section. All wiring
must comply with current I.E.E. Regulations
or local regulations if outside the UK.
3. A double pole fused spur having contact
separation of at least 3mm in all pole must be
used and fitted with a 3A fuse.
4. This fan is double insulated and does not
require an earth connection.
5. The fan should not be accessible to a person
using either the shower or the bath.
Switch off mains supply before making any electrical
connections.
Installation must be supervised by a qualified electrician.
This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory and mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning the use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children
without supervision.
Precautions must be taken to avoid the back-flow of gases
into the room from the open flue of gas or other open-fire
appliances when mounted in outside windows or walls.
Fan must be disconnected from electrical power before any
maintenance is carried out.
M200P/ M200S/ M200T/ M200H/ M200HP
CENTRIFUGAL EXTRACTOR FANS

INSTALLATION INSTRUCTIONS
SURFACE FITTING
Select a suitable position for the fan
and cut the 112mm diameter hole for the
discharge duct.
1. Mark the position on the wall for the 255mm
high x 205mm wide surface mounted box, hold
in position and mark the four fixing holes. Care
must be taken to ensure the discharge hole
is the correct orientation to suit the fan when
fitted.
2. Drill and plug the four fixing holes and screw
the surface mount box to the wall (care must
be taken not to over tighten the screws).
3. Bring the power cable into position and
ensure that you allow extra cable protruding to
facilitate connection.
4. Remove the front cover of the fan by first
removing the cover fascia (one screw located
at the top behind the red/white hole plug –
remove this by gently prying it out with a fine
tipped screwdriver) and then removing the
fixing screw located at the bottom, the cover
then clips off. The chassis is fixed to the
surface mount box by four screws. Refer to
separate wiring details for connection.
RECESSED/FLUSH FITTING
Select a suitable position for the fan and
cut a hole to suit the outlet and a recess to
suit the body of the fan.
1. Vertical Discharge (Usually in the stud work
internal walls) 225mm high x 180mm wide x
120mm deep.
2. Horizontal Discharge (Usually cavity external
walls) 225mm high x 180mm wide x 75mm
deep.
3. Position of Discharge hole Care must be taken
to ensure the 112mm discharge spigot is the
correct orientation to suit the recess. Always
check studwork walls to ensure the hole and
recess are between vertical timber studs.
4. Bring the power cable into position and
ensure that you allow extra cable protruding to
facilitate connection.
5. Hold the chassis in the recess and mark the
position of the fixing holes. Drill and plug the
four fixing holes and screw the chassis into
position.
6. Refer to separate wiring details for connections.
DIAGRAM 3
Diagram 1
DECREASE
INCREASE
INCREASE
Neutral
Switched Live
Permanent Live

1. Wiring of Standard Model
The fan can either be operated from a separate pullcord switch fitted to the ceiling of the room or
can be connected to the light switch so that the fan will start when the light is switched on. Requires
a permanent live and neutral supply.
2. Wiring of Pullcord Model
This fan has its own integral pullcord on/off switch. Requires a permanent live and neutral supply.
3. Wiring of Timer Model - Diagram 1
The fan can either be operated from a separate pullcord switch fitted to the ceiling of the room
or can be connected to the light switch so that the fan will start when the light is switched on.
Requires a permanent live, a switch live and neutral supply.
4. Wiring of Humidity Model - Diagram 2
For the fan to operate as a normal time delay unit with humidity override i.e. when connected
with a switched live coming from the light switch into the fan, the fan will operate when the light
is switched on, and switch off after about 20 seconds to 35 minutes (timer is pre-set for the
minimum). However, should the humidity in the room reach about 75%, which will happen if
the shower is run or the bath filled with hot water, the fan will switch on and keep running until
the humidity has been reduced to a normal level, about 65%. (Humidity sensor is adjustable.)
Requires a permanent live, switch live and neutral supply.
5. Wiring of Humidity Pullcord Model - Diagram 3
This model is the same as the humidity model but with its own pullcord switch and a neon light
power indicator. It does not require a switched live power supply. Requires a permanent live and
neutral supply.
WIRING
Please refer to the first page, under the heading ‘wiring’ this is for safety information &
general skill.
Diagram 2
MAX
45 min
1 min
MIN
40 %
90%
OFF RH 0N
Neutral
Switched Live
Permanent Live

A
B
Recess/Flush&
Surface Mount
Front View
Dimensions
A B C D E F G H
SURFACE MOUNT 208 255 N/A 87 63 98 N/A N/A
FLUSH MOUNT 208 255 19 68 63 98 225 178
DIAGRAM 4
Flush Fit Surface Mount
C D DE E
F F
G
H
077353 08/14
PLEASE DISPOSE OF
USED FAN AT YOUR
LOCAL CIVIC AMENITY
SITE. DO NOT DISPOSE
IN DOMESTIC WASTE
