Manrose FAN0046 User manual

NOTE: (i) Thefanistobeinstalledsothatthebladesaremorethan2.1mabovetheoor.For
 bestresultsthisExtractorFanshouldbettedashighonthewallaspossible,orif
 preferred,ontheceiling.
 (ii) Donotinstalltheunitwithinashowercubicle.UseourshowerfanSF125models
(iii) Switchoffmainssupplybeforemakingelectricalconnections.Thissystemshould
 beinstalledbyaqualiedelectrician.
 (iv) Thisfanisdoubleinsulatedanddoesnotrequireanearth.
 (v)Wheninstallingfanthroughanexternalwall,anexternalwallgrillemustbetted
at all times.
1. Cuta112mmmin.diameterholeinthewall.Ifthefanistobexedontotheceiling
ensurethattheholeisbetweenthejoists.
2. Fit100mm(internaldiameter)ductingushtotheplaster.
3. Removethecoverfromthefanbysimplyunclippingthefascia.Thefrontcoverscrew
 andplugareconvenientlylocatedwithinthefanhousingasshownindiagram1&2.
4. Holdthebodyofthefanagainstthewallorceilingandmarkthefourscrewholes
 andthecableentry. IMPORTANT: Ensurethatthefanissquareonthewallorceiling.
5. Bringpowercableintoposition,asmarked.Allowanextra230mm(9”)protrudingto
facilitate connection.
6. IfanXP100kit-Selectasuitablepositionontheoutsidewallfortheweatherproof
 cowl.Carefullyremovethecowlfromitshousingbyleveringgentlyatthesideswith
 asmallscrewdriver.Cuta115mmholeensuringrstthattheareaisfreefrom
obstruction.
7. Wiring of Standard Model FAN0046. (see Diagram 1).
 Thefancanbeconnectedtothelightswitchsothatthefanwillstartwhenthelightis
 switchedon.Thefanshouldnotbeaccessibletoapersonusingeithertheshoweror
the bath.
NOTE: Allwiringmustbexedsecurelyandthecabletothefanshouldbea 
minimum of 1mm2insection.AllwiringmustcomplywithcurrentRegulations.
Thissystemmustbeinstalledbyaqualiedelectrician.
IMPORTANT
FAN MUST BE INSTALLED
THIS WAY UP WHEN
MOUNTED ON WALL
Diagram 2
Diagram 2A
Rotary adjuster
for time delay
Thank you for selecting our Manrose 100mm Wall/Ceiling Fan.
Please read all instructions before commencing installation.
FAN0046/0048/0053 Wall Fan and Kits
CLASSIC SERIES
INSTALLATION INSTRUCTIONS
Manrose is proudly distributed by Ventair Pty Ltd
4 Capital Place, Carrum Downs, 3201 VIC, AUSTRALIA.
Technical Support [phone]
e: [e-mail] | www.ventair.com.au | www.manrose.com.au
Wereservetherighttochangespecicationwithoutpriorwarning
FAN0046/0048/0053 Wall Fan and Kits IM Iss:01 03/20

8. Wiring of Pullcord Models. (See Diagram 1 / 1A)
(THIS MODEL IS NOT SUITABLE FOR CEILING FIXING)
 Thisfanhasitsownintegralpullcordon/offswitch.Thefanshouldnotbeaccessibleto
apersonusingeithertheshowerorthebath.
NOTE: Allwiringmustbexedsecurelyandthecabletothefanshouldbeaminimum
of 1mm2insection.AllwiringmustcomplywithcurrentRegulations. Thissystemmust
beinstalledbyaqualiedelectrician.
9. Wiring of Timer. (See Diagram 2 / 2A).
 Thefancanbeconnectedtothelightswitchsothatthefanwillstartwhenthelight 
 isswitchedon.Whenthelightswitchorpullcordisswitchedoffthefanwillrunfor 
 between20sec&30minutes(pre-setto1minute).Thefanshouldnotbe  
 accessibletoapersonusingeithertheshowerorthebath.
NOTE: Allwiringmustbexedsecurelyandthecabletothefanshouldbeaminimum
of 1mm2insection.AllwiringmustcomplywithcurrentRegulations. Thissystemmust
 beinstalledbyaqualiedelectrician.
Timer Adjustment only
T histimedelaycanbeadjustedbyrstlyswitchingoffthepowertothefanand 
 removingthefascia.LocatetherotaryadjusterasshowninDiagram2.Theserrated 
 adjusterwheelcanberotatedusingathumbnailtoadjustthetimersetting.
   +=Rotatetotherighttoincreasethetime(indicatedby+onthediagram)
   -=Rotatetothelefttodecreasethetime(indicatedby-onthediagram)
Only adjust with power switched off.
Specications:
 Model:  NZNVF100SBB;NZNVF100TBB;NZNVF100PBB
 Electrical: 220-240V~50Hz
 FanWattage: 20W
 MaxTemp: 40˚C
 Airow:  23l/s(85m3/hr)-freeairperformance
 MaxPressure: 20Pa
 SoundVolume: 41dB(A)
 IPRated:  IP44(exceptpullcordmodelIP24)
Diagram 1
IMPORTANT
FAN MUST BE
INSTALLED THIS
WAY UP WHEN
MOUNTED ON WALL
Diagram 1A
IMPORTANT
• Isolate the mains supply before making any electrical connections. This system
 shouldbeinstalledbyaqualiedelectrician.
• Whenttingthroughanexternalwall,anexternalgrillemustbettedatalltimes.
• Fanshouldonlybeinstalledbyxedwiring,aexiblecordshouldnotbeused.
• Theapplianceisnotintendedforusebyyoungchildrenorinrmpersonswithoutsupervision.
• Young children should be supervised to ensure that they do not play with the appliance.
• Precautionsmustbetakentoavoidtheback-owofgasesintotheroomfrom 
 theopenueofgasorotheropen-reapplianceswhenmountedinoutside 
windows or walls.
