Marcy REVOLUTION CYCLE User manual

NOTE:
Please read all instructions
carefully before using this
product
NOTA:
Por favor lea atentamente
las instrucciones antes de
utilizar este producto
Table of Contents / Índice
Safety Notice / Aviso de
seguridad
Important Assembly
Information / Información
importante de montaje
Care and Maintenance /
Cuidado y mantenimiento
Parts List / Lista de piezas
Warranty / Garantía
Ordering Parts / Solicitud de
piezas
Model / Modelo
JX-7038
Retain This Manual for
Reference / Conserve
este manual para
futura referencia
221229
OWNER'S MANUAL /
MANUAL DEL
USUARIO
BICICLETA REVOLUCIÓN
CLUB
JX-7038
IMPEX®INC.
2801 S. Towne Ave., Pomona, CA 91766
Tel: [phone] [phone]
Fax: [phone]
www.marcypro.com
[e-mail]

© IMPEX INC. www.marcypro.com
1
TABLE OF CONTENTS
BEFORE YOU BEGIN
1
IMPORTANT SAFETY NOTICES
2
WARNING LABEL PLACEMENT
3
HARDWARE PACK
4
ASSEMBLY INSTRUCTIONS
5
EXPLODED DIAGRAM
8
PARTS LIST
9
CARE AND MAINTENANCE
10
OPERATING NOTES
11
EXERCISE GUIDELINES
12
WARRANTY
14
ORDERING PARTS
14
BEFORE YOU BEGIN
Thank you for selecting the MARCY Club Revolution Cycle JX-7038 by IMPEX®
INC. For your safety and benefit, read this manual carefully before using the bike.
As a manufacturer, we are committed to provide you complete customer
satisfaction. If you have any questions, or find there are missing or damaged parts,
we guarantee you complete satisfaction through direct assistance from our factory.
To avoid unnecessary delays, please call our TOLL-FREE customer service
number. Our Customer Service Agents will provide immediate assistance to you.
Toll-Free Customer Service Number
1-800-999-8899
Mon. - Fri. 9 a.m. - 5 p.m. PST
www.impex-fitness.com
[e-mail]

© IMPEX INC. www.marcypro.com
2
IMPORTANT SAFETY NOTICE
PRECAUTIONS
This exercise bike is built for optimum safety. However, certain precautions apply
whenever you operate a piece of exercise equipment. Be sure to read the entire
manual before you assemble or operate your bike. In particular, note the following
safety precautions:
1. Keep children and pets away from the exercise bike at all times. DO NOT leave
children unattended in the same room with the bike.
2. Only one person at a time should use the bike.
3. If the user experiences dizziness, nausea, chest pain, or any other abnormal
symptoms, STOP the workout at once. CONSULT A PHYSICIAN IMMEDIATELY.
4. Position the bike on a clear, leveled surface. DO NOT use the bike near water or
outdoors.
5. Keep hands away from all moving parts.
6. Always wear appropriate workout clothing when exercising. DO NOT wear robes or
other clothing that could become caught in the bike. Running or aerobic shoes are
also required when using the bike.
7. Use the bike only for its intended use as described in this manual. DO NOT use
attachments not recommended by the manufacturer.
8. Do not place any sharp object around the bike.
9. Disabled person should not use the bike without a qualified person or physician in
attendance.
10. Before using the bike to exercise, always do stretching exercises to properly warm
up.
11. Never operate the bike if it is not functioning properly.
12. Read all warnings posted on the exercise bike.
13. Inspect the exercise bike for worn or loose component prior to use. Tighten/replace
any loose or wore components prior to use.
14. Care should be taken in mounting or dismounting the exercise bike.
15. This exercise bike is for consumer and home use only.
WARNING: BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT YOUR
PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE
AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL
INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC.
ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY
DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT.
SAVE THESE INSTRUCTIONS.

© IMPEX INC. www.marcypro.com
3
WARNING LABEL PLACEMENT
The Warning Labels and Caution Label shown here have been placed on the Rear Stabilizer and Main
Frame.
If the labels are missing or illegible, please call customer service at 1-800-999-8899 for replacement. Apply
the labels in location shown.

© IMPEX INC. www.marcypro.com
4
HARDWARE PACK
NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.

© IMPEX INC. www.marcypro.com
5
COMPONENTS FOR ASSEMBLY

© IMPEX INC. www.marcypro.com
6
ASSEMBLY INSTRUCTION
•Tools Required For Assembling the Bike: One Crossing Wrench and Allen Wrench,
provided by manufacturer.
•NOTE: It is strongly recommended that two or more people assemble this bike to
avoid possible injury.
STEP-1
A.) Attach the Front Stabilizer (#9) to the Main Frame (#1). Secure it with four M8x ¾” Allen Bolts (#36)
and four Ø ⅝” Washers (#38).
B.) Attach the Rear Stabilizer (#8) to the Main Frame (#1). Secure it with four M8 x ¾” Allen Bolts (#36),
and four Ø ⅝” Washers (#38).
C.) Thread the Pedal (#20R) clockwise onto the right Crank (#17R).
D.) Thread the Pedal (#20L) counterclockwise onto the left Crank (#17L)
E.) Attach Water Bottle Rack (#16) to the Main Frame (#1), Secure with two M5 x 5/8” Philips Bolts
(#35).
F.) Use the two Level adjustment knobs (#22) to stabilize the Bike on floor.

© IMPEX INC. www.marcypro.com
7
STEP 2
A.) Insert the Handle Post (#3) into the front opening on Main Frame (#1). Use the M16 Lock Knob
(#19) to hold the Handle Post at selected height. And lock the Handle Post (#3) by using M8 x
½” Lock Knob (#43).
B.) Attach the Handle (#2) to the Handle Post (#3). Secure them together with one M10 L-shaped
Lock Knob (#13) and Handle Sliding Block (#10) (which was pre -fitted inside of the tube).
C.) Attach two Elbow Supports (#6) into the split on the handle (#2), secure each of them with one
Rubber Spacer (#25) , one R29 Arc Washer (#7) and one M6 Knob (#18).
D.) Insert the Seat Post (#4) into the opening on Main Frame. Use the M16 Lock Knob (#19) to hold
the Seat Post at selected height.
E.) Flip over the Seat Pad (#14). Insert the tube on the Seat Support (#5) into the open slot and
securely fasten the two Nuts to secure the Seat Pad to the tube.
F.) Insert the Seat Support (#5) through the open slot on Seat Post. Use the M10 Seat Lock Knob
(#29) to hold the Seat at selected position.

© IMPEX INC. www.marcypro.com
8
EXPLODED DIAGRAM

© IMPEX INC. www.marcypro.com
9
JX-7038 PARTS LIST
PART NO.
DESCRIPTION
SPEC.
QUANTITY
1
Main Frame
1
2
Handle
1
3
Handle Post
1
4
Seat Post
1
5
Sliding Seat Support
1
6
Elbow Support
2
7
Arc Washer
R29
2
8
Rear Stabilizer
1
9
Front Stabilizer
1
10
Handle Sliding Block
1
11
Seat Support Sleeve
1
12
Level Knob Locking Nut
M12
2
13
L-shaped Lock Knob
M10
1
14
Seat Pad
1
15
Roller Wheel Sleeve
2
16
Water Bottle Rack
1
17
Crank L/R
1
18
Elbow Support Pad Lock Knob
M6
2
19
Lock Knob
M16
2
20
Pedal L/R
1
21
Tension/Brake Knob
1
22
Level Adjustment Knob
4
23
Handle Cone-shaped End Cap
Ø 1”
4
24
Handle End Cap
Ø 1”
2
25
Rubber Spacer
2
26
Handle Support End Cap
2 ⅜” x ¾”
2
27
Sliding Seat Support End Cap
1 ⅝” x ¾”
2
28
Sleeve
1 ⅝” x 3 ⅛”
2
29
Seat Lock Knob
M10
1
30
Plastic Cover
1
31
Belt Cover
1
32
Stabilizer Right End Cap
2
33
Stabilizer Left End Cap
2
34
Roller Wheel
2
35
Philips Bolt
M5 x ⅝”
2
36
Allen Bolt
M8 x ¾”
8
37
Allen Bolt
M6 x 1 ⅝”
2
38
Washer
Ø ⅝”
8
39
Washer
Ø ½”
2
40
Aircraft Nut
M6
2
41
Lower Handle Foam Grip
2
42
Upper Handle Foam Grip
2
43
Lock Knob
M8 x ½”
1

© IMPEX INC. www.marcypro.com
10
CARE AND MAINTENANCE
1. Inspect and tighten all parts each time you use the bike. Replace any worn parts
immediately.
2. The bike can be cleaned using a damp cloth and mild non-abrasive detergent. Do not use
solvents.
3. Store the bike IN-DOOR. Excess moisture and water would cause rust on the frame.
4. The Bike shall be placed at least 24 inches away from the wall or/and any other object such
as furniture to provide safe access to and passage around the bike.
5. To avoid possible injury, the help of two or more people are needed when moving the bike
around.
6. Disposal Instructions – The equipment can be safely disassembled and disposed without
unreasonable hazards. Call your local recycle agency regarding details of recycling.
7. The maximum user weight is 300 lbs.
8. Assembled Dimension: 45.5” x 20” x 44”
Brake Pad Lubricating Oil
Apply few drops of Brake Lubricating Oil to the brake pad periodically.
!!Warning!!
Contains Silicon based oil.
Not for consumption.
Keep away from children!

© IMPEX INC. www.marcypro.com
11
OPERATING NOTES
ADJUSTMENT
1. Use the Tension/Brake Knob (#21) to adjust the resistance for exercises.
2. Loosen and pull out the Lock Knob (#19). Slide the Seat Post to the desired height and
lock at the position by fastening the Lock Knob (#19).
3. Loosen and pull out Lock Knob (#19 & #43). Slide Handle Post to desired height and
Lock at the position by fastening the Lock Knob (#19 & #43).
4. The seat height adjustment is in approximately 1” increment.
*The seat height can be adjusted for 10 different height ranges from 35” to 44”.
5. The height of Elbow Support can be adjusted with 6 positions range from 36” to 41” with
approximately 1” adjustment.
6. Loosen and pull out the Seat Lock Knob (#29). Slide the Seat Support to the desired
position and lock at the position by fastening the Seat Lock Knob.
7. Loosen the L-shaped Lock Knob (#13), move the Handle Sliding Block (#10) to desired
position; lock the Handle at position by fastening the L-shaped Lock Knob.
Stopping the Exercise
1. Press down the Tension/Brake Knob (#21) to stop the fly wheel. ONLY when
the flywheel has stopped, will it be safe to remove feet from pedals.
2. DO NOT stop pedaling: doing so could result in serious injury.
3. DO NOT attempt to stop the Fly Wheel by hands, feet or any other device not
indicated in this instruction.
TRANSPORT
The Bike has a pair Roller Wheels on Front Stabilizer.
To move, carefully tilt the cycle forward, and then roll.

© IMPEX INC. www.marcypro.com
12
EXERCISE GUIDELINES
Using your Bike will provide you with several benefits, it will improve your physical fitness, tone
muscle and in conjunction with calorie controlled diet help you lose weight.
1. The Warm Up Phase
This stage helps get the blood flowing around the body and the muscles working properly. It will
also reduce the risk of cramp and muscle injury. It is advisable to do a few stretching exercises
as shown below. Each stretch should be held for approximately 30 seconds, do not force or jerk
your muscles into a stretch - if it hurts, STOP.
2. The Exercise Phase
This is the stage where you put the effort in. After regular use, the muscles in your legs will
become more flexible. Work to your targeted heart rate but it is very important to maintain a
steady tempo throughout. The rate of work should be sufficient to raise your heartbeat into the
target zone shown on the graph below.
This stage should last for a minimum of 12 minutes though most people start at about
15-20 minutes
SIDE BENDS OUTER THIGH
INNER THIGH
FORWARD
BENDS
CALF / ACHILLES

© IMPEX INC. www.marcypro.com
13
3. The Cool Down Phase
This stage is to let your Cardio-vascular System and muscles wind down. This is a repeat of the
warm up exercise e.g. reduce your tempo, continue for approximately 5 minutes. The stretching
exercises should now be repeated, again remembering not to force or jerk your muscles into the
stretch.
As you get fitter you may need to train longer and harder. It is advisable to train at least three
times a week, and if possible space your workouts evenly throughout the week.
MUSCLE TONING
To tone muscle while on your MAGNETIC BIKE you will need to have the resistance set quite
high. This will put more strain on our leg muscles and may mean you cannot train for as long as
you would like. If you are also trying to improve your fitness you need to alter your training
program. You should train as normal during the warm up and cool down phases, but towards
the end of the exercise phase you should increase resistance making your legs work harder.
You will have to reduce your speed to keep your heart rate in the target zone.
WEIGHT LOSS
The important factor here is the amount of effort you put in. The harder and longer you
work the more calories you will burn. Effectively this is the same as if you were training
to improve your fitness, the difference is the goal.

© IMPEX INC. www.marcypro.com
14
IMPEX®INC.
LIMITED WARRANTY
IMPEX Inc. ("IMPEX
®
") warrants this product to be free from defects in workmanship and material, under normal use and service conditions,
for a period of two years on the Frame from the date of purchase. This warranty extends only to the original purchaser. IMPEX's obligation
under this Warranty is limited to replacing or repairing, at IMPEX'soption.
All returns must be pre-authorized by IMPEX. Pre-authorization may be obtained by calling IMPEX Service Centers. All freights on
products returned to IMPEX must be prepaid by the customer. This warranty does not extend to any product
or damage to a product caused
by or attributable to freight damage, abuse, misuse, improper or abnormal usage or repairs
not provided by an IMPEX authorized service
center or for products used for commercial or rental purposes. No other warranty beyond that specifically set forth above is authorized by
IMPEX.
IMPEX is not responsible or liable for indirect, special or consequential damages arising out of or in connection with the use or
performance of the product or other damages with respect to any economic loss, loss of property, loss of revenues
or profits, loss of
enjoyments or use, costs of removal, installation or other consequential damages or whatsoever natures.
Some states/provinces do not allow
the exclusion or limitation of incidental or consequential damages. Accordingly, the above limitation may not apply to you.
The warranty extended hereunder is in lieu of any and all other warranties and any implied warranties of merchantability or fitness for a
particular purpose is limited in its scope and duration to the terms set forth herein. Some states/provinces do not allow limitations on how
long an implied warranty lasts. Accordingly, the above limitation may not apply to you.
This warranty gives you specific legal right. You may also have other rights which vary from states/provinces to states/provinces.
Register on-line at www.marcypro.com
To request technical assistance under warranty, the customer must always present the cash ticket with the item along with its packaging
and accessories, in the store where it was bought, so that the claim can be studied, or you can contact the IMPEX Service Centers.
Coverage area: 15 km around the service center or Walmart stores are covered for home service. Distance of more than 15 km has an
additional cost.
Exclusion for the warranty: Installation, maintenance, cleaning or periodic reviews and controls of the product. If you are interested in
getting these services, you can contact the service center with an additional cost.
Service Centers:
Honduras
Nombre:
R&P ELECTRONICS
Dirección
completa:
Barrio Santa Ana 14 calle 7-8 avenida
N.O San Pedro Sula
Teléfono de
contacto:
504 2552 0221, 504 2550-1074
Mail de
contacto:
[e-mail]
Guatemala
Nombre:
Servicios y electronicos MAX
Dirección
completa:
Dirección 2da av 13-35 zona 17 ofibodega
los almendros bodega 26. Guatemala
Teléfono de
contacto:
Oficina Centrales: 502 2256-4439
Sucursal Zone 1: 502 2253 0529
Mail de
contacto:
[e-mail]
Nicaragua
Nombre:
RELESA Electronics
Dirección
completa:
Colonia y Avenida Las Mercedes, Pje los
Fresnos #2. San Salvador
Teléfono de
contacto:
503 2566-7000
Mail de
contacto:
[e-mail]
El Salvador
Nombre:
Home Solutions Electronic Center, S.A.
Dirección
completa:
Centro Comercial Zumen 3 Cuadras al
Este 15 vrs al sur.
Teléfono de
contacto:
Oficinas Centrales
505 2260 3212,505 2253 9247,
Sucursal Oriental: 505 2251 1281
Mail de
contacto:
[e-mail]
Costa Rica
Nombre:
Repuestos Romano e hijos
Dirección
completa:
175m oeste de la plaza de deportes
Frente Central de Mangueras, Rotulo
TVROMANO, San Jose La Uruca
Teléfono de
contacto:
Oficinas Centrales: 506 2221-5151
Sucursal del Este: 506 2223-5151
Sucursal del Heredia: 506 2262-5151
Mail de
contacto:
[e-mail]

© IMPEX INC. www.marcypro.com
15
ÍNDICE DE CONTENIDO
ANTES DE COMENZAR
15
AVISOS IMPORTANTES DE SEGURIDAD
16
UBICACIÓN DE LA ETIQUETA DE ADVERTENCIA
17
PAQUETE DE FERRETERÍA
18
INSTRUCCIONES DE MONTAJE
20
DIAGRAMA ESQUEMÁTICO
22
LISTADO DE PIEZAS
23
CUIDADO Y MANTENIMIENTO
24
DIRECTRICES DE EJERCICIO
25
GARANTÍA
27
PEDIDO DE REPUESTOS
27
ANTES DE COMENZAR
Gracias por elegir la Bicicleta Revolución Club JX-7038 MARCY hecha por
IMPEX® INC. Para su seguridad y beneficio, lea atentamente este manual antes
de utilizar el equipo. Como fabricante, nos comprometemos con proporcionarle
completa satisfacción al cliente. Si tiene alguna pregunta, o le faltan piezas o las
mismas están dañadas, le garantizamos completa satisfacción a través de la
asistencia directa de nuestra fábrica. Para evitar demoras innecesarias, por favor
llame a nuestra línea de servicio al cliente. Nuestros agentes de servicio al cliente
le proporcionarán asistencia inmediata.
Número de servicio al cliente
1-800-999-8899
Lunes a Viernes de 9 a.m. a 5 p.m. PST
www.marcypro.com
[e-mail]

© IMPEX INC. www.marcypro.com
16
AVISOS IMPORTANTES DE SEGURIDAD
PRECAUCIÓN:
Esta bicicleta estacionaria está construida para una seguridad óptima. Sin embargo,
deben aplicarse ciertas precauciones al operar una bicicleta estacionaria. Asegúrese de
leer todo el manual antes de montar o de operar la bicicleta. Principalmente, observe las
siguientes precauciones:
1. Mantenga a los niños y animales alejados de la bicicleta en todo momento.
No deje a los niños sin supervisión en la misma habitación con la bicicleta.
2. Sólo una persona a la vez debe usar la bicicleta.
3. Si el usuario experimenta mareos, náuseas, dolor de pecho o cualquier otro
síntoma anormal, deje de hacer ejercicio de inmediato. CONSULTE A SU
MÉDICO INMEDIATAMENTE.
4. Coloque el bicicleta sobre una superficie nivelada, libre de otros objetos. NO
utilice el bicicleta cerca del agua o al aire libre.
5. Mantenga las manos lejos de todas las partes móviles.
6. Siempre use ropa apropiada para hacer ejercicios al usar la máquina. NO use
batas u otra ropa que pueda engancharse en la bicicleta. También debe usar
zapatillas para correr o aeróbicas al utilizar el bicicleta.
7. Use la bicicleta solamente para su uso previsto como se describe en este manual.
NO use accesorios no recomendados por el fabricante.
8. No coloque ningún objeto filoso cerca de la bicicleta.
9. Las personas discapacitadas no deberían usar la bicicleta.
10.Antes de usar el bicicleta para hacer ejercicio, siempre haga ejercicios de
estiramientos para precalentarse adecuadamente.
11.No utilice la bicicleta si no está funcionando correctamente.
12.Lea todas las advertencias en la bicicleta estacionaria.
13.Inspeccione la bicicleta estacionaria por partes gastadas o flojas antes de usarla.
Ajuste o reemplace cualquier parte floja o gastada antes de utilizar.
14.Debe tener cuidado al subir y bajar de la bicicleta estacionaria.
15.Esta bicicleta estacionaria es únicamente para uso de consumidores y en el
hogar.
ADVERTENCIA: ANTES DE COMENZAR CUALQUIER PROGRAMA DE
EJERCICIOS, CONSULTE A SU MÉDICO. ESTO ES ESPECIALMENTE
IMPORTANTE PARA LAS PERSONAS MAYORES DE 35 AÑOS O PERSONAS
CON PROBLEMAS DE SALUD PREEXISTENTES. LEA TODAS LAS
INSTRUCCIONES ANTES DE UTILIZAR CUALQUIER EQUIPO DE EJERCICIOS.
IMPEX INC. NO ASUME NINGUNA RESPONSABILIDAD POR LESIONES
PERSONALES O DAÑOS MATERIALES SUFRIDOS POR O MEDIANTE EL USO
DE ESTE PRODUCTO.
GUARDE ESTAS INSTRUCCIONES

© IMPEX INC. www.marcypro.com
17
COLOCACIÓN DE ETIQUETAS DE ADVERTENCIA
La etiqueta de advertencia y de precaución que se muestran arriba se han colocado en el Estabilizador
Trasero y en el Marco Principal. Si faltan las etiquetas o las mismas son ilegibles, por favor llame a
servicio al cliente al 1-800-999-8899 para obtener reemplazos. Coloque las etiquetas en la ubicación que se
muestra.

© IMPEX INC. www.marcypro.com
18
PAQUETE DE FERRETERÍA
NOTA: Las siguientes piezas no están dibujadas a escala. Utilice su propia regla para medir el
tamaño.
Perno Allen M8 x ¾” x 8
Perno Phillips M5 x 5/8” x 8
Llave Allen 5# x 1
Llave Multiple x 1
Perilla de bloqueo en forma de L M10 x 1
Arandela
Ø
5/8” x 8

© IMPEX INC. www.marcypro.com
19
COMPONENTES PARA MONTAJE
No. 1 Marco Principal No. 2 Mango No. 3 Poste de la manija
No. 4 Poste de asiento
No. 20 Pedal derecho/izquierdo No. 32 Botellero
No. 27 Asiento
No. 9 Estabilizador Frontal No. 32 Estabilizador Trasero
No. 6 Apoyo de codo
