Master EM-007 User manual

English
ENGLISH (Original instructions)
EM-007 Master Expert Manual
Battery Operated Yale ElectroPick Device
1 Trigger 4 Vibration Adjustment Knob
2 Battery Compartment Cover 5 Pick Blade
3 Pick Blade Holder 6 Lamp
_____________________________________________________
1 Rechargeable ElectroPick Device
2Rechargeable 5C Lithium Batteries
3Charging Unit
4Pick Blade Set
5USB Charging Cable
6Thick Tension Tool
7Thumb Turn Lock Pick
8Allen Key-2.5 mm
9Drawer Lock Pick
10 Spare Pick Blades
11 Blade Holder and Screws
12 Tensions in Various Sizes
Specification
•
Due to our continuing program of research and development, the specifications herein are subject to change without
notice.
• The weight may differ depending on the attachment(s), including the battery. The lightest and heaviest combination,
according to EPTA-Procedure 01/2014, are shown in the table.
Model
MASTER EXPERT EM-007
Hitting capacity of pins
1 mm - 8 mm
No load speed
0 - 17.000 min-1
Impacts per minute
0 - 17.000 min-1
Overall length
232 mm
Rated voltage
D.C. 3,7 V
Net weight
0,34 kg
Gross weight (with battery)
0,40 kg

English
Applicable battery and charger
Battery Type
5C
Battery Type
Lithium Ion
Battery Capacity
1.500 –3.000 mAh
Battery Charge Time
1,5 hour
Charger
XTAR SC1
Charger input voltage (Input)
SV 2.1A
• The battery and charger specifications listed above may vary.
Intended use
This tool is a rechargeable electropick tool for
unlocking cyliders or closed doors for locksmith
professionals.
Noise
The typical A-weighted noise level determined
according to EN62841-2-2:
Sound pressure level (LpA): 85 dB (A)
Sound power level (LWA): 88 dB (A)
Uncertainty (K): 3 dB (A)
Vibration
The vibration total value (tri-axial vector sum)
determined according to EN62841-2-2
Work mode: impact tightening of fasteners of the
maximum capacity of the tool.
Vibration emission (a
h
): 2,5 m/s
2
Uncertainty (K): 1,5 m/s2
EC Declaration of Conformity
For European countries only
A copy of the CE declaration of conformity is given in
the side column.
WARNING: Wear ear protection.
WARNING: The noise emission during actual
use of the power tool can differ from the declared
value(s) depending on the ways in which the
tool is used especially what kind of workpiece is
processed.
WARNING:
The vibration emission during actual
use of the power tool can differ from the declared
value(s) depending on the ways in which the tool is
used especially what kind of workpiece is processed.
NOTE 1: The declared noise emission value(s) has
been measured in accordance with a standard test
method and may be used for comparing one tool with
another.
NOTE 2: The declared noise emission value(s) may
also be used in a preliminary assessment ofexposure.
NOTE: The declared vibration total value(s) has been
measured in accordance with a standard test method
and may be used for comparing one tool with another.
NOTE: The declared vibration total value(s) may also
be used in a preliminary assessment of exposure.
WARNING: Only use the battery and charger listed above. Use of any other battery and charger may
cause injury and/or fire.
WARNING:
DO NOT let comfort or familiarity
with product (gained from repeated use)
replace strict adherence to safety rules for the
subject product.
MISUSE or failure to follow the safety rules
statedin this instruction manual may cause
serious personal injury.

English
SAFETY WARNINGS
Save all warnings and instructions for
future reference.
The term “power tool” in the warnings refers to your
cordless, battery-operated power tool.
1. Hold the power tool by insulated gripping
surfaces, when performing an operation
where the fastener may contact hidden
wiring. Fasteners contacting a "live" wire may
make exposed metal parts of the power tool
"live" and could give the operator an electric
shock.
2. Always be sure you have a firm footing.
Be sure no one is below when using the tool
in high locations
3. Hold the tool firmly.
4. Wear ear protectors.
5. Keep hands away from vibrating parts.
6. Use a tension supplied with the tool set.
1. Do not disassemble or tamper with the
battery. It may result in a fire, excessive
heat, or explosion.
2. If operating time has become excessively
shorter, stop operating immediately. It may
result in a risk of overheating, possible
burns and even an explosion.
3. If burr gets into your eyes, rinse them out
with clear water and seek medical attention
right away. It may result in loss of your
eyesight.
4. Do not short the battery cartridge:
(1) Do not touch the terminals with any
conductive material.
(2) Avoid storing battery cartridge in a
container with other metal objects such
as nails, coins, etc.
(3) Do not expose battery cartridge to water
or rain.
A battery short can cause a large current
flow, overheating, possible burns and even
a breakdown.
5. Do not store and use the tool and battery in
locations where the temperature may reach
or exceed 50 °C (122 °F).
6. Do not incinerate the battery even if it is
severely damaged or is completely worn out.
The battery can explode in a fire.
7. Do not nail, cut, crush, throw, drop the battery
or hit against a hard object to the battery.
Such conduct may result in a fire, excessive heat,
or explosion.
8. Do not use a damaged battery.
9. The contained lithium-ion batteries are subject
to the Dangerous Goods Legislation
requirements..
For preparation of the item being shipped, consulting
an expert for hazardous material is required. Please
also observe possibly more detailed national
regulations.
Tape or mask off open contacts and pack up the
battery in such a manner that it cannot move around
in the packaging .
10. When disposing the battery remove it from
the tool and dispose of it in a safe place.
Follow your local regulations relating to
disposal of battery.
11. After use, the battery should be removed
from the tool.
12. Carry the tool in its original bag.
13. During and after use, the battery may take on
heat which can cause burns or low temperature
burns. Pay attention to the handling of hot
battery cartridges.
14. Do not touch the terminal of the tool
immediately after use as it may get hot enough
to cause burns..
15. Do not allow chips, dust, or soil stuck into the
terminals, holes, and grooves of the battery
cartridge. It may cause heating, catching fire, burst
and malfunction of the tool or battery resulting in
burns or personal injury.
16. Keep the battery away from children.
WARNING: Read all safety warnings, instruc-
tions, illustrations and specifications provided
with this power tool.
Failure to follow all instructions
listed below may result in electric shock, fire and/or
serious injury.
Safety warnings for the Battery-
powered Yale ElectroPick
General power tool safety warnings
Important safety instructions for
battery

English
Tips for maximum battery life
1. Charge the battery before it is completely
discharged. When you notice that the power of
the tool is starting to weaken, stop the tool,
replace the battery and charge the discharged
battery.
2. Never recharge a fully charged battery.
Overcharging shortens the service life of the
battery.
3. Charge the battery at room temperature of
10°C - 40°C (50 °F - 104 °F). Allow a hot
battery to cool before charging.
4. Remove the battery from the tool or
charger when not in use.
Switch action
► Picture 1 –No: 1 Switch trigger
To start the tool, simply press the switch trigger. Release the
switch trigger to stop .
Lighting up thefront lamp
► Picture 1 –No: 6 Lamp
Press the switch trigger to light the lamp. The lamp stays on
while the switch trigger is pressed. The lamp goes out about 10
seconds after the key trigger is released .
Manufacturer and Dealers
Manufacturing Company:
MASTER TEKNIK TASARIM MAKINA
SAN. ve TIC. LTD.
Cumhuriyet Mah. Fatih S. M. Cad. No: 20
34457 Sariyer, Istanbul, TURKIYE
www.masterpick.net
Dealer in Germany:
A-KEY, GmbH
Ziegelei 10
89542 Herbrechtingen, Germany
[phone] |[e-mail]
Dealer in Italy:
ParmaKey S.R.L.
P.zza Bruno Mora, 7/A (area ex Salamini)
43122 Parma, Italy
[phone] | [email protected]
Operation
► Picture 1
Open the tool's battery compartment. (Pic.1-No:2)
Insert one of the batteries in the set. Make sure that the
pick blade is attached to the tip of it. (Pic.1-No:5)
Take one of the tension included in the set and place it
above the lock core. Insert the key on the end of the
device through the lock core. (Pic.1-No:5)
Start the tool by holding down the trigger. (Pic.1-No:1)
Start from the back and work your way forward to hit
the pins. In the meantime, make sure that the pins you
have dropped are down by pressing the tension lightly.
When you drop all the pins, with the help of the tension
in your other hand, the lock core will turn and open the
door.
► Picture 1- No: 3 Pick Blade Holder
When you want to change the pick blade, loosen the nut
in No-3 with the allen wrench included in the set, insert
the new blade and tighten the nut again.
► Picture 1-No: 4 Vibration Adjustment Knob
Do not use this setting button unless absolutely
necessary. (Pic.1-No:4)
This adjustment knob is used to determine the limits of
the up-down movement of the pick blade attached at the
tip. This gap should be in the range of 3-6 mm .
Maintenance
The tool does not need periodic maintenance. When you are not
using the tool, we recommend that you remove the lithium-ion
battery from its socket and store the tool in its own bag.
______________________________________
Dealer in Netherlands:
Expert Training Center
Griendstraat 27
2921 LA, Krimpen a/d IJssel, Netherlands
Tel: [phone] | [email protected]
Dealer in Spain:
Cerraelx
C/ Bufart, 8
03203 –Elche, Spain
Tel: [phone] | [email protected]
Inserting and removing the battery
CAUTION: Do not look in the light or see the
source of light directly.
NOTE: Use a dry cloth to wipe the dirt off the lens of
the lamp. Be careful not to scratch the lens of lamp, or
it may lower the illumination.
WARNING: Hold both the tool and the battery
firmly when inserting or removing the battery.
Failure to hold the tool or battery tightly may result in them
being dropped, resulting in damage or serious damage to
the tool and/or battery.
