MasterCraft 068-0558-4 User manual

continuation tabs
IMPORTANT:
Please read this manual carefully before assembling
and using this cabinet and save it for reference.
INSTRUCTION
MANUAL
BASE CABINET
Model no. 068-0558-4

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 062-3582-8 | contact us 1-800-689-9928
TABLE OF CONTENTS

1
TABLE OF CONTENTS
TABLE OF CONTENTS
2
3
4
11
Safety
Parts List
Assembly Instructions
Warranty
SAVE THESE INSTRUCTIONS
This manual contains important safety and operating instructions.
Read all instructions and follow them with use of this product.
NOTE:
If any parts are missing or damaged, or if you have any questions,
please call our toll-free helpline at 1-800-689-9928.

2
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 068-0558-4 | contact us 1-800-689-9928
SAFETY
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 062-3582-8 | contact us 1-800-689-9928
• To reduce the risk of serious injury, read the following safety
instructions before assembling and using the cabinet.
• This cabinet is intended for domestic, indoor use only.
• The cabinet should be positioned on a level surface.
• Any assembly or maintenance of the cabinet must be carried
out by adults only.
• Arrange for necessary manpower when assembling and moving
the cabinet.
• Check all the nuts and bolts periodically for tightness.
When required, tighten them again.
• Use a slightly damp, soft cloth to clean the cabinet.
• Do not stand on the cabinet and do not use it as a scaffold.
• Do not exceed the weight limit specified for this cabinet.
Maximum middle shelf load: 66 lb (30 kg).
Maximum drawer load: 44 lb (20 kg).
Maximum cabinet load: 320 lb (145.5 kg).
SAVE THESE INSTRUCTIONS
This manual contains important safety and operating instructions.
Read all instructions and follow them with use of this product.

3
PARTS LIST
PARTS LIST
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
No.
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
Description
Drawer back panel
Drawer base panel
Drawer mat
Swivel wheel with brake
Swivel wheel w/o brake
Bumper
Magnet
Screwdriver
M4 x 10 screw
M4 x 8 screw
M8 x 18 screw
M4 x 18 screw
Hook
Key
Washer
Push bar
Corner protector A
Corner protector B
Description
Bottom panel
Front frame
Right panel
Left panel
Left door
Bottom back panel
Upper back panel
Right door
Middle shelf
Solid wood board
Drawer front panel
Left drawer side panel
Right drawer side panel
Qty.
1
1
1
1
1
1
1
1
1
1
1
1
1
Qty.
1
1
1
2
2
4
2
1
57
25
16
16
4
2
6
1
1
1

4
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 068-0558-4 | contact us 1-800-689-9928
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 062-3582-8 | contact us 1-800-689-9928
ASSEMBLY INSTRUCTIONS
ASSEMBLY PREPARATION
• Assemble the storage cabinet on a clean, level surface.
• Remove all items from the packaging box and ensure that all parts listed on page
3 are included.
• When installing parts that have more than one screw, tighten all screws by hand
before tightening them with the screwdriver provided.
ASSEMBLY INSTRUCTIONS
1. Open the cardboard box to remove
the solid wood board (Part 10) and
other parts (see Fig. A).
2. Place the front frame (Part 2) on
the front of the solid wood board (Part
10). Insert two M4 x 10 screws (Part
22) through the front frame and
tighten them using the screwdriver
(Part 21) (see Fig. B).
Note: The screw holes have some tolerance.
Always make sure that the top and sides of the
front frame align with the solid wood board.
Doing so will prevent the need to make
adjustments at the final stage, therefore
reducing time to assemble.
Fig. A
Fig. B

5
ASSEMBLY INSTRUCTIONS
3. Place the left panel (Part 4) on the solid
wood board (Part 10). Make sure the top
of the left panel is aligned with the screw
holes on the front frame (Part 2) and the
solid wood board. Attach the left panel to
the solid wood board and front frame. Add
three washers (Part 28) to the three M4 x
10 screws (Part 22) that will attach the
solid wood board; no washers are
necessary with the three M4 x 10 screws
(Part 22) that attach the front frame.
Tighten the screws using the screwdriver
(Part 21) (see Fig. C).
4. Place the right panel (Part 3) on the
solid wood board (Part 10). Make sure the
top of the right panel is aligned with the
screw holes on the front frame (Part 2)
and the solid wood board. Attach the right
panel to the solid wood board and front
frame. Add three washers (Part 28) to the
three M4 x 10 screws (Part 22) that will
attach the solid wood board; no washers
are necessary with the three M4 x 10
screws (Part 22) that attach the front
frame. Tighten the screws using the
screwdriver (Part 21) (see Fig. D).
5. Attach the upper back panel (Part 7)
and bottom back panel (Part 6) between
the left panel (Part 4) and right panel (Part
3). Make sure the top of the upper back
panel is on the solid wood board. Line up
the screw holes of the back panels. Insert
13 M4 x 10 screws (Part 22) and tighten
them using the screwdriver (Part 21) (see
Fig. E).
Fig. C
Fig. D
Fig. E
Note: Four screw holes provided at top end of the
upper back panel are reserved for corner protectors.

6
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 068-0558-4 | contact us 1-800-689-9928
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 062-3582-8 | contact us 1-800-689-9928
ASSEMBLY INSTRUCTIONS
6. Attach the bottom panel (Part 1) to
the left panel (Part 4), right panel (Part
3), front frame (Part 2) and bottom back
panel (Part 6). Line up the screw holes,
insert eight M4 x 10 screws (Part 22)
into the screw holes and tighten them
using the screwdriver (Part 21) (see Fig.
F).
Note: Only the centre holes of the left panel,
right panel, front frame and bottom back panel
are used for attaching the bottom panel. Other
holes are reserved for corner bumpers.
7. Attach swivel wheels with brakes
(Part 17) and swivel wheels without
brakes (Part 18) to the bottom of the
cabinet. Make sure the swivel wheels
with brakes are installed at the front.
Insert 16 M8 x 18 screws (Part 24) into
the four swivel wheels and tighten them
using the screwdriver (Part 21) (see Fig.
G).
8. Attach the bumpers (Part 19) to the
bottom four corners of the cabinet.
Insert 16 M4 x 18 screws (Part 25) into
the bumpers and tighten them using the
screwdriver (Part 21) (see Fig. H).
Note: After finishing this step, turn the cabinet
to upright position.
Fig. G
Fig. H
Fig. F

7
ASSEMBLY INSTRUCTIONS
9. Align left drawer side panel (Part 12)
and right drawer side panel (Part 13) one
at a time to the back of the drawer front
panel (Part 11). Make sure both drawer
side panels are placed in contact with the
rear of the drawer front panel. Line up the
screw holes of the drawer side panels,
insert four M4 x 8 screws (Part 23) and
tighten them using the screwdriver (Part
21) (see Fig. I).
10. From above, attach drawer base
panel (Part 15) between the two drawer
side panels and to the back of the drawer
front panel (Part 11). Insert six M4 x 8
screws (Part 23) into the drawer base
panel and tighten them using the
screwdriver (Part 21) (see Fig. J).
Note: Do not fully tighten any of the screws until
all screws are partially screwed in.
11. Attach the drawer back panel (Part
14) to the back of the assembled drawer.
Insert seven M4 x 8 screws (Part 23) into
the drawer back panel and tighten them
using the screwdriver (Part 21) (see Fig.
K).
12. Pull out the ball bearing track (1)
towards the front of the slider (2) (see Fig. L).
Note: Do not fully tighten any of the screws until
all screws are partially screwed in.
Fig. I
Fig. J
Fig. K
Fig. L

8
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 068-0558-4 | contact us 1-800-689-9928
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 062-3582-8 | contact us 1-800-689-9928
ASSEMBLY INSTRUCTIONS
13. To insert the drawer, pull out the
drawer tracks (1) and ball bearing
tracks (2) as far as possible (see Fig. M).
14. Fit the drawer tracks inside the
track attached to the left panel (Part 4)
and right panel (Part 3). Repeatedly
push and pull the slider until the drawer
is installed in the cabinet. Finally, place
the drawer mat (Part 16) inside the
drawer (see Fig. N).
15. Use four M4 x 10 screws (Part 22)
to attach the magnets (Part 20) to the
front frame (Part 2) (see Fig. 0).
Note: The black plate of the magnet (Part 20)
should be facing the front.
16. Decide the height for the middle
shelf. Place the hooks (Part 26) into the
hook slots and push them down. Place
the middle shelf (Part 9) into the cabinet
at the decided height and push it down
(see Fig. P).
Note: The middle shelf needs hooks at four
corners for support. Make sure the hooks are
placed at the same height.
Fig. M
Fig. N
Fig. O
Fig. P

9
ASSEMBLY INSTRUCTIONS
17. Attach the left door (Part 5) to the
unit. Insert four M4 x 8 screws (Part 23)
into the left door and tighten them using
the screwdriver (Part 21) (see Fig. Q).
18. Attach the right door (Part 8) to the
unit. Insert four M4 x 8 screws (Part 23)
into the right door and tighten them using
the screwdriver (Part 21) (see Fig R).
Note: The screw holes on the door hinge have
some tolerance, thereby enabling the door to be
adjusted and centred on the door frame.
19. Use eight M4 x 10 screws (Part 22) to
attach the push bar (Part 29) to the
drawer cabinet (see Fig. S).
20. Attach corner protector B (Part 31) to
the back left of the drawer cabinet using
five M4 x 10 screws (Part 22) and attach
corner protector A (Part 30) to the back
right of the drawer cabinet using five M4
x 10 screws (Part 22) (see Fig. T).
Fig. Q
Fig. R
Fig. S
Fig. T

10
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 068-0558-4 | contact us 1-800-689-9928
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 062-3582-8 | contact us 1-800-689-9928
ASSEMBLY INSTRUCTIONS
To remove the drawers from the
cabinet.
1. To pull the drawers out of the unit,
pull up the black plastic clip on the right
(1) of the drawer and push down the
black plastic clip on the left (2) of the
drawer (see Fig. U).
2. The cabinet is ready to use. Use the
keys (Part 27) to lock the right door
(Part 8) of the cabinet, if desired (see
Fig. V).
NOTE:
This product provides fingerprint-resis-
tant surfaces and increased durability.
Stainless Steel Maintenance:
A fingerprint-resistant finish has been applied to these parts. Do not use traditional
stainless steel cleaners on this unit. Lightly wipe off once a month with clean warm
water and a soft cloth (preferably a microfibre cloth). This is the safest formula to
prevent new stains from appearing over time and manage unwanted fingerprints or
grease marks. Remember to always wipe in the direction of the surface grain
(NEVER ACROSS) and always use a lint-free cloth. Once the surface is clean,
thoroughly wipe dry with a soft, absorbent cloth.
Fig. U
Fig. V

This Mastercraft® product carries a one (1) year warranty from the date of the original
retail purchase, against defects in material and workmanship. Subject to the condi-
tions and limitations described below, this product, if returned to us with proof of
purchase within the stated warranty period and if covered under this warranty, will be
repaired or replaced (with the same model, or one of equal value or specification), at
our discretion. We will bear the cost of any repair or replacement and any costs of
labour relating thereto.
This warranty is subject to the following conditions and limitations:
a. a bill of sale verifying the purchase and purchase date must be provided;
b. this warranty will not apply to any product or part thereof which is worn or broken
or which has become inoperative due to abuse, misuse, accidental damage, neglect or
lack of proper installation, operation or maintenance (as outlined in the applicable
owner's manual or operating instructions) or which is being used for industrial, profes-
sional, commercial or rental purposes;
c. this warranty will not apply to normal wear and tear or to expendable parts or acces-
sories that may be supplied with the product which are expected to become inopera-
tive or unusable after a reasonable period of use;
d. this warranty will not apply to routine maintenance and consumable items such as,
but not limited to, fuel, lubricants, vacuum bags, blades, belts, sandpaper, bits, fluids,
tune-ups or adjustments;
e. this warranty will not apply where damage is caused by repairs made or attempted
by others (i.e., persons not authorized by the manufacturer);
f. this warranty will not apply to any product that was sold to the original purchaser as
a reconditioned or refurbished product (unless otherwise specified in writing);
g. this warranty will not apply to any product or part thereof if any part from another
manufacturer is installed therein or any repairs or alterations have been made or
attempted by unauthorized persons;
h. this warranty will not apply to normal deterioration of the exterior finish, such as, but
not limited to, scratches, dents, paint chips, or to any corrosion or discolouring by heat,
abrasive and chemical cleaners; and
i. this warranty will not apply to component parts sold by and identified as the product
of another company, which shall be covered under the product manufacturer's
warranty, if any.
WARRANTY
11

headline bars
continuation tabs
notes
warnings
Additional Limitations
This warranty applies only to the original purchaser and may not be
transferred. Neither the retailer not the manufacturer shall be liable for
any other expense, loss or damage, including, without limitation, any
indirect, incidental, consequential or exemplary damages arising in
connection with the sale, use or inability to use this product.
Notice to Consumer
This warranty gives you specific legal rights, and you may have other
rights, which may vary from province to province. The provisions
contained in this warranty are not intended to limit, modify, take away
from, disclaim or exclude any statutory warranties set forth in any applica-
ble provincial or federal legislation.
Made in China
Imported by
Mastercraft Canada Toronto, Canada M4S 2B8

ARMOIRE BASSE
Modèle nº 068-0558-4
continuation tabs
IMPORTANT :
Veuillez lire attentivement ce guide avant d’assembler
et d’utiliser cette armoire haute et le conserver à titre de référence.
GUIDE
D’UTILISATION

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 062-3582-8 | contact us 1-800-689-9928
TABLE OF CONTENTS

1
TABLE DES MATIÈRES
TABLE DES MATIÈRES
2
3
4
11
Sécurité
Liste des pièces
Instructions d’assemblage
Garantie
REMARQUE :
Si des pièces sont manquantes ou endommagées, ou si vous avez des questions,
veuillez contacter notre service de soutien téléphonique sans frais au 1 800 689-9928.
CONSERVEZ CES INSTRUCTIONS
Le présent guide d’utilisation contient un mode d’emploi et des
consignes de sécurité importants. Lisez et respectez toutes les
instructions lorsque vous utilisez cet article.

2
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
Modèle n° 068-0558-4 | Contactez-nous au 1 800 689-9928
SÉCURITÉ
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 062-3582-8 | contact us 1-800-689-9928
• Pour réduire les risques de blessures graves, lisez les consignes de
sécurité suivantes avant d’assembler et d’utiliser l’armoire.
• Cette armoire est conçue pour un usage domestique, à l’intérieur
seulement.
• L’armoire doit être placée sur une surface plane.
• Tout assemblage ou entretien de l’armoire doit être effectué par des
adultes seulement.
• Demandez à d’autres personnes de vous aider à assembler et
déplacer l'armoire.
• Vérifiez périodiquement le serrage de tous les écrous et boulons.
Au besoin, resserrez-les.
• Utilisez un chiffon doux légèrement humide pour nettoyer l’armoire.
• Ne vous tenez pas debout sur l’armoire et ne l’utilisez pas comme
échafaudage.
• Ne dépassez pas la limite de poids spécifiée pour cette armoire.
Charge maximale de la tablette du milieu : 66 lb (30 kg).
Charge maximale du tiroir : 44 lb (20 kg).
Charge maximale de l'armoire : 320 lb (145,5 kg).
CONSERVEZ CES INSTRUCTIONS
Le présent guide d’utilisation contient un mode d’emploi et des
consignes de sécurité importants. Lisez et respectez toutes les
instructions lorsque vous utilisez cet article.

3
LISTE DES PIÈCES
LISTE DES PIÈCES
Nº
1
2
3
4
5
6
7
8
9
10
11
12
13
Nº
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
Description
Panneau arrière du tiroir
Panneau de fond du tiroir
Tapis de tiroir
Roue pivotante à blocage
Roue pivotante libre
Pare-chocs
Aimant
Tournevis
Vis M4 x 10
Vis M4 x 8
Vis M8 x 18
Vis M4 x 18
Crochet
Clé
Rondelle
Barre de tirage
Protecteur de coin A
Protecteur de coin B
Description
Panneau inférieur
Cadre avant
Panneau latéral droit
Panneau latéral gauche
Porte gauche
Panneau arrière inférieur
Panneau arrière supérieur
Porte droite
Tablette
Plateau en bois massif
Facade de tiroir
Panneau latéral gauche du tiroir
Panneau latéral droit du tiroir
Qté
1
1
1
1
1
1
1
1
1
1
1
1
1
Qté
1
1
1
2
2
4
2
1
57
25
16
16
4
2
6
1
1
1

4
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
Modèle n° 068-0558-4 | Contactez-nous au 1 800 689-9928
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 062-3582-8 | contact us 1-800-689-9928
INSTRUCTIONS D’ASSEMBLAGE
PRÉPARATION À L'ASSEMBLAGE
• Assemblez I'armoire sur une surface propre et plane.
• Retirez tous les éléments de la boite d'emballage et assurez-vous que toutes les
pièces énumérées à la page 3 sont disponibles.
• En installant les pièces qui ont plus d'une vis, serrez toutes les vis à la main
avant de les serrer avec le tournevis fourni.
INSTRUCTIONS D’ASSEMBLAGE
1. Ouvrez la boite cartonnée pour
retirer le plateau en bois massif (10)
et autres pieces (voir Fig.A).
2. Placez le cadre avant (2) aI'avant
du plateau en bois massif (10).
Insérez deux vis M4 x 10 (22) à
travers le cadre avant et serrez-les a
I'aide du tournevis (21) (voir Fig. B).
Remarque : Les trous de vis ont une
certaine tolérance.Veillez a ce que le dessus et
les cotes du cadre avant soient toujours
alignes avec le plateau de bois massif.Cela
permettra d'éviter le besoin de faire des
ajustements a la dernière étape, donc de
réduire le temps de montage.
Fig. A
Fig. B
