Masterflex L/S Series User manual

MASTERFLEX®L/S®SERIES
DIGITAL PROCESS
PUMP DRIVES
Quick Start Guide

DANGER: Remove power from the pump before any cleaning operation is started.
WARNINGS: Remove power from the pump before attempting any maintenance.
The Power switch on the Back Panel is not the main disconnect. A contactor or
other device that routinely disconnects and reapplies the AC line to the drive to
start and stop the motor can cause drive hardware damage. The drive is designed
to use control input signals that will start and stop the motor.
WARNINGS: Tubing breakage may result in fluid being sprayed from pump. Use
appropriate measures to protect operator and equipment.
Turn Pump System off before removing or installing tubing. Fingers or loose clothing
could be caught in drive mechanism.
CAUTIONS: Replace the fuse only with one of the same type and rating. The fuse
rating and type are stated on the rear panel.
Power must be turned off before connecting the external remote control cable to
prevent damage to the drive.
CAUTIONS: To avoid electrical shock, the power cord protective grounding
conductor must be connected to ground. Not for operation in wet locations as defined
by EN61010-1.
If the product is not used in a manner specified in the instructions, the protection
provided by the equipment may be impaired.
CAUTION: Risk of Danger. Consult Operator’s manual for nature of hazard and
corrective actions.
CAUTION: Risk of crushing. Keep fingers away from rotor while pump is in operation.
Stop pump before loading or unloading tubing.
CAUTION: Risk of electric shock. Consult Operator’s manual for nature of hazard
and corrective actions.
This product is not designed for, nor intended for use in patient connected
applications; including, but not limited to, medical and dental use, and accordingly
has not been submitted for FDA approval.
This product is not designed for, nor intended for use in hazardous duty areas as
defined by ATEX or the NEC (National Electrical Code); including, but not limited to
use with flammable liquids. Consult the factory for products suitable for these types
of applications.
SAFETY
PRECAUTIONS
!
Explanation of
Symbols
WARNING:
Product Use
Limitation
!
!
!
1
C2year
warranty RoHS ®
IP
66
EN61010-1:2001 L.V. DIR.
EN61326-1:2006 EMC DIR.
EN60529/ IEC 60034-5
07575-30, -40 0.1-600 rpm
70 dba @ 1M
+0C, +32F +40C, +104F
07575-30, -40
26 lbs (11.8 kg)
07575-30, -40 IP66 (NEMA 4X)
-25C, -13F +65C, +149F

Product Accessories
07575-80 Remote control cable 31-pin (NEMA 4X), 25ft (7.62m)
07575-84 Footswitch (NEMA 4X)
23
Step1 Step2 Step3
Screw in Motor cable Plug in Power Cable Switch On Power
1
Replacement Cord/Plug Sets Ordering Information
Catalog
Number
Catalog
Number
Catalog
Number
Description Description Description
50001-60
50001-62
50001-64
50001-68
50001-69
50001-70
50001-72
50001-74
50001-76
50001-78
—
—
Australia
Denmark
India
U.S. STD. 115V
Israel
Europe
England
Switzerland
Italy
U.S. 230V
—
—

Graphic Interface
4
5
LANGUAGE
IDIOMA
LANGUE
SPRACHE
LINGUA
MAIN MENU
MEN PRINCI PAL
MENU PRINCIPAL
HAUPTMEN
MENU PRINCIPALE
メインメニュー
CONTINUOUS MODE
MODO CONTINUO
MODE CONTINU
DAUERMODUS
MOD CONTINUA
SETUP
MONTAJE
INSTALLATION
SETUP
IMPOSTAZIONE
セットアップ
FLOW RATE
CAUDAL
DB IT
DURCHFLUSSRATE
INDICE DI FLUSSO
KEYPAD LOCKOUT
BLOQUEO DETECLADO
VERROUILLAGE CLAV.
TASTENFELDSPERRE
BLOCCO DEITASTI
REMOTE CONTROL
CONTROL REMOTO
TLC OMMANDE
FERNBEDIENUNG
CONTROLLO REMOTO
TUBING SIZE
TAMA O DEL TUBO
TAILLE DU TUYAU
ROHRLEITUNGSGR.
DIMENSIONE TUBI

Keypad Legend
PUMP DIRECTION
DIRECCI N BOMBA
DIRECTION POMPE
PUMPRICHTUNG
DIREZIONE POMPA
FLOW UNITS
UNIDADES DE FLUJO
UNITS DE DB IT
DURCHFLUSSEINHEIT
UNIT DI FLUSSO
ENTER
ENTRE
ENTRER
EINGABE
INSERIRE
START/STOP
INICIO/DETENCI N
DM ARRER/ARR˚TER
START/STOPP
AVVIO/ARRESTO
/
/
PRIME
CEBAR
AMOR˙ER
ANSAUGEN
ADESCARE
ANTI-DRIP
SIN GOTEO
ANTI-GOUTTES
KEIN TROEN
ANTISGOCCIOLO
6
7
CONTINUOUS MODE
MODO CONTINUO
MODE CONTINU
DAUERMODUS
MOD CONTINUA
CONTINUOUS MODE
MODO CONTINUO
MODE CONTINU
DAUERMODUS
MOD CONTINUA

COPY DISP. MODE
DUPLICAR DISP.
DISTR. REPETEE
WH.F RD .MOD.
MOD DIST COPIA
SETUP
MONTAJE
INSTALLATION
SETUP
IMPOSTAZIONE
セットアップ
VOL DISP. MODE
VOLUMEN DISP.
DISTR. VOLUME
MENG.F RD .MOD.
MOD DIST VOLUME
TIME DISP. MODE
TEMPORIZAR DISP.
DISTR. PROGRAM.
ZEITFR D.MOD.
MOD DIST TEMPO
FLOW UNITS
UNIDADES DE FLUJO
UNITS DE DB IT
DURCHFLUSSEINHEIT
UNIT DI FLUSSO
87
COPY DISP. MODE
DUPLICAR DISP.
DISTR. REPETEE
WH.F RD .MOD.
MOD DIST COPIA
8
9
SETUP
MONTAJE
INSTALLATION
SETUP
IMPOSTAZIONE
セットアップ
VOL DISP. MODE
VOLUMEN DISP.
DISTR. VOLUME
MENG.F RD .MOD.
MOD DIST VOLUME
TIME DISP. MODE
TEMPORIZAR DISP.
DISTR. PROGRAM.
ZEITFR D.MOD.
MOD DIST TEMPO
TUBING SIZE
TAMA O DEL TUBO
TAILLE DU TUYAU
ROHRLEITUNGSGR.
DIMENSIONE TUBI

9
TUBING CAL
CAL DE TUBER˝A
TALON. TUYAU
ROHRLEITUNGSKAL
TARATURA TUBI
FLOW RATE
CAUDAL
DB IT
DURCHFLUSSRATE
INDICE DI FLUSSO
ANTI-DRIP
SIN GOTEO
ANTI-GOUTTES
KEIN TROEN
ANTISGOCCIOLO
25
19148
3
1
2
7
13
18
24
29
31
30
1
3
5
7
9
11
13
15
2
4
6
8
10
12
14
20
22
16-19, 21
23, 26-31
24
25
Description
Pin No.
Circ.-31
Pin No. Circ.-31
Speed Control Voltage Input (0-10 V)
Speed Control Current Input (0-20 mA)
Speed Control Input Ground Return
Speed Signal Current Output (0-20 mA)
Speed Signal Output Ground Reference
(Motor Running N.O. Default) 1A @24V (Open Collector)
Motor Running Ground Return
(Motor Running N.C. Default) 1A @24V (Open Collector)
Speed Signal Voltage Output (0-10 V)
Remote Start/Stop Input
Remote CW/CCW Input
Remote Start/Stop, CW/CCW, Prime Grnd Ref.
Tach Ground Reference
Tach Output (open collector)
Remote Prime Input
General Alarm Output
Local/Remote Indicator
Reserved - Not Used
Reserved - Not Used
Aux 24V+
Aux 24V-

US & Canada only
Toll Free 1-800-MASTERFLEX | 1-800-637-3739
Outside US & Canada
1-847-381-7050
*EN809 manufactured by:
Masterflex LLC
28W092 Commercial Avenue, Barrington, IL 60010
[email protected] | www.masterflex.com
A-1299-1125B Edition 05
