Matrix G3 STRENGTH G3-S10 User manual

G3 STRENGTH
G3-S10 CHEST PRESS
MATRIX FITNESS | 1600 LANDMARK DRIVE COTTAGE GROVE WI 53527 USA
To l l Free 866.693.4863 matrixfitness.com Fax [phone]
PART # MH0204515B
REV. 2.1
ACTION FREQUENCY
Clean Upholstery Daily
Inspect Cables Daily
Clean Guide Rods Monthly
Inspect Hardware Monthly
Inspect Frame Bi-Annually
Clean Machine As Needed
Clean Grips As Needed
Lubricate Guide Rods As Needed
Upholstery & Grips should be cleaned with a non-ammonia based cleaner (like Simple Green) or a mild soap and water.
Guide rods should be lubricated with Teflon based lubricant. Apply the lubricant to a cotton cloth and then apply up and
down the guide rods.
MAINTENANCE CHECKLIST
PRODUCT SPECIFICATIONS
TECH SPECS
Overall dimensions 61”L X 49”W x 73”H (155 cm x 124.5 cm x 185.4 cm)
Weight 603.5 lbs (274 kg)
Shipping weight 650 lbs (295 kg)
WARRANTY (Valid in USA only)
Frame (not coatings) 10 years
Structural parts 10 years
Weight stacks 5 years
Pulleys 5 years
Pivot bearings 5 years
Any items not specified 3 years
Labor (excluding upholstery/cables/grips) 3 years
Upholstery/cables/grips/springs 1 year
IMPORTANT SAFETY INFORMATION
It is the sole responsibility of the purchaser of MATRIX Fitness Systems products to instruct all individuals, whether they
are the end user or supervising personnel on proper usage of the equipment.
It is recommended that all users of MATRIX Fitness Systems exercise equipment be informed of the following information
prior to its use.
PROPER USAGE
Do not use any equipment in any way other than designed or intended by the manufacturer. It is imperative that MATRIX
Fitness Systems equipment be used properly to avoid injury.
Keep hands and feet clear at all times from moving parts to avoid injury.
CHECK FOR DAMAGED PARTS
1. DO NOT use any equipment that is damaged and or has worn or broken parts. Use only replacement parts supplied by
your country’s local MATRIX Fitness Systems dealer.
2. MAINTAIN LABELS AND NAMEPLATES: Do not remove labels for any reason. They contain important information.
If unreadable or missing, contact your MATRIX Fitness Systems dealer for a replacement.
3. SECURING EQUIPMENT: All equipment MUST be secured to the floor to stabilize and eliminate rocking or tipping over.
This must be performed by a licensed contractor.
4. MAINTAIN ALL EQUIPMENT: Preventative maintenance is the key to smooth operating equipment as well as keeping
your liability to a minimum. Equipment needs to be inspected at regular intervals.
5. Ensure that any person(s) making adjustments or performing maintenance or repair of any kind is qualified to do so.
MATRIX Fitness Systems dealers will provide service and maintenance training at our corporate facility upon request.
WARNING: SERIOUS INJURY CAN OCCUR ON THIS EQUIPMENT. FOLLOW THESE PRECAUTIONS TO
AVOID INJURY!
1. Never allow children on freeweight or bench equipment. Teenagers must be supervised at all times while using
this equipment.
2. All warnings and instructions should be read and proper instruction obtained prior to use.
3. Cease exercise if you feel faint or dizzy. Obtain a medical exam before beginning an exercise program
4. Keep body, hair, clothing and fitness accessories free and clear of all moving parts.
5. Inspect the machine before use. DO NOT use machine if it appears damaged or inoperable.
6. This equipment should only be used in supervised areas where access and control are regulated by the owner.
S10_chest_press_r2.1.indd 1 12/13/10 9:00 AM

G3-S10 CHEST PRESS
UNPACKING G3-S10 CHEST PRESS
Thank you for purchasing a MATRIX Fitness product. This machine is an EN957-1 and EN957-2 complaint Class S product. Your
MATRIX G3-S10 CHEST PRESS is inspected before it is packaged. It is shipped in multiple pieces to facilitate the compact
packaging of the machine. Prior to assembly, confirm all the components by matching them with the exploded diagrams. Carefully
unpack the unit from this box and dispose of the packing materials in accordance with your local laws.
CAUTION
The weight of the G3-S10 CHEST PRESS is 603.5 lbs. (274 kg) including the weight stack. To avoid injury to yourself and prevent
damage to the frame components, be sure to have proper assistance removing the frame pieces from this box. Please be sure to
install the equipment on a stable base, properly level the machine and leave at least two feet of clearence to enter and exit the
machine. Maximum user weight for this machine is 300 lbs. (136 kg).
INCLUDED TOOLS REQUIRED FOR ASSEMBLY
6MM L-Shaped Allen Wrench
8MM L-Shaped Allen Wrench
10MM L-Shaped Allen Wrench
17MM Open-End Wrench
If any items are missing please contact your country’s local MATRIX dealer for assistance.
0mm 10 20 30 40 50 60 70 80 90 100 1
10 120 130 140 150 160
Step 1
Frame Detail
Arc-at Washer
Flat Washer(M10)
Screw (M10X25L)
G13
G12
D32
G14
8
16
24
Qty
16
Item
D32
G14
Description
G12
G13
G14
Screw
Flat Washer
Flat Washer
Screw
Screw
Arc-at Washer
Spring Washer(M10)
Spring Washer
Spring Washer
Step 2
Input Detail
D30
D16
H16
D22
D17
D16
D16
D17
H16
D22
D20
D20
D31
D16
Input Arm
Flat Washer
Screw
Screw
Flange Bushing
Flange Bushing
Input Arm Detail
D17
D16
D20
D22
Item Description
Screw (M12X25L)
Flat Washer(M12)
Lock Washer(M12)
Wavy Washer
Qty
2
2
2
D30
D31
H16
Bolt(M12X110L)
Flange Bushing
Nylon Nut(M12)
1
1
2
4
Step 3
Upholstery Detail
Item Description Qty
11G11 Screw (M10X25L)
G11
G11
Step 6
Accessory Detail
Qty
6
6
2
6
2
4
6
1
1
2
Water Bottle Holder
DescriptionItem
Screw (M8X30L)
Screw (M4X12L)
Description panel
Screw(M8X18L)
Internal Tooth Lock Washer(M4)
Weight Shield
Upper Cover
Rubber Shield Spacer
Rubber Tip Weight Shield Bolt(M8X40L)
B24
B26
B43
B46
B47
B51
Q01
Q02
Q05
Q06
Upper Cover
Towel / Water
Bottle Holder
AB1
B46
B47
Q01
Q06
Q05
Weight Shield
Q02
B51
B43
B26
B24
Step 4
Weight Stack Detail
K12
K12
L14
F19
F18
B26
K07
AL1
K18 L11 L09
K05
Top Plate Detail
Item Description Qty
B26 Screw (M8x30L) 2
F18 Flat Washer (M5) 4
F19 Lock Washer (M5) 4
K05 Knurled Belt Securing Insert 1
K07 Rubber Stack Cushions 2
K12 E-Clipper 4
K18 Flat Washer (M8) 2
L09 Screw (M8x20L) 2
L11 Lock Washer (M8) 2
L14 Screw (M5x16L) 4
Knurled Belt
Securing Insert Guide Rod
Guide Sleeve
Screw
Selector Pin
Top Weight
Step 5
Belt Routing Detail
F01
AF4
AF1
AF4
F02
F03
F18
F19
F13
1. Firstly, to use that shorter belt to cross ccover, and then to
x the small cam to ensure the belt xation plate is at the top
of the cam and at level. Secondly, to tighten the belt before
xing the xation plate on the other side. At the meantime,
keep around 30mm uncovering on two sides of the belt.
Finally, to x cam cover.
2. To x one side of the other belt at the botton of the big cam
rstly and then tighten the belt. Secondly, to x the other side
of the belt by xation pin. At the meantime, to keep around
30mm uncovering on two sides of the belt.
F02
Lock Washer (M5)
Flat Washer (M5)
Screw (M5x35L)
Belt Fixer
Belt
F13
12
12
12
1
Qty
1
6
F19
F18
F01
Item Description
F03
Belt
Lock Washer
Belt Fixer
Belt
Screw
Flat Washer
