Matrix SPARSH VP330 User manual

Thank you for choosing SPARSH VP330! Please read this guide first for correct
installation and retain it for future reference. The information in this guide was
current at the time of publication. All specifications are subject to change
without notice.
This Guide is meant to help you install and connect the phone. For detailed
installation instructions, refer to the ETERNITY/NAVAN System Manual.
Copyright
All rights reserved. No part of this document may be copied or reproduced in any form
or by any means without the prior written consent of Matrix Comsec Pvt. Ltd.
Warranty
Limited Warranty. Valid only if primary protection is provided, mains supply is within limit
and protected, and environment conditions maintained within product specifications.
Complete warranty statement is available on our website: www.MatrixComSec.com
SELECT A LOCATION
Step 1
Ÿ Phone Body with Handset
Ÿ RJ45 Cable
Ÿ Power Adapter 5V, 2.0 Amp.
Ÿ 4P4C Spring Cord
Ÿ A Foot Stand
Ÿ A Warranty Card Set
Ÿ Wall Mounting Template
Ÿ Quick Installation Guide (printed copy)
Know Your SPARSH VP330
What Your Package Contains
Installing SPARSH VP330
You can mount the phone on a wall or on the desk.
Mount SPARSH VP330 on a Wall
Ÿ Use the mounting template to drill holes of appropriate size and distance.
Ÿ Fix the screw grips in the holes you drilled.
Ÿ Fix two screws in the holes on the wall, ensuring that they are aligned
with the Keyhole Slots 1 and 2 of SPARSH VP330. The screws should
protrude from the wall to fit into the Keyhole Slots.
Ÿ Now, mount the phone with the screws fitting into the Keyhole Slots.
Mount SPARSH VP330 on the Desk
Handset
Speaker key
Volume decrease key
LCD Screen
Ringer LED
DSS keys
Volume increase key
Dial Pad
1
2
3
4
5
6
7
8
9
Fixed Function keys
123
456
789
0
*#
abc def
ghi jkl mno
pqrs tuv wxyz
2
3
1
4
8 7 6
95
Ÿ You can attach the Foot Stand in the following ways - at an angle of 35
degrees and 50 degrees.
Keyhole
Slot 2
Keyhole
Slot 1

MATRIX COMSEC
Head Office
394-GIDC, Makarpura, Vadodara - 390010, India
Tel.:[phone], Fax: [phone]
E-mail: [email protected]
Manufacturing Unit
19-GIDC, Waghodia - 391760,Dist. Vadodara, India
Tel.:[phone]
Customer Care
Tel.: [phone]
E-mail: Customer[email protected], Suppor[email protected]
www.MatrixComSec.com
Version 1, October 2014.
Connect the Headset (not supplied by Matrix)
If you want to use a Headset,
Ÿ Plug any standard stereo headset with 3.5mm single connector into the
headset jack with the symbol on the left side panel of the phone.
Ÿ You may also plug in a stereo headset with RJ9 connector into the headset
port on the left side panel of the phone, marked with the symbol . Ÿ When the IP Phone is connected to the network and supplied with power, the
booting process initiates.
Ÿ After loading the application, the phone obtains the Network Settings,
updates the Firmware (if required), obtains the Configuration and then
attempts to register.
Ÿ To configure and register the phone as a SIP Extension, refer to the
ETERNITY/NAVAN System Manual. For operating instructions refer to the
SPARSH VP330 User Guide. Both the documents are available on the CD
ROM provided to you with the ETERNITY/NAVAN System.
STARTUP AND OPERATE
Step 3
CONNECT
Step 2
Connect the Handset
Ÿ Connect the handset of the SPARSH VP330 to the phone body using the
spring cord.
4. 5.
Connect the IP Network
You can connect to the network using the Ethernet cable or Wireless USB
Adapter.
Ÿ Connect the LAN Port of the phone to the IP Network — A DSL Modem /
router or LAN Switch — using the Ethernet cable.
OR
Ÿ Connect the Wireless USB Adapter into the USB port of the phone.
Note: You can purchase the Wireless USB Adapter as an optional peripheral
device to support wireless network from Matrix.
Connect a PC to the Phone
Ÿ Plug in the Ethernet cable into the PC Port of the phone and the other end into
the LAN Port of your PC.
Connect the Power Supply
Ÿ Plug in the connector of the Adapter provided with the phone into the power
jack (DC Jack) with the label at the back of the phone.
Ÿ Plug in the Power adapter into a power outlet.
Note: Do not connect the Adapter, if you are powering your PoE enabled
phone with a LAN Switch that supports Power over Ethernet (PoE as per IEEE
802.3af).
6.
Handset
Headset
Headset
Stand attached at
35 degree angle
5VDC--2A(Max)
LAN
PC
Adapter
Router /
DSL Modem
Computer
USB Dongle
Stand attached at
50 degree angle
