McHale Fusion 2 Operating manual

Fusion 2
Fusion 2Fusion 2
Fusion 2
Technical Service Manual
Issue 1
McHale Engineering Limited,
Castlebar Rd, Ballinrobe
Co. Mayo, Ireland.
Tel [phone]
Fax [phone]
Email [email protected]
WWW.MCHALE.NET
WWW.MCHALE.NETWWW.MCHALE.NET
WWW.MCHALE.NET

Introduction
Table of contents
Getting Familiar with the Fusion 2
General Safety
Specific Safety Warnings
Tractor Requirements & Preparations
Baler Requirements and Preparation
Wrapper Operation
Baler Field Operation & Adjustments
Machine Maintenance
Electronic Control System
Hydraulic and Lubrication Systems
Drive Systems
Trouble Shooting
Technical Specifications
1.
12.
13.
14.
15.
11.
10.
9.
4.
5.
6.
7.
8.
2.
3.

McHale Fusion 2
McHale Fusion 2 round baler wrapper technical service manual
Issue 1: 0208

McHale Fusion 2 Introduction section 01-1
McHale Fusion 2 round baler wrapper technical service manual Issue 1: 0208
Section 1
Fusion 2 Introduction

McHale Fusion 2 Introduction section
01-2
McHale Fusion 2 round baler wrapper technical service manual
Issue : 0208
1. Introduction
The McHale Fusion 2 round baler wrapper combination is a completely new
product. This product combines the baling process with the wrapping process all in
one machine. The design has been carried out on the basis of long term constant
research and development in the field of round bale wrappers and round balers.
The following service manual has been compiled from feedback received from
service personnel and importers who have worked on and serviced the machine in
the field.
As a result this manual provides information on the electronic systems (section 11)
and hydraulic systems (section 12) used on the machine. It also provides general
information in relation to machine maintenance (section 10) and also give a
service technician guidelines with regard to trouble shooting problems (section
14).
It is important that everybody who services and supports this machine in the field
reads and understands this manual before conducting tests or replacing parts
on the machine.
If any of the instructions appear unclear do not hesitate to contact your McHale
supplier. It is vital to replace defective parts of the machine immediately and to
use only genuine McHale spare parts, as these are designed and manufactured to
the same standard as the original machine obtained from your McHale Supplier .
If you feel that any areas should be added to this manual for
future editions, please email through your suggestions to
[email protected].
Your feedback is invaluable!
Thank you in advance for your help.
Note: This manual provides guideline only, and as a rule, it is highly
recommended to get acquainted slowly at first with any new machinery. Take
the time to both learn and understand all the features of the machine.
If you require further copies of this technical service manual, please quote part
number: CLT00079
Due to a policy of continuous product development and improvement, McHale Engineering Ltd.
reserves the right to alter machine specifications without prior notice. Please note that all
specifications marked with an in this manual only relate to certain models or optional equipment.
Also these specifications may not be available in all countries.

McHale Fusion 2 round baler wrapper technical service manual Issue 1: 0208
2. Contents
Section Page
1. Introduction …...………………………………………………….. 01-1
2. Contents ……………………………………………………………... 02-1
3. Getting familiar with the McHale Fusion 2 ……………………….. 03-1
4. General Safety
4.1 Be aware of all safety information………………………….. 04-1
4.2 Follow all safety instructions………………………………... 04-1
4.3 Store all items carefully …………………………………... 04-1
4.4 Protective clothing …………………………………………. 04-1
4.5 In case of emergencies …………………………………… 04-2
4.6 Stay clear of rotating elements ……………………..……... 04-2
4.7 Operating the McHale Fusion 2 with safety……………….. 04-2
4.8 In the event of a fire ………………………………………... 04-2
4.9 General safety warnings ………………………………….. 04-3
5. Specific safety warnings
5.1 Electronic safety warnings…………………………………. 05-1
5.2 Hydraulic safety warnings…………………………………. 05-1
5.3 Noise level……………………………………………………. 05-2
5.4 Fire precautions……………………………………………... 05-2
5.5 Special safety devices/ instructions ……………………. 05-2
5.6 Safety/ instruction decal locations ……………………. 05-3
5.7 Description of safety warnings and instructions……... 05-5
5.8 Description of the serial number plate…..……………… 05-9
5.9 Machine lifting eye location points ……………………. 05-10
6. Tractor requirements and preparations
6.1 Tractor requirements………………………………………. 06-1
6.2 Control box installation……………………………………. 06-1
6.3 Lighting system…………...………………………………. 06-2
6.4 Attaching the Fusion 2 to a 540 rpm PTO………..…………… 06-2
6.5 Attaching to drawbar……………………...…………….. 06-2
6.6 Attaching breakaway brake………………………………... 06-2
6.7 What is the hydraulic system on the tractor and
how does it affect the Fusion 2 set-up ?……………… ... 06-3
6.8 What hydraulic system does the tractor use? ………. 06-4
6.9 Hydraulic spool valve set-up ………………………….. 06-5
6.10 Attaching hydraulic hosing to tractor ……………… 06-6
McHale Fusion 2 contents section 02-i

McHale Fusion 2 round baler wrapper technical service manual
Issue 1: 0208
McHale Fusion 2 contents section
02-ii
Section Page
7. Baler requirements and preparation
7.1 Net requirements…………………………………………... 07-1
7.2 Care of the net roll ……………………………………... 07-1
7.3 Care of the net wrapping system……………………….. 07-1
7.4 Loading netter system……………………………………. 07-2
7.5 Net cutter setting………………………………………….. 07-3
7.6 Net tension bar setting……………………………………. 07-4
7.7 Chopper unit knife removal and installation…………. 07-5
7.8 Automatic lubrication system ……………………….... 07-7
7.9 Gear box oil………………………………………………… 07-8
7.10 Tyre inflation pressures ………………………………. 07-8
7.11 Drawbar and PTO shaft stand usage…………………. 07-9
7.12 Drawbar adjustment ………………………………. 07-11
7.13 PTO shaft adjustment ………………………………. 07-11
8. Wrapper operation
8.1 Loading plastic film ……………………………………. 08-1
8.2 Plastic film requirements ……………………………... 08-3
8.3 Wrapping process ……………………………………. 08-4
8.4 Dispenser adjustment ……………………………… 08-4
8.5 Cut and hold system ……………………………………. 08-5
Cut and hold Rail Adjustment…………………… 08-6
Cut and hold horizontal position adjustment…... 08-6
8.6 Dispenser gear options ……………………………….. 08-7
9. Baler field operation and adjustments
9.1 Break in period………………………………………….. 09-1
9.2 Swath preparation ……………………………………. 09-1
9.3 Pick-up adjustment ……………………………………. 09-2
9.4 Crop guard adjustment ……………………………... 09-2
9.5 Unblocking system ……………………………………. 09-3
9.6 Chopping system …………………………………… 09-4
9.7 Knife pressure gauge …………………………………. 09-4
9.8 Bale density gauge ……………………………………. 09-5
9.9 Setting chamber pre-charge pressure…………… 09-5
9.10 Chamber door lock ……...……………………… 09-6
9.11 Spare film holders and door safety latch operation 09-6
9.12 Adjusting pick-up float spring……………………….. 09-7

McHale Fusion 2 round baler wrapper technical service manual Issue 1: 0208
Section Page
McHale Fusion 2 contents section 02-iii
10. Machine maintenance
10.1 Maintenance intervals………………………………………. 10-1
10.2 Maintenance intervals/ recommended service……….. 10-2
10.2.1 Replace cam bearings………………………………... 10-3
10.2.2 Check key way on pick-up reel sprocket ……………. 10-3
10.2.3 Check chain tensioners………………………………. 10-4
10.2.4 Chain tension adjustment………………………….. .. 10-4
10.2.5 Check for broken magnets on the knife unit……….. 10-5
10.2.6 Ensure all oiler pipes to the chain and grease pipes
to the bearings are not damaged…………………… 10-5
10.2.7 Check roll pins/ bolts on the knife holder bracket…. 10-6
10.2.8 Check spiral pins on tine bars………………………. 10-6
10.2.9 Check spur gears……………………………………... 10-7
10.2.10 Replace bearing on pick up reel shaft……………… 10-7
10.2.11 Grease pick up reel shaft and slip clutch bearing… 10-8
10.2.12 Check left/ right auger……………………………….. 10-9
10.2.13 Replace rotor drive side bearing………………….… 10-10
10.3 Density pressure check …………. .….…………………… 10-11
10.4 Replace nilos ring ………………..………………………… 10-12
10.4.1 Check bolts on chamber door hinges …………...…. 10-13
10.4.2 Remove top door chamber panels and blow out …… 10-14
10.4.3 Check brake pads on dispenser ring………………… 10-15
10.4.4 Replacing ring brake pads ………..….……………… 10-16
10.4.5 Lubricate wrapper roller drive chains ...……………… 10-17
10.5 Check dispenser for tack/ glue build up……………….... 10-18
10.5.1 Grease dispenser springs..…………………………… 10-18
10.5.2 Clean cut and tie rails…….………………...………… 10-19
10.5.3 Check cut and tier bearing alignment………………. 10-19
10.5.4 Clean and oil all chains and grease all bearings….... 10-20
10.5.5 Clean the netter unit and apply grease………………. 10-20
10.5.6 Apply grease to exposed ram rods….………………. 10-20
10.5.7 Clean & lubricate the rollers in the bale chamber…. 10-20
10.5.8 Apply oil/ spray grease to the knifes ….………………. 10-20
10.5.9 Change the gearbox oil…………...….………………. 10-20
10.5.10 Apply oil/ spray grease to the knifes ….……………. 10-20
10.5.10 Start of season machine preparation…………..…… 10-21
10.5 Chain Adjustment………………………….……………….... 10-22
10.6.1 Main drive chain adjustment..…………………………… 10-22
10.6.2 Bottom chamber chain adjustment..…………………… 10-22
10.6.3 Top chamber chain adjustment..……………………... 10-23
10.6.4 Bottom door to drive chain adjustment..……………… 10-24
10.6.5 Pick up reel tine chain adjustment..…………………… 10-24
10.6.6 Reel chain adjustment………………………………….. 10-24
10.6.7 Chopper unit duplex chain adjustment………………… 10-25

McHale Fusion 2 round baler wrapper technical service manual
Issue 1: 0208
Section Page
McHale Fusion 2 contents section 02-iv
11. Electronic control system
11.1 Component location…...……………………………… 11-2
11.2 Electrical Control parts……………………………….. 11-2
11.2.1 Net feed clutch……………………………………. 11-4
11.2.2 Chamber fully open sensor………………….... 11-4
11.2.3 Dispenser rotation sensor ………………………. 11-5
11.2.4 Motor speed sensor………………………………. 11-5
11.2.5 Dispenser rotate button…………………………….. 11-6
11.2.6 Chamber full sensor………………………………. 11-6
11.2.7 Safety switch access door and tip sensor……….. 11-7
11.2.8 PWM constant current module…………………… 11-8
11.2.9 Net cut sensor………………………………………. 11-8
11.2.10 By pass valve…………………………………… 11-9
11.2.11 Film Monitoring Operation………………………… 11-10
11.2.12 Control Box……………………………………….. 11-12
11.3 Electonic component operation………………………….. 11-13
11.3.1 Control system……………………………………. 11-13
11.3.2 Control box………………………………………... 11-13
11.3.3 Normal cycle operation……………………………. 11-1
11.4 Sensor testing…………………………………………………. 11-14
11.4.1 Reed Sensor testing…………………………………. 11-14
11.4.2 Proximity sensor testing……………………………… 11-15
11.5 Wiring diagrams………………………………………………. 11-16
11.5.1 Safety warnings……………………………………. 11-16
11.5.2 Wiring loom sections……….………………….... 11-16
11.5.3 Guide to wiring diagrams………………………. 11-17
11.5.4 Main hydraulic valve solenoids……………………. 11-17
11.5.5 Wiring scheme…………………………………... 11-18
11.5.6 Forward rotate circuit………………………………. 11-20
11.5.7 Reverse rotate circuit…………………...……….. 11-21
11.6 Electrical control box………………………………………… 11-22
11.6.1 Control box functions…………………………………… 11-22
11.6.2 Menu structure………..………………………………… 11-24
11.6.3 Control box features…………………………………… 11-26
11.6.4 Error messages and their meaning…………………… 11-32
11.7 Running a simulated “bale to wrapping cycle”…………… 11-35
11.7 Fusion 2 input/ output tests…………………...…………… 11-36
11.7 Uploading expert plus software……………………………. 11-37

McHale Fusion 2 round baler wrapper technical service manual Issue 1: 0208
Section Page
McHale Fusion 2 contents section 02-v
12. Hydraulic Systems Overview
12.1 What is the hydraulic system on the tractor and how does it
affect the Fusion 2 set up………………………………………… 12-1
12.2 What hydraulic system does the tractor use?…………………12-2
12.3 Hydraulic spool valve set up…………………………………… 12-3
12.4 Attaching hydraulic hosing to the tractor………………………12-4
12.5 Fusion main schematic………………………………………… 12-5
12.6 Main valve overview…………………………………………… 12-6
12.6.1 Main valve port functions……………………….…….. 12-7
12.6.2 Main valve break down………………………….…….. 12-8
12.6.3 Hydraulic system valve assembly…………………….. 12-9
12.7 Bale density valve……………………………………………….. 12-10
12.7.1 Setting the chamber pre-charge pressure…………… 12-10
12.7.2 Bale density valve break down……………………..… 12-11
12.7.3 Chamber holding pressure…………….…………..…. 12-12
12.7.4 Accumulator test………………………………………. 12-13
12.8 Knife/ floor valve overview………………………………………. 12-14
12.8.1 Knife/ floor valve breakdown……………………………. 12-15
12.8.2 Valve trouble shooting……………………………………….12-16
12.9 Rotate, tip, bypass valve………………………………………… 12-17
12.9.1 Rotation, tip, bypass valve breakdown………………. 12-18
12.9.1 Rotation, tip, bypass valve ports……...………………. 12-19
12.9.3 Wrapper during normal operation……………………… 12-20
12.9.4 Wrapper during 50?50 operation………………………. 12-21
12.9.5 Wrapper ring reverse…………………………………….. 12-22
12.10 Cut and hold (800 mm stroke) open and close……………. 12-23
12.10.1 Cut and hold (50 mm stoke) release………………… 12-24
12.11 Tip arm down…………………………………...……………. 12-25
12.11.1 Tip Arm up/ Oiler cycle…………………………….. 12.26
12.12 Lubrication system……………………………………………. 12-27
12.12.1 Oiler and greaser components………………………… 12-28
12.12.2 Oiler and greaser system; Schematic………………… 12-29
12.12.3 Oiler and greaser system fittings……………………. 12-30
12.12.4 Oiler and greaser system; fittings at block……………. 12-31
12.12.5 Oiler and greaser system fittings at ends………………. 12-32

McHale Fusion 2 round baler wrapper technical service manual
Issue 1: 0208
Section Page
McHale Fusion 2 contents section 02-vi
13. Drive Systems
13.1 Gearbox……………………………………………………………. 13-2
13.2 Chamber drive side……………………………………………… 13-2
13.3 Chopper/ pick up drive………………………………………….. 13-5
13.4 Chains and belts………………………………………………….. 13-6
13.5 Roller locations…………………………………………………… 13-7
13.5.1 Baler chamber rollers…………………………………… 13.8
13.5.2 Procedure for removing the sprocket from the roller…. 13-9
13.5.3 Procedure for reassembly of sprocket on the roller shaft..13-10
13.5.4 Procedure for removing splined shaft sprocket ……….13-11
13.5.5 Procedure for for reassembly of sprocket (splined shaft) 13-12
13.6 Netter clutch unit…………………………………………………… 13-13
13.7 Slip clutch settings/ torque adjustments……………………….13-15

McHale Fusion 2 round baler wrapper technical service manual Issue 1: 0208
Section Page
McHale Fusion 2 contents section 02-vii
14. Trouble Shooting
14.1 Trouble shooting overview…………………………………. 14-1
14.2 Machine using higher than expected hp when chopping 14-1
14.3 Pick up slip clutch going off easily…………………………. 14-1
14.4 Rotor clutch going off easily…………………………………. 14-2
14.5 Knives not remaining up while chopping………………….. 14-2
14.6 Chamber losing pressure…………………………………….. 14-3
14.7 Machine making soft bales…………………………………… 14-3
14.8 Net will not feed during an automatic cycle……………….. 14-4
14.9 Net not cut correctly……………………………………………. 14-4
14.10 Net feeds in, in the middle of a bale…………………………. 14-5
14.11 Netting process complete but chamber door will not open 14-5
14.12 Safety switch error……………………………………………… 14-6
14.13 Bale transfer starts but bale fails to transfer to wrapper… 14-6
14.14 Wrapper will not start after bale transfer……………………. 14-7
14.15 Ring will not rotate even though the motors are rotating.. 14-7
14.16 Film break error when the film is not broken or run out…. 14-8
14.17 Dispenser breaking plastic……………………………………. 14-8
14.18 Cut and hold not going out all the way……………………… 14-9
14.19 Cut and hold not cutting clean………………………………… 14-9
14.20 Cut and hold releasing while the machine is baling………. 14-9
14.21 Wrapper not counting/ counting incorrectly………………… 14-10
14.22 Wrapper won’t index by a 1/2 rotation from the button…… 14-10
14.23 Dispenser moving out of position during work…………….. 14-11
14.24 Hydraulic wheel brake sticking………………………………… 14-11
14.25 Control box setting altered……………………..……………….. 14-11
15. Technical Specifications
15.1 General dimensions/ specifications……………………………..15-1
15.2 Tractor attachment………………………………………………….15-1
15.3 Machine specifications……………………………………………. 15-1
15.4 Tightening torque values…………………………………………..15-2
15.5 Tyre specifications………………………………………………….15-3
15.6 Deceleration of conformity……………………………………….. 15-3

McHale Fusion 2 round baler wrapper technical service manual
Issue 1: 0208
McHale Fusion 2 contents section 02-viii

McHale Fusion 2 main component reference section 03-1
McHale Fusion 2 round baler wrapper technical service manual
Issue 1: 0208
3. Getting familiar with the McHale Fusion 2

McHale Fusion 2 main component reference section 03-2
McHale Fusion 2 round baler wrapper technical service manual
Issue 1: 0208

McHale Fusion 2 round baler wrapper technical service manual Issue 1: 0208
McHale Fusion 2 generic safety section 04-1
4. General Safety
4.1 Be aware of all safety information
The symbol opposite is the symbol used to alert you to safety
issues. It appears both in this manual and on some of the safety
decals. On the decals it appears on a yellow background while in
this manual it appears in black and white.
Follow all safety precautions and practice safe operation of all
machinery at all times.
When reading through this manual, pay attention to where you see the above
symbol paying extra care to where you will see the Warning and Caution pointers.
4.2 Follow all safety instructions
Using this manual, read all safety instructions, messages and be
aware of the meanings of all safety decals. Ensure, if safety decals
are damaged or missing due to wear and tear or due to component
replacement, that they be replaced. Use the Decals section in the
provided spare parts book as a handy reference for spare part
codes and relevant decals, which are available from your McHale
dealer.
As with all machinery, learn all operations and use of controls by reading this
manual thoroughly. Do not attempt to let anyone operate this machine without
being fully instructed.
4.3 Store all items carefully
Store all attachments such as spare net rolls, film rolls and any
other stored items in a secure and safe manner so as to prevent
items from falling. Keep storage areas clear of bystanders and
children.
4.4 Protective clothing
Always wear clothing and safety equipment that is fit for the job
at hand, never wear loose clothing. In the event of loud noises,
wear suitable protective hearing devices. Use of radio (walkman)
headphones are not recommended while operating machinery
as this impairs operators attention.

McHale Fusion 2 round baler wrapper technical service manual
Issue 1: 0208
McHale Fusion 2 generic safety section
04-2
4.5 In case of emergencies
In the event of any accident, emergency
equipment should be kept close at hand. A first
aid kit and fire extinguisher along with emergency
phone numbers should always be available to
machine operators.
4.6 Stay clear of rotating elements
Serious injury or death can result from entanglement of clothing or body parts with
PTO shafts, drivelines and other rotating and moving components.
Keep all guards in place at all times, only wear close fitting clothing and ensure that
tractor engine has stopped, key removed and that PTO has stopped turning
before carrying out any adjustments, connections or cleaning of PTO driven
equipment.
4.7 Operating the McHale Fusion 2 safely
In order to avoid serious injury or even death by being pulled into the machine:
1. Never attempt to feed net or crop into the baling chamber or attempt to unplug
pick-up area while the baler is running.
2. Disengage PTO, shut tractor engine off and remove the key.
3. Stand well clear of baler and tractor when machine is operating.
4.8 In the event of a fire
In the event of a fire, the following is only given as a guideline procedure,
as it is the operators decision to ascertain the seriousness and hence the
solution to the situation.
1. Switch control box to manual mode (see section on Electronic control system).
Immediately tip bale off rear roller, leave roller in tipped position.
2. Eject bale from baling chamber by opening chamber doors.
3. Move tractor and baler away from the flammable material.
4. Disengage PTO, turn off tractor and remove key. Remove all hosing and
electrical looms from the machine.
5. With all connections removed, disengage drawbar from tractor. Drive tractor
away from baler.
6. Using a suitable fire extinguisher put out all fires.
Note: It is recommended that the baler be kept reasonably clean and free of
build-ups of grass, lubricants etc., this will help to reduce the risk of fires.

McHale Fusion 2 round baler wrapper technical service manual Issue 1: 0208
McHale Fusion 2 generic safety section 04-3
4.9 General safety warnings
¾Read and understand this operator’s manual before using the machine. If any
of the instructions appear unclear do not hesitate to contact your McHale
dealer.
¾Only competent persons who have read and fully understood this manual are
qualified to operate this machine. The owner of this machine is obliged by law
to ensure that every operator must understand all the functions, controls,
working processes and safety warnings before operating the machine.
¾All safety devices such as guards, protection parts and safety controls must
be in place and in fully functioning condition. It is forbidden to operate this
machine with defective or incomplete safety devices (never disable or defeat
any electrical safety circuits).
¾All safety decals on the machine must be kept in good condition. If they are
not, they must be replaced by genuine McHale decals from your McHale
dealer (part numbers are available in this manual).
¾Before operating this machine, the operator must ensure that all covers are
closed and all safety devices are in operating mode.
¾Before operating this machine the operator must ensure that the
manufacturer’s instructions for attaching and detaching the machine are
followed. This includes the drawbar attachment, the electric and hydraulic
lines, in particular the lighting and brake system.

McHale Fusion 2 round baler wrapper technical service manual
Issue 1: 0208
McHale Fusion 2 generic safety section
04-4
¾Before operating this machine the operator must ensure that no persons or
animals are carried on the machine or are hidden under the machine (on the
tractor persons are only allowed to sit on the relevant seats).
¾Before operating this machine the operator must ensure that there is no
person in the “danger zone” (in front of tractor, between tractor and round
baler wrapper combination, and a minimum of 5 m behind the machine).
Note: It is the operator’s responsibility to keep all people out of this area!
In this area a person is subject to a risk to his/her own health or safety!”
¾While operating this machine on hilly or sloping ground the operator must
take extra precautions, in particular the “danger zone” is increased in such
conditions as bales are more likely to roll away causing a potential risk.
¾While operating this machine the operator must ensure that there is a
minimum of 4 m clearance between the machine and any obstacle above, in
particular electrical high voltage lines.
¾Before working on this machine, such as replacing net or film rolls, clearing
forage away from any part of the machine or altering any setting, the operator
must ensure that the tractor has definitely stopped moving, handbrake is
applied, engine has stopped and ignition key is removed, PTO shaft is
removed from pto stub and electric power supply is disconnected. It is
forbidden to open any safety guards or to carry out any work on the machine
unless the above-specified precautions have been carried out.
¾Warning! If carrying out inspection during machine operation within the danger
zone (highly dangerous and not recommended!), then there should be a
trained and fully competent second person operating both the tractor and baler
controls. If at any time the second operator loses sight of the inspector, turn off
all tractor power immediately! Such inspection should only be carried out if all
guards are fully in place, machine on level ground and a safe distance from the
machine maintained from any hazards on the machine e.g. pick-up region.
¾Maintenance and repair work on this machine should always be carried out
in accordance with this manual.
¾Maintenance and repair work exceeding the content of this manual should
only be carried out by qualified persons or your McHale dealer.
¾Before travelling on public roads the owner of this machine is obliged by law
to ensure that every operator has got a valid driving licence and is familiar with
the road traffic regulations relating to the country of use.
¾Ensure that no bale is carried on the wrapper section, while travelling on
public roads.
¾When parking both wheels of this machine have to be blocked using wheel
chocks according to the road traffic regulations relating to the country of use.

McHale Fusion 2 specific section 05-1
McHale Fusion 2 round baler wrapper technical service manual Issue 1: 0208
5. Specific safety warnings
5.1 Electronic safety warnings
¾This machine is equipped with electronic parts and components which comply
to the EMC directive 89/336/EEC but still may be influenced by
electromagnetic transmissions of other apparatus, such as welding machines,
etc.
¾Check electric cables regularly for signs of breakage or wear. If in doubt
always replace (faulty safety circuits will cause risks).
¾Do not modify any safety circuits.
5.2 Hydraulic safety warnings
¾The maximum pressure in the hydraulic system of this machine should not
exceed 210 bar.
¾Always ensure system is not under pressure before working on the machine.
Oil under pressure can penetrate the skin and cause injury. Beware of pipes
under accumulator pressure, depressurise lines by unthreading connections
extremely slowly.
¾Hydraulically actuated devices, such as pick-up, cutting device and wrapping
ring, must be blocked mechanically against movement, before working on the
machine.
¾If any hoses are removed or replaced ensure they are marked and re-installed
to the correct position during re-assembly.
¾Check hoses regularly for signs of leakage or wear. If in doubt always
replace – the recommended maximum working time of hoses should not
exceed 5 years. Only use exact specification, McHale genuine replacement
parts.
¾Do not work on hydraulic systems unless you are qualified to do so, this work
should only be carried out by qualified persons or your McHale dealer.
