Meanwell CSP Series User manual

Installation Manual
Type：Enclosed Type Switching Power Supply
(Families: C S P, ENP, ERP, G3, HDP, HEP, HRP, HRP-N, HRP-N3, HRPG, HSP, LRS, MSP,
NED, NEL, NES, N S P, PSP, PSPA, Q P, RS, RSP, RST, SE, S P, SPV, TP, U H P, USP)
Introduction
Enclosed type switching power supplies possess a metal or plastic case for covering their internal PCB and will be
installed inside the case of the end system. Mean Well’s enclosed type power supplies include 2 different groups of
power supplies, with built-in fan and without built-in fan, depending on their rated power or design concept.
Installation
（1）Before any installation or maintenance work, please disconnect your system from the utility.
Ensure that it can’t be re-connected inadvertently!
（2）Keep enough insulation distance between mounting screws and internal components of power supplies. Please
refer to case drawing on specifications to receive the maximum length of mounting screw.
（3）Mounting orientations other than standard orientation or operate under high ambient temperature may
increase the internal component temperature and will require a de-rating in output current. Please refer to
the specification sheets to receive the optimum mounting position and information about the de-rating curve.
（4）Fans and ventilation holes must be kept free from any obstructions. Also a 10-15 cm clearance must be kept
when the adjacent device is a heat source.
（5）Input and Output terminal
Terminal Screw
Series
Screw Size Suggested
Torque
RSP-750 / 1000 / 1500 / 2000 / 2400 / 3000
SE-450 / 1000 / 1500
HEP-600，HRP-300，HRP-300N，HRP-300N3，HRPG-300，MSP-300
SP-480
，
SP-750
，
SPV-1500
，
USP-500
，
RST-10000
M4 10-12kgf-cm
HRP-075 / 100 / 150 / 150N / 150N3 / 200，HRPG-150 / 200
LRS-035 / 050 / 075 / 100 / 150 / 150F / 200 / 350
MSP-100 / 200
NED-035 / 050 / 075 / 100，NET-035 / 050 / 075
NES-025 / 035 / 050 / 075 / 100 / 150 / 200 / 350
QP-200 / 320 / 375
RD-050 / 065 / 085 / 125，RID-050 / 065 / 085 / 125
RS-035 / 050 / 075 / 100 / 150
RSP-075 / 100 / 150 / 200 / 320
SP-075 / 100 / 150 / 200 / 240 / 320，SPV-150/300
SE-100 / 200 / 350，HSP-250，PSP-600
M3.5 8-10 kgf-cm
RSP-1600
RD-035，RT-050 / 065 / 085 / 125
RQ-050 / 065 / 085 / 125
TP-075 / 100 / 150，QP-100 / 150
RS-015 / 025
NES-015，USP-150
NSP-1600 / 3200
M3 6-8 kgf-cm
ERP-350
HDP-190 / 240
NEL-200 / 300
#6 8-10 kgf-cm

Installation Manual
ENP-120 / 180 / 240 / 360 M2.6 4-5 kgf-cm
Terminal Screw
Series
Input Output
Screw Size Suggested
Torque Screw Size Suggested
Torque
HRP-450 / 600 / 600N / 600N3
HRPG-450 / 600
MSP-450 / 600 / 1000
SE-600
M3 6-8kgf-cm M4 10-12kgf-cm
HSP-150 / 200 /300
HSN-200 / 300 M3 6-8kgf-cm M3.5 8-10kgf-cm
RSP-500 M3.5 8-10kgf-cm M4 10-12kgf-cm
RST-5000 M4 10-12kgf-cm M8 10-12kgf-cm
NEL-400 #6 8-10kgf-cm M3 8-10kgf-cm
UHP-200(R) / 350(R) M3 5kgf-cm M3.5 8kgf-cm
UHP-200A M3.5 13kgf-cm M3.5 8kgf-cm
CSP-3000
M4
10-12kgf-cm
M6
13kgf-cm
UHP-500(R) / 750 / 1000 M3 5kgf-cm M4 10-12kgf-cm
HEP-600 / 1000 M4 10-12kgf-cm M4 10-12kgf-cm
（6）Torque can be various due to different material, please refer to the following chart.
A Recommend torque for aluminum：
Size of screw (Imperial units)
Recommend torque (kgf-cm)
3-56
4-40
4-48
5-40
5-44
6-32
6-40
8-32
8-36
2.3±20%
3.0±20%
3.3±20%
4.5±20%
4.7±20%
5.6±20%
6.3±20%
10.4±20%
10.8±20%
Size of screw (Metric Units)
Recommend torque (kgf-cm)
M2.5
M3
M3.5
M4
M5
M6
M7
M8
2.2±20%
4.1±20%
6.5±20%
9.7±20%
19.5±10%
33.1±10%
55.3±10%
80.6±10%

Installation Manual
B Recommend torque for iron：
Size of screw (Imperial units)
Recommend torque (kgf-cm)
3-56
4-40
4-48
5-40
5-44
6-32
6-40
8-32
8-36
5.0±20%
6.9±20%
7.0±20%
9.4±20%
9.9±20%
12.0±20%
13.4±20%
21.8±20%
23.0±20%
Size of screw (Metric Units)
Recommend torque (kgf-cm)
M2.5
M3
M3.5
M4
M5
M6
M7
M8
4.6±20%
8.8±20%
13.7±20%
20.4±20%
41.1±10%
69.1±10%
117.5±10%
169.4±10%
If above mentioned is not enough due to special application，Nylok Blue Patch screw is recommend, and extra
torque can be added if needed.
（7）Recommended wires are shown as below.
AWG
18
16
14
12
10
8
Rated Current of
Equipment (Amp)
6A 6-10A 10-16A 16-25A 25-32A 32-40A
Cross-section of
Lead(mm2) 0.75 1.00 1.5 2.5 4 6
Note: Current each wire carries should be de-rated to 80% of the current
suggested above when using 5 or more wires connected to the unit.
Make sure that all strands of each stranded wire enter the terminal connection and the screw terminals are
securely fixed to prevent poor contact.
（8）Wiring: The wire color will vary by country, please refer to the table below.
North America
European Harmonized
Live and ACL Black Brown
Neutral and ACN
white
Blue
PE and FG (Class I only) Green Green/yellow
（a）Connect the FG wire (green or green/yellow) of the power supply to PE (green or green/yellow), this step
can be skipped when the unit is marked class II, ungrounded.
（b）Connect the ACL wire (black or brown) of the power supply to Live (black or brown).
（c）Connect the ACN wire (white or blue) of the power supply to Neutral (white or blue).
（d）Make sure all wires are secured to prevent poor contact.

Installation Manual
（9）For other information about the products, please refer to www.meanwell.com for details.
Warning / Caution !!
（1）Risk of electrical shock and energy hazard. All failure should be examined by a qualified technician. Please do
not remove the case of the power supply by yourself!
（2）Please do not install power supplies in places with high moisture or near the water.
（3）Please do not install power supplies in places with high ambient temperature or near fire source. The
maximum ambient temperature please refer to their specifications.
（4）Output current and output wattage must not exceed the rated values on specifications.
（5）The ground(FG) must be connected to earth ground.
（6）All MW’s PSUs are designed in accordance with EMC regulations and the related test reports are available by
request. Since they are belong to component power supplies and will be installed inside system enclosure,
when they are integrated into a system, the EMC characteristics of the end system must be re-verified again.
（7）This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(a) This device may not cause harmful interference, and
(b) this device must accept any interference received, including interference that may cause undesired
operation.operation.
（8）For series of LRS, NES, PSP, PSPA, RD, RSP, RS, SE that certified with BSMI approvals, flammability of V1 or
above is required for surrounding equipment and operation of this equipment in a residential environment
could cause radio interference.
