Megasat DVB-T 50 User manual

Brillantes Fernsehen
DVB-T 50
Outdoor
Powerantenne
Artikelnummer
Beschreibung
Einsatz
Frequenzbereich
Empfangsbereich
Verstärkung
Rauschmaß
Ausgangsleistung
Widerstand
Anschluss
Stromversorgung
Abmessungen (B/H/T)
Lieferumfang
200172
DVB-T Antenne
Außenbereich
VHF: 87.5 - 230 MHz
UHF: 470 - 862 MHz
FM / VHF / UHF
36 dB
< 3.5 dB
max. 100 dBµV
75 Ohm
F-Stecker
AC 230V 50 Hz / DC 12V 50 mA
175 x 600 x 110 mm
Megasat DVB-T 50, Bedienungsanleitung,
Netzteil, Masthalterung, Wetterschutz,
12/24 Volt KFZ-Anschlusskabel,
Aktiver 2-fach Verteiler
Technische Daten Leistungsmerkmale
megasat.tv
• Aktive DVB-T Antenne für den Empfang terrestrischer
Fernseh- und Radioprogramme.
• Für die Verwendung im Außenbereich.
• Stromversorgung über den Receiver oder über das mitgelieferte Netzteil.
Megasat Werke GmbH | Industriestraße 4a | D-97618 Niederlauer
Tel. [phone] | Fax. [phone] | Email: [e-mail] | Internet: www.megasat.tv
DV B -T DVB-T2 KOMPATIBEL
4 046173 102963

DVB-T 50 Outdoor Powerantenne
user manual #1/2
Introduction:
This is a special designed antenna for digital terrestrial TV broadcasting reception. It is the best solution for home reception and digital portable
TV reception. The antenna is an active antenna that can be used with TV or set-top-box which can be powered by coaxial cable or external power
adapter. Complete accessories are included for wall or pole mounting. With the anti-UV water proof housing, it can be used both indoor and
outdoor.
Technical Data:
• Frequency range: VHF 87.5 - 230 MHz
UHF 470 - 862 MHz
• Receiving range: UHF / VHF / FM
• Max. gain: 36 dB
• Output level: max. 100 dBµV
• Out Impedance: 75 Ohm
• Noise figure: < 3.5 dB
• Power supply: via separate AC/DC adapter (DC 12V/50mA)
or via DTV set-top-box (DC 5V / 40mA)
• Connector: F-connector
12 3 4
Product Features:
• Anti-UV coating and water-proof design for durability
• Lightweight, compact size and easy to install
• For both analog and digital HDTV signal reception
• Built-In high gain and low noise amplifier
• With dipole inbuilt for the excellent UHF band signal reception.
• Specially compatible with HDTV of various digital terrestrial signal
(DVB-T, ISDB-T, DMB-T/H, ATSC) and DAB/FM radios.
Mounting the antenna:
Note: This antenna can be used outdoor, with the included mounting accessories, it can be mounted on the wall or the pole.
(Fig. 1) use the pole mounting accessories to fix the antenna on the pole
(Fig. 2) use the wall mounting accessories to fix the antenna on the wall
Fig. 1 Fig. 2
Included in package:
Before start your installation, please check the contents.
1. Antenna main unit
2. mounting accessories
3. AC/DC power adapter
4. Water-proof kit
Receiver TV signal from
the front side, please face
it to the signal tower.
Using the screws to fix
the antenna on the wall.
Horizontal Vertical
u-shape cable
arranging prevents
water from entering
Dig a hole on the eaves,
and arrange the cable
into inner house
Water-proof kit
F-type connector
Pole fixing mast
Fixing screws
Wall install. metal
Fixing direction nut
Be sure to face down here.
Do not use adhesive tape to plug here
Falling-proof installation hole
Water hole

DVB-T 50 Outdoor Powerantenne
user manual #2/2
(Fig. 3) use the pole mounting accessories to fix the antenna on the balcony
(Fig. 4) connect the„F“ male connector of the coax cable to the„F“ connector of the antenna,
and wear the water-proof cap to the end of the connected„F“ connector.
Note: After the antenna mounting is finished, please move the antenna to a best reception an then fix it. Organize the coax cable for neat,
tidy and safety. Please take reference of following positioning way to adjust the antenna position.
(Fig. 7) through the fixing the screws to adjust the antenna position in left or right in horizontal direction.
Directly connected to set-top-box Connected through power supply
outside
inside
Powered from
12V AV/DC
power adapter
Installation: Please take following (Fig. 5) and (Fig. 6) installation instruction for the reference.
Fig. 3
Fig. 5 Fig. 6
Fig. 7
Fig. 4
Operation Instruction:
Note: For the best reception, please check the following conditions.
1. Keep the antenna away from the sources of interference: Keep the
antenna away from those big power consumption devices, such as air
conditioner, elevator, hair dryer and microwave oven etc.
2. Place the antenna near windows when use the antenna in indoor
environment.
3. Install the antenna as high as possible: In digitalterrestrial reception,
if there are some interceptions between antenna and transmission
tower, it will cause the signal loss temporarily. So if the antenna is
installed as possible, those interceptions will be reduced.
please face the antenna to the TV signal
transmitter tower direction
