Introduction
Thank you for your purchase of the Megger BITE5 Battery Tester. Be assured that your unit has been designed with
emphasis on reliability, simplicity, and ease of use. It will provide you with the information you need to reliably test
batteries.
Purpose of this manual
This document is the operator manual for the Megger BITE5 Battery Tester. It provides a description of the operation of
the unit as well as operating instructions. Read this manual before installing or using the equipment. Special emphasis
should be placed on all safety discussions.
Audience
This manual is written for technical personnel who are familiar with the various measurements performed by volt
meters and current meters and have a general understanding of their use and operation. Such personnel should also be
thoroughly familiar with the hazards associated with the use of this equipment and should have received proper safety
training.
If you find any discrepancies in the BITE5 or have any comments, please send them to Megger via fax, e-mail, or phone.
Megger
Valley Forge Corporate Center
2621 Van Buren Avenue
Norristown, PA, 19403
Attn: Customer Service
Fax: [phone]
E-mail: [e-mail]
For Technical Support, please consult the Megger Web Site at www.megger.com for the local distributor near you.
www.megger.com BITE5 5
Introduction

Items received
Qty Description Image
1 BITE5 Battery Tester
1 Duplex Probes
1 Voltage Leads
1 Charger
1 Micro SD Card
1 Micro SD Card Reader
1 Mini USB Cable
1 Neck Strap
1 Zero Bar
1 Stylus
Optional AC/DC CT
Optional PC Bluetooth Dongle
www.megger.com
BITE5
6
Items received

Optional 11.75 mm (¼”) Tip Concentric Probes
Optional 25.4 mm (1”) Tip Concentric Probes
www.megger.com BITE5 7
Items received

Safety
Warnings and safety precautions
WARNING!
Death, serious injury, or fire hazard could result from improper use/installation of this instrument. Read
and understand this manual before installing this instrument.
Installation of this instrument MUST be performed in compliance with the National Electric Code and any additional
safety requirements applicable to your installation.
Installation, operation, and maintenance of this instrument MUST be performed by qualified personnel only. The
National Electrical Code defines a qualified person as one familiar with the construction and operation of the
equipment and the hazards involved.
Safety Precautions
The following safety precautions MUST be taken whenever the instrument is installed:
Wear safety glasses and insulated gloves when making connections to power circuits
Hands, shoes, floor/ground must be dry when making any connection to a powered line
These warnings and safety precautions are to be used where appropriate when following instructions in this manual.
CAUTION!
The equipment could be impaired from improper use. Read the complete manual before use.
WARNING!
The equipment should not be used while its battery door is removed or if there is any visible damage
to the case or if the hardware holding the unit together has been loosened.
G
F
F
www.megger.com
BITE5
8
Warnings and safety precautions

Technical Specificaions
Power supply
AC charging adapter Input 100 – 240 V AC (50/60 Hz)Output 12 V DC at 2.5
A
Battery pack Li-Ion rechargeable pack > 5.4 Ah
Voltage rating 7.4V
Charge time 4 hrs
Battery life > 8 hrs
300 charge/discharge cycles
Mechanical specifications
Dimensions 240 x 160 x 65 mm
9.45” x 6.30” x 2.56”
Weight 0.9kg
1.98lbs
Shock and vibration EN61010-1
Ingress/protection IP54
EN60529
Electric IP2X terminal
Operating specifications
Operating temperature 0 ~50 °C
32~122 °F
Storage temperature -20 ~50 °C
-4~122 °F
Charging temperature 10 ~40 °C
50~104 °F
Altitude Operational 0 ~ 2000 m
Non-operational 0 ~ 10 000 m
Relative humidity 10 ~ 85 % NC
Safety specifications
CAT rating 500V CAT III, Pollution Degree 2
Standards IEC61010-1:2010 (3rd Ed)
EN61010-1:2010 (3rd Ed)
IEN61326-1:2013
EN55011/A1:2010 (Class A)
EN61000-3-2:2014
EN61000-3-3:2013
Markings Double Insulated
CE
UKCA
Record capacity
Memory 8 M Flash Storage
Impedance record Max 1000 records
VA record Max 512 records
www.megger.com BITE5 9
Technical specifications

Electrical specifications
Internal impedance
Range Resolution Accuracy
3 mΩ 1 μΩ +/- 1 % of reading +/- 10 digits
30 mΩ 10 μΩ +/- 0.8 % of reading +/- 10 digits
300 mΩ 100 μΩ
3 Ω 1 mΩ
30 Ω 10 mΩ
300 Ω 100 mΩ
Voltage DC/AC
Range Resolution Accuracy
5 V DC 0.00 1 V +/- 0.5 % of reading +/- 5 digits
50 V DC 0.0 1 V
500 V DC 0.1 V
1000 V DC 1 V
5 V AC .001 V +/- 0.75 % of reading +/- 5 digits
(40 Hz – 100 Hz)
50 V AC 0.01 V
500 V AC 0.1 V
600 V AC 1 V
Current DC/AC
Range Resolution Accuracy
4 A DC 0.001 A +/- 0.5 % of reading +/- 5 digits +
(CT Tolerance)
40 A DC 0.01 A
400 A DC 0.1 A
1000 A DC 1 A
4 A AC 0.001 A +/- 0.75 % of reading +/-10 digits +
(CT Tolerance)
40 A AC 0.01 A
400 A AC 0.1 A
1000 A AC 1 A
Temperature
Range Resolution Accuracy
10 °C ~ 100 °C
50 °F ~ 212 °F 0.1 °C +/-1 °C +/- 2 digits
Ripple Voltage
Range Resolution Accuracy
0 - 5 V 0.001 V +/- 0.5 % of reading +/- 10 digits (40
Hz – 10 KHz)
Accuracy specifications assume an ambient temperature of 18 °C to 28 °C, stable within +/-1 °C and a warm-up time
of 30 minutes.
www.megger.com
BITE5
10
Technical specifications

Connections and controls
Connections
Mini USB input and micro SD card slot
Current probe input
Voltage lead inputs
Impedance probe inputs
ON/OFF switch
DC power adapter input
Controls
Lock and unlock screen
Ohmic testing
VA testing
Data and string records
Recorded data charts
Instrument configuration
Zero adjustment
For accurate ohmic measurements, it is recommended that a zero adjust is performed when changing probes.
To perform a zero adjust, use the included zero bar.
When performing a zero adjustment, place the source pin on the outer copper surface of the zero bar and place the
sensor pin in one of the holes of the zero adjust bar.
www.megger.com BITE5 11
Connections and controls

Zero adjustment procedure
Select “0-ADJ”.
The BITE5 will prompt you to make a zero adjustment bar.
Select YES.
NOTE: Place the probes on the zero adjustment bar as shown within 10 seconds of selecting YES, or the BITE5 will time
out.
This zero adjustment will begin. Hold probes on zero bar until adjustment is complete.
Operation
Configuration of BITE5
The BITE5 allows you to customize the unit for your needs. You can set the desired language, the date and time format,
the screen brightness setting, a unit and display auto off time out, temperature format, and the desired buzzer volume.
This screen also allows you to format the micro SD card and reset the unit to defualt conditions.
CONFIGURATION ICON
www.megger.com
BITE5
12
Configuration of BITE5

To configure the unit, select the
CONFIGURATION ICON.
Under the impedance tab, the temperature measurment scale can be selected (Celcius or Fahrenheit).
Then select the “Etc” tab.
This screen allows you to customize the settings of your BITE5.
From this screen you can select the following:
Language Set the instrument language
Date format Select the desired date format
Brightness Set the brightness setting of the display screen
www.megger.com BITE5 13
Configuration of BITE5

Display off Set a display time out. After an amount of time of no activity, the
display will turn off. Simply touch the screen to re-activate the
display
Time Set the date and time of the instrument
Buzzer Set the volume of the buzzer or disable it
Auto P. off Set a unit power off time out. After an amount of time of no
activity, the instrument will turn off
BT printer Enable or disable the optional bluetooth printer
SD card Format the micro SD card. NOTE: This will cause all data and
configurations to be erased
Reset settings Resets the instrument settings to default factory settings
Configuration of string
The BITE5 allows you to configure strings. The configuration allows you to assign the string a name, input the type of
battery, the number of batteries, and the model of the battery. In addition, you cen enter baseline reference data as
well as warning and alarm limits.
To configure a new battery string press the RECORD ICON.
Select “String Ω”.
www.megger.com
BITE5
14
Configuration of string

Select “Add…”
This will open the String Configuration screen.
Idx Sets an index number for the string in the BITE5. This is
set automatically. It can be set manually if desired
Type Select the type of battery to be tested:
Lead acid
Ni-CD
Ni-MH
Li-ion
Li-poly
Cell Cell
Name Name of string
Model Model number of batteries
Capacity Battery capacity in Ah or mAh
Ref Ω Baseline reference value
Warning Warning upper ohmic limit
Alarm Alarm upper ohmic limit
Ref V Cell float voltage
Lower Low voltage limit
When the setting are complete, select OK to save the string configuration.
www.megger.com BITE5 15
Configuration of string

Performing an impedance test
In the ohm mode, the BITE5 will record and save voltages, impedance values and temperature. These measurements
can be performed on individual cells or sequentially on battery strings. These measurements can be taken on any
individual battery up to 200 V DC.
Operation:
Measuring and saving individual battery measurements.
Connect the impedance leads to the input connector of the BITE5.
On the BITE5 select “Ω”.
Select “Meter”.
www.megger.com
BITE5
16
Performing an impedance test

Select “Limit” if you would like to program impedance and voltage limits for the measurement.
This screen will allow you to program a warning and alarm limit for the impedance value and a lower limit for the
voltage. This is an optional step. Select OK when done.
Note this feature can be disabled as well by selecting OFF.
Start testing by place the probes across the battery.
The BITE5 will beep when the measurement is complete.
www.megger.com BITE5 17
Performing an impedance test

Press “Hold” to freeze the value on the screen.
Automatic Saving of Values
Select “Auto Hold” and the BITE5 will automatically save any measurement with a date and time stamp.
Performing an impedance test on a battery string.
Connect the impedance leads to the input connector of the BITE5.
On the BITE5 select “Ω”.
www.megger.com
BITE5
18
Performing an impedance test on a battery string

Select “String”.
Select “Select”.
Select desired string. Select “New Test” to start a new test on the selected string.
Select “Select Test” if you wish to continue a test that was already in progress.
www.megger.com BITE5 19
Performing an impedance test on a battery string.

Start testing by placing the probes on the first cell in the string.
The BITE5 will beep when the measurement is complete and save the cell voltage, cell impedance, and cell temperature
to memory automatically.
The results will be displayed on the screen.
Move to the next battery in the string and take a measurement.
The recorded values will be displayed on the screen.
Continue taking a measurement of each cell in sequence on the string until you reach the last cell in the string.
www.megger.com
BITE5
20
Performing an impedance test on a battery string.
