Megger Vidar User manual

WWW.MEGGER.COM
User’s Manual
VIDAR
Vacuum tester
Art No. ZP-BR01E Doc. BR0150GE V02a 2015

Contents
1 Safety
............................................................. 4
1.1 Symbols on the instrument ..........................4
1.2 Safety instructions........................................4
2 Introduction
............................................................. 6
2.1 General........................................................6
2.2 Flashover threshold voltage..........................6
3 Instrument description
............................................................. 8
4 Operating instructions
........................................................... 10
4.1 Connecting................................................10
4.2 Conducting a test ......................................10
5 Troubleshooting
........................................................... 12
6 Specifications
........................................................... 14

VIDAR
Vacuum tester
NOTICE OF COPYRIGHT & PROPRIETARY RIGHTS
© 2013-2015, Megger Sweden AB. All rights reserved.
The contents of this manual are the property of Megger Sweden AB. No part of this work may be reproduced or transmitted in any form or
by any means, except as permitted in written license agreement with Megger Sweden AB. Megger Sweden AB has made every reasonable
attempt to ensure the completeness and accuracy of this document. However, the information contained in this manual is subject to change
without notice, and does not represent a commitment on the part of Megger Sweden AB. Any attached hardware schematics and technical
descriptions, or software listings that disclose source code, are for informational purposes only. Reproduction in whole or in part to create
working hardware or software for other than Megger Sweden AB products is strictly prohibited, except as permitted by written license
agreement with Megger Sweden AB.
TRADEMARK NOTICES
Megger® and Programma® are trademarks registered in the U.S. and other countries. All other brand and product names mentioned in this
document are trademarks or registered trademarks of their respective companies.
Megger Sweden AB is certified according to ISO 9001 and 14001.
User’s Manual
Postal address:
Megger Sweden AB
Box 724
SE-182 17 DANDERYD
SWEDEN
T [phone]
F [phone]
[e-mail]
www.megger.com
Visiting address:
Megger Sweden AB
Rinkebyvägen 19
SE-182 36 DANDERYD
SWEDEN
BR0150GE ZP-BR01E VIDAR 3

4VIDAR ZP-BR01E BR0150GE
1 SAFETY
1Safety
1.1 Symbols on the
instrument
Caution, refer to accompanying docu-
ments.
Protective conductor terminal.
WEEE, Waste Electrical and Electronic
Equipment. Please utilize your local
WEEE collection facilities in the dispo-
sition of this product and otherwise
observe all applicable requirements.
1.2 Safety instructions
Important
Read and comply with the following in-
structions.
Always comply with local safety regula-
tions.
Warning
People with pacemakers must not use the VIDAR
since a pacemaker can be disturbed by the electrical
discharges.
When testing a circuit breaker that is permanently
mounted you must make certain that there is no risk
of burning out the collector busbar if it can not be
disconnected.
Circuit breakers on vehicles and also circuit break-
ers of the plug-in type must be tested outside their
holders.
Applying abnormally high voltage across a pair of
contacts in vacuum may be dangerous. However, as
a precautionary measure against possibility of ap-
plication of higher than recommended voltage (or a
contact spacing below normal), it is recommended
that all operating personnel stands at least 3 m
(10 ft) away in front of the breaker.
High voltage/current on input/output terminals.
Do not attempt to service the instrument yourself.
Opening or removing covers may expose you to dan-
gerous voltage. If you attempt to service the instru-
ment yourself the warranty is no longer valid.
Do not use any accessories that are not intended for
use together with the instrument.
Disconnect the instrument from the mains before
cleaning. Use a damp cloth for cleaning. Do not use
liquid cleaners or aerosol cleaners.
Important

BR0150GE ZP-BR01E VIDAR 5
1 SAFETY
Always turn the equipment off before connecting.
Always use manufacturer approved and supplied
cable sets.
Always connect protective earth (ground).
Never leave the instrument unattended while it is
turned on.
Use only approved mains detachable cable set with
the instrument. Main supply cables shall be rated
for the maximum current for the equipment and the
cable shall meet the requirements of IEC 60227 or
IEC 60245. Mains supply cables certified or approved
by a recognized testing authority are regarded as
meeting this requirement.
Unplug the instrument from the mains supply when
it is left unattended or not in use.
Do not expose the instrument to rain or moisture.
Refer all servicing to Megger authorized personnel.
If you need to return the instrument, please use
either the original crate or one of equivalent strength

6VIDAR ZP-BR01E BR0150GE
2 INTRODUCTION
2Introduction
2.1 General
The VIDAR vacuum tester is used to test the ability of
the breaking chamber in a vacuum circuit breaker to
inhibit flashover. The rugged, lightweight, compact
and portable VIDAR is ideal for field work.
The vacuum bottles in vacuum breakers do not last
forever. Leakage starts after years or decades and the
bottles fill with air making the breaker unreliable. In
most cases the leakage process is rapid once it has
started. In addition to leakage, dirt on the poles and
on the exterior surface of the bottle can make it un-
safe during operation. The mechanics of the breaker
can become misaligned so that the distance between
the poles no longer is adequate. Vidar, introduced in
1985, uses high voltage DC to test the integrity of
vacuum breakers. There are some 2000 units of Vidar
in field service all over the world that perform daily
tests on the integrity of vacuum breakers.
2.2 Flashover threshold
voltage
The curve shown in Fig. 1 illustrates the relationship
between a vacuum chamber’s internal pressure and
its ability to inhibit flashover. This relationship permits
the vacuum to be checked indirectly by measuring
the voltage threshold. One special advantage of this
method is that you do not need to disassemble the
circuit breaker in order to test it.
The voltage shall be selected so that test point A (see
diagram) is sufficiently far from point B (when the
chamber is filled with air). However the electric stress in
the chamber must not be too high. In normal situations
the pressure is less than 10-2 mbar.
For guidance on test voltage refer to IEC 694 and
ANSI C37-06 standards.
p ~10 mbar
p
-2 po
B
A
Up
log p
log Ud
Fig. I. Flashover threshold voltage plotted against pressure in
vacuum chamber.
p : chamber pressure
po: atmos. pressure
pp: max. pressure on passing voltage test
ud: breakdown voltage
up: test voltage

BR0150GE ZP-BR01E VIDAR 7
3 INSTRUMENT DESCRIPTION

8VIDAR ZP-BR01E BR0150GE
3 INSTRUMENT DESCRIPTION
3Instrument description
1. High voltage cable. For connection of the test voltage
and ground to the vacuum breaking chamber.
2. Yellow CANCEL indicator lamp. Lights up when:
▪the test interval has exceeded one minute.
▪you try to conduct a one minute test less than two
minutes after the latest test.
▪the HIGH-VOLTAGE indicator malfunctions.
3. Red HIGH-VOLTAGE warning lamp. Shows that the
high voltage is applied.
4. Test voltage selector. Five standard voltages and one
customized voltage, determined at the factory.
5. Protective earth (ground) terminal.
6. SAFETY CONTROL KNOBS. Both knobs must be
turned simultaneously to their TEST positions to apply
high voltage to the object being tested.
7. Green ACCEPTABLE Indicator lamp. Lights up when
the breaking chamber test result is positive.
8. Power ON/OFF.
9. Red DEFECTIVE indicator lamp. Lights up when:
▪the breaking chamber test result is negative
▪the flashover threshold voltage is too low.
1 4 5
6976
32
8

BR0150GE ZP-BR01E VIDAR 9
4 OPERATING INSTRUCTIONS

10 VIDAR ZP-BR01E BR0150GE
4 OPERATING INSTRUCTIONS
4Operating instructions
4.1 Connecting
Important
Read the manual and comply with the
Safety instructions, see page 4, before us-
ing VIDAR.
Always comply with local safety regula-
tions.
1] Check that the circuit breaker is in OPEN
position.
2] Check that the master ON/OFF switch on the
VIDAR is in OFF position and that the red
HIGH-VOLTAGE warning lamp is not flashing.
3] Connect the protective earth (ground) cable
from VIDAR to the station earth (ground).
4] Connect the part with the black crocodile
clamp of the high-voltage cable to the con-
trol mechanism side of the breaking cham-
ber.
5] Connect the part with the red crocodile
clamp of the high-voltage cable to the other
terminal on the breaking chamber.
6] Connect VIDAR to the mains power.
4.2 Conducting a test
Note For guidance on test voltage refer to IEC 694
and ANSI C37-06 standards.
1] Connect the VIDAR as instructed in section
4.1 Connecting.
2] Select the desired test voltage depending on
the type of breaking chamber being tested.
3] Turn the power ON/OFF switch to the ON
position. The green lamp beside the switch
will light up.
4] Using both hands, turn the two SAFETY
CONTROL knobs to their respective end limits
in the directions shown by the two arrows on
the control panel. Wait until either the green
ACCEPTABLE indicator lamp or the red DE-
FECTIVE indicator lamp lights up and remains
lighted throughout at least five seconds.
While the test is in progress, the red HIGH
VOLTAGE warning lamp will flash. If the red
HIGH VOLTAGE warning lamp is faulty, the
yellow CANCEL indicator lamp will light up.
a. If the green ACCEPTABLE lamp lights up
and remains lighted for at least five seconds
the test is complete and the breaking cham-
ber can be considered in good condition.
Release the SAFETY CONTROL KNOBS.
b. If the red DEFECTIVE lamp lights up and
remains lighted for at least five seconds,
release the SAFETY CONTROL knobs
Turn off the power and check the ground
connection and other connections. Start
again from point 3.
If the red DEFECTIVE lamp lights up again,
disconnect VIDAR from the breaking cham-
ber (see below section “Disconnection after
test”). Repeat the test with reversed polarity
in order to eliminate false DEFECTIVE indica-
tion due to field emission.
Note Any metallic discharge sounds that are heard
during the test are of no importance. The
results shall be based solely on the lighting up
of either the green ACCEPTABLE lamp or the
red DEFECTIVE lamp.

BR0150GE ZP-BR01E VIDAR 11
4 OPERATING INSTRUCTIONS
5] When the test is completed turn the power
ON/OFF switch on the VIDAR to its OFF posi-
tion.
Note The yellow indicator lamp lights if the test
lasts longer than 1 minute.
If you want to conduct a full time 1 minute
test after that, there must be a 2 minutes
pause before starting next test. (This pause
permits proper resetting of VIDAR’s internal
timercounter.)
Disconnection after testing
1] Check that the power ON/OFF switch is at the
OFF position.
2] Remove the ground connection (black cable
terminal) and connect it to the metallic part
of the highvoltage cable (red cable terminal)
before removing it from the circuit breaker.
3] Remove the protective earth (ground) cable
from station earth (ground).
Note Electrostatic charges can build up on:
a) adjacent insulated parts
b) the metallic centre-section of the breaking
chamber
c) the entre centre part of dual breaking
chambers due to the fact that the VIDAR uses
DC.
When a ground connection is established,
it takes (depending on surface conditions)
about 10 seconds for statically charged parts
to assume ground potential. As a rule these
electrostatic charges do not entail any serious
risk.

12 VIDAR ZP-BR01E BR0150GE
5 TROUBLESHOOTING
5Troubleshooting
Fault Cause Remedy
Green POWER ON
lamp does not light.
Probably no mains
power.
Check the mains, the master ON/OFF switch and the auto-
matic fuse adjacent to the mains nameplate.
Red HIGH-VOLTAGE
warning lamp does
not flash.
Yellow CANCEL lamp
lights up instead.
The lamp in the HIGH-
VOLTAGE warning lamp
is probably faulty.
Unscrew and remove the red protector lens (turn it
anticlockwise). Push the lamp down, then twist slightly
anticlockwise to release it from its bayonet socket. Pull
the lamp out of its socket and replace it with a new one
(Halogen 12 V, 5 W BA9 type, Megger Sweden art. no. is
34-00020).
Insert the light bulb in the socket, push the lamp down,
then twist slightly clockwise. Replace the red protective
lens by turning it clockwise.
Yellow CANCEL lamp
Ilghts up but glows
weakly.
Wrong mains voltage. Check to see that the mains voltage is the same as that
shown on the mains nameplate.

BR0150GE ZP-BR01E VIDAR 13

14 VIDAR ZP-BR01E BR0150GE
6 SPECIFICATIONS
6Specifications
Specifications VIDAR
Specifications are valid at nominal input voltage and an ambi-
ent temperature of +25°C, (77°F). Specifications are subject to
change without notice.
Environment
Application field The instrument is intended for use in
medium and high-voltage substations
and industrial environments.
Temperature
Operating -10°C to +50°C (14°F to +122°F)
Storage & transport -40°C to +70°C (-40°F to +158°F)
Humidity 5% – 95% RH, non-condensing
CE-marking
LVD 2006/95/EC
EMC 2004/108/EC
General
Mains voltage 115 / 230 V AC (switchable), 50 /60 Hz
Power consumption 69 VA (max)
Protection Overload cut-out
Dimensions
Instrument 250 x 210 x 125 mm
(9.8” x 8.3” x 4.9”)
Transport case 460 x 430 x 210 mm
(18.0” x 17” x 8.3”)
Weight 6.9 kg (15.5 lbs)
10.7 kg (23.6 lbs) with accessories and
transport case
Measurement section
Indicators
Green lamp Indicates an approved breaking chamber
Red lamp Indicates a defect breaking chamber,
lights up if the current exceeds 0.3 mA
Yellow lamp Indicate that the test was interrupted
Output
Standard voltages,
switchable
10, 14, 25, 40 and 60 kV DC
Customized voltage Between 10 and 60 kV DC. Determined
at the factory. Default voltage is 50 kV.
Accuracy 0 to -15%
Ripple Max 3%

BR0150GE ZP-BR01E VIDAR 15
6 SPECIFICATIONS

WWW.MEGGER.COM
Your “One Stop” Source for all your electrical test equipment needs
Megger is a leading global manufacturer and supplier
of test and measurement instruments used within the
electric power, building wiring and telecommunication
industries.
With research, engineering and manufacturing facilities
in the USA, UK, Germany and Sweden, combined with
sales and technical support in most countries, Megger
is uniquely placed to meet the needs of its customers
worldwide.
Megger is certified according to ISO 9001 and 14001.
Megger is a registered trademark.
Postal address:
Megger Sweden AB
Box 724
SE-182 17 DANDERYD
SWEDEN
T [phone]
F [phone]
[e-mail]
www.megger.com
Visiting address:
Megger Sweden AB
Rinkebyvägen 19
SE-182 36 DANDERYD
SWEDEN
▪Battery Test Equipment
▪Cable Fault Locating Equipment
▪Circuit Breaker Test Equipment
▪Data Communications Test Equipment
▪Fiber Optic Test Equipment
▪Ground Resistance Test Equipment
▪Insulation Power Factor (C&DF) Test Equipment
▪Insulation Resistance Test Equipment
▪Line Testing Equipment
▪Low Resistance Ohmmeters
▪Motor & Phase Rotation Test Equipment
▪Multimeters
▪Oil Test Equipment
▪Portable Appliance & Tool Testers
▪Power Quality Instruments
▪Recloser Test Equipment
▪Relay Test Equipment
▪T1 Network Test Equipment
▪Tachometers & Speed Measuring Instruments
▪TDR Test Equipment
▪Transformer Test Equipment
▪Transmission Impairment Test Equipment
▪Watthour Meter Test Equipment
▪STATES® Terminal Blocks & Test Switches
▪Professional Hands-On Technical and
Safety Training Programs
▪AUSTRALIA
▪BULGARIA
▪CANADA
▪CZECH REPUBLIC
▪CHINA
▪FRANCE
▪GERMANY
▪HUNGARY
▪INDIA
▪INDONESIA
▪KINGDOM OF BAHRAIN
▪KOREA
▪MALAYSIA
▪PAKISTAN
▪PHILIPPINES
▪POLAND
▪ROMANIA
▪RUSSIA
▪SINGAPORE
▪SLOVAK REPUBLIC
▪SOUTH AFRICA
▪SPAIN
▪SWEDEN
▪SWITZERLAND
▪TAIWAN
▪THAILAND
▪UNITED ARAB EMIRATES
▪USA
▪VIETNAM
Megger Group Limited
UNITED KINGDOM
Dover, Kent CT17 9EN
ENGLAND
Subject to change without notice. Printed matter No. ZP-BR01E Doc. BR0150GE V02a 2015
