Assembly Instructions & User’s Manual
For
Member’s Mark Camden 3pc Chat Set
Item Number: 990018804
Model Number: GC-41104-3PC
Customer Assistance (spare/replacement parts): 1-888-691-2824
or Email: [email protected]
THIS ASSEMBLY MANUAL CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.

2 | P a g e
Table of Contents
Quality Statement ....................................................................................................................................3
Important Safety Information................................................................................................................3
Before Assembly .....................................................................................................................................3
Care & Use.................................................................................................................................................3
Package Contents ...................................................................................................................................4
Product Information ................................................................................................................................4
Components..............................................................................................................................................5
Hardware....................................................................................................................................................5
Tools ...........................................................................................................................................................5
Step 1 .........................................................................................................................................................6
Step 2 ...........................................................................................................................................7
Warranty Information............................................................................................................................12

3 | P a g e
Quality Statement
Important Safety Information
Please read all instructions carefully before assembling this product.
Where applicable, and for your safety, assembly by an adult is strongly
recommended.
Use only vendor-supplied hardware to assemble this item. Using unauthorized
hardware could jeopardize the structural integrity of the item.
Hardware may loosen overtime. Periodically check that all connections are tight.
Before Assembly
Remove all parts and hardware from the box. Place all items on a carpeted or
scratch-free work surface, as this will avoid damaging parts during assembly.
The shipping box can provide an ideal work surface if none is available.
Use the components and hardware lists below to identify, inventory and separate
each of the hardware and components included.
To avoid accidentally discarding small components or hardware, do not dispose
of any packaging or contents of the shipping carton until assembly is complete.
DO NOT USE power tools unless it is explicitly identified in this manual as
required for use during assembly. Power tools can damage the fasteners,
hardware and/or components.
Do not fully tighten all fasteners / screws until all parts are in place. Failure to
follow these instructions may cause the fasteners / screws to misalign during
assembly.
Care & Use
Use a soft, clean cloth that will not scratch the surface when cleaning.

4 | P a g e
Package Contents
Component
Description
Quantity
Component
Description
Quantity
A
Chair frame
1
G
M8 Washer
8
B
Chair base
1
H
M8 Spring Washer
4
E
Metal plate
4
I
M8 Damping Nut
4
F
Hex Head Bolt
M8x50mm
4
Product Information
Product Dimensions：
Swivel Rocker Chair: 31.7"x35.8"x34.6" (80.5cm x 91cm x 87.8cm)
Side table: φ20"x20" (φ50.8cm x 50.8cm)
Product Weight Capacity
Swivel Rocker Chair: Supports up to 250 lbs. (114 kg)
Side table: Supports up to 50 lbs. (23 kg)
Need Assistance? Visit us at: samsclub.com/membersmarkhelp

5 | P a g e
Components
(A)
Chair frame
Qty: 1pc
(B)
Chair base
Qty: 1pc
(C)
Seat cushion
Qty: 1pc
(D)
Back cushion
Qty: 1pc
Hardware
(E)
Metal plate
Qty: 4pcs
(F)
Hex Head Bolt
M8x50mm
Qty: 4pcs
(G)
M8 Washer
Qty: 8pcs
(H)
M8 Spring Washer
Qty: 4pcs
(I)
M8 Damping Nut
Qty: 4pcs
Tools
(J)
M8 Hex Wrench
Qty: 2pc
Need Assistance? Visit us at: samsclub.com/membersmarkhelp

6 | P a g e
Step 1
(A)
Chair frame
Qty: 1pc
(B)
Chair base
Qty: 1pc
(E)
Metal plate
Qty: 4pcs
(F)
Hex Head Bolt
M8x45mm
Qty: 4pcs
(G)
M8 Washer
Qty: 8pcs
(H)
M8 Spring Washer
Qty: 4pcs
(I)
M8 Damping Nut
Qty: 4pcs
(J)
M8 Hex Wrench
Qty: 2pcs
Carefully place chair frame(A) upside down a soft, flat and non-abrasive surface.
Attach the chair base (B) to chair frame (A) using M8 bolts(F), Washer(G), Spring
washer (H) and M8 Damping nuts (I) .
Tighten all the M8 bolts (F) and M8 damping nuts (I) with the hex wrench(J).
Need Assistance? Visit us at: samsclub.com/membersmarkhelp

7 | P a g e
Step 2
Carefully turn the chair over.
Place the seat cushions (C) and back cushion (D) on the swivel chair.
The chair is ready for your enjoyment.
Need Assistance? Visit us at: samsclub.com/membersmarkhelp

8 | P a g e
Furniture Cover
Component
Description
Quantity
Component
Description
Quantity
K
Swivel Rocker
Chair
2
M
Side Table
1
L
Furniture Cover for
Swivel Rocker
Chair
2
N
Furniture Cover for
Side table
1
For maximum protection, use Heavy Duty Furniture Cover (L&N). Fasten
adjustable cord lock to secure the cover from wind and snug fit.
Need Assistance? Visit us at: samsclub.com/membersmarkhelp

9 | P a g e
Warranty Information
This product component has a 5 year guarantee against defects in material and/or workmanship. If you
have any questions regarding the warranty or spare / replacement parts, please call our toll-free number
1-888-691-2824 or email us at [email protected]
NOTE: Please consider recycling all applicable packaging material.
