MEMOLUB ONE User manual

EN - 03.2020
Installation instructions
MEMOLUB® ONE
PRECAUTIONS
• Do not open the housing: loaded spring
• Hold MEMOLUB® down during manual checks
• Leq < 70 dB
• Use MEMOLUB® only for greasing machinery
• Use only lubricant cartridges and batteries recommended by the manufacturer
CONTENTS
Technical information .................................................................................................................................page 2
A Replacing cartridge .....................................................................................................................................page 3
B Direct installation ..........................................................................................................................................page 3
C Remote installation ...................................................................................................................................... page 4
D Check Function ............................................................................................................................................. page 4
ENGLISH

101 mm
3.98 in
240 cm3
1
2
3
4
5
6
7
8
9
10
147 mm
6.56 in
10 ring
TECHNICAL INFORMATION
Settings of the Memo
Color Emptying time of cartridge Average daily output
white 12 months 0,65 cm3 / day
red 6 months 1,3 cm3 / day
green 3 months 2,6 cm3 / day
yellow 1 months 8 cm3 / day
1 stroke with manual grease gun ≈ 1 cm3
Dimensions
2

2
1
a1a2a3
a4a5
2
1
a6
b3
b4
b1
BSP1/4
!
b2
3
A
B
Insert new battery pack
and seal
Close and lock (fingers on ribs)
Install MEMOLUB® on Memo
Open (fingers on ribs)
REPLACING CARTRIDGE
DIRECT INSTALLATION
Squeeze air out of cartridge
Prime lube point
and remove nipple
MEMOLUB® works immediately
Prime MEMOLUB®
Replace cartridge
Screw in Memo using
threadlocker

4
C
D
21
d1d2
c7c9c8
90°
c5c4c6
c1c2c3
Install Memo and F1/4 fitting
Insert hose into quick fitting
MEMOLUB® works immediately
Prime lube point
and remove nipple
To check unit: unscrew
and screw again
REMOTE INSTALLATION
CHECK FUNCTION
Screw BSP 1/8 fitting
Insert hose into quick fitting
Secure bracket
Check regularly
Cut hose to required size
Install MEMOLUB® on Memo
