Perma PRO 250 User manual

Translation of the
Original Operating Instructions
perma
PRO 250 / 500
PRO C 250 / 500
PRO / PRO C LINE 250 / 500
PRO MP-6 Distributor
PRO / PRO C MP-2
The Expert in Lubrications Solutions

perma-tec GmbH & Co. KG
perma PRO 250 / 500
perma PRO C 250 / 500
perma PRO / PRO C LINE 250 / 500
perma PRO MP-6 Distributor
perma PRO / PRO C MP-2
Accessories and Spare Parts
Declaration of conformity:
• permaPRO/PROLINE
• permaPROC/PROCLINE
• permaPROMP-6Distributor
• permaPRO/PROCMP-2
© 2013perma-tecGmbH&Co.KG

Withoutthespecicapprovalofperma-tecGmbH&Co.KGnopartofthisdocumentation
canbecopiedormadeavailabletothirdparties.
Wehavetakengreatcarewhencompilingallthedetailscontainedinthisdocumentation.
However,wecannotruleoutdiscrepanciesandwereservetherighttomaketechnical
changestotheproductwithoutgivingadvancenotice.
Wedonotassumeanyjudicialresponsibilityorliabilityfordamageswhichmayensueas
aresult.
Wewillincludeanynecessarychangesinthenextedition.
Compiledandprinted:  03/03/2014
Thisoperatingmanualisvalidfor:

Chap.4.3
perma PRO MP-6 Distributor
Drilling template

45
7566.5
6.5
Drilling template
ScrewsM6
2xFastingpoints 3xFastingpoints

Table of Contents
The lubrication system perma PRO1
Quick reference guide 2
1. Various 3
 1.1 Delivery/Content
 1.2 Storage
 1.3 Markings
 1.4 IntendedUsage
 1.5 LegalRequirements

2. Safety Instructions5
 2.1 PersonsResponsibleforSafety
 2.2 GeneralSafetyInstructions
 2.3 SafetyInformationforpermaPRO
3. Technical Data 6
 3.1 DesignofthepermaPROLubricator
4. Mounting and Assembly of the Lubrication System 8
 4.1 MountingtheDriveUnitontoaFixingDeviceforWall-Mounting
 4.2 AssemblyoftheLubricator
5. Display and Control Elements of the Lubrication System 11
 5.1 DisplayElements
 5.2 FunctionIndicationontheDisplay
 5.3 FunctionIndicationviatheLEDs
 5.4 ControlButtons
6. Operation and Control 12
 6.1 Preparations
 6.2 PriortoOperation
 6.3 SettingintoOperation
 6.4 DuringOperation
 6.5 SwitchingtheLubricationSystemOn
 6.6 SwitchingtheLubricationSystemOff
 6.7 DeterminingtheDischargePeriod
 6.8 SettingsandDisplay
 6.9 CalculationoftheRemainingDischargePeriod
7. Replacement of the PRO LC unit18
 7.1 SettingtheVolumeofthePROLCunit
 7.2 HowtoReplacethePROLCunit
8. Trouble Shooting 20
 8.1 ErrorMessagesontheDisplay
 8.2 TroubleShootingGuide
9. Disposal21
10. Service 21
Translation of the Original Operating Instructions
perma PRO 250 / 500

permaPRO -1-
Config.
TimePIN
Outlets
1
3
2
4
5
6
Days
Weeks
Months
%Vol.
LC250
Display
Drive Unit
Protection cover
Withbayonetcatchforquick
opening/closing.
PRO LC unit
(LubricationCanister)
Cartridge,piston,spindle
lledwithlubricant.
Red LED
Additionalmalfunction
indication.
Push Button: MODE/SAVE
Leadstothe
CongurationMenuandsaves
theselectedsettings.
Drive Unit
Containselectronics,
motor,andpumpsystem.
Con guration menu
Forenteringthesettings.
Outlets 1 - 6
Showsactivatedoutlets
Number
Showsremainingvolume,
dischargeperiod,outletno.,
PIN,andmalfunctioncodes.
Setting Mode
Displaysthecurrentsettingindays,
weeks,ormonths.
Size of PRO LC unit
DisplaysvolumeofLCunit
(250or500cm3)
Ice icon
Indicateseitherthatthetemperature
fellbelow0°C/32°F(iconblinking),
orthatthelowtemperatureshutoff
(below-20°C/-4°F)hasturnedthe
systemoff(iconpermanent).
Battery Compartment
Forinsertionofbattery
set
Catch
Fordrivingthespindle
Interlocking Teeth
Topositionthe
PROLCunit.
No function!Settingof
PROLCunitsizeisdone
viamenuonthedisplay.
PRO
Battery B
PRO Battery
B plus
Lubrication System perma PRO
Remaining volume
of the PRO LC unit
Showsthelubricant
remaininginthePRO
LCunitin%volume.
Content
Descriptionofthellingdateandthe
containedlubricant.
Type
ProducttypeandsizeofPRO
LCunit
Display
Informsaboutoperatingconditions,
malfunctions,settings,andthe
lubricantvolumeleftinthe
PROLCunit.
Push Button: ON/OFF/SELECT
ToturnsystemONorOFFandto
changesettings.
Green LED
Additionalindicationofthecurrent
operatingcondition.
Connector for distributor
PRO MP-6
Connection thread
G3/8forapplicationinto
alubricationpointorfor
connectingagreasetube.

permaPRO-2-
Quick Reference Guide for the Lubrication System perma PRO
OnthispageyouwillndsomeimportantinformationforquickandeasyoperationandsettingofthepermaPRO.
BeforetherstinstallationofthepermaPRO,andwheneveryouneeddetailedinstructions,youshouldreadthe
completeOperatingManualwhichcontainsinformationthatmustbeobserved.Makesuretofollowtheinstructions
giveninthechapter“SafetyNotes”.
1Assembly of perma PRO / Exchange of PRO LC unit
(refer to chapter 4 and 7)
♦ Mountthedriveunitonthemountingplateandsecureitatthethreepre-drilledholes(seeattached
template).
♦ Insertanewbatterysetintothebatterycompartment(followdirectionsofthearrows).
♦ PlacethePROLCunitinsidethecoverandremovetheplugofthePROLCunit.
♦ PushthePROLCunitintothecoveruntillubricantcomesoutoftheopening.
♦ PlacethePROLCunitwithitscoveronthedrive-unit.Makesurethatthecatchlocksandthatthe
teethofPROLCunitanddriveunitinterlock.
♦ Turnthecoverclockwiseuntilthebayonetcatchlocks.
2Determine Discharge Period
(refer to chapter 6.7)
♦ Refertothemanufacturer’sguidelinesaboutthelubricationpointthatyouwanttolubricate,inorder
todeterminetherequiredlubricantamountincm3peronehundredoperatinghours.
♦ Refertochart3(chapter6.7,chart4)andndyourrequiredlubricationamount.Basedonthat,
thechartwillshowyoutherequiredPROLCunitsize,thesettingofthedischargeperiod,and
thesettingmode.
♦ YoumayalsorefertoourpermaSelectprogramwhichcanbedownloadedfromourwebpagefree
ofcharge.Ithelpsyouinselectingthecorrectsettings.
3Setting of LC unit Size, Discharge Period, Outlets and PIN
(refer to chapter 6.8)
♦ HolddowntheMODE/SAVEbuttonuntilthesettimeisdisplayed.
♦ HolddowntheMODE/SAVEbuttonagainuntilyoureachthecurrentPIN(PINcannotbechanged
here/PINsettingatdeliveryis“ ”).
♦ HolddowntheMODE/SAVEbuttonagainuntilyoureachtheothersettingmenus:
LCunit,dischargeperiod,outlets(onlywithattachedMP-6),andPINchange.Changesettingswith
ashortpushofMODE/SAVEorON/OFF/SELECT.
4Save Settings
(refer to chapter 6.8)
♦ KeeptheMODE/SAVEbuttonpresseduntildisplayshows“ ”.
5Starting perma PRO
(refer to chapter 6.5)
♦ HolddowntheON/OFF/SELECTbuttonuntilthe“RemainingVolume”appearsinthedisplayand
thegreenLEDstartsblinking.
6Stopping perma PRO
(refer to chapter 6.6)
♦ KeeptheON/OFF/SELECTbuttonpresseduntilthedisplayshows“ ”.

permaPRO -3-
1. Various
About this Operating Manual
♦ ThisoperatingmanualisintendedforthesafeoperationofthepermaPROautomaticlubricator.
Itcontainssafetyinstructionswhichmustbeadheredto.
♦ Everyonewhoworksonorwiththelubricatormusthaveaccesstothisoperatingmanualduringtheirshift.
Theymustalsopayattentiontoallrelevantinstructionsandnotices.
♦ Theoperatingmanualmustalwaysbekeptcompleteandineasytoreadcondition.
Terms Used
♦Lubrication system perma PRO
Inthefollowingtext,the“lubricationsystempermaPRO”willeitherbecalled“lubricator”orbyits
name“permaPRO”.
♦Lubrication Canister
Inthefollowingtext,the“LubricationCanister”willbecalled“PROLCunit”.Theusercanorderthe
PROLCunitwithdifferentlubricantsandinsize250cm3and500cm3.
Usage of Safety Instructions
Allsafetyinstructionsinthisoperatingmanualarestandardized.
Danger Signs
Thissignwarnsyouofanydangertopeople’shealthortosubjects.
Tips
Thissignalertsyoutoapplicationtipswhichwillhelpyouindoingcertaintasksquickerandsafer.
1.1 Delivery / Content
♦ permaPROwillbedeliveredaccordingtocustomerspecicationsinregardstotypeofgreaseandsize
ofPROLCunit.
Theusermustonlyassembleitandadjustthedesiredsettings.
♦ Mountingdeviceandscrewsincluded.
♦ OperatinginstructionsandECConformityDeclarationincluded.
Upondelivery,makesuretocheckifthedeliveredgoodscorrespondtoyourorder.perma-tecGmbH
&Co.KGwillnotacceptliabilityforsubsequentclaimsofanyshortcomings.
♦ Pleaseimmediatelyforwardanyclaims:
ofnoticeabletransportdamage:directlytotheforwarder.
ofnoticeablefaults,shortcomingsordefects:directlytoyourpermadistributor.
1.2 Storage
Whenthelubricatorsarenotimmediatelyinstalled,youmustensure
appropriatestorageconditionsindry,dustfreeplaceswithatemperature
of+20°C±5°C(+68°F±9°F).
MakesurethatPROLCunitsandbatterysetsarenotstoredlongerthanoneyear.
Fordriveunit(1)protectionduringstorage:Donotremoveprotectioncover(2),
disc(3),andplug(4)untilyouarereadytoinstallthesystem(seechapter6.2).
(4)
(2)
(1)
(3)

permaPRO-4-
1.3 Markings
♦ ThelubricatorpermaPROisclearlymarkedwithalabel(serialnumber)onthedrivesystemandalabelon
thePROLCunit.
♦CE mark onthedriveunit.
♦UL markonthedriveunit:
“ThisequipmentissuitableforuseinClassI,Div.2,GroupsA,B,CandD;orNon-HazardousLocationsonly.
Warning-ExplosionsHazard-SubstitutionofcomponentsmayimpairsuitabilityforClassI,Division2.
Thelubricantsdispensedbythisequipmentaretohaveashpointsgreaterthan200°F.“
♦ Manufacturer:
perma-tecGmbH&Co.KG
HammelburgerStraße21
97717Euerdorf
Germany
Tel: +49(0)9704609-0 E-mail: [email protected]
Fax:+49(0)9704609-50 Homepage: www.perma-tec.com
1.4 Intended Usage
ThelubricatorpermaPRO
♦ immediatelysuppliesalllubricationpointswithlubricant,ata pressure build-up of max. 25 bar(360psi.),
permanently,preciselyandindependentoftemperature;
♦ haspassedtheenvironmentalauditaccordingtostandardEN60068-2-6(vibrationtest)withoutany
componentdamageormalfunctions.Intest:PROdriveunitwithMP-6,PROLCunit500cm3,andmounting
deviceinvariousmountingpositions;
♦ canbeusedforalllubricationpointsofsliding-androllerbearings,drive-andtransportchains,sliding
guideways,opengearsandseals;
♦mustbeusedwithasuitableprotectionbox(referto”AccessoriesandSpareParts”)ifoperatedoutsideor
aroundsplashingwater;
♦ shouldonlybeconnectedto/usedwithoriginallubricationtubesfromperma-tecGmbH&Co.KG;
♦ isintendedforuseonmachineryandequipment;
♦ isonlytobeusedfortheorderedpurposeandpurposesconrmedbyperma-tec;
♦ isonlytobeusedforoperatingconditionsrecommendedinthisoperatingmanual;
♦ isonlytobeusedwithsettingsandvariationsrecommendedinthisoperatingmanual.
Any other usage, setting, addition, and variation is considered to be inappropriate!
1.5 Legal Requirements
Liability
♦ Theinformation,dataandtipsstatedinthisoperatingmanualwereup-to-dataasoftheprintingdate.
NoclaimsforalreadydeliveredlubricatorspermaPROcanbemadebasedontheinformation,picturesand
descriptions.
♦ perma-tecGmbH&Co.KGcannotbeheldliablefordamagesandmalfunctionscausedby:
inappropriateusage;
unauthorizedalterationstothedrivesystemorthePROLCunit;
inappropriateoperationsonorwiththelubricator;
incorrectoperationandsettingsofthelubricator;
incorrectsettingsoftimeandsizeofthelubricator;
ignoringtheoperatingmanual.
Warranty
♦ Warrantytermsandconditions:seetermsandconditionsofsaleanddeliveryappertainingtoperma-tec
GmbH&Co.KG.
♦ Lodgeanywarrantyclaimswithyourlocalsupplierimmediatelyafterthedefectorerrorhasbeenidentied.
♦ Thewarrantyexpiresinallinstanceswherenoliabilityclaimscanbeenforced.

permaPRO -5-
2. Safety Instructions
2.1 Persons Responsible for Safety
♦ Theoperatororhissafetyofcermustwarrant,
thatalltherelevantregulations,instructionsandlawsareadheredto;
thatonlyqualiedpersonnelwillworkwithandonthelubricator;
thatunauthorizedpersonnelarenotallowedtoworkwithandonthelubricator;
thatthesafetyregulationsareadheredtowhenmountingthelubricatororduringmaintenance.
2.2 General Safety Instructions

♦ Wearenotlayingclaimtocompletenessinregardstothesesafetyinstructions.Pleasecontactperma-tec
CustomerServiceifyouhaveanyquestionsorproblems.
♦ Atthetimeofdeliverythelubricatorisinlinewithstate-of-the-arttechnologyandinprincipleisconsideredto
besafetooperate.
♦ Dangersemanatefromthelubricatorforpersons,thelubricatoritselfandforothermaterialassetsofthe
operatorif:
unqualiedpersonneloperatesthelubricator;
thelubricatorisusedinappropriatelyandforoperationsthatitwasnotintendedtobeusedfor;
thelubricatorsetting/variationisincorrect;
thelubricatorisopenedbyforcewhileinoperation;
thelubricatorisnotmountedwiththepermamountingdevice;
thetubeconnectiontothelubricationpointwasnotcarriedoutandattachedcorrectly;
♦ Operatethelubricatoronlywhenitisinperfectcondition.
♦ Retrotting,changing,orreconstructingthelubricatorisprohibited.perma-tecmustbeconsultedrst.
♦ Onlyoriginaltubeconnectionsandconnectorsfromperma-teccanbeusedonorwiththelubricationsystem
sincethesewillwithholdhighpressuresofupto25bar(360psi).
♦ Ambientmedia,especiallychemicallyaggressivesubstances,canattacksealsandplastic.
2.3 Safety Information for perma PRO
Safety during Installation and Maintenance
♦ Ensurethatallworkstationsandtrafcroutesarecleanandsafe!
♦ Ensurethattherelevantregulationsandguidelinesareadheredtowhentheinstallationormaintenancework
iscarriedoutinplaceswheredangeroffallingexists.
♦ Ensurethattherelevantsafetyandoperatinginstructionsareobservedwhenthelubricatorsareinstalledor
servicedonmachinesorinfactories(i.e.tostopthemachine).
Safety when Handling the PRO LC unit
♦ Avoidcontactoflubricantwitheyes,skin,andclothing!
♦ Avoidswallowingoflubricant!
♦ Preventlubricantfromgettingintosoilorsewersystem!
♦ Observesafetydatasheetsoflubricants!
Youmayalsodownloaddatasheetsoflubricantssuppliedbyperma-tecfromperma-tec´swebpage
(www.perma-tec.com)oraskyourlocalsupplier.
♦ Lubricantontrafcwayswillincreasethedangerofslipping!Therefore,immediatelycleanlubricantfrom
oorswithspecialcleaner.
♦ OnlyuseoriginalPROLCunitsfromperma-tec!
Safety when Handling Batteries!
♦ Avoidcontactofbatterysubstanceswitheyes,skinandclothing!
♦ Avoidswallowinganyleakingbatterysubstances!
♦ Donotexposebatteriestoextremeheatanddonotthrowintoopenre!
♦ Donotrechargebatteries!
♦ Ensurethatregulationsforwastedisposalofbatteriesareobserved!
♦ Onlyuseoriginalbatterysetsfromperma-tec!

permaPRO-6-
Thedashedstandardgrease-anddottedlowtemperature-linesshowthemaximumvaluesallowed.
tubelengthinmeter
-20°C
-10°C
0°C
10°C
20°C
30°C
40°C
50°C
60°C
0°F
20°F
40°F
60°F
80°F
100°F
120°F
140°F
0 1 2 34 5
4
4
3
3
2
2
1
1
Temperaturein°C
 Diagramshowingdependencyofapplicationtemperature
 andtubelength(inner-Ø5mm)forperma-standardgrease
 andlowtemperaturegrease
Temperaturein°F
Applicationareafor
standardgrease
Applicationareafor
Lowtemp.grease
outofspecicationrange
no warranty!
3. Technical Data
gure1
PRO 250 PRO 500
Volume of the PRO LC unit 250cm3500cm3
Length (L) 210mm 260mm
Diameter (D) 92mm 92mm
Weight, empty 1.30kg 1.37kg
Weight,  lled with SF04 1.53kg 1.82kg
Discharge period 1dayto24months 1dayto12months
Discharged volume per lubrication impulse 0.5cm3
Application temperature -20°Cto+60°C/-4°Fto+140°F
Maximum pressure build-up 25bar/360psi
Maximum tube length (inner-Ø 5mm) 5m
Lubricants Greasesuptorated
consistencyNLGI2
Power supply (0 °C to +60 °C / +32 °F to +140 °F) BatterysetPROB(3Valkalinemanganese,notrechargeable)
Power supply, low temperature
(-20 °C to +60 °C / -4 °F to +140 °F) BatterysetPROBPLUS(3Vlithium,notrechargeable)
Emission sound pressure level <70dB(A)
Connection thread G3/8
Protection class IP54
chart1
Combination of these Maximum-
Values can only be realized by
temperatures of ≥ 20 °C/ 68 °F.
At lower temperatures, the
application is limited according
to the diagram below.
L
D
If your application is out of the speci cation range shown in this diagram, please contact your local
distributor. perma-tec cannot be held liable for these applications.
Example:
1.The application temperature is +5 °C / +41 °F. What is the maximum tube length allowed for standard grease?
CorrectAnswer:3mmax.tubelengthforstandardgrease,5mmax.tubelengthforlowtemp.grease(arrow
1meetsthedashedlineofthestandardgreaserangeat3m).
2.You want to use a 4 m tube. Up to which temperature can the system be used?
CorrectAnswer:+10°C/50°Fwithstandardgrease-5°C/23°Fwithlowtemp.grease(arrow3meetsthe
dottedlineoflowtemp.greaseatthe-5°Cmark;andthedashedlineofthestandardgreaseatthe
+10°Cmark).

permaPRO -7-
3.1 Design of the perma PRO Lubricator
Lubricatorsareavailableas250cm3and500cm3versionsandtheycanbesuppliedwiththelubricantrequested
bythecustomer.Theyconsistof(refertogure2):
Protectioncoverforthedriveunit,re-usable.
PROLCunit(LubricationCanister),canbe
suppliedas250cm3and500cm3versionswith
thelubricantrequestedbythecustomer.
Use only original perma PRO LC units!
Batteryset,consistingoftwobatteries.
Thebatteriesarenotrechargeable
andmustbechangedeverytimethe
PROLCunitisreplaced.
Batteries can only be used once!
Usage of perma-tec battery sets only!
Driveunit,consistingofagearmotor,
apumpsystemandanelectronicunit
forthecontrolsystem,re-usable.
gure2

permaPRO-8-
4. Mounting and Assembly of the Lubrication System
4.1 Mounting the Drive Unit onto a Fixing Device for Wall-Mounting
♦ Attachthesuppliedmountingdevicetothedriveunitusingthetwoenclosedhexheadbolts(M6x16)and
thetwowashers.
♦ Screwthemountingdevicewiththedriveunitontoasupportofyoursystem.
Theboringtemplateofthethreemountingscrews(141.5x45)canbeseenbelowingure3oronthe
templatethatisincluded.YouhavetouseatleastthreehexagonscrewsM6x25(e.g.onmetalground).
♦ Beforeyouconnecttheoutletofthedriveunittothelubricanttube,youhavetomakesurethatthe
lubricationpointsandthecompletelubricanttubeispre-lubricatedwiththesamelubricantthatiscontained
inthePROLCunit.Forthat,perma-tecoffersa400glubricationcartridgeformanually-operatedgrease
presseswiththerequestedlubricant.
♦ Connectthelubricanttube(connectionG3/8)totheoutletofthedriveunitandinstallthetubecorrectly
betweentheoutletandthelubricationpoint.Thelubricanttubemustnotbelongerthanvemeters.
Make sure that you assemble the connections and lubricant tubes correctly and tightly to avoid
possible leakage.
141.5
45
gure3
2hexheadbolts
M6x16,maximum
torque3Nm(supplied
forattachingthe
permaPROtothe
mountingdevice)
Hexagonscrews
M6x25
(forwallmounting
onmetal)
2hexagonscrews
M6x25
(forwallmounting
onmetal)
113

permaPRO -9-
4.2 Assembly of the Lubricator
a)
♦ Insertthebatterysetintothedriveunit(accordingtothedirectionofthearrowonthelabel).
b)
♦ PlacethePROLCunitinsidetheprotectioncoverandremovetheplugofthePROLCunit(refertogure5).
gure5
Protectioncover
PROLCunit
Plug
Nofunction!
SettingofPROLCunitsizeisdonevia
menuondisplay
Batteryset
Catch Interlockingteeth
gure4

permaPRO-10-
c)
♦ PushthePROLCunitintotheprotectioncoveruntillubricantcomesoutoftheopening(refertogure6).
d)
♦ PlacethePROLCunitwithitsprotectioncoveronthedrive-unit.Makesurethatthecatchlocksandthatthe
teethofthePROLCunitandthedriveunitinterlock(refertogure4andgure7).
♦ Turnthecoverclockwiseuntilthebayonetcatchlocks.
gure6
gure7

perma PRO -11-
5. Display and Control Elements of the Lubrication System
5.1 Display Elements
TheoperatingstatusofthelubricatorcanbedeterminedviathegreenortheredLEDandviathedisplay
atthecontrolunit(refertogure8)ofthepermaPRO.
ThepermaPROoffersamenu-guidedsetting.Changesofthesettingsareshownonthedisplay.Error
messages,e.g.incasethepressureinthelubricanttubegetstoohigh,arealsoindicatedonthedisplay.
5.2 Function Indication on the Display
ThedisplayislocatedonthecontrolunitofthepermaPRO(refertogure8,chapter5.1).
Thedisplayshowssettings,operatingconditionsanderrormessagesofthelubricator.
Incaseofanerrorfreeoperationofthelubricationsystem,thedisplayshowstheremainingvolumeofthe
mountedPROLCunitinpercentvolume(%Vol.).Figure9showsanexampleofthedisplayedinformation
ifthePROLC500-unitisnewandfull.
push-button
MODE
SAVE
LCD
RedLED
push-button
ON/OFF
SELECT
GreenLED
Connectorfor
distributorMP-6
gure8
The display cannot be switched off by the operator. If the lubrication system is switched off, the display
will always show two lines (see gure 10 below).
%Vol.
LC 500
gure9
gure10
5.3 Function Indication via the LEDs
LED Signal Signal Length Explanation
green ash every10seconds operation(OK)
red ash every3seconds error/malfunction
greenandred ash every3seconds PROLCunitempty
green light permanently Lubricatorisdischarging
greenandred none none Lubricatorswitchedofforbatterylow
chart2

perma PRO-12-
PRESS Short Short
Long > 4 sec. until
the display content
changes completely
Long > 4 sec. until
the display content
changes completely
BUTTON MODE
SAVE
gure11
ON/OFF
SELECT
gure12
MODE
SAVE
gure11
ON/OFF
SELECT
gure12
FUNCTION
Selection
incurrent
display
Changingof
values
Movestonewmenuand
savesselectedvalues
Returnstooriginalmenu
withoutsavingchanges
chart3,gure11,gure12
5.4 Control Buttons
Therearetwopush-buttonsonthecontrolunit(refertogure8)whichcanbeusedforamenu-guidedchangeof
thesettings.
♦ WiththeMODE/SAVEbutton(refertofigure11),youcanreachtheconfigurationmenu,changethemode
andsavethemodifiedsettingsforfurtheroperation.
♦ WiththeON/OFFSELECTbutton(refertofigure12)youcandothefollowing:turnlubricatorOn/Off,increase
dischargeperiod(Days,Weeks,Months-eachtimeyoupressthebuttonincreasesthedischargeperiodby
onecalendarunit),changePROLCunitsize,activateMP-6outletsandsetPIN.
6. Operation and Control
6.1 Preparations
♦ Priortotheinstallationofthelubricator,thelubricationpointandthecompleteconnectiontubemustbe
sufficientlyprelubricatedwiththesamelubricantthatthePROLCunitcontains.Forthis,perma-tecoffersa
400glubricationcartridgeforgreasepresseswiththecorrespondinglubricant(referto“Accessoriesand
SpareParts”).
♦ WheninstallingthepermaPRO,thesuppliedperma-tecmountingdeviceshouldbeused.
♦ Thelubricanttubemustbeinstalledandmountedcorrectly.Thelengthofthelubricanttubemaynotexceeda
maximumof5metersandthetubemustbeaperma-tecproduct.
♦ PleasecheckifthethreadofthepermaPRO(G3/8)correspondstotheconnectionthreadofthelubrication
point.Ifthisisnotthecase,youcanorderacorrespondingreducerorotherpartsfromthepermaaccessory
range.
FortheinitialsettingintooperationofapermaPRO,thepumpsysteminthedriveunitispre-lledwith
SF04fromperma’sstandardrangeoflubricants.Anexceptionismadewithregardtolubricantsforthefood
industry.Acompletedischargeofthispumpllingisguaranteedafterapprox.10discharges(carryoutadditional
discharges,ifnecessary).
6.2 Prior to Operation
♦ Checkallpartsofthelubricatorforobviousdamages!
♦ IsthenewPROLCunitlledwiththerequiredlubricant?
♦ Didyouinsertanewbatteryset?
♦ Didyouremoveprotectioncover,discandplugfromdriveunit(seechapter1.2)?
♦ Didyouassembleandmountallofthepartscorrectlyandtightly?


perma PRO -13-
6.3 Setting into Operation
♦ Ifnecessary,mountthedriveunitontoaxingdeviceforwall-mounting(refertochapter4.1).
♦ InsertthebatterysetintothedriveunitandthePROLCunitintotheprotectioncoverandclosethecomplete
system(refertochapter4.2b-d).
♦ Determinethedischargeperiod(refertochapter6.7).
♦ SetvolumeofPROLCunit,dischargeperiod,outletsofMP-6,andthePINviabuttonsondisplay(referto
chapter6.8).
♦ Switch-onthelubricationsystem(refertochapter6.5).
♦ Carryoutanadditionaldischarge(refertochapter6.8).
IfthedrivemotorhasstartedandthegreenLEDislit,thelubricatorhasstartedtodischarge.Thedisplay
indicatestheremainingvolume(%Vol.)ofthePROLCunit.
The operator must always check the customer-specic settings and if necessary change them before the
lubricator is set into operation!
6.4 During Operation
♦ Carryoutregularinspectionsduringtheoperation.Youshouldpayspecialattentionwithregardtoleakage
andtotheconditionofthelubricator!
♦ Checktheconditionofthelubricanttubeandtheconnectionsregularly!
♦ CheckthellinglevelofthetransparentPROLCunitregularly!
♦ Afteroneorseveraladditionaldischarges,youhavetocalculatethereduceddischargeperiodandnotethis
onyourlubricationandmaintenanceschedule.
♦ Ifamalfunctionisindicatedonthedisplay,youcandeterminethecauseusingthetroubleshootingguide
(refertochart7,chapter8.2).Ifthefaultcannotbexed,pleasecontactyoursupplierfortechnicalsupport.
Additional discharges and long machine standstills must always be taken into account with regard to the
remaining discharge period of the lubricator.
6.5 Switching the Lubrication System On
Toswitchthelubricationsystemon(refertogure13),keeptheON/OFF/SELECTbuttonpresseduntilthe
indication(“ ”)onthedisplayisreplacedbyanindicationoftheremainingvolume–e.g. %VOL(witha
newPROLCunit)–andthegreenLEDstartsblinking.
6.6 Switching the Lubrication System Off
Toswitchthelubricationsystemoff(refertogure14),keeptheON/OFF/SELECTbuttonpresseduntilthe
displaynolongerindicatestheremainingvolume–%VOL–butindicates(“ ”)instead.Whenthelubrication
systemisswitchedoff,allofthesettingsaresaved.Thismeansthatifyoustartthelubricatoragain,itwilltake
uptheoperationatthepointwhereithadbeenswitchedoff.
ON/OFF
SELECT
%Vol.
LC 500
gure13
ON/OFF
SELECT
%Vol.
LC 500
gure14

perma PRO-14-
6.7 Determining the Discharge Period
Thedischargeperiodisautomaticallyfactory-settosixmonthsaccordingtothesuppliedPROLCunit.
Uponrequest,afactory-settingofthedischargeperiodrequiredbythecustomerisalsopossible.Thesizeofthe
PROLCunitistakenintoaccount.
Ifyouwanttodeterminethedischargeperiod,youneedtoknowtherequiredamountofthelubricantincubic
centimetersfor100operatinghours(cm3/100h).Thisinformationcanbetakenfromthetechnicaldocuments
ofthemanufacturerofthelubricationpoint.
Withthisinformation,youcandeterminethedischargeperiodusingthefollowingchart(chart4).
Pleasetakeintoaccountthatincaseofoneorseveraladditionaldischarges,theremainingdischargeperiod
ofthelubricationsystemmustberecalculated(refertochapter6.9).Thisalsoappliesincaseofacut-offofthe
lubricationsystemduetoalongmachinestandstill(e.g.weekendsorannualholidays).Youshouldalsonotethe
resultofyourcalculationoftheremainingdischargeperiodinyourlubricationandmaintenanceschedule.
The perma SELECT software helps you to determine the discharge period.
Visit our website www.perma-tec.com for a free download of this software.
Average discharge volume in cm3per 100 operating hours
PRO LC unit 250 500
Days Weeks Months Days Weeks Months
1 1041.7 148.8 34.3 2083.3 297.6 68.5
2 520.8 74.4 17.1 1041.7 148.8 34.3
3 347.2 49.6 11.4 694.4 99.2 22.8
4 260.4 37.2 8.6 520.8 74.4 17.1
5 208.3 29.8 6.9 416.7 59.5 13.7
6 173.6 24.8 5.7 347.2 49.6 11.4
7 148.8 21.3 4.9 297.6 42.5 9.8
8 130.2 18.6 4.3 260.4 37.2 8.6
9 115.7 16.5 3.8 231.5 33.1 7.6
10 104.2 14.9 3.4 208.3 29.8 6.9
11 94.7 13.5 3.1 189.4 27.1 6.2
12 86.8 12.4 2.9 173.6 24.8 5.7
13 80.1 11.4 2.6 160.3 22.9 --
14 74.4 10.6 2.4 148.8 21.3 --
15 69.4 9.9 2.3 138.9 19.8 --
16 65.1 9.3 2.1 130.2 18.6 --
17 61.3 8.8 2.0 122.5 17.5 --
18 57.9 8.3 1.9 115.7 16.5 --
19 54.8 7.8 1.8 109.6 15.7 --
20 52.1 7.4 1.7 104.2 14.9 --
21 49.6 7.1 1.6 99.2 14.2 --
22 47.3 6.8 1.6 94.7 13.5 --
23 45.3 6.5 1.5 90.6 12.9 --
24 43.4 6.2 1.4 86.8 12.4 --
25 41.7 -- -- 83.3 -- --
26 40.1 -- -- 80.1 -- --
27 38.6 -- -- 77.2 -- --
28 37.2 -- -- 74.4 -- --
29 35.9 -- -- 71.8 -- --
30 34.7 -- -- 69.4 -- --
chart4
Setting mode
Setting point
Discharge period

perma PRO -15-
MODE
SAVE Display ON/OFF
SELECT Meaning / Description
Displayatdeliverywith
attachedPROLCunit
MODE
SAVE
Time
Months
Showsdischargeperiod
PIN-reset
Info
MODE
SAVE
PIN
Changerstdigit
ON/OFF
SELECT
EnterrstdigitofcurrentPIN
PIN“ ”atdelivery
PIN Entry
MODE
SAVE
PIN
Changeseconddigit
ON/OFF
SELECT
Enterseconddigit
ofcurrentPIN
MODE
SAVE
Config.
LC 500
Changefrom
LC500toLC250
ON/OFF
SELECT
SetLCunitsize
LC
MODE
SAVE
88
Outlets
1
3
2
4
5
6
Days
Weeks
Months
%Vol.
LC2500LC2500
Config.
TimeTimePIN
Config.
Time
Months
ChangeMonths
ON/OFF
SELECT
Setdischargeperiod:
EitherMonths,Weeks,orDays
Time
MODE
SAVE
88
Outlets
1
3
2
4
5
6
Days
Weeks
Months
%Vol.
LC2500LC2500
Config.
TimeTimePIN
Config.
Time Weeks
ChangeDaysor
Weeks
ON/OFF
SELECT
Setdischargeperiod:
Goto“Days”or“Weeks”
MODE
SAVE
Config.
Outlets
1
3
2
4
5
6
Outlet1On/Off
ON/OFF
SELECT
Activateoutlets:
Activateoutlet1
OutletsonlydisplayedifMP-6
isconnected
Outlets
Config.
Outlets
1
3
2
4
5
6
Outlet1activated
MODE
SAVE
Config.
Outlets
1
3
2
4
5
6
Outlet2On/Off
ON/OFF
SELECT
Outlet2activated
(ifdesired,otheroutletsmaybeturned
On/Offthesameway)

MODE
SAVE 
MODE
SAVE
Config.
PIN
Changerstdigit
ON/OFF
SELECT
PIN(rstdigit)enterforinitial
congurationorafteraPIN-reset
–otherwise,settingiscomplete
PIN
MODE
SAVE
Config.
PIN
Changeseconddigit
ON/OFF
SELECT
PIN(seconddigit)enterforinitial
congurationorafteraPIN-reset
MODE
SAVE
Congurationnished
chart5
I N T R O
C O N F I G U R A T I O N M E N U
6.8 Settings and Display for perma PRO
 (seecaptiononpage16)
