Mercia Garden Products 01OVLPA0304SDNW-V1 User manual







 

 
















  



2mm Drill bit
x2 





























































 


































¡













¡





 
Before assembly
please make sure you have a
suitable base ready to erect your
building
MADE IN GREAT BRITAIN
Overall Dimensions:
Width = 859mm
Depth = 1313mm
Height = 1856mm
Base Dimensions:
Width = 80mm
Depth = 1190mm
2
134
56
13
14
15
50mm Screw x24
Felt Tacks x80
20mm Screw x6
30mm Screw x 76
16
Door Gable QTY1
AI-01OVLPDG1826X1130-V1
Plain Side QTY 2
AI-01OVLPPS800X1567-V1
Plain Gable QTY 1
AI-01OVLPPG1826X1130-V1
Floor QTY 1
AI-01OSBF795X1180-V1
Roof QTY 2
PI-03-0330
Door QTY 1
AI-01MBDR1600X660-v1
Ridge Bar - 28x28x744mm QTY 1
F2828-744mm
Eave Frame - 28x28x835mm QTY 2
F2828-835mm
Fascia - 12x60x694mm QTY 4
S1260-694mm
Door Strip - 12x28x1530mm QTY 2
S1228-1530mm
Cover Trim - 12x45x1560mm QTY 4
S1245-1560mm
Finial QTY 2
T-hinge QTY 2
PI-07-0021
“L” Bracket QTY 2
PI-07-0012
Turn Button QTY 2
PI-07-0034
Nail Bag
Building Content:
7
8
9
11
12
10
Felt


 
Pre Assembly
Before assembling remove the transportation
blocks from the bottom of each panel.
Take care removing the blocks as to not damage
the panels. Tap with a at headed screwdriver
and hammer.
Dispose of the blocks once removed.
30mm
screw
Pre drill
hole
13
1
Step 1
Parts Needed - No. 1 QTY 1
No. 6 QTY 1
No. 13 QTY 2
Rest the door (No. 6) into the door
gable (No. 1) opening and secure
into place with 2x T-hinges (No. 13)
using 7x30mm per hinge.
*Ensure to align the hinges and
screws with the framing on the
back of the door.
14x30mm Screws
IMPORTANT: Pre-drill before xing screws.
6
IMPORTANT: Pre-drill before xing screws.
4
Step 2
Parts Needed - No. 4 QTY 1
Place the oor (No. 4) onto a rm
and level base. Ensure your base has
suitable drainage and is free from
areas where standing water can
collect.
IMPORTANT: Pre-drill before xing screws.
50mm
screw
Pre drill
hole
23
a
a
Step 3
Parts Needed - No. 2 QTY 1
No. 3 QTY 1
Sit the plain gable (No.3) and the
rst plain side (No. 2) onto the oor.
*Ensure the plain gable sits inside
the plain side.
Fix the panels at the corner using
3x50mm screws.
Do NOT secure the building to the
oor until the roof has been tted.
3x50mm Screws
a
a


 
IMPORTANT: Pre-drill before xing screws.
a
a
a
a
a
a
a
a
a
50mm
screw
Pre drill
hole
2
1
Step 4
Parts Needed - No. 1 QTY 1
No. 2 QTY 1
Rest the assembled door gable
(No.1) and the second plain side
(No. 2) onto the oor.
*Ensure the door gable sits inside
the plain sides.
Fix the panels at the corner using
9x50mm screws.
Do NOT secure the building to the
oor until the roof has been tted.
9x50mm Screws
a
IMPORTANT: Pre-drill before xing screws.
14
7
a
Pre drill
hole
20mm
screw
30mm
screw
b
a
Step 5
Parts Needed - No. 7 QTY 1
No. 14 QTY 2
Attach the “L” brackets (No. 14)
to each end of the ridge bar (No.
7), ensuring the backs are ush
with the edge of the framing
using 2x20mm screws per “L”
bracket.
Fix to both gables centrally with
2x30mm screws per side.
4x20mm Screws
4x30mm Screws b
30mm
screw
Pre drill
hole
8
5
IMPORTANT: Pre-drill before xing screws.
Step 6
Parts Needed - No. 5 QTY 2
No. 8 QTY 2
Attach an eave frame (No. 8) to each
roof sheet (No. 5) as shown in the
illustration using 3x30mm screws.
Fix the the assemble roof sheets
onto the gables, securing each sheet
with 8x30mm screws.
22x30mm Screws
Step 7
Once the roof has been xed into position,
secure the building to the oor using
12x50mm screws.
*Ensure to align the screws with the oor
bearers.
12x50mm Screws
IMPORTANT: Pre-drill before xing screws.
50mm
screw
Pre drill
hole
b
b
b
b
b
b
b


 
Felt
tacks
16
Step 8
Parts Needed - No. 16 QTY 1
Cut the felt into 8 sheets measuring 940mm (L)
x 300mm (W) and lay onto the roof as shown in
the diagram, allowing approximately 50mm of
overhang around the building.
Fix the felt into position using felt tacks at
100mm intervals.
80 x Felt Tacks
100mm
HANDLE
WITH CARE
1 2
3
4
12
3 4
5
6
7
8
IMPORTANT: Pre-drill before xing screws.
11
11
11
11
30mm
screw
Pre drill
hole
Step 9
Parts Needed - No. 11 QTY 4
Fix the cover trims (No. 11) to the
corners of the building, securing each
trim using 3x30mm screws.
12x30mm Screws
IMPORTANT: Pre-drill before xing screws.
912
9
9
912
30mm
screw
Pre drill
hole
Step 10
Parts Needed - No. 9 QTY 4
No. 12 QTY 2
Attach the fascia’s (No. 9) and nial’s
(No.12) to the front and back of the
building as shown in the illustration,
using 12x30mm screws.
*Ensure to trap the felt between the
fascia’s and the building.
12x30mm Screws


 
IMPORTANT: Pre-drill before xing screws.
30mm
screw
Pre drill
hole
10 10
10
Step 11
Parts Needed - No. 10 QTY 2
Secure the door strips (No. 10) to the
inside of the door gable, xing each
strip into place with 4x30mm
screws.
8x30mm Screws
IMPORTANT: Pre-drill before xing screws.
Step 12
Parts Needed - No. 15 QTY 2
Attach the turn buttons (No. 15) to the
door gable as shown in the illustration,
xing each turn button into place using
2x30mm screws.
2x30mm Screws
Pre drill
hole
30mm
screw
15
It is ESSENTIAL that you apply wood
treatment immediately after the building
has been assembled.



¡




¡


¡

¡


¡



¢





¡
¡¡

¢


¢

 
¡








£

 








£
¤¥













¢


¤





















