Mercia Garden Products 0619LOG001-V4 Instruction manual

P 1
2mm Drill bit
Winter = High Moisture = Expansion
Summer = Low Moisture = Contraction
All buildings should be
erected by two adults
For ease of assembly, you
MUST pilot drill all screw
holes and ensure all screw
heads are countersunk.
CAUTION
Every eort has been made during the
manufacturing process to eliminate the
prospect of splinters on rough surfaces of the
timber. You are strongly advised to wear gloves
when working with or handling rough sawn
timber.
Please retain product label and instructions for future reference
General Instructions
BEFORE YOU START PLEASE READ INSTRUCTIONS CAREFULLY
- Check the pack and make sure you have all the parts listed.
- When you are ready to start, make sure you have the right tools at hand (not supplied)
including a Phillips screwdriver, Stanley knife, wood saw, step ladder and drill with 2mm
bit.
- Ensure there is plenty of space and a clean dry area for assembly.
TIMBER
As with all natural materials, timber can be aected during various weather conditions.
For the duration of heavy or extended periods of rain, swelling of the wood panels may
occur. Warping of the wood may also occur during excessive dry spells due to an interior
moisture loss. Unfortunately, these processes cannot be avoided but can be helped. It is
suggested that the outdoor building is sprayed with water during extended periods of
warm sunshine and sheltered as much as possible during rain or snow.
BUILDING A BASE
When thinking about where the building and base are going to be constructed:
Ensure that there will be access (60cm) to all sides for maintenance work and annual
treatment.
Ensure the base is level and is built on rm ground, to prevent distortion. Refer to
diagrams for the base dimensions. The base should be slightly smaller than the external
measurement of the building, i.e. The cladding should overlap the base, creating a run
o for water. It is also recommended that the oor be at least 25mm above the
surrounding ground level to avoid ooding.
TYPES OF BASE
- Concrete 75mm laid on top of 75mm hard-core.
- Slabs laid on 50mm of sharp sand.
Whilst all products manufactured are made to the highest standards of Safety and in
the case of childrens products independently tested to EN71 level, we cannot accept
responsibility for your safety whilst erecting or using this product.
Refer to the instructions pages for your specic product code
For ease of assembly use a
rubber mallet to t the log
boards. Do NOT use a heavy
hammer.
Ensure to measure and check before cutting
boards.
0619LOG001-V4 (2x2.5m)
0619LOG001-V4: 2x2.5m 19mm apex cabin
For assistance please contact customer care on: 01636 821215
Mercia Garden Products Limited,
Sutton On Trent,
Newark,
Nottinghamshire,
NG23 6QN
www.merciagardenproducts.co.uk
It is advisable to use a hand
saw when cutting roof and
oor boards.
To ensure log boards are even, use a spirit
level to check each layer has been installed
correctly.

2
1
3
4
5
6
7
8
9
10
11
13
14
17
18
Storm Brace - 27x44x2000mm QTY 8
F2744-2000
19
20
15
16
21
P 2
0619LOG001-V4
Overall Dimensions:
Width = 2614mm
Depth = 2024mm
Height = 2542mm
Base Dimensions:
Width = 2304mm
Depth = 1803mm
Please retain product label and instructions for future reference
Before assembly
please make sure you have a
suitable base ready to erect your
building
MADE IN GREAT BRITAIN
Short Window Pack*
QTY 1
Single Door Pack* LOG 001 Gable - 2500mm
QTY 2
Starter Board - 19x66x2500mm QTY 2
LB19RT66-A-2500
Log Board - 19x120x1370mm QTY 6
LB19-B-1370
Log Board - 19x120x310mm QTY 30
LB19-B-310
Log Board - 19x120x310mm QTY 12
LB19-C-310
Log Board - 19x120x2500mm QTY 19
LB19-A-2500
Log Board - 19x120x2000mm QTY 38
LB19-A-2000
Log Board - 110x19x2000mm QTY 2
LB19RG110-A-2000
Roof Purlin - 40x90x2004mm QTY 3
F4090-A-2004
Fascia - 16x120x1347mm QTY 4
S16120-1347
Eaves Frame - 44x27x2000mm QTY 2
F2744-2004
Roof Board - 121x16x1344mm QTY 38
MB16-C-1344
Floor Board - 121x16x2264mm QTY 16
MB16-C-2264
Bearer - 44x44x2304mm QTY 2
F4444-2304-PT
Bearer - 44x44x1715mm QTY 9
F4444-1715-PT
Log Board - 120x19x2500mm
LB19-AD-2500
*All components for the Windows and Doors are
shown in the Windows and Doors instruction packs.
Felt
12 Closure Trim - 16x28x2400mm (approx length) QTY 8
S1628-2400

Felt Tacks x200
70mm Screw x56
Nail Bag
40mm Screw x280
30mm Screw x48
60mm Bolt Set x16
P 3
Please retain product label and instructions for future reference
Pre-assembly
*Please note:
Each board interlocks at
either end in a staggered pattern.
Before securing ensure that the boards
are tted properly in their respective
tongues and grooves.

Pre drill
hole
70mm
screw
Pre drill
hole
70mm
screw
Pre drill
hole
b
a
a
b
For assistance please contact customer care on: 01636 821215
Mercia Garden Products Limited,
Sutton On Trent,
Newark,
Nottinghamshire,
NG23 6QN
www.merciagardenproducts.co.uk
P 4
Please retain product label and instructions for future reference
Step 1
Parts Needed - No. 17 QTY 2
No. 18 QTY 9
Lay the bearers (No’s. 17 & 18 )
onto a rm and level surface
(free from areas where standing
water can collect ) as shown in the
illustration.
Fix the framing together at each
corner using 8x70mm screws,
ensuring the frame is ush.
8x70mm Screws
70mm
screw
Step 2
Parts Needed - No. 4 QTY 2
No. 9 QTY 2
Place the starter boards (No’s. 4
& 9) on to assembled base frame
along the longest sides.
*Ensure the notches at either
end of each board are ush
and level with the ends of the
frame.
Fix each of the starter boards to
the frame by screwing through
the notch into the frame as shown
in the illustration.
4x70mm Screws
17
18
18
18 18 18 18
18
18 18
4
4
9
9
4
17
IMPORTANT: Pre-drill before xing screws. IMPORTANT: Pre-drill before xing screws.
Following the same
method arrange the
remaining framing (No. 18)
inside the assembled frame.
*Ensure there is an equal
amount of space between
each frame.
Secure each of the frames in
place using 2x70mm screws
for each side of the bearer,
ensuring the framing remains
level.
28x70mm Screws 18
17
18
Example picture
2 screws per bearer per end

P 5
Please retain product label and instructions for future reference
Step 3
Parts Needed - No. 5 QTY 6
No. 6 QTY 6
No. 8 QTY 6
No. 9 QTY 12
Following the same method
outlined in Pre-Assembly, lay
the rst 6 boards (No’s. 5, 6
8 & 9) onto the starter boards
to create your rst level.
*Ensure that the boards are
level and ush with each
other as you lay each one.
Step 5
Parts Needed - No. 6 QTY 12
No. 7 QTY 6
No. 8 QTY 6
No. 9 QTY 12
Following the same method
outlined in Pre-Assembly, lay
the next 6 boards (No’s. 6, 7,
8 & 9) onto the assembly to
create your second level.
*Ensure that the boards are
level and ush with each
other as you lay each one.
*Doors can be hung once the
boarding has enclosed the
door frame by 12-13 boards,
refer to door installation
instructions, if not, you can
install the door at step 7.
9
9
5
6
8
9
6
6
7
9
8
Step 4
Once you have laid 6 log boards (o
of the starter) up the door section,
slide the assembled door frame (No.
2) over the boards resting the frame
on top of the starter board.
*Please note: This image is for illustra-
tive purposes and may dier from
your choice in product (regarding
door position). Nevertheless the
process of tting the door frame is
the same.
**Please Note: The short boards at
the
front of the building (either side of
the door and window opening’s) can
be placed either side depending on
your needs.

P 6
Please retain product label and instructions for future reference
Please retain product label and instructions for future reference
Step 7 (See Pre-Assembly)
Parts Needed - No. 6 QTY 12
No. 7 QTY 6
No. 8 QTY 6
No. 9 QTY 12
Following the same method
outlined in Pre-Assembly, lay
the remaining boards (No’s. 6, 7,
8 & 9) onto the assembly to
bring the board level to the top
of the window and door frames.
*Ensure that the boards are
level and ush with each
other as you lay each one.
9
6
6
7
9
8
Step 6
Once you have laid the second
level of boards onto the assembly
slide the window(s)(No. 1) between the
smaller boards and rest on to the
longer board.
*Ensure the boards are level with
each end.
*Please note: This image is for
illustrative purposes and may
dier from your choice in product
(regarding window position ).
Nevertheless the process of tting
the window is the same.
Step 8
Parts Needed - No. 8 QTY 1
No. 10 QTY 2
No. 20 QTY 1
Following the same method
outlined in Pre-Assembly, lay
the last two boards (No’s. 8 & 20)
onto the front of the assembly.
Once in position place log
board AR (No. 10) onto the
window and plain side.
Step 9
Parts Needed - No. 3 QTY 2
Place the gable tops (No. 3) onto
the assembly. Fix into position by
screwing through the notches as
shown in the illustration.
*Ensure that the boards are level
and ush with each other as you
lay each one.
4x70mm Screws
Pre drill
hole
70mm
screw
10
8
20
3
3
10

P 7
Please retain product label and instructions for future reference
Pre drill
hole
70mm
screw
40mm
screw
Pre drill
hole
*Cut to t
23b 15
15
15
11
11
11
11
IMPORTANT: Pre-drill before xing screws.
a
b
Step 11
Parts needed - No. 11 QTY 3
Align the Roof Purlin(s) (No.
11) into the cut out slots on each
gable top ensuring each roof purlin
interlocks the boards.
Secure the roof purlin at
each end by screwing through the
bars into the boards (ensure to
pre-drill to avoid the boards split-
ting) using 4x70mm screws per
purlin.
*Please note: The gable shown is for
illustrative purposes and may dier
in width from your choice in prod-
uct.
Nevertheless, despite any dierenc-
es
the process of xing the roof purlin
is the same.
12x70mm Screws
a
b
Step 12
Parts needed - No. 15 QTY 38
Place the rst two roof
board’s (No. 15) onto the assembly
on each side, making sure the
boards are ush to the end of the
roof purlin. Once in position x to
each purlin using 3x40mm screws.
*Ensure the roof boards meet at the
top of the apex and leave an over-
hang at the bottom.
Continue adding the roof boards
along the roof, xing each one into
position using 3x40mm screws,
making sure that each board is
interlocked, ush at the bottom &
meet at the top of the apex.
The last board on each side
will overhang: Using a straight edge
and a pencil mark out a line as
a guide.
Cut along the pencil mark and
remove the excess. Place the cut
down board’s back onto the roof
and secure into place using
3x40mm screws per board.
*Please Note: This image is for
illustrative purposes and may
dier from your choice in product.
Nevertheless the process of
cutting and tting the last roof
board(s) is the same.
114x40mm Screws
a
b
IMPORTANT: Pre-drill before xing screws.
a
b

P 8
Please retain product label and instructions for future reference
16
Step 13
Parts Needed - No. 14 QTY 2
Ensuring the roof boards are ush
at the overhanging side and meet
at the apex, x the eaves frames
(No. 14) to the underside of the roof
boards using 9x40mm screws as
shown in the illustration
*Please Note: This image is for
illustrative purposes and may
dier from your choice in
product. Nevertheless the process
of xing the eaves frames is the
same.
18x40mm Screws
40mm
screw
Pre drill
hole
Step 14
Parts Needed - No. 16 QTY 17
Place the rst oor board (No. 16)
inside the building ush to the log
board on one side. Continue adding
the oor boards (internally) making
sure to interlock each individual
board.
*Do NOT secure the boards until
the last board has been measured
and cut.
Following the same method outlined
previously measure the gap between
the bottom of the tongue (on the last
board placed) and the log board.
Using a straight edge mark out the
measurement onto the last oor
board (No. 16) and cut along the
length removing the excess.
**Please note: Mark the nal board
2mm under the measurement; This
will allow the timber to expand and
contract correctly.
Once all the oor boards are in
position secure each board into
position using 8x40mm screws.
***Please Note: Ensure to screw
through each of the oor boards
into the oor bearers.
136x40mm Screws
40mm
screw
Pre drill
hole
*Cut to t
16
28
14
IMPORTANT: Pre-drill before xing screws. IMPORTANT: Pre-drill before xing screws.

P 9
Please retain product label and instructions for future reference
HANDLE
WITH CARE
12
3
4
Felt
tacks
Step 17
Parts needed - No. 21
Cut the felt into three strips and lay
onto the roof in the order shown in
the illustration.
*Ensure there is approximately
50mm of overhanging felt each
side.
Once the felt is laid out x to the
roof using felt tacks at 100mm
intervals.
*Felt size: 2124mm
88x Felt Tacks
1. 2.
3.
Closure Trim
Internal
23
*Measure and cut the
closure trims to
t the internal space.
23
23
Closure Trim
Internal
12
*Measure and cut the
closure trims to
t the internal space.
12
12
Pre drill
hole
30mm
screw
*trim to t
Step 15
Parts needed - No. 12 QTY 4
Inside the building place the closure
trim (No. 12) against the boarding
and align with the roof as shown in
the illustration, ensuring the angled
face follows the roof line.
Once in position x each trim
into place by pre drilling a pilot hole
and using 6x30mm screws per trim,
equally spacing them along the face
of the board.
24x30mm Screws
30mm
screw
Pre drill
hole
*Cut to t
Step 16
Parts needed - No. 12 QTY 4
Once the oor has been laid arrange the
closure trim (No. 12) around the outside
edge of oor (internally), measure and cut
down accordingly to best match the
internal space.
Secure each trim section into place using
6x30mm spaced equally along the board
as shown in the illustration.
*Do NOT x the closure trim to the oor
boards.
24x30mm Screws
RoofRoof

P 10
Please retain product label and instructions for future reference
It is ESSENTIAL that you apply wood treat -
ment immediately after the building has
been assembled.
Step 18
Parts Needed - No. 13 QTY 4
Align the fascia’s (No. 13 ) with
the roof and x into place using
3x40mm screws per fascia,
making sure to screw through the
fascia into the roof purlins and
eaves frame.
*Ensure the angled cuts meet
at the top of the apex.
12x40mm Screws
Pre drill
hole
40mm
screw
14
14
14
14
IMPORTANT: Pre-drill before xing screws.
19
19
Pre drill
hole
60mm
bolt
Step 19
Parts needed - No. 19 QTY 8
Arrange the storm braces (No. 19 )
around the building (internally ).
Place 2x storm braces per side
xing into place using 2x 60mm
bolts per brace making sure the
washer & nut are tightened from
the outside of the building.
*Ensure the storm braces are
secured at the highest point
possible on each side.
**Storm braces will help your
building expand and contract
properly.
***Important: Ensure each
bolt is tightened using a
washer so as not to damage
the log boards.
16x60mm Bolt Sets
