Mercia Garden Products 01VINLOG0303-V1 Instruction manual

P 1
01VINLOG0303-V1 & 01VINSTR0303-V1
3x3 Log store and 3x3 store
2mm Drill bit
x2 Winter = High Moisture = Expansion
Summer = Low Moisture = Contraction
All building’s should be
erected by two adults
For ease of assembly, you
MUST pilot drill all screw
holes and ensure all screw
heads are countersunk.
For assistance please contact customer care on: 01636 880514
Mercia Garden Products Limited,
Sutton On Trent,
Newark,
Nottinghamshire,
NG23 6QN
www.merciagardenproducts.co.uk
CAUTION
Every eort has been made during the
manufacturing process to eliminate the
prospect of splinters on rough surfaces of the
timber. You are strongly advised to wear gloves
when working with or handling rough sawn
timber.
Please retain product label and instructions for future reference
General Instructions
BEFORE YOU START PLEASE READ INSTRUCTIONS CAREFULLY
- Check the pack and make sure you have all the parts listed.
- When you are ready to start, make sure you have the right tools at hand (not supplied)
including a Phillips screwdriver, Stanley knife, wood saw, step ladder and drill with 2mm
bit.
- Ensure there is plenty of space and a clean dry area for assembly.
TIMBER
As with all natural materials, timber can be aected during various weather conditions.
For the duration of heavy or extended periods of rain, swelling of the wood panels may
occur. Warping of the wood may also occur during excessive dry spells due to an interior
moisture loss. Unfortunately, these processes cannot be avoided but can be helped. It is
suggested that the outdoor building is sprayed with water during extended periods of
warm sunshine and sheltered as much as possible during rain or snow.
Our buildings are pre treated with a water based treatment**; this only helps to protect
the product during transit and for upto 3 months against mould. To validate your
guarantee and ensure longevity of the product, it is ESSENTIAL the building is treated
with a wood preserver within the rst three months of assembly and thereafter in
accordance with the manufactures recommendations. Care must be taken to ensure
the product is placed on a suitable base.
BUILDING A BASE
When thinking about where the building and base is going to be constructed:
Ensure that there will be access to all sides for maintenance work and annual
treatment.
Ensure the base is level and is built on rm ground, to prevent distortion. Refer to
diagrams for the base dimensions, The base should be slightly smaller than the external
measurement of the building, i.e. The cladding should overlap the base, creating a run
o for water. It is also recommended that the oor be at least 25mm above the
surrounding ground level to avoid ooding.
TYPES OF BASE
- Concrete 75mm laid on top of 75mm hard-core.
- Slabs laid on 50mm of sharp sand.
Whilst all products manufactured are made to the highest standards of Safety and in
the case of childrens products independently tested to EN71 level, we cannot accept
responsibility for your safety whilst erecting or using this product.
Refer to the instructions pages for you specic product code
Pressure Treated Timber
Pressure treating is a chemical process which helps to protect wood against adverse weather which could
lead to rot or insect damage.
The most common chemicals used to pressure treat wood are Alkaline Copper Quaternary (ACQ),
Copper Azole (CA), and Micronized Copper Quaternary (MCQ).
Safety: Always wear gloves, eye protection and a dust mask when handling wood. Due to chemicals in
pressure treated wood, never burn its sawdust or scraps; instead dispose in a landll.

50mm Screw x26
30mm Screw x11
70mm Screw x5
30mm Black Screw x30
Step 1
Place the oor onto a rm and level
base, ensuring the base has suitable
drainage & is free from areas where
standing water can collect.
Pre Assembly
Before assembling remove the transportation
blocks from the bottom of each panel.
4
3
72
Step 2
Place the rst gable, back panel and
rear post onto the oor. Secure each
panel to the rear post using 3x50mm
screws per panel.
*Ensure the panels are ush to the
inside edge of the post.
Fix the panels to the oor with
2x50mm screws per panel, making
sure to align the screws with the
oor bearers.
*Before securing to the oor ensure
the post is ush with end of the oor.
10x50mm Screws
Pre drill
hole
50mm
screw
P 2
01VINLOG0303-V1 & 01VINSTR0303-V1
Overall Dimensions:
Length = 992mm
Width = 1003mm
Height = 1559mm
Base Dimensions:
Length = 968mm
Width = 968mm
Please retain product label and instructions for future reference
Before assembly
please make sure you have a
suitable base ready to erect your
building
MADE IN GREAT BRITAIN
2
13456
7
8
9
10
Right Gable Back Panel Left Gable Floor Roof Door
Rear Post - 75x75x1511mm QTY 2
Front Post - 75x75x1305mm QTY 2
Side Fascia - 12x95x1003mm QTY 2
Front Fascia - 12x95x991mm
11
T-Hinge QTY 3
12
Hasp & Staple
13
Turn Button QTY 2
(01VINSTR0303-V1 only)
Nail Bag
(01VINSTR0303-V1 only)
(01VINSTR0303-V1 only)
(01VINSTR0303-V1 only)

Step 4
Following the same method outlined
in steps 2 & 3 x the second gable into
position and secure the front posts
in place using 50mm screws.
11x50mm Screws
Step 3
Attach the second rear post to the building,
screwing though the panel into the post
as shown in the illustration.
*Ensure the panel is ush to the inside
edge of the post.
3x50mm Screws
7
Pre drill
hole
50mm
screw
Pre drill
hole
50mm
screw
Step 5
Place the roof on top of the building,
aligning the roof so that it is ush with
the rear. Secure the roof in place with
4x70mm screws as shown in the
illustration.
*Ensure to screw through the roof into
the posts.
4x70mm Screws
Pre drill
hole
70mm
screw
Step 6
Attach the fascia’s to the front and
sides of the building, securing each
fascia into place using 3x30mm
screws.
9x30mm Screws
Pre drill
hole
30mm
screw
9
9
10
P 3
Please retain product label and instructions for future reference
5
8
8
2

It is ESSENTIAL that you apply wood
treatment immediately after the building
has been assembled.
6
11
Step 7: 01VINSTR0303-V1 Only
Place the door into the door gap
and x into place using 3x T-hinges
securing each hinge with 7x30mm
black screws.
*Ensure the door can open & close
freely without restriction.
21x30mm Black Screws
30mm
screw
Pre drill
hole
12
13
Step 8: 01VINSTR0303-V1 Only
Fix the turn buttons to the top and
bottom of the posts, ensuring they
fasten the door, using 2x30mm
black screws.
Secure the hasp and staple to the
post and door using 5x30mm black
scerws.
7x30mm Black Screws
30mm
screw
Pre drill
hole
a
b
a
b
*Please note: The door can be hinged either way
depending on your needs for the product.
