Mercia Garden Products 01LOGST-V1 Instruction manual

01LOGST-V1 16/03/2012
Overall Dimensions:
Length = 803mm
Width = 1943mm
Height = 1264mm
Base Dimensions:
Length = 740mm
Width = 1830mm
For Assistance Please
Contact Customer Care on
01636 880514
2mm Drill bit
x2
Winter = High Moisture = Expansion
Summer = Low Moisture = Contraction
This building should be erected by
two people.
For ease of assembly, it is advisable to
pilot drill all screw holes and ensure
all screw heads are countersunk.
BEFORE YOU START PLEASE READ INSTRUCTIONS CAREFULLY
- Check the pack and make sure you have all the parts listed.
- When you are ready to start, make sure you have the right tools at hand
(not supplied) including a Phillips screwdriver, Stanley knife, wood saw,
step ladder and drill with 2mm bit.
- Ensure there is plenty of space and a clean dry area for assembly.
TIMBER
As with all natural materials, timber can be aected during various weather
conditions. For the duration of heavy or extended periods of rain, swelling of the
wood panels may occur. Warping of the wood may also occur during excessive
dry spells due to an interior moisture loss. Unfortunately, these processes cannot
be avoided but can be helped. It is suggested that the outdoor building is
sprayed with water during extended periods of warm sunshine and sheltered as
much as possible during rain or snow.
Our buildings are delivered pre-treated with a water based timber treatment
however this only helps to protect during transit of your garden item. To
validate your guarantee and for better protection against weathering it is
ESSENTIAL that you treat the garden building with a wood preserver within 3
months of assembly. This will need to be re-applied annually to ensure longevity
of your building. Care must be taken when constructing the garden building
that it is not touching the ground and is on a suitable base.
BUILDING A BASE
When thinking about where the building and base is going to be constructed: Ensure that there will be access to all sides for maintenance
work and annual treatment.
TYPES OF BASE
- Concrete 75mm laid on top of 75mm hard-core.
- Slabs laid on 50mm of sharp sand.
Ensure the base is level and is built on rm ground, to prevent distortion. Refer to diagrams for the base dimensions, The base should be
slightly smaller than the external measurement of the building, i.e. The cladding should overlap the base, creating a run o for water. It is also
recommended that the oor be at least 25mm above the surrounding ground level to avoid ooding.
Whilst all products manufactured are made to the highest standards of Safety and in the case of childrens products independently tested to EN71
level,we cannot accept responsibility for your safety whilst erecting or using this product.
Please retain product label and instructions for future reference
Before assembly
please make sure you have a
suitable base ready to erect your
building
MADE IN GREAT BRITAIN
Fixing Kit
Floor Qty 2
2
1
3
45
Left Gable
Qty 1
Right Gable
Qty 1
Back Panel
Qty 2
Roof
Qty 1
Corner
Bracing
Qty 3
6
7
8
9
1x Front Fascia- 7x50x1929mm
2x Side Fascia- 7x50x828mm
1x Front Support- 27x45x970mm

Nail Bag
40mm Screw x4
30mm Screw x12
50mm Screw x30
20mm Screw x14
Step 1
Remove transportation blocks
from the bottom of each panel
before beginning assembly. Each
Panel should have two blocks.
Place the floor on a firm and level base, ensure
base has suitable drainage free from areas where
standing water can collect. (see front page on
base requirements).
Place both oors next to each other with the oor
framing facing up and x together using 3x40mm
screws.
3x40mm screws
Step 2
1
1
1
1
3 x 50mm screws
DO NOT SECURE THE BUILDING TO
THE FLOOR UNTIL AFTER THE
ROOF HAS BEEN FITTED.
Position the panels so there are
equal gaps between the oor
and cladding
Step 3
Fix the corners with
3 x 50mm screws as in the
diagram.
3
4
Attach the right gable and a back panel
together with 3x50mm screws.
6 x 50mm screws
DO NOT SECURE THE BUILDING TO
THE FLOOR UNTIL AFTER THE
ROOF HAS BEEN FITTED.
Fix the corners with
3 x 50mm screws as in the
diagram.
Position the panels so there are
equal gaps between the oor
and cladding
Step 4
Attach the left gable and the second
back panel together with 50mm screws.
2
4

6 x 50mm screws
Step 5
Attach the roof ontop of the gables and
x through the framing on the side into
the gable cladding using 50mm screws.
5
12 x 20mm screws
Step 6
Attach the Front Support to the roof and
oor using a corner brace at each end.
Fix each corner brace using 4x20mm
screws.
Attach a third corner brace to x the roof
to the back panels using 4x20mm
screws.
8
9
9
9
9
12 x 50mm screws
Fix the panels to the oor
with 3x50mm screws per
panel as in the diagram.
Position the panels so there are
equal gaps between the oor
and cladding
Step 7
Fix the panels to the oor using 50mm
screws as shown in the illustration.
b
b
bb
b
b
b
b
bb
b
b
b
10 x 30mm screws
Step 8
Attach the front fascia to the edge of the
roof using 4x30mm screws.
Attach the side fascias using 3x30mm
screws each.
Make sure the screws go through the
fascia and into framing.
