LIMITED WARRANTY
All goods sold hereunder are warranted to be free from defects in material and factory workmanship for a period of three years from the
date of purchase. Decorative finishes warranted for one year. We will replace at no costs goods that prove defective provided we are
notified in writing of such defect and the goods are returned to us prepaid at Sanford, NC, with evidence that they have been properly
maintained and used in accordance with instructions. We shall not be responsible for any labor charges or any loss, injury or damages
whatsoever, including incidental or consequential damages. The sole and exclusive remedy shall be limited to the replacement of the
defective goods. Before installation and use, the purchaser shall determine the suitability of the product for his intended use and the
purchaser assume all risk and liability whatever in connection therewith. Where permitted by law, the implied warranty of merchantability
is expressly excluded. If the products sold hereunder are consumer products, the implied warranty of merchantability is limited to a
period of three years and shall be limited solely to the replacement of the defective goods. All weights stated in our catalogs and listed
are approximate and are not guaranteed.
â
Sensor-Operated Battery-Powered
Lavatory Faucets
Z6920
Z6920
AquaSense
Z6920 Series
Sensor-Operated Lavatory Faucet for
Battery or Plug-In Installations.
Installation, Operation, Maintenance,
and Parts Manual
Patented and Patents Pending

IMPORTANT:
 ALL PLUMBING IS TO BE INSTALLED IN ACCOR-
DANCE WITH APPLICABLE CODES AND REGULA-
TIONS.
 FLUSH ALLWATER LINES PRIOR TO INSTALLATION.
 SENSOR UNITS SHOULD NOT BE LOCATED ACROSS
FROM EACH OTHER OR IN CLOSE PROXIMITY TO
HIGHLY REFLECTIVE SURFACES.
1. - Cover Plate Installation
(For faucets with -CP4 or -CP8 suffix)
Remove adhesive backing from gasket and then pass
sensor connector wire and shank through gasket. Align
gasket with faucet bottom and press firmly together. Pass
sensor connector and shank through cover plate and fasten
to the faucet with the provided screws.
3.- Electronics Module Installation
Attach sensor connector wire from the faucet to the mating
sensor connector wire from the eletronics module. Orient
connectors so that the pins are properly aligned before
pressing connectors together. Do not force together,
damage to pins may occur. Secure the cable connectors
with the locking ring provided. Be certain that the cable
connection is made before the batteries are installed.
Attach electronics module to the shank using the hex nut and
gasket provided. Orient the electronics in a convenient
location and tighten hex nut.
DO NOT USE THREAD SEALANT.
2.- Spout Installation
If there is an exsisting faucet, turn off water supply and remove
the old faucet. Assure supply lines are completely flushed and
free of debris. Clean lavatory rim around the mounting area for
the new sensor faucet.
Place the sensor connector wire and shank through cover
plate gasket and hole in the lavatory. Orient black plastic
mounting washer with the slot facing up. Place mounting
washer and star washer over shank and secure the entire
assembly to the lavatory with the mounting nut. The sensor
wires must pass through slot in plastic mounting washer.
*Do not pinch Sensor wires.
4a.- Battery Installation
Loosen the battery cover screw with the supplied allen
wrench. Remove the cover and install the batteries as
indicated on the battery case. Replace the battery cover and
secure.
4b.- ACA Plug-In Adapter Installation
When using the -ACA plug-in power supply remove sticker
at location (A) and plug in adapter.
5.- Filter or Mixing Valve Installation
The supplied inlet filter must be used with every faucet,
unless a mixing valve is ordered. The inlet filter is attached
directly to the electronics modules water inlet. Tempered
water is then supplied to the filter using a standard 1/2 ball
riser (supplied by others.)
The optional mixing valve (-MV) with integral filter replaces
the standard inlet filter. The mixing valve outlet is attached to
the electronics module with a 3/8 compression to 1/2 ball
riser (supplied by others). Hot and cold water is then
supplied to the appropriate mixing valve 3/8 compression
inlets.

â
5
FV321
ZURN INDUSTRIES, INC. ¨COMMERCIAL BRASS OPERATION ¨5900 ELWIN BUCHANAN DRIVE ¨SANFORD NC 27330
Phone: [phone] ¨Fax: [phone] ¨World Wide Web: www.zurn.com
In Canada: ZURN INDUSTRIES LIMITED ¨3544 Nashua Drive ¨Mississauga, Ontario L4V1L2 ¨Phone: [phone] Fax: [phone]
Description Product No.
1) Spout Base with SensorAssembly P6920-1
2) Electronics Box with Solenoid P6920-B-L
3) Solenoid Rebuild Kit (Diaphram, plunger and plunger spring) P6900-SKR
4) Filter Kit P6900-120
5) Base Plate Gasket P6920-42
6) Mounting Kit P6920-43
7) Filter Screen P6900-MV-7
8) Optional Plug-in Power Converter P6920-ACA
9) 5 3/8 Gooseneck Spout with Nut P6900-GB
10) 2.0 GPM Vandal ResistantAerator P6900-20A-GN
11) Shank Gasket P6900-SG
12) 4 Cast Cover Plate w/Gasket P6920-CP4
13) 8 Cast Cover Plate w/Gasket P6920-CP8
14) Mixing Valve w/Filter P6900-MV
Z6920 Repair Kits

OPERATION
1.) Invisible light rays are continually emitted
from the faucet sensor.
2.) When the users hands come into range of
the sensors detection zone (8 approx.), the
beam is reflected back to the sensors reciever
and converted to a low voltage electrical signal
activating a solenoid valve.
3.) After the user removes their hands, the
absense of reflected light stops the low voltage
electrical signal, closing the valve. The circuit
automatically resets for the next user.
4.) If an object is in view continuously for thirty
seconds, the faucet will automatically shut off.
The faucet will remain off until the object is
removed.After the object is removed, the
faucet functions normally.
CARE AND CLEANING INSTRUCTIONS
DO NOT use abrasive or chemical cleaners to clean faucets as
they will dull the luster and attack the chrome or special decora-
tive finishes. Use only mild soap and water, then wipe dry with a
clean cloth or towel. While cleaning the bathroom tile and floor,
the faucet and electronics should be protected from splattering
of water, cleaner, acids and cleaning fluids that can damage the
sensor faucet.
TROUBLESHOOTING GUIDE
PROBLEM
FAUCET WILL NOT
FLOW WATER
POSSIBLE CAUSE
Water supply not turned on.
Batteries not connected.
Cable connection is not
fully engaged.
Solenoid valve inoperative.
Sensor/electronics are
inoperative.
Filter is plugged.
Solenoid valve is dirty.
FAUCET CONTINUES
TO RUN FOR MORE
THAN 30 SECONDS
OR DRIPS
TO DIAGNOSE
Check supply stops.
Check connections.
Check cable connection.
Move hand in front of faucet to
see if solenoid valve is clicking.
Move hand in front of faucet
to see if solenoid valve is clicking.
See note in Step 4.
Shut off water supply. Remove
clean out cap.
Open the solenoid valve
and check for debris. Carefully
observe the way valve goes
together for reassembly.
REMEDY
Turn on water.
Reconnect batteries.
Remove battery, and disengage the
cable connection. Check cable
connection for broken pins and
reconnect cable.Check battery for
voltage level and reinstall.
If clicking, open solenoid valve and
clean it.
If not clicking, replace solenoid
valve.
Remove the battery and short
circuit the battery terminals with
allen wrench. This will reset the
electronics. Replace battery.
Clean the filter and reassemble.
Shut off water supply. Disassemble
solenoid and remove debris from
diaphragm and/or plunger tip.
Reassemble solenoid.
ZURN INDUSTRIES, INC. ¨COMMERCIAL BRASS OPERATION ¨5900 ELWIN BUCHANAN DRIVE ¨SANFORD NC 27330
Phone: [phone] ¨Fax: [phone] ¨World Wide Web: www.zurn.com
In Canada: ZURN INDUSTRIES LIMITED ¨3544 Nashua Drive ¨Mississauga, Ontario L4V1L2 ¨Phone: [phone] Fax: [phone]
AquaSense

is a registered trademark of Zurn Industries, Inc.
â
Printed in the U.S.A. Form No. FV321, 9/02
SPECIFICATION
Voltage:
Sensor Range:
Operating Water
Pressure:
Ambient
Temperature:
Operational Water
Temperature:
Aerator:
6 VDC
(4 AA Alkaline)
7.5 Approximate
20-80 psi
32ºF to 122ºF (0ºC to 50ºC)
35°F to 140°F (2°C to 60°C)
2.0 GPM Vandal-Resistant (Standard)
