Metos RG-350 User manual

9(*(7$%/(6/,&(5
RG-350
,QVWDOODWLRQDQG2SHUDWLRQ0DQXDO
S/N: Rev.: 2.0

 5HY
Dear Customer,
Congratulations on deciding to choose a Metos appliance for your kitchen activities. You
made an excellent choice. We will do our best to make you a satisfied Metos customer
like thousands of customers we have around the world.
Please read this manual carefully. You will learn correct, safe and efficient working meth-
ods in order to get the best possible benefit from the appliance. The instructions and hints
in this manual will give you a quick and easy start, and you will soon note how nice it is
to use the Metos equipment.
All rights are reserved for technical changes.
You will findthe main technical dataon the rating plate fixed to the equipment. When you
need service or technical help, please let us know the serial number shown on the rating
plate. This will make it easier to provide you with correct service.
For your convenience, space is provided below for you to record your local Metos service
contact information.
METOS TEAM
Metos service phone number:...............................................................................................
Contact person:....................................................................................................................

 5HY

 5HY
*HQHUDO  
1.1 Symbols used in the manual .......................................................................................... 1
1.2 Symbols used on the appliance ...................................................................................... 1
1.3 Checking the relation of the appliance and the manual ................................................. 1
1.4 Fig 1 - 5 ......................................................................................................................... 2
1.4.1 Contruction ............................................................................................................ 3
6DIHW\ 
2.1 Safe use of the appliance ............................................................................................... 4
2SHUDWLRQLQVWUXFWLRQV  
3.1 Operation procedures ..................................................................................................... 5
3.1.1 Fitting the pusher plate .......................................................................................... 5
3.1.2 Removing the pusher plate .................................................................................... 5
3.1.3 Fitting the feed hopper ........................................................................................... 5
3.1.4 Removing the feed hopper ..................................................................................... 5
3.1.5 Choosing the right cutting tools ............................................................................. 6
3.1.6 Fitting the cutting tools .......................................................................................... 6
3.1.7 Removing the cutting tools .................................................................................... 7
3.1.8 Using the feeders ................................................................................................... 7
3.2 After use ........................................................................................................................ 8
3.2.1 Cleaning ................................................................................................................ 8
3.2.2 Periodic service ...................................................................................................... 8
,QVWDOODWLRQ 
4.1 Unpacking the appliance ............................................................................................... 9
4.2 Installation ..................................................................................................................... 9
7URXEOHVKRRWLQJ 
6SDUHSDUWV  
7HFKQLFDOVSHFLILFDWLRQV 

 5HY

 5HY
*HQHUDO
1
 *HQHUDO
Carefully read the instructions in this manual as they contain important information re-
garding proper, efficient and safe installation, use and maintenance of the appliance.
Keep this manual in a safe place for eventual use by other operators of the appliance.
The installation of this appliance must be carried out in accordance with the manufactur-
er’s instructions and following local regulations. The connection of the appliance to the
electric and water supply must be carried out by qualified persons only.
Persons using this appliance should be specifically trained in its operation.
Switch off the appliance in the case of failure or malfunction. Have the appliance serviced
by a technically qualified person authorized by the manufacturer and using original spare
parts.
Not complying with the above may put the safety of the appliance in danger.
 6\PEROVXVHGLQWKHPDQXDO
This symbol informs about a situation where a safety risk might be at hand.Given instruc-
tions are mandatory in order to prevent injury.
This symbol informs about the right way to perform in order to prevent bad results, appli-
ance damages or hazardous situations.
This symbol informs about recommendations and hints that help to get the best perform-
ance out of the appliance.
 6\PEROVXVHGRQWKHDSSOLDQFH
This symbol on the appliance warns about sharp knife plates and moving part
 &KHFNLQJWKHUHODWLRQRIWKHDSSOLDQFHDQGWKHPDQXDO
The rating plate of the appliance indicates the serial number of the appliance. If the man-
uals are missing, it is possible to order new ones from the manufacturer or the local rep-
resentative. When ordering new manuals it is essential to quote the serial number shown
on the rating plate. Write your appliances type and theserialnumber in enclosed column.
Type Serial number Time of buying
RG-350

 5HY
*HQHUDO
2
 )LJ

 5HY
*HQHUDO
3
 &RQWUXFWLRQ
)LJ
)LJ
)LJ
)LJ
)LJ
1:A Pusherplate
1:B Locking knob
1:C Feeder/lid
1:D Ejector plate
1:E Cutting tool
1:F Dicing grid
1:G Pestle
1:H Feed tube
1:I Pusherplate shaft
1:J Cabbage screw
1:K Spanner
1:L Pusherplate handle
1:M Switches: -green: start -red: stop
2:A Normal use of feeder
2:B Place/stack products as shown in fig (2:B) to cut in a definite direction
2:C The feed tube is used for cutting long products such as cucumbers
3:A Standard slicer
3:B Dicing cutter
3:C Grimping slicer
3:D1 Fine cut slicer, 1 knife
3:D2 Fine cut slicer, 2 knives
3:F Julienne cutter
3:G1 Type 1 dicing grid, dices in combination with suitable slicer. Cannot be used
combined with 14 mm and 20mm fine cut slicer or 15 - 20 mm standard slicer.
3:G2 Type 2 dicinggrid,dicesin combination with14 mm and 20 mm fine cutslicer
and 15 - 20 mm standard slicer
3:H French fries grid, together with 10 mm and 20 mm standard slicer
3:K Raw food garter
3:L Fine garter
4:A Wall rack, plastic
4:B Brush
4:C Rack for tools, stainless steel, wall or trolley-model.
4:N Feed hopper
5:A ja D Fitting/removing pushing plate
5:I Pushing plate shaft
5:S Feed hopper mounting
5:N Feed hopper
5:C Feeder/lid
5:O Feed hopper shaft
5:P Feed hopper locking knob
5:R Feed hopper locking screw

 5HY
6DIHW\
4
 6DIHW\
 6DIHXVHRIWKHDSSOLDQFH
Take great care not to injure your hands on sharp blades and moving parts.
Never put your hands in the feeder or feed hopper (1:C/4:N).
Hold only the pusherpalte handle (1:L) when the feeder is to be opened or closed.
Always use the pestle (1:G) when cutting through the feed tube (1:H), and never put your
hands into the feed tube.
The 3-phase version of the RG-350 may be installed only by an authorized specialist.
Only an authorized specialist should be allowed to repair the machine and open the ma-
chine housing.
The gabbage screw (1:J) must be unscrewed clockwise by means of the spanner (1:K).

 5HY
2SHUDWLRQLQVWUXFWLRQV
5
 2SHUDWLRQLQVWUXFWLRQV
 2SHUDWLRQSURFHGXUHV
 )LWWLQJWKHSXVKHUSODWH
•Grip the pusher plate with both hands (5:A) and insert the shaft end (5:B) into the
mounting on the machine (5:S)
•Press the pusher plate with the palm of your right hand as far as it will go (5:D).
 5HPRYLQJWKHSXVKHUSODWH
•Raise the pusher plate (1:L) and swing it out to the left so that the feeder/lid (1:C)
is open.
•Grip the pusher plate with both hands (5:A).
•Pull up/out the pusher plate with the right hand.
 )LWWLQJWKHIHHGKRSSHU
•Fit the feed hopper (5:N) to the feeder/lid (5:C) with the feed hopper shaft (5:O)
against the mounting on the machine (5:S) and with the feed hopper locking knob
(5:P) pointing straight out from the machine (unlocked position).
•Press the feed hopper into the feeder/lid as far as it will go.
•Turn the feed hopper locking knob anticlockwise as far as it will go (locked posi-
tion) and turn the feed hopper locking screw (5:R) firmly clockwise.
 5HPRYLQJWKHIHHGKRSSHU
•Turn feed hopper locking knob (5:P) clockwise so that it points straight out from
the machine (unlocked position) and release the feed hopper locking screw (5:R)
anticlockwise, and remove the feed hopper.

 5HY
2SHUDWLRQLQVWUXFWLRQV
6
 &KRRVLQJWKHULJKWFXWWLQJWRROV
•For dicing, thedimensions of the dicing grid (3:G) should beequal to or larger than
the dimensions of the slicing tool (3:A or D).
•Standard slicer (3:A): A Slices firm materials. Dices in combination with type 1
dicing grid (3:G1).
•Dicing grid (3:B): Dices in combination with type 1 dicing grid (3G1) from 12,5 x
12,5 mm upwards.
•Crimping slicer (3:C): Produces rippled slices.
•Fine cut slicer, 2 knives (3:D2): Slices firm and soft foods. Shreds cabbage.
•Fine cut slicer, 1 knife (3:D1): Slices firm, soft, juicy and delicate foods. Shreds
lettuce. 4 or 6 mm mm chops onion in combination with type 1 dicing grid (3:G1)
10 x 10 mm. 4, 6 and 10 mm dices in combination with type 1 dicing grid. 14 and
20 mm dices in combination with type 2 dicing grid (3:G2).
•Julienne cutter (3:F): Shreds and cutscurved French Fries. 2,5 x 6 mm for leaf-free
shredding of gabbage.
•Type 1 dicing grid (3:G1): Dices in combination with suitable slicer. Cannot be
combined with 14 and 20 mm fine cut slicer. See type 2 dicing grid below.
•Type 2 dicing grid (3:G2): Dices in combination with 14 and 20 mm fine cut slicer
or 15 mm and 20 mm standard slicer.
•Potato chip/french fry grid (3:H): Cuts straight potato chips in combination with
10 mm fine cut slicer.
•Raw food grater (3:K): Grates carrots, gabbage, nuts, cheese, dry bread, etc.
•Fine grater (3:L): Fine grates raw potatoes, hard/dry cheese.
Processing frozen foods is stricktly forbidden
 )LWWLQJWKHFXWWLQJWRROV
•Lift the pusher plate (1:A) and swing it out to the left, or remove the feed hopper
(4:N).
•Turn the locking knob (1:B) anti-clockwise and raise the feeder/lid (1:C)
•Place the ejector plate (1:D) on the shaft and turn/press down the ejector plate into
its coupling.
•Fordicing, first place a suitable dicing grid in the machine and then turn the dicing
grid clockwise as far as it will go. Then choose a suitable standard slicer or fine cut
slicer and fit the slicer to the shaft and then turn it so that the slicer drops into its
coupling. For chopping onions, use a fine cut slicer
•For slicing, shredding and grating, fit instead only the selected cutting tool to the
shaft and turn the cutting tool so that it drops into its coupling.
•Fit the gabbage scrwe (1:J) by turning it anticlockwise onto the center shaft of the
cutting tool.
•Lower the feeder/lid and turn the locking knob clockwise to the locked position.

 5HY
2SHUDWLRQLQVWUXFWLRQV
7
 5HPRYLQJWKHFXWWLQJWRROV
•Raise the pusher plate (1:A) and swing it out to the left, or remove the feed hopper
(4:N).
•Turn the locking knob (1:B) anticlockwise and raise the feeder/lid (1:C).
•Remove the gabbage screw (1:J) by turning it clockwise by means of the spanner
(1:D).
•Remove the cutting tool/tools and the ejector plate (1:D).
 8VLQJWKHIHHGHUV
The large feed compartment is used mainly for bulk feeding to potatoes, onions, etc. (2:A)
and for cutting larger products such as cabbage.
The large feed compartment is also used when the material is to be cut in a definite direc-
tion, such as tomatoes and lemons. Place/stack the products as shown in the figure (2:B).
The feed tube is used for cutting long products such as cucumbers (2:C).
The feed hopper (4:N) is used for continuous cutting of large quantities of potatoes, etc.

 5HY
2SHUDWLRQLQVWUXFWLRQV
8
 $IWHUXVH
 &OHDQLQJ
•Switch off the machine and remove the power supply plug from the socketor open
the isolating switch.
•Carefully clean the machine immediately after use.
•If you have used a dicing grid (3:G), leave it in the machine, and use the brush
(4:B) for pushing out any product remaining in the grid.
•Remove the loose parts of the machine, wash them and dry them thoroughly.
•Wipe the machine with a damp cloth.
•Always store the cutting tools (3) on the racks (4:A/4:C) on the wall or trolley.
Always wipe the knives of the cutting tools dry after use.
Never clean the cutting tools or other light alloy objects with a detergent with a high pH
value (often used in dishwashers).
Never use sharp objects or a high-pressure spray gun for cleaning.
Never spray water on the sides of the machine.
 3HULRGLFVHUYLFH
&KHFNHYHU\ZHHN
•Check that the machine stops as soon as the pusher plate (1:A) has been moved up
and swung out, and that restarts when the pusher plate has been swung in and low-
ered.
•Check that the machine cannot be started with the feeder/lid (1:C) removed and
with the pusher plate lowered.
•Removethe plug from the power supply socket and then check that the electric ca-
ble is in good condition and is not craced on the outside.
If any of the two safety functions does not perform as intended or if the electric cable is
cracked, get a specialist to attend to the machine before connecting it back to the power
supply.
•Check that the pusher plate shaft (1:I) has been lubricated as necessary and runs
freely. If the shaft does not run freely, clean it carefully and lubricate it with a few
drops of machine oil.
•Check that the knives and shredder plates are in good condition and sharp.

 5HY
,QVWDOODWLRQ
9
 ,QVWDOODWLRQ
 8QSDFNLQJWKHDSSOLDQFH
Check that all of the parts have been delivered, that the machineoperates as intended, and
that nothing has been damaged in transit. The machine supplier should be notified of any
shortcomings within eight days.
 ,QVWDOODWLRQ
•Connect the machine to an electric power supply which is suitable for themachine.
•Themachine should be placed on a countertop or table which isabout 450-500 mm
high.
•Locate the rack (4:A) for the cutting tools (3) on the wall or (4:C) on a trolley in
the vicinity of the machine for convenient and safe use
Check the following two points without cutting tools or ejector plate (1:D) fitted to the
machine:
•Check that the machine stops when the pusher plate (1:A) is moved up and swung
out, and that it restarts when the pusher plate is swung in and lowered.
•Check that the machine cannot be started with the feeder/lid (1:C) removed and
with the pusher plate lowered.
If the machine does not perform correctly, summon a specialist for remedying the fault
before taking the machine into opration.

 5HY
7URXEOHVKRRWLQJ
10
 7URXEOHVKRRWLQJ
PROBLEM MEASURES
The machine cannot be started, or stops while
its running and cannot be restarted. Check that the plug issecurely fitted into the power supply socket,or thatthe isolating switch is closed . Check that the feeder/lid (1:C), pusher plate (1:A)
or the feed hopper is locked in the correct position. Move down the pusher
plate (1:A) into the feeder/lid. Check that the fuses in the fuse box for the
premises have not blown and that they have the correctrating. Wait for a few
minutes and try to restart the machine. If the machine still fails to run, call a
specialist.
Low capacity or poor cutting results. Make sure that you are using the correct cutting tool or combination of cut-
ting tools (3). Fit the gabbage screw (1:J). Check that the knives and shred-
der plates are in good condition and are sharp. Press the food down loosely.
The cutting tool (3) cannot be removed. Always use the ejector plate (1:D). Use a thick leather glove or the like that
the knives of the cutting tool cannot cut through, and turn the cutting tool
clockwise to release it.
The cabbage screw (1:J) cannot be removed. Use the spanner (1:K) to unscrew the cabbage screw clockwise.

 5HY
7HFKQLFDOVSHFLILFDWLRQV
23
 7HFKQLFDOVSHFLILFDWLRQV
&RQQHFWLRQGLDJUDP5*9
&RQQHFWLRQGLDJUDP5*9
&RQQHFWLRQGLDJUDP5*9
,QVWDOODWLRQGUDZLQJ

Connection-diagram RG-350 220-230V 3 50/60
Musta / black / svart Musta / black / svartMusta / black / svart
Ruskea / brown / brun
Sulake
fuse
säkring
(1F1)
100 mA
Kelt./vihr. yellow/green gul/grön
Magn.kytkin
Magn. switch
Magn.avbrytare
(1S1)
Sulake/ fuse/säkring
200 mA
Kelt./vihr.
yellow/green
gul/grön
Kytkin/Switch/
Avbrytare
(1S6)
Kytkin/Switch/
Avbrytare
(1S5) Kytkin/Switch/
Avbrytare
(1S4)
Kelt./vihr.
yellow/green
gul/grön
Kelt./vihr.
yellow/green
gul/grön
Muut johdot punaisia
Other cables red
Övriga kablar röda
Painonapit
Push buttons
Tryck-knappar
Kelt./vihr.
yellow/green
gul/grön
Valkoinen/white/vit
Valkoinen/white/vit
*1
Musta
black
svart
*2
Ruskea
brown
brun
*1 *1 *1 *2 *2 *2
Teräpesä/knife chamber/
knivhus
Moottori / motor

Connection-diagram RG-350 380-415V 3 50
Musta / black / svart Musta / black / svart
Ruskea / brown / brun
Sulake
fuse
säkring
(1F1)
100 mA
Kelt./vihr. yellow/green gul/grön
Magn.kytkin
Magn. switch
Magn.avbrytare
(1S1)
Sulake/ fuse/ säkring
200 mA
Kelt./vihr.
yellow/green
gul/grön
Kytkin/Switch/
Avbrytare
(1S6)
Kytkin/Switch/
Avbrytare
(1S5)
Kytkin/Switch/
Avbrytare
(1S4)
Kelt./vihr.
yellow/green
gul/grön
Kelt./vihr.
yellow/green
gul/grön
Muut johdot punaisia
Other cables red
Övriga kablar röda
Painonapit
Push buttons
Tryck-knappar
Valkoinen/white/vit
Valkoinen/white/vit
*1
Musta
black
svart
*2
Ruskea
brown
brun
*1 *1 *1
*2 *2 *2
Teräpesä/knife chamber/
knivhus
Sininen / blue / blå
Kelt./vihr.
yellow/green
gul/grön
Moottori / motor

Connection-diagram RG-350 220-240V 1 50/60
Musta / black / svart
Musta / black / svart
Sulake
fuse
säkring
(1F1)
100 mA
Kelt./vihr. yellow/green gul/grön
Magn.kytkin
Magn. switch
Magn.avbrytare
(1S1)
Kelt./vihr.
yellow/green
gul/grön
Kytkin/Switch/
Avbrytare
(1S6)
Kytkin/Switch/
Avbrytare
(1S4)
Kelt./vihr.
yellow/green
gul/grön
Muut johdot punaisia
Other cables red
Övriga kablar röda
Painonapit
Push buttons
Tryck-knappar
Teräpesä/knife chamber/
knivhus
Moottori /
motor
Valkoinen/white/vit
Kelt./vihr.
yellow/green
gul/grön
Kytkin/Switch/
Avbrytare
(1S5)
Kelt./yell./gul
Musta/black/svart
Pun./red/röd
Rusk./brown/brun
Rusk./brown/
brun
Kelt./yell./gul
Sin./blue/blå
Valk./white/vit
Käynn.rele/startrelay/
startrelä
Musta/black/svart
Musta/black/svart
