INSTALLATION INSTRUCTIONS FOR PART 99-7316
KIT FEATURES
•DIN head unit provision
•ISO DIN head unit provision
A) Radio Housing l B) ISO Brackets | C) Trim Plate
KIT COMPONENTS
TOOLS REQUIRED:
99-7316
A
APPLICATIONS
2000-2005 Hyundai XG300/XG350
Phillips Screwdriver I Small Flat Blade Screwdriver
BC

99-7316
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Unclip and remove entire panel sur-
rounding radio and climate controls
including pocket assembly at bottom
of panel. (Figure A)
2
2000-2005 HYUNDAI XG300/XG350
Remove (4) Phillips screws per side
to remove radio and climate control.
Note: It is not necessaryto discon-
nect climate control.
(Figure B)
3
DASH DISASSEMBLY
A
B

99-7316
KIT ASSEMBLY
Slide the DIN cage into the Radio
Housing and secure by bending the
metal locking tabs down. (Figure A)
1
A
Slide the aftermarket head unit into
the cage and secure. ( Figure B)
2
B
DIN HEAD UNIT PROVISION

Mount the ISO Brackets to the head
unit with the screws supplied with
the unit. (Figure A)
1
Slide the head unit into the radio
opening until the side clips engage.
(
Figure B)
2
Snap the Trim plate into the Radio
Housing. (Figure B)
3
ISO DIN HEAD UNIT PROVISION
A
B
99-7316
KIT ASSEMBLY

FINAL ASSEMBLY
1
Locate the factory wiring harness in the dash and make the connection as shown.
Metra recomends using the proper mating adapter and making the connections as
shown. (Isolate and individually tape off the ends of any unused wires to prevent
electrical short circuit.)
2
Re-connect the negative battery terminal and test the unit for proper operation.
3
Reassemble radio and dash assemblies in reverse order of disassembly.
A
A) Strip wire ends back 1/2"
B) Twist ends together
C) Solder
D) Tape
B
C
D
Make wiring connections using the EIA color code chart shown below and the instructions included with the head
unit. Metra recommends making connections as shown below; Strip, Splice, Solder, Tape. Isolate and individually
tape off ends of any unused wires to prevent electrical short circuit.
12V Ignition / Acc . . . Red
12V Batt / Memory . . Yellow
Ground . . . . . . . . . . . Black*
Power Antenna . . . . . Blue
Amp Turn-On . . . . . . Blue / White
Amp Ground . . . . . . . Black / White
Illumination. . . . . . . . Orange
Dimmer . . . . . . . . . . Orange / White
Right Front (+) . . . . . Gray
Right Front (-). . . . . . Gray / Black
Left Front (+) . . . . . . White
Left Front (-) . . . . . . . White / Black
Right Rear (+). . . . . . Violet
Right Rear (-) . . . . . . Violet / Black
Left Rear (+). . . . . . . Green
Left Rear (-) . . . . . . . Green / Black
*NOTE: When Black a wire is not present, ground radio to vehicle chassis.
All colors may not be present on all leads due to manufacturer’s specifications.
METRA / EIA WIRING CODE
FINAL WIRING CONNECTIONS
99-7316
KIT ASSEMBLY
