Metra Electronics 99-7506 User manual

INSTALLATION INSTRUCTIONS FOR PART 99-7506
Cutting ool • Phillips Screwdriver • Socket Wrench
1-800-221-0932 www.metraonline.com
KI FEA URES
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION
• DIN Head Unit Provision with pocket
• ISO DIN Head Unit Provision with pocket
• Double DIN Head Unit Provision
• Stacked ISO DIN Head Unit Provision
• Painted Matte Black to Match Factory
A) Radio Housing • B) Snap-In Pocket • C) ISO Brackets • D) ISO rim Plate • E) Double DIN Brackets
• F) Double DIN rim Plate • G) (4) Panel Clips
KI COMPONEN S
99-7506
APPLICATIONS
2006-2008
C
BE
D
F
F
WIRING AND ANTENNA CONNECTIONS (S ld Separately)
Harness:
• 70-7903 - Mazda harness 2001-up
Antenna Adapter:
• N t required
Mazda MX-5 Miata
A

Dash Disasse bly ....................................................................... 1, 2
Kit Preparation ............................................................................... 3
Kit Asse bly:
DIN Head Unit Provision.................................................................. 4
ISO DIN Head Unit Provision........................................................... 5
Double DIN Head Unit Provision..................................................... 6
Stacked ISO DIN Head Unit Provision............................................ 7
Final Asse bly .............................................................................. 8
99-7506
TABLE OF CONTENTS
KNOWLEDGE IS POWER
Enhance your installation and fabrication skills
by enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com
or call 800-354-6782 for more information
and take steps toward a better tomorrow.
Metra reccommends MECP
certified technicians

99-7506 DASH DISASSEMBL
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Unclip panel below steering column
and remove. (Figure A)
2
MAZDA MX-5 MIATA 2006-2008
Remove (4) Phillips screws from
metal brace below steering column
and remove. (Figure A)
3
Looking at the side of the radio/cli-
mate control panel from underneath
the steering column opening, remove
(1) 10mm bolt from the side of the
radio chassis. (Figure B)
4
Carefully remove the side panels
from each side of the radio/climate
control panel by pulling straight back
towards the rear of the car.
(Figure C)
5
A
B
C
1

99-7506 DASH DISASSEMBL
Remove (2) Phillips screws, (1) on
each side, from the side of the
radio/climate control panel.
(Figure D)
6
Pull radio/climate control panel out,
disconnect plugs and remove.
(Figure E)
7
MAZDA MX-5 MIATA 2006-2008
urn the radio/climate control panel
over and remove the (4) screws that
hold the climate control to the bezel,
then remove the climate control.
(Figure F)
8
D
E
F
2

99-7506 KIT PREPARATION
Attach the (4) Panel Clips to the posts
on the back of the radio housing.
(Figure A)
1
MAZDA MX-5 MIATA 2006-2008
A
3

4
urn over the 99-7506 housing, take
the climate control and screws
removed from the factory panel and
attach the climate control to the kit
housing using the factory screws.
(Figure A)
1
Slide the DIN cage into the Radio
Housing and secure by bending the
metal locking tabs down. (Figure C)
3
A
C
D
Slide the pocket into the bottom
section of the kit housing.
(Figure B)
2
Slide the aftermarket head unit into
the cage and secure.
(Figure D)
4
DIN HEAD UNIT PROVISION
B
99-7506
KIT ASSEMBL

5
Mount the ISO Brackets to the head
unit with the screws supplied with
the unit. (Figure C)
3C
D
Slide the pocket into the bottom
section of the kit housing.
(Figure B)
2
Slide the head unit into the radio
opening until the side clips engage.
(Figure D)
4
ISO DIN HEAD UNIT PROVISION
99-7506
KIT ASSEMBL
urn over the 99-7506 housing, take
the climate control and screws
removed from the factory panel and
attach the climate control to the kit
housing using the factory screws.
(Figure A)
1
A
B
Snap the rim plate into the Radio
Housing.
(Figure D )
5

6
Slide the appropriate DDIN bracket
into the kit housing. (Figure B)
3
C
Cut the rib in the middle of the 99-
7506 housing to make room for the
DDIN brackets.
(Figure A)
2
Slide the DDIN radio unit into DDIN
brackets and secure the unit to the
kit using the screws supplied with
the head unit.
(Figure C)
4
DOUBLE DIN HEAD UNIT PROVISION
99-7506
KIT ASSEMBL
urn over the 99-7506 housing, take
the climate control and screws
removed from the factory panel and
attach the climate control to the kit
housing using the factory screws.
(Figure A)
1
A
B
Snap the DDIN trim plate into the
front of the kit housing.
(Figure C )
5

7
Slide the appropriate DDIN bracket
into the kit housing.
(Figure B)
3
C
Cut the rib in the middle of the 99-
7506 housing to make room for the
DDIN brackets. (Figure A)
2
Slide the stacked ISO DIN units into
the DDIN bracket assembly and
secure the units to the kit using the
screws supplied with the head units.
(Figure C)
4
STACKED ISO DIN HEAD UNIT PROVISION
99-7506
KIT ASSEMBL
urn over the 99-7506 housing, take
the climate control and screws
removed from the factory panel and
attach the climate control to the kit
housing using the factory screws.
(Figure A)
1
A
B
Snap the DDIN trim plate into the
front of the kit housing.
(Figure C )
5

8
FINAL ASSEMBL
1
Locate the factory wiring harness in the dash and make the connection as shown.
Metra recomends using the proper mating adapter and making the connections as
shown. (Isolate and individually tape off the ends of any unused wires to prevent
2
Re-connect the negative battery terminal and test the unit for proper operation.
3
Reassemble radio and dash assemblies in reverse order of disassembly.
A
A) Strip wire ends back 1/2"
B) Twist ends together
C) Solder
D) Tape
B
C
D
Make wiring onne tions using the EIA olor ode hart shown below and the instru tions in luded with the head
unit. Metra re ommends making onne tions as shown below; Strip, Spli e, Solder, Tape. Isolate and individually
tape off ends of any unused wires to prevent ele tri al short ir uit.
12V Ignition / A . . . Red
12V Batt / Memory . . Yellow
Ground . . . . . . . . . . . Bla k*
Power Antenna . . . . . Blue
Amp Turn-On . . . . . . Blue / White
Amp Ground . . . . . . . Bla k / White
Illumination. . . . . . . . Orange
Dimmer . . . . . . . . . . Orange / White
Right Front (+) . . . . . Gray
Right Front (-) . . . . . . Gray / Bla k
Left Front (+) . . . . . . White
Left Front (-) . . . . . . . White / Bla k
Right Rear (+). . . . . . Violet
Right Rear (-) . . . . . . Violet / Bla k
Left Rear (+). . . . . . . Green
Left Rear (-) . . . . . . . Green / Bla k
*NOTE: When Bla k a wire is not present, ground radio to vehi le hassis.
All olors may not be present on all leads due to manufa turer’s spe ifi ations.
METRA / EIA WIRING CODE
FINAL WIRING CONNECTIONS
99-7506
FINAL ASSEMBL

9
99-7506
NOTES

99-7506 INSTRUCTIONS
1-800-221-0932 www.metraonline.com
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION INST99-7506
REV. 09/16/10
