Metra Electronics iBeam TE-AHD7M User manual

©COPYRIGHT 2021 METRA ELECTRONICS CORPORATION
iBEAMUSA.comiBEAM Vehicle Safety Systems ®REV. 06/08/2021 INSTTE-AHD7M/9M
Attention! When testing the aftermarket
equipment, ensure that all factory equip-
ment is connected before cycling the key to
ignition.
TE-AHD7M/
TE-AHD9M
Button operation and accessing the menu......2-3
Menu....................................................................4-5
Wiring.......................................................................6
Specifications..........................................................7
TABLE OF CONTENTS
TOOLS REQUIRED
• Wire stripper
• Tape
• Digital Multi-meter
Commercial AHD 7 inch or 9 inch Monitor
2 Camera Input
Visit iBEAMUSA.com for more detailed informatuon about the product and up-to-date vehicle specific
applications.
Product Features
• 7 inch monitor (TE-AHD7M)
• 9 inch monitor (TE-AHD9M)
• 2 camera inputs, audio on both inputs
• Resolution: 1240 X 600
• PAL/NTSC auto switching
• 720p/960p/1080p auto switching
Part Components
A) Monitor B) Harness and hardware C) Sunshade and mount
A B C

386-257-1187
|
iBEAMUSA.com
2
Normal button press operation
1. Power - Turns the monitor on and off
2. Mode - Switch between input 1 and input 2
3. Left arrow - One press of the button brings up the volume menu and will
decrease the volume.
4. Menu - Pulls up the Settings menu
5. Right arrow - One press of the button brings up the volume menu and
will increase the volume.
6. Brightness mode - switches through different preset brightness settings
7. Mirror image - Mirrors the image of the camera that is active
8. Remote IR
Accessing the Settings menu
1. Press the MENU button to access the settings menus
2. Use the MENU button to cycle through the Menu icons on the left of the
screen
3. To select the desired menu, press the RIGHT ARROW button.
4. Once in the menu, use the MODE button to cycle through the options
5. Use the LEFT ARROW and RIGHT ARROW to change the settings.
Location of IR sensors and slight differences in
sunshade between 7 inch and 9 inch models.
BUTTON OPERATION - ACCESSING THE SETTINGS

REV. 06/08/2021 INSTTE-AHD7M/9M 3
Figure A
REMOTE
Remote - the buttons on the remote will work
the same way the monitor buttons are listed
on Page 2
1. Power
2. Mode
3. Up/positive increase
4. Menu
5. Down/negative decrease
6. Mode Selection

386-257-1187
|
iBEAMUSA.com
4
Settings Menus
Image settings - This menu will allow you to
change the settings on the USER preset
• Brightness - 0-100
• Contrast - 0-100
• Saturation - 0-100
• Reset resets all the settings to 50
1. Voice settings - adjusts the volume of the
audio inputs
• Volume - 0-100
Figure A
Figure B
MENU

REV. 06/08/2021 INSTTE-AHD7M/9M 5
Settings Menu (cont.)
1. System - this menu allows you to change
specific settingsfor the operating system
• Language - changes the language - see
specs for different languages (page 7)
• Acc-Time - 0-15 sec - Changes the time
of the delay for the trigger after it is no
longer active
• Sleep - changes the time the monitor
will stay active before it goes into sleep
mode - 00-100 minuntes by 10s
• Flips - Rotates the camera image
• RD - Right down
• LD - Left down
• LU - Left up
• RU - Right up
2. Function
• Guidelines - turns the guidelines on and off -
only visible while the trigger is active
Figure A
Figure B
MENU CONT.

386-257-1187
|
iBEAMUSA.com
6
WIRING

REV. 06/08/2021 INSTTE-AHD7M/9M 7
Resolution 1240X600 RGB
Video input format 720p/960p/1080p HD 25/30fps
TV System NTSC/PAL auto switching
Aspect ratio 16:9
Working Voltage 12V-24V
Storage Temp. -30°~80 ºC
Working Temp. -20°~70 ºC
Languages Chinese, English, Dutch, Duetch,
French, Italian, Portugese,
Spanish, Russian
SPECIFICATIONS

©COPYRIGHT 2021 METRA ELECTRONICS CORPORATION
iBEAMUSA.comiBEAM Vehicle Safety Systems ®REV. 06/08/2021 INSTTE-AHD7M/9M
KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
®
TE-AHD7M/
TE-AHD9M
Having difficulties? We’re here to help.
Contact our Tech Support line at:
386-257-1187
Or via email at:
[e-mail]
Tech Support Hours (Eastern Standard Time)
Monday - Friday: 9:00 AM - 7:00 PM
Saturday: 10:00 AM - 7:00 PM
Sunday: 10:00 AM - 4:00 PM
Metra Recommends MECP
certified technicians
9 in
TE-AHD7M TE-AHD9M
7 in
