Operating manual
Adaptive wheelchair
Model 1.155 NANO / 1.156 NANOX /
1.158 NANOC

2
Contents
Meaning of the applied markers 5
Introduction 5
List of models 5
Indications / contraindications 5
Acceptance 6
Intended purpose 6
Use 6
Wheelchair folding/unfolding/carrying 7
Adjustment 7
Combination with manufacturer foreign products 8
Reinstallment 8
Life span 8
Overview 9
Model 1.155 / 1.156 / 1.158 9
Brake 10
Pressure brake - user 10
Locking the brakes 10
Releasing the brakes 10
Service brake 10
Light pressure brake, swivelling 11
Locking the brakes 11
Releasing the brakes 11
Service brake 11
Drum brake for accompanying persons 12
Function as operating brakes 12
Leg supports 13
Calf belt 13
Removing the calf belt 13
Attaching the calf belt 13
Length adjustment of the calf belt 13
Footboard, model 1.155 / 1.156 / 1.158 14
Model 1.156 14

3
Clothes guard 15
Removable clothes guard 15
Removal of clothing guards 15
Inserting the clothes guard 15
Back support 16
Folding over the back support 16
Folding up the back support 16
Back support belt 17
Fitting the back belt 17
Removing the back support upholstery 18
Placing the back support upholstery 18
Push handles 19
Push handles with clamping device 19
Special features of the clamping lever 19
Carbon handles 20
Wheels 20
Drive wheels 20
Tyre damage on pneumatic tyres 21
Hand and spoke guard 21
Support castors 22
Swivel away support castors 22
Swinging the support castors 22
Retaining strap 23
Basic safety information 24
Special safety information for model 1.158 24
Accompanying person 25
Transfer out of the wheelchair 25
Reaching for objects 25
Driving on falling, rising or transverse gradients 25
Crossing obstacles 26
Loading the wheelchair 27

4
Transport in vehicles 27
Transport safety of the empty wheelchair 27
Transport of people inside a motor vehicle 27
Transport in public methods of transportation 28
Driving on public highways 28
Cleaning 29
Finish 29
Disinfection 30
Repairs 30
Repairs 30
Customer Service 30
Spare parts 30
Information for extended pauses of use 31
Disposal 31
Maintenance 31
Maintenance 31
Maintenance schedule 32
Technical data 35
Tyre pressure of pneumatic tyres 35
Applied norms 35
Data according to ISO for model 1.155 NANO 36
Further technical data for model 1.155 NANO 37
Data according to ISO for model 1.156 NANO X 38
Further technical data for model 1.156 NANO X 39
Data according to ISO for model 1.158 NANO C 40
Further technical data for model 1.158 NANO C 41
Meaning of the symbols on the washing instruction 42
Meaning of the labels on the wheelchair 43
Meaning of the symbols on the type plate 44
Inspection certificate 45
Warranty / Guarantee 46
Warrantee / Guarantee section 47
Inspection certificate for transfer 47

5
MEANING OF THE AP-
PLIED MARKERS
Safety instructions with a coloured back-
ground are mandatory and need to be
observed under any circumstance!
☞This symbol indicates tips and recom-
mendations.
[ ] Reference to a picture number.
( ) Reference to a function element within
a picture.
INTRODUCTION
Read and observe this manual before first
operation.
If needed have this document read to you
by a supervising or accompanying per-
son.
Your specialist dealer should also intro-
duce you into the use of your wheelchair.
This operating manual is to help you get ac-
customed to the handling of the wheelchair
as well as to prevent accidents.
☞Please note that the illustrated equip-
ment variants can deviate from your
model.
We have therefore also listed chapters with
options that might not be applicable for
your individual wheelchair. A list of the avail-
able options and accessories can be viewed
in the order form of your wheelchair.
Users with visual impairments can find the
PDF-files together with further information
on our website:
< www.meyra.com >.
☞Contact your specialist dealer when re-
quired.
Alternatively users with visual impairments
can have the documentation read out by a
helper.
Inform yourself regularly about product
safety and possible recalls of our products
in the < Information center > on our website:
< www.meyra.com >.
We have developed a product that fulfils
the technical and legal requirements of
medical devices. For information about a se-
vere accident that can still not be ruled out
completely, please use our E-mail address
< [email protected] > and inform the respon-
sible governmental agency of your country.
LIST OF MODELS
This operating manual applies to the follow-
ing models:
Model 1.155 (fixed frame)
Model 1.156 (folding)
Model 1.158 (fixed frame)
INDICATIONS /
CONTRAINDICATIONS
In case of allergic reactions, skin rashes
and/or pressure sores during the use of
the wheelchair sores contact a doctor im-
mediately.
In order to prevent contact allergies, we
recommend to use the wheelchair only
when wearing clothes.
The wheelchair serves as support in case of
extremely pronounced walking disability
resp. inability to walk, e.g. caused by:
– paralysis,
– defects or deformations of limbs,
– loss of limbs,
– damages or contractures in joints,

6
– other diseases (severe to fully pro-
nounced impairments in mobility/
walking in cases of structural an/or
functional damages of the lower ex-
tremities, u. o. amputations, results of
injuries, musculoskeletal/neuromuscu-
loskeletal caused movement disorders).
The wheelchair may not be used with a dis-
ability to sit.
The wheelchair may not be used without an
accompanying person, in cases of:
– uncontrolled balance disorders,
– cognition disorders,
– loss of extremities on both arms,
– contractures / damages of the joints on
both arms,
– insufficient or no eyesight.
☞Please ask your doctor, therapist or
specialist dealer to these and possi-
ble other risks in combination with
this product.
ACCEPTANCE
All products are checked for faults in the
factory and packed in special boxes.
☞However, we request that you check
the wheelchair for possible transport
damage immediately on receipt – pref-
erably in the presence of the carrier.
☞The packaging of the wheelchair
should be stored for a further transport
that might become necessary.
INTENDED PURPOSE
The wheelchair serves for independent
mobility of a grown up person, or transport
with help of an accompanying person.
USE
Do not reach into the spokes or grip the
tyres of the rotating wheels. – Danger of
injury!
Do not reach into the space between the
pressure brake and the tyre when propel-
ling the wheelchair. – Danger of injury!
Avoid a jerky propulsion of your wheel-
chair. – Danger of tipping over or tilting!
Do not use the wheelchair without leg
support and arm support!
The wheelchair is applicable on level, firm
surfaces and can be used as follows:
– for indoors (e.g. apartment, day care),
– outdoors (e.g. paved paths in parks),
– as a companion on tours (e.g. in a bus
or train),
☞In specific dimensions (overall
height, overall width, overall length,
turning radius) your wheelchair is
not suited for transport within a
train.
☞Get information on possible limita-
tions before the transport.
– transport within an airplane should
only be done with PU-tyres.
☞Ask the airline for possible limita-
tions before transport in an airplane.
– Never expose the wheelchair to ex-
treme temperatures and damaging
environmental conditions, such as sun-
light, extreme cold or salty water.

7
– Sand and other dirt particles can seize
on moving parts and render them with-
out function.
– Use only the handrims on the drive
wheels to propel your wheelchair.
You must not let yourself be carried in your
wheelchair by having the wheelchair lifted
from the floor. Parts that are not securely
fixed, e.g. height adjustable push handles
or clothes guard, can come away and thus
cause an accident.
Only apply the wheelchair within the
scope of the specifications and limitation
described in chapter Technical data on
page 35.
WHEELCHAIR FOLDING/
UNFOLDING/CARRYING
You wheelchair model 1.156 can be folded
without the aid of tools.
☞Observe possible jamming points in
the area of the crossbrace of the seat
and the two seat tubes!
1. Remove the seat cushion, if applicable.
2. Fold up the footboard.
3. Pull the seat belt upward in the centre
of the front and back.
☞When using auxiliary drives (wheel
hub drives) tilt the wheelchair over
one side while folding.
Your wheelchair can be carried without dif-
ficulty when folded.
For this, push one lower arm from the front
under the upward folded seat belt. Place
other hand underneath the rear seat fold for
support.
Lift the wheelchair to horizontal position.
Tip the wheelchair slightly to one side in
order to make the unfolding easier. At the
side resting on the floor, press the seat tube
down to the end stop.
☞You may need to press down both seat
tubes with the hands in order to do this.
☞Ensure that the seat tube sits securely
on the support surface.
ADJUSTMENT
Always have adaptation, adjustment or re-
pair work carried out by a specialist dealer.
The wheelchair offers manifold adjustment
possibilities to individual vital statistics. Be-
fore first use an adaptation of the wheel-
chair and a practical instruction in the
functionalities of your wheelchair should
be carried out by your specialist dealer. The
adaptation will take into account the driving
experience, the physical limits of the user
and the main place of use of the wheelchair.
Before first use, check the functionality of
your wheelchair.
☞We recommend a regular control if
the wheelchair adjustment in order to
ensure a long-term optimal provision
even with changing illness/handicap
patterns of the user. Especially for juve-
niles an adjustment every 6 months is
recommendable.

8
COMBINATION WITH MAN-
UFACTURER FOREIGN
PRODUCTS
Any combination of your wheelchair with
components not supplied by us generally
results in an amendment to your wheel-
chair. Please inquire with us if there is a valid
combination clearance/release.
Auxiliary drives
Mounting of additional- and front attach-
ment drives constitute an extreme amend-
ment of the wheelchair. The amendment
will result in a forfeiture of the declaration of
conformity for the wheelchair.
☞The verification of conformity in combi-
nation with the valid medical device di-
rective / medical device ordinance lies
in the responsibility of the supplier of
the additional or header drive. He is also
responsible for the product included
documentation of the medical product
combination.
REINSTALLMENT
The wheelchair is suited for reinstallment.
With the building block system the wheel-
chair can be fit to accommodate different
handicaps body sizes. Before reimplemen-
tation the wheelchair is to undergo a com-
plete inspection.
☞Hygienical measures required for rein-
stallment are to be carried out accord-
ing to a validated hygienic plan and
must include disinfection.
The service manual, intended for the spe-
cialist dealer provides information to the re-
installment and reinstallment frequency of
your wheelchair.
LIFE SPAN
We expect an average life span of about
4 years for this wheelchair, as far as the
wheelchair is applied for its designated
purpose and all maintenance and service
guidelines. The life span of your wheelchair
depends upon the frequency of use, the ap-
plication environment and care. The imple-
mentation of spare parts can prolong the
life span of the wheelchair. As a rule spare
parts are available up to 5 years after pro-
duction is discontinued.
☞The indicated lifespan does not consti-
tute additional guarantee.

13
12
11
10 8
6
4
32
1
9
5
7
9
OVERVIEW
Model 1.155 / 1.156 / 1.158
The overview shows, representative for all models, the most important components of the
wheelchair.
Pos. Description
(1) Back support
(2) Back support strap / Back support up-
holstery
(3) Clothes guard
(4) Seat belt/seat cushion
(5) Utensils bag
(6) Slanted front section
(7) Footboard
(8) Steering wheel
(9) Pressure brake / Swing brakes
(10) Driving wheel
(11) Handrim
(12) Locking knob – Quick release axle
(13) Type plate
– Model 1.155 / 1.158 at axles tube as
shown
– Model 1.156 at the crossbrace

1
1
3
2
10
BRAKE
Arrange an immediate repair of the brakes
by your specialist workshop if the braking
performance reduces.
Wheelchairs with PU-tyres when stored
for longer periods of time, should be put
away safely without activated pressure
brakes, since otherwise permanent defor-
mations to the tyre surface could occur.
By locking the brakes with the brake lever
(1), the wheelchair is secured against rolling
away unintentionally (parking brake).
Pressure brake - user
Locking the brakes
To secure the wheelchair against any unin-
tentional rolling, press both brake levers for-
ward all the way [3].
☞Observe jamming point between brake
lever and frame tube!
☞It should not be possible to push the
wheelchair forward when both brakes
are locked.
Releasing the brakes
Pull both brake levers back all the way [2].
Service brake
The wheelchair is braked down with help of
the handrims.
☞If needed use suitable gloves in order to
brake down the wheelchair.

1
2
11
Light pressure brake, swivelling
Locking the brakes
To secure the wheelchair against any un-
intentional rolling, swivel both brake levers
outward all the way [2].
☞It should not be possible to push the
wheelchair forward when both brakes
are locked.
Releasing the brakes
Swivel both brake levers inward all the way
[1].
☞Observe jamming point between brake
lever and frame tube!
Service brake
The wheelchair is braked down with help of
the handrims.
☞If needed use suitable gloves in order to
brake down the wheelchair.

1
C
A
B
2
12
Drum brake for accompanying
persons
The drum brake is activated by the accom-
panying person through the brake levers [1].
Function as operating brakes
Use both brake levers evenly and only light-
ly in order to achieve a controlled decelera-
tion of the wheelchair.
Locking the drum brakes
Pull both brake levers [1] and press the lock-
ing latch (2) forward.
Release the brake lever. – Depending on the
adjustment the latch engages in the first (A)
or second (B) locking position and activates
the brake.
☞If the third locking position (C) is re-
quired to activate the brake, it must be
readjusted by a specialist workshop.
Loosen the drum brakes
Pull both brake levers (1) until the latches
(2) automatically jump out of the locking
points.
Let go of both brake levers. – The parking
brakes are released and the wheelchair
ready for use.

2
1
3
13
LEG SUPPORTS
Before any actions on the leg supports
the wheelchair is to be secured against
unintentional rolling motions.
☞Therefore observe chapter Brake on
page 10.
Calf belt
Do not drive without the calf belt. – Dan-
ger of accidents.
The removable calf belt (1) prevents the feet
from sliding off the back of the footboard.
Removing the calf belt
To remove the calf belt, open the velcro fas-
tener (2).
Attaching the calf belt
For attachment, guide the calf belt through
the attachment jig [3] and close the velcro
fastener (2).
Length adjustment of the calf belt
For length adjustment, the calf belt is guid-
ed around the special attachment pins [3]
and adjusted in length with a velcro fasten-
er (2).

3
1
2
14
Footboard, model 1.155 / 1.156 /
1.158
Have the adjustments carried out in your
specialist workshop.
The footboard [1] can be adjusted height,
angle and depth to accommodate your in-
dividual requirements.
Model 1.156
The footboard is to be folded up for enter-
ing or exiting the wheelchair [2].
☞Observe jamming point between foot-
board and frame tube!
– Remove both feet from the foot plate.
– Remove lower calf belt, if present.
☞Therefore observe chapter Calf belt
on page 13.
☞Before starting to drive the footboard
need to be folded back down [1] and
the calf belt attached.
Folding up the footboard
In order to fold up the footboard lift the
loose end of the footboard as far as possible
[2].
Folding the footboard down
In order to fold down the footboard, lower
the loose end of the footboard as far as pos-
sible down onto the footboard bracket [3].

1
2
15
CLOTHES GUARD
Do not use the clothes guard to lift or car-
ry the wheelchair.
Do not drive without the clothes guard.
No not grab between the frame and
clothes guard. – Danger of squashing!
When being pushed in the wheelchair by
the accompanying person the user has to
keep his hands on the arm supports or in
his lap and not at the sides between body
and arm support. – Danger of squashing
the fingers!
During the sideward transfer without
clothes guard there is a danger of un-
intentionally activating the brakes and
soiling of the clothes through the drive
wheel.
The clothes guard [1] (depending on model
and version) is firmly attached or removable
and simultaneously serves as a clothes and
wind guard.
Removable clothes guard
Removal of clothing guards
To remove the clothes guard, pull it upward
[2].
Inserting the clothes guard
To insert the clothes guard, press it from the
top into the receptacle [1].
☞Observe jamming point between
clothes guard and frame tube!

3
1
2
16
BACK SUPPORT
Folding over the back support
The back support [1] can be folded down
for storage or transport [2].
Then unlock the back support by pulling
or pressing the rope (3) and fold it onto the
seat [2] until the pressure bolt of the rope
audibly locks into place.
☞Check the engagement of the back
support with a quick jerk.
Folding up the back support
First pull or press the rope (3) in the middle
in order to raise the back support. Then pull
the back support up as far as possible [1].
– The pressure bolt must audibly lock into
place.
☞Check the engagement of the back
support with a quick jerk.
☞The greasing of the thrust bolts is rec-
ommended for an easier latching of the
backrest.

4
5
17
Back support belt
Fitting the back belt
The overlapping of the Velcro fastener has
to be at least 10 cm!
The tension of the back support is adjust-
able.
1. Pull off the flap of the back support and
fold it to the front [4].
2. Open the Velcro fastener of the belt
that you wish to adjust and close it
again after adjustment.
3. Pull the back belt to the back again and
attach the velcro strap [5].

21
3
4
18
Removing the back support upholstery
For removal, first pull off the rear part of the
back support upholstery (1), then fold it over
to the front and pull it off of the adjustable
back strap (3).
Placing the back support upholstery
For placing the back support upholstery (1),
lay it centred around the upper velcro straps
(2) and attach it to the adjustable back strap
with the velcro fasteners (3).
☞For a soft upper edge you should leave
a little space between the upper span-
ning belt (2) and the folded back sup-
port upholstery (1).
☞When the user leans against the back
support upholstery (1) again, pay atten-
tion that:
☞The pressure of the back must be
spread evenly throughout the back
support upholstery.
☞A complete hand should fit in between
the cushion and back at the upper edge
of the back support upholstery.
☞The head of the user must be held in
balance through the adjustment of the
spanning straps.
The extended parts of the back support are
fastened to the top or bottom seat surface
depending on the adjusted back support
height [4].

2
3
1
19
PUSH HANDLES
The height adjustable push handles are
about 150 mm continuously height adjust-
able and secured against being pulled out
[1].
Push handles with clamping
device
☞In doing so, hold onto the push handle
that is to be adjusted with one hand.
☞After each adjustment the clamping
lever is to be tightened sufficiently, so
that the push handle cannot be turned
anymore.
Height adjustment:
Loosen the clamping screw with the clamp-
ing levers (2) so far that the respective push
handle can be adjusted into the desired po-
sition.
Angle adjustment:
To change the position of the push handles,
loosen the clamping screw through the
clamping lever (2) and turn the push han-
dles into the desired position.
Extracting/inserting:
1. Press down the respective spring but-
ton (3) in order to extract or insert the
push handles.
2. Afterwards retighten the clamping
screw with the clamping levers (2).
Special features of the clamping
lever
The clamping lever (2) can be turned into
an operation position that is comfortable
for you.
For this pull the clamping lever (2) outward
(direction of the arrow), until the teething is
released.
After turning the clamping lever (2) let the
teething snap back into place.

3
2
1
20
CARBON HANDLES
(Code 411) (only model 1.158)
Do not use the carbon handles to push,
lift or carry the wheelchair.
The carbon handles [1] are there for posi-
tioning.
WHEELS
Tyres are made of a rubber mixture and
can leave permanent or difficult-to-re-
move marks on some surfaces (e.g. plas-
tic, wooden or parquet flooring, carpets,
mats).
Drive wheels
Do not use the wheelchair without
mounted drive wheels.
After inserting the drive wheel the locking
button (3) must stick a couple of millime-
tres out of the wheel nut.
The drive wheels are supported on a quick
release axle [2] and can be removed resp.
attached without tools.
First press the locking button (3) of the quick
release axle in the center of the hub.
Afterwards remove or attach the drive
wheel.
☞The air pressure value for the tyres of
the wheelchair can be read in the Tech-
nical data on page 35 or details on
both sides of the tyre cover.
☞If the drive wheels has too much side-
ward lag or the quick release axle does
not engage, contact your specialist
dealer immediately for repair.
☞No person may be seated in the wheel-
chair during assembly or removal. The
wheelchair should stand on a level and
firm surface. Before starting the disas-
sembly work, support the frame to pre-
vent the wheelchair from tipping over
and secure it to prevent an unwanted
movement or tipping over.
