MicroNet EtherFast SP624EA User manual

Quick Installation Guide
EtherFast 10/100M Switch
Model No.: SP624EA
Website http://www.micronet.info

1
Introduction
Micronet SP624EA provides powerful, high-performance Ethernet
switch, with all ports capable of 10 and 100Mbps auto-negotiation
operation.
Store-and-forward switching mode promises the low latency plus
eliminates all the network errors, including runt and CRC error
packets. To work under full-duplex mode, transmission and
reception of the frames can occur simultaneously without causing
collisions as well as double the network bandwidth.
The switch is plug-n-play without any software to configure and also
fully compliant with all kinds of network protocols. Moreover, the
diagnostic LEDs on the front-panel can provide the operating status
of individual port and whole system.

2
Package Contents
Before you start installing the device, verify the following items are in
the package:
yOne SP624EA Ethernet Switch
yQuick Installation Guide
yOne power cord
yWall-Mount accessories
Features
yComplies with 10Base-T/100Base-TX specifications of the
IEEE802.3/802.3u standard
ySupport Auto-Negotiation function to automatically select optimal
speed (10/100Mbps) and mode (Full/Half Duplex)
y8K MAC address table
y320 Kbyte memory buffer
ySupport auto uplink, no more cross-over cable
yForward and filter packets at non-blocking, full wire speed
y100 - 240V AC, universal internal power supply

Physical Description
SP624EA front panel view
SP624EA rear panel view
Please refer to the following table for LED definition
LED Status Operation
Steady Green Power is on
Power Off Power is off
Steady Green A valid link is established
Off No link is established
LINK/ACT
Blinking Green Transmitting or receiving data
3

4
Installation
Micronet SP624EA Switches do not require software configuration.
Users can immediately use any of the features of this product simply
by attaching the cables and turning on the power.
Connect each station to the switch by twisted-pair cable. Plug one
RJ-45 connector into a RJ-45 port of the switch, and plug the other
RJ-45 connector into the station’s network adapter. Power on the
switch and then system is ready.
In making a switch interconnection, you could use any port to
connect another switch with straight or crossover cable. As all the
ports support auto-uplink (MDI / MDI-X) function, using a straight
cable to make a switch-to-switch connection is allowed.
For cable selection, refer to the following table：
Network Speed Cable Type Max. Length
10Mbps Cat. 3, 4, 5 UTP/STP 100 meters
100Mbps Cat. 5 UTP/STP 100 meters
Note: To prevent costly equipment damage and downtime, please
consider installing a surge suppression device or a UPS
(Un-interrupted Power Supply).

5
Specifications
Standard IEEE802.3, IEEE802.3u
IEEE802.3x : Flow Control
Interface 24 * RJ-45 ports (10/100Mbps)
Cable Connections 10BASE-T: Category 3, 4, 5 UTP/STP
100BASE-TX: Category 5 UTP/STP
Network Speed 10/100Mbps & Full/Half duplex mode
auto detection
Uplink Auto Uplink (Auto MDI / MDI-X)
Switch Fabric 4.8Gbps
Memory 320 KByte
MAC Address Table 8K entries
Filtering/Forwarding
Rate 10Mbps: 14,880pps/14,880pps 100Mbps: 148,800pps/148,800pps
Emission FCC Class A, CE
Operating Temperature 0o ~ 55o C (32o ~ 131o F)
Operating Humidity 10% - 95% (Non-condensing)
Dimension & Weight 267 x 161 x 42 mm, 1.3kg
Power Supply 100 - 240V AC, 50/60 Hz
Full range internal power supply

6
CE Mark Warning
This equipment complies with the requirements relating to
electromagnetic compatibility, EN 55022 class A for ITE, the
essential protection requirement of Council Directive 89/336/EEC on
the approximation of the laws of the Member States relating to
electromagnetic compatibility.
Company has an on-going policy of upgrading its products and it
may be possible that information in this document is not up-to-date.
Please check with your local distributors for the latest information.
No part of this document can be copied or reproduced in any form
without written consent from the company.
Trademarks:
All trade names and trademarks are the properties of their
respective companies.
Copyright © 2004, All Rights Reserved

P/N: 2300-0228
