Midea MC-IF7222CCD User manual

Induction Hob
Instruction Manual / Installation Manual
MODEL: MC-IF7222CCD

Content
1. Foreword ............................................................................................. 4
1.1 Safety Warnings ..........................................................................4
1.2 Installation .................................................................................4
1.2.1 Electrical Shock Hazard...................................................4
1.2.2 Cut Hazard....................................................................4
1.2.3 Important safety instructions...........................................4
1.3 Operation and maintenance...........................................................5
1.3.1 Electrical Shock Hazard...................................................5
1.3.2 Health Hazard ...............................................................6
1.3.3 Hot Surface Hazard ........................................................6
1.3.4 Cut Hazard....................................................................6
1.3.5 Important safety instructions...........................................6
2. Product Introduction............................................................................ 8
2.1 Top View ....................................................................................8
2.2 Control Panel ..............................................................................8
2.3 Working Theory ...........................................................................8
2.4 Before using your New Induction Hob .............................................9
2.5 Technical Specification..................................................................9
3. Operation of Product ............................................................................ 9
3.1 Touch Controls ............................................................................9
3.2 Choosing the right Cookware.......................................................10
3.3 Pan Dimension ..........................................................................10
3.4 How to use ...............................................................................11
3.4.1 Start cooking...............................................................11
3.4.2 Finish cooking..............................................................11
3.4.3 Using the Boost Function...............................................12
3.4.4 Keep Warm .................................................................12
3.4.5 Flexible Area ...............................................................13
3.4.6 Locking the Controls.....................................................14
3.4.7 Timer control...............................................................14
3.4.8 Using the Pause control.................................................16
3.4.9 Default working times...................................................16
4. Cooking Guidelines............................................................................. 16
4.1 Cooking Tips .............................................................................17
4.1.1 Simmering, cooking rice................................................17
4.1.2 Searing steak ..............................................................17
4.1.3 For stir-frying ..............................................................17
4.2 Detection of Small Articles ..........................................................17
5. Heat Settings ..................................................................................... 18
6. Care and Cleaning .............................................................................. 18
7. Hints and Tips .................................................................................... 19
8. Failure Display and Inspection ........................................................... 20
9. Installation ........................................................................................ 21
9.1 Selection of installation equipment ...............................................21
2

9.2 Before installing the hob, make sure that ......................................23
9.3 After installing the hob, make sure that ........................................23
9.4 Before locating the fixing brackets................................................24
9.5 Adjusting the bracket position .....................................................24
9.6 Cautions...................................................................................24
9.7 Connecting the hob to the mains power supply ..............................25
3

1. Foreword
1.1 Safety Warnings
Your safety is important to us. Please read this information
before using your cooktop.
1.2 Installation
1.2.1 Electrical Shock Hazard
Disconnect the appliance from the mains electricity supply
before carrying out any work or maintenance on it.
Connection to a good earth wiring system is essential and
mandatory.
Alterations to the domestic wiring system must only be
made by a qualified electrician.
Failure to follow this advice may result in electrical shock or
death.
1.2.2 Cut Hazard
Take care - panel edges are sharp.
Failure to use caution could result in injury or cuts.
1.2.3 Important safety instructions
Read these instructions carefully before installing or using
this appliance.
No combustible material or products should be placed on
this appliance at any time.
Please make this information available to the person
responsible for installing the appliance as it could reduce
your installation costs.
In order to avoid a hazard, this appliance must be installed
according to these instructions for installation.
This appliance is to be properly installed and earthed only by
a suitably qualified person.
This appliance should be connected to a circuit which
incorporates an isolating switch providing full disconnection
from the power supply.
4

Failure to install the appliance correctly could invalidate any
warranty or liability claims.
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.
Warning: If the surface is cracked, switch off the appliance
to avoid the possibility of electric shock, for hob surfaces of
glass-ceramic or similar material which protect live parts
Metallic objects such as knives, forks, spoons and lids should
not be placed on the hob surface since they can get hot
A steam cleaner is not to be used.
Do not use a steam cleaner to clean your cooktop.
The appliance is not intended to be operated by means of an
external timer or separate remote-control system.
WARNING: Danger of fire: do not store items on the cooking
surfaces.
The cooking process has to be supervised. A short term
cooking process has to be supervised continuously.
WARNING: Unattended cooking on a hob with fat or oil can
be dangerous and may result in fire. NEVER try to extinguish
a fire with water, but switch off the appliance and then cover
flame e.g. with a lid or a fire blanket.
1.3 Operation and maintenance
1.3.1 Electrical Shock Hazard
Do not cook on a broken or cracked cooktop. If the cooktop
surface should break or crack, switch the appliance off
immediately at the mains power supply (wall switch) and
contact a qualified technician.
5

Switch the cooktop off at the wall before cleaning or
maintenance.
Failure to follow this advice may result in electrical shock or
death.
1.3.2 Health Hazard
This appliance complies with electromagnetic safety
standards.
However, persons with cardiac pacemakers or other
electrical implants (such as insulin pumps) must consult with
their doctor or implant manufacturer before using this
appliance to make sure that their implants will not be
affected by the electromagnetic field.
Failure to follow this advice may result in death.
1.3.3 Hot Surface Hazard
During use, accessible parts of this appliance will become
hot enough to cause burns.
Do not let your body, clothing or any item other than
suitable cookware contact the Induction glass until the
surface is cool.
Keep children away.
Handles of saucepans may be hot to touch. Check saucepan
handles do not overhang other cooking zones that are on.
Keep handles out of reach of children.
Failure to follow this advice could result in burns and scalds.
1.3.4 Cut Hazard
The razor-sharp blade of a cooktop scraper is exposed when
the safety cover is retracted. Use with extreme care and
always store safely and out of reach of children.
Failure to use caution could result in injury or cuts.
1.3.5 Important safety instructions
Never leave the appliance unattended when in use. Boilover
causes smoking and greasy spillovers that may ignite.
Never use your appliance as a work or storage surface.
Never leave any objects or utensils on the appliance.
Do not place or leave any magnetisable objects (e.g. credit
cards, memory cards) or electronic devices (e.g. computers,
MP3 players) near the appliance, as they may be affected by
6

its electromagnetic field.
Never use your appliance for warming or heating the room.
After use, always turn off the cooking zones and the cooktop
as described in this manual (i.e. by using the touch controls).
Do not rely on the pan detection feature to turn off the
cooking zones when you remove the pans.
Do not allow children to play with the appliance or sit, stand,
or climb on it.
Do not store items of interest to children in cabinets above
the appliance. Children climbing on the cooktop could be
seriously injured.
Do not leave children alone or unattended in the area where
the appliance is in use.
Children or persons with a disability which limits their ability
to use the appliance should have a responsible and
competent person to instruct them in its use. The instructor
should be satisfied that they can use the appliance without
danger to themselves or their surroundings.
Do not repair or replace any part of the appliance unless
specifically recommended in the manual. All other servicing
should be done by a qualified technician.
Do not place or drop heavy objects on your cooktop.
Do not stand on your cooktop.
Do not use pans with jagged edges or drag pans across the
Induction glass surface as this can scratch the glass.
Do not use scourers or any other harsh abrasive cleaning
agents to clean your cooktop, as these can scratch the
Induction glass.
This appliance is intended to be used in household and
similar applications such as: -staff kitchen areas in shops,
offices and other working environments; -farm houses; -by
clients in hotels, motels and other residential type
environments; -bed and breakfast type environments.
WARNING: The appliance and its accessible parts become
hot during use.
Care should be taken to avoid touching heating elements.
Children less than 8 years of age shall be kept away unless
continuously supervised.
7

Congratulations on the purchase of your new Induction Hob.
We recommend that you spend some time to read this Instruction / Installation Manual in order to fully
understand how to install correctly and operate it.
For installation, please read the installation section.
Read all the safety instructions carefully before use and keep this Instruction / Installation Manual for
future reference.
2. Product Introduction
2.1 Top View
2.2 Control Panel
2.3 Working Theory
Induction cooking is a safe, advanced, efficient, and economical cooking technology. It works by
electromagnetic vibrations generating heat directly in the pan, rather than indirectly through heating the
1. Max. 1800/3000 W zone
2. Max. 1800/3000 W zone
3. Max. 1800/3000 W zone
4. Max. 1800/3000 W zone
5. Free induction zone. 3000/4000 W
6. Free induction zone. 3000/4000 W
7. Glass plate
8. Control panel
1. Power / Timer slider touch control
2. Heating zone selection controls
3. Pause control
4. Keylock control
5. ON/OFF control
6. Keep warm control
7. Boost control
3
4
2
1
8
6
5
7
8

glass surface. The glass becomes hot only because the pan eventually warms it up.
2.4 Before using your New Induction Hob
Read this guide, taking special note of the ‘Safety Warnings’ section.
Remove any protective film that may still be on your Induction hob.
2.5 Technical Specification
Cooking Hob
MC-IF7222CCD
Cooking Zones
4 Zones
Supply Voltage
220-240V~ 50Hz or 60Hz
Installed Electric Power
7200W
Product Size L×W×H(mm)
590X520X60
Building-in Dimensions A×B (mm)
560X490
Weight and Dimensions are approximate. Because we continually strive to improve our products we may
change specifications and designs without prior notice.
3. Operation of Product
3.1 Touch Controls
The controls respond to touch, so you don’t need to apply any pressure.
Use the ball of your finger, not its tip.
You will hear a beep each time a touch is registered.
Make sure the controls are always clean, dry, and that there is no object (e.g. a utensil or a cloth)
covering them. Even a thin film of water may make the controls difficult to operate.
iron pot
magnetic circuit
ceramic glass plate
induction coil
induced currents
9
