Midea VC-35A1Q3 User manual

Midea Vacuum Cleaner
User Manual
VC-35A1Q3
Please keep the User Manual in good custody for reference.
Please read the User Manual carefully before using the product.

1
Welcome to use Midea vacuum cleaner. For your own safety, please read this user
manual (note: this manual only applies to VC-35A1Q3 products) carefully before any
operation. Keep this manual in a secure place for future reference.
I. Safety Precautions
II. Components & Sketch
III. Circuit Diagram
IV. Before Use
V. How to Use
VI. Cleaning, Maintenance and Storage
VII. Troubleshooting
Safety Precautions
This is an electric appliance. It shall be used under normal operating conditions.
Never leave it running without human attendance.
- This appliance is not intended for use by persons(included children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
- Children should be supervised to ensure that they do not play with the appliance.
This appliance is intended to be used in household and similar applications as:
- Staff kitchen areas in shops, offices and other working environments;
- Farm houses;
- By clients in hotels, motels and other residential type environments;
- Breakfast type environments.
Do not use the vacuum cleaner to pick up the following objects, otherwise it may
damage the vacuum cleaner or cause a fire and bodily injuries, etc.
A．Hot objects, e.g., charcoal fire, cigarette butt.
B．Large sharp debris, e.g., glass.
C．Hazardous objects (solvents, corrosives), aggressive agents (acids, detergents)
and liquids such as water.
D．Explosives and flammables such as gasoline or alcoholic products.
To clean or repair the vacuum cleaner or put it idle, disconnect it from the power

2
supply. When disconnecting, never pull the cord but hold the plastic part of the
plug and take it out with care.
Do not pull or fold the hose forcibly to prevent deformation or damage.
Check and make sure the rated voltage of the vacuum cleaner complies with the
local power supply.
Do not insert the power cord of the vacuum cleaner through any sharp objects to
avoid damages.
Do not immerse the machine into water, approach it to heaters or expose it to
sunshine, otherwise, it may catch a fire.
Do not attempt to move the machine by dragging the power cord.
Do not allow children to tamper with or operate the machine to prevent accidents.
Do not press the dust bag release button when handling the machine; otherwise,
it may detach from the machine and cause damage.
It is not recommended to use this machine to pick up lime, ash concrete or any
other construction waste because it may damage the motor or the machine.
Do not operate the machine in any case of the following:
A. The machine is apparently damaged or does not work properly after falling
off.
B. The power cord is damaged.
In case of the above situations, do not turn on the machine. Send it to our
repair centre for repair immediately.
Do not have the machine operate for prolonged period of time when the inlet
is clogged to prevent damage to the motor or deformation of the machine due
to overheating.
The machine uses Y connection, therefore, in case the power cord is
damaged, for safety, please ask a specialist from the manufacturer, its service
department for replacement.

3
Main Body
4
5
3
1
7
6
8
1. Floor brush
2. Hose assembly
3. Connecting tube
4. Main body
5. Cord rewind button
6. Speed control button
7. Switch button
8. Round brush
9. Bedsheets brush
10. Flat nozzle
9
2
10

4
Circuit Diagram

5
How to Use
How to assemble?
1. (Fig. 1) Attach hose to cleaner body
Align the hose connector with the inlet and insert it as shown.
To detach the hose, press the clips on the connector and pull the hose out.
2. (Fig. 2) Attach elbow pipe to connecting tube
Align and insert as shown.
3. (Fig. 3) Attach connecting tube to floor brush
Rotate the parts in opposite directions until secure.
4. (Fig. 4) Unwind power cord
Pull the power cord out to the yellow marking. Never pull beyond the red
marking.
5. (Fig. 5) Rewind power cord
After use, unplug the machine first then press the rewind button to collect the
power cord back into the machine.
6. (Fig. 6) Switch button
Plug the machine to power supply and push the switch button to control the
start and stop of the machine.
Fig 1
Fig 2
Fig 3
Fig 4
Fig 5
Fig 6

6
How to clean dust cup
1. Open the front cover as shown in Fig. 7.
2. Take out the dust cup as shown in Fig. 8.
3. Hold the bottom of the dust cup and push gently the dump button with the
other hand. The cup will automatically open and dump the dust inside it.
See Fig. 9 & Fig. 10.
4. In case the suction power is insufficient when the waste has not reached
MAX, turn off the machine, repeat the above steps 1-2-3, and clean the
filter as shown in Fig. 11 and Fig. 12.
Note: After cleaning the filter, dry it first before putting back into the machine for
use. It is suggested to expose to sunshine for 24 hours until it’s completely dry. Make
sure each component is back in place otherwise it may cause malfunction; do not
allow water to get into the electrical components otherwise it may cause malfunction.
How to replace dust bag?
1. Open the front cover as shown in Fig. 13.
2. Push the button on the right and pull the dust bag out, as shown in Fig.
14.
3. Push the button on the right, put the dust bag into the groove and then
release the button, as shown in Fig. 15.
Fig 7
Fig 8
Fig 9
Fig 10
Fig 11
Fig 12

7
How to use the accessories?
1. The combination brush is suitable for picking up dust from gaps of windows,
furniture, and corners, and downs or fabric upholstery. The brush head can
turn as needed.
2. The bedsheets brush is suitable for picking up dust from the surface of
furniture, such as bed, fabric sofa, table, etc.
3. Step on the floor brush pedal to let the brush bristle out for floor cleaning.
(See Fig. 16 & 17)
4. Step on the floor brush pedal to retreat the brush bristle for carpet cleaning.
(See Fig. 18)
Hints: Use big suction power for heavily contaminated carpets and floors and
smaller suction power for articles such as curtains, table cloths, etc.
Fig 14
Fig 15
Fig 16
Fig 18
Fig 13
Fig 17

8
Troubleshooting
Refer to the following table first in case of any abnormities during use.
Problem
description
Possible cause
Solution
The machine
does not work
completely
1. The machine is not plugged
well to the outlet.
2. There’s no power of the
outlet.
3. The switch of the machine is
not turned on.
1. Re-plug.
2. Check the circuit
breaker.
3. Press the switch
button to turn on the
machine.
The suction
power is weak
1. The floor brush or auxiliary
nozzle is clogged.
2. The dust bag is full of dust.
3. The filter and Hepa are
heavily contaminated by
dust.
1. Remove the clogging.
2. Empty the dust bag
timely.
3. Clean the filter and
Hepa timely.

美的真空吸塵器產品說明書
VC-35A1Q3
請妥善保管本產品說明書
使用前請自信閱讀本產品說明書

1
歡迎使用美的吸塵器！為確保使用安全，在您操作之前，請您仔細閱讀說明書（注：本
說明書適用於 VC-35A1Q3 系列產品，請根據您所購買的產品對照型號選取閱讀），並妥善保
存以便日後參考。
一、 使用安全及注意事項
二、 產品零部件名稱及示意圖
三、 產品電路圖
四、 使用準備
五、 使用本產品
六、 清潔、保養和存放
七、 常見故障排除指南
使用安全及注意事項
您的吸塵器是一臺電動器具：它必須按照正常使用條件進行使用。切勿讓吸塵器在無人
看管情況下獨自運轉。
- 除非在適當監管或指引下，為安全起見，此產品不適宜殘疾、智障、精神病患者、兒
童或缺乏相關經驗及知識人士使用。
- 請小心照看好兒童，確保他們不玩耍此電器。
- 此器具打算用於家庭和以下類似場所使用：商店、辦公室和其他工作環境的廚房區域；
農家；旅館；汽車旅館和其他住宿環境裡供客人使用的；吃早餐的地方。
嚴禁吸入下列物體，否則可能會損壞吸塵器或引起火災，造成人身傷害等意外。
A．發熱物體，如炭火，煙頭。
B．大截銳利碎片，如玻璃。
C．有害物品（溶劑、腐蝕劑），侵蝕劑（酸劑、清潔劑）及水等液體。
D．易燃易爆物品，如汽油或酒精製品。
清潔、維修或暫時不用吸塵器時，必須切斷電影。切斷電源時，不可拉電源線，應
用手拿住插頭塑膠部位拔下插頭。
避免強拉或折疊軟管，否則易導致軟管變形或破損。
檢查確認吸塵器使用電壓必須與供電電壓一致。
吸塵器的電源線，不要讓它穿越鋒利的物品，以免破壞電源線。
切忌將吸塵器浸入水中，避免接近發熱器具或暴曬，以免發生火災。
切勿拖拉電源線來移動本吸塵器。
切勿讓小孩玩弄、操作吸塵器，以免發生意外。
搬運過程中不得按塵桶按鈕，以防機器脫落軋傷。

2
使用本產品吸取石灰、水泥灰或其他建築垃圾有可能導致電機故障或產品破壞，故
建議不要使用吸塵器吸取該類垃圾。
下列情形時，請不要使用吸塵器：
A. 發生跌落並出現明顯破壞或運轉不正常。
B. 電源線破損。
遇到這種情況時，不要打開機器，及時運至本公司指定維修中心檢修。
避免在吸入口堵住的狀態下長時間運行，以免電機損壞及吸塵器發熱變形。
本產品屬於 Y型連接，如果電源軟線破壞，為了避免危險，必須由製造商、其
維修中心的專業人員更換。
主體
4
5
3
1
7
6
8
1 主地刷（根據型號有區別）
2 軟管组件
3 接插管
4主機身
5 收線按鈕
6調速滑鈕
7開關按鈕
8 小圓刷
9 床單刷
10 扁吸
9
2
10

3
產品電路圖

4
使用方法介紹
使用前組裝方法
1 （圖 1）軟管與吸塵器連接
將軟管接頭對準吸塵器進風口，請如圖示插入。
如果要拆卸軟管，請按住接頭兩卡扣拔出即可。
2.（圖 2）彎管與接插管連接
連接時，請於圖示對準插入即可。
3.（圖 3）接插管與地刷連接
連接時，請相反用力加以轉動以連接牢固。
4.（圖 4）拉出電源線
電源線可拉至黃色標記長度，嚴禁超過紅色標記。
5.（圖 5）捲回電源線
使用完畢後請先從插座拔下插頭，然後用手指按下吸塵器後部的電源線捲線按
鈕即可。
6.（圖 6）開關
將插頭插入電源插座後，按下開關按鈕即可控制吸塵器的啟動與停止。
圖1
圖2
圖3
圖4
圖5
圖6

5
塵杯的清潔
塵杯清潔步驟
1.如圖 7所示，打開前蓋
2 .如圖 8所示，直接取出塵杯
3.如圖 9、10 所示，右手握住塵杯底，左手輕按倒塵按鈕，塵杯自動打開，翻
轉倒塵
4.當塵杯中的垃圾未超過 MAX 線時，如感覺吸力下降，請關機後在 1-2-3 步驟
的基礎上，如圖 11、12 所示，取下過濾網清潔即可。
注：以上各過濾部件清洗後必須風乾後才可裝回使用，建議陽光下曬 24 小時確保
徹底風乾後再使用；必須確保各部件安裝到位，否則會引起產品故障；不可將水滲入吸
塵器電器元件內，否則可能會引起產品故障
圖7
圖8
圖9
圖10
圖11
圖12

6
塵袋更換步驟
1. 如圖 13 所示，打開前蓋
2. 如圖 14 所示，按住右邊按鈕，拉出塵袋
3. 如圖 15 所示，按住右邊按鈕，將塵袋放入固定卡槽內，鬆開按鈕
即可
配件使用
1 組合吸刷適合吸除窗縫、傢俱縫、角落等小縫隙處的灰塵或短毛布藝傢俱處
的灰塵，可根據需求轉動刷頭調節。
2 床單刷適合清除床面、布藝沙發、臺面等傢俱表面的灰塵。
3 踏下地刷踏板，伸出刷毛時可進行地板吸塵（如圖 16、17）
4踏下地刷踏板，縮進刷毛時可進行地毯吸塵（如圖 18）
提示：對於髒的地毯和地板，使用大吸力：對於窗簾、桌布等物品時，使用
小吸力。
圖14
圖15
圖16
圖18
圖13
圖17

7
常見故障排除指南
本品在使用時如發現異常，請先查閱下表。
故障現象
可能原因
處理方法
吸塵器完全不運
行
1、電源插頭未在插座上插牢
2、電源插座沒有電
3、吸塵器開關沒有打開
1、重新插入插頭
2、檢查斷路器
3、按下機器的電源開關
吸力減弱
1、主地刷或附件吸頭堵塞
2、塵桶中的灰塵過滿
3、金屬網和海帕上灰塵過多
1、清理堵塞物
2、及時清理垃圾
3、清洗過濾網和海帕
