Mitel 600/700 DECT Phone
Messaging and Alerting
Applications
USER GUIDE

NOTICE
The information contained in this document is believed to be accurate in
all respects but is not warranted by Mitel Networks™ Corporation
(MITEL®). The information is subject to change without notice and should
not be construed in any way as a commitment by Mitel or any of its
affiliates or subsidiaries. Mitel and its affiliates and subsidiaries assume
no responsibility for any errors or omissions in this document. Revisions
of this document or new editions of it may be issued to incorporate such
changes.
No part of this document can be reproduced or transmitted in any form
or by any means - electronic or mechanical - for any purpose without
written permission from Mitel Networks Corporation.
Trademarks
The trademarks, service marks, logos and graphics (collectively
"Trademarks") appearing on Mitel's Internet sites or in its publications are
registered and unregistered trademarks of Mitel Networks Corporation
(MNC) or its subsidiaries (collectively "Mitel") or others. Use of the
Trademarks is prohibited without the express consent from Mitel. Please
contact our legal department at [email protected] for additional
information. For a list of the worldwide Mitel Networks Corporation
registered trademarks, please refer to the website:
http://www.mitel.com/trademarks.
Mitel 600/700 DECT Phone Messaging and Alerting Applications
User Guide
Release 9.1 - February 2024
,Trademark of Mitel Networks Corporation
©Copyright 2024, Mitel Networks Corporation
All rights reserved

1
Mitel 600/700 SIP-DECT Phone Messaging and Alerting Applications
Introduction................................................................................................ 2
Other Documentation ..........................................................................2
Safety Instructions ..............................................................................2
Notes on Authorization and Licences .................................................2
Message Types ..................................................................................3
Message Options ........................................................................... 4
Menu: Text messages.................................................................... 5
Menu: Info ...................................................................................... 6
Receiving Text Messages / Jobs ............................................................... 7
Message Pop-up Window ...................................................................7
Key Behaviour ....................................................................................7
Audible Indicators ...............................................................................8
Visual Indicators .................................................................................9
Visual Indicator with Info Box ..............................................................10
Message Window Re-pop-up .............................................................10
Confirmation of a Text Message .........................................................12
Confirmation of a Job ..........................................................................12
Normal Job..................................................................................... 12
Urgent Job...................................................................................... 13
Receiving Confirmation Messages .....................................................14
Receiving Information Messages ........................................................15
Menu: Inbox / Jobs (Lists) ...................................................................16
Sending Text Messages / Jobs ................................................................. 18
Message Editor ...................................................................................19
Text Editor...................................................................................... 19
Address Editor................................................................................ 19
Menu: Outbox (List) ............................................................................20
Menu: Use last text .............................................................................21
Menu: Pre-defined messages .............................................................22
Creating a Pre-defined Message ................................................... 22
Sending a Pre-defined Message.................................................... 23
Using the Options Menu ............................................................................ 24
Setting Options for Messages Receipt ...................................................... 27
Menu: Overwrite .................................................................................27
Menu: Melodies (for Message Receipt) ..............................................27
Menu: Volume (for Message Receipt) ................................................28
Message List Access through Programmed Keys..................................... 30
Special Functions ...................................................................................... 31
Locating Alert ......................................................................................31
Locating Menu ....................................................................................31
Querying locating data on the DECT Phone.................................. 32
Programming locating access on a key ......................................... 32
Call-back Function / Paging ................................................................32
Sending a Paging Message ........................................................... 33

Mitel 600/700 SIP-DECT Phone Messaging and Alerting Applications
2
Receiving a Paging Message / Call-back ...................................... 33
Personal directory Entries as vCards .................................................34
Activating vCard Reception ........................................................... 35
Sending vCards ............................................................................. 35
Receiving vCards........................................................................... 36
Switching the DECT Phone On/Off ........................................................... 37

DECT PHONE MESSAGING
AND ALERTING

Mitel 600/700 DECT Phone Messaging and Alerting Applications
2
INTRODUCTION
Your SIP-DECT solution supports message and alarm
solutions. Message and alarm management is possible by
connecting external alarm servers or by using the basic
functions of the OpenMobility Integrated Messaging & Alerting
service (OM IMA). In addition, the system can be equipped
with the OpenMobility Locating application (OML) which
enables DECT phone location based on the DECT base
stations that the DECT phone uses.
The Mitel 600/700 series of DECT phones provide features for
handling messages. They are particularly suitable for use with
these Mitel applications.
OTHER DOCUMENTATION
This user guide describes the special messaging features of
the Mitel 600/700 DECT phone series and how to use them.
For basic information on DECT phone operation, please see
the:
•Mitel 600 series DECT Phone User Guide
•Mitel 700 series DECT Phone User Guide
SAFETY INSTRUCTIONS
Please note the safety instructions included with the device.
Please read these safety instructions first before using your
DECT phone.
NOTES ON AUTHORIZATION AND LICENCES
Sending and receiving of text messages and tasks is subject
to licensing and also depends on user permission. This means
that not every subscriber in a DECT system can use these

3
Introduction
features automatically. Ask your system administrator which
particular features are enabled for your DECT phone.
Sending text messages to a FAX gateway or to an SMS
gateway (for GSM phones) also requires additional
applications available on the communications system. Sending
text messages to an e-Mail gateway is possible without
additional applications.
MESSAGE TYPES
Messages can be managed by an integrated data processing
of your communications system or by an external application
(server). All supported message types are described below,
however, available message types depend on the application.
Messages sent by the DECT phone are identified as normal
or urgent, and furthermore in text messages and jobs. Text
messages require no or basic confirmation from the sender.
Jobs are messages containing tasks. They must be confirmed
as “read”, “accepted” and – in case of urgent jobs – as “done”.
In addition, an application can send information messages
(e.g., news ticker), alarm messages, and messages to locate
a person.
MESSAGE TYPE SENT FROM ... ACKNOWLEDGMENT
BY RECEIVER/
CONFIRMATION TO
SENDER
Text message as info
(e.g. news ticker)
Alarm server No / No
Text messages with
low priority (e.g.,
confirmation
message)
Alarm server Yes / No

Mitel 600/700 DECT Phone Messaging and Alerting Applications
4
MESSAGE OPTIONS
Messages can contain options when sent from the alarm
server. Options include settings for melody, volume, ringer,
vibrator, or display color, as well as options to disconnect a call,
initiate a callback, or suppress in-band signaling.
The following tables shows all message options. Note that
message options overwrite the respective DECT handset local
settings when the message is received.
Normal text
messages (normal
priority)
Alarm server
and/or other
DECT phone* or
as fax*, SMS*,
email*
Yes / No
Urgent text
messages (high
priority)
Alarm server
and/or other
DECT phone*
Yes / Yes
Alarm message Alarm server Yes* / Yes*
Normal jobs (normal
priority)
Alarm server and
or other DECT
phone*
Yes / Yes
Urgent jobs (high
priority)
Alarm server
and/or other
DECT phone*
Yes / Yes
Alarm job Alarm server Yes / Yes
Locating alert Alarm server Yes / Yes
*Dependant on system configuration. Fax, SMS (email): features must be
supported by an external messaging / alarm application. Email is supported
by the internal message / alarm application.
OPTION ATTRIBUTE DESCRIPTION
melody Overwrites DECT phone melody setting.
MESSAGE TYPE SENT FROM ... ACKNOWLEDGMENT
BY RECEIVER/
CONFIRMATION TO
SENDER

5
Introduction
MENU: TEXT MESSAGES
Messages are saved and managed in a separate DECT phone
menu. To open this menu, do the following:
With the DECT phone idle, briefly press the key. Navigate
to the Text messages menu option and press Ok. The
following options are available:
•New message: to create new messages
•Use last text: to make further use of the last message and
recipient
•Outbox: shows the sent messages / jobs list
•Inbox: shows the received messages list
•Jobs: shows jobs not-yet-completed list
volume Overwrites DECT phone volume setting.
ringerTone Overwrites DECT phone “use ringer”
setting.
increasingVol Overwrites DECT phone “increasing
volume” setting.
vibraCall Overwrites DECT phone “vibration”
setting.
noInband Overwrites DECT phone “In-band new
message signalization” setting.
disconnectCall Automatically disconnects a call when the
message is received at the DECT phone.
autoCallback Establishes an automatic callback from
the message recipient’s DECT phone to a
phone number.
textColour (R,G, B) Text colour for the message.
bgColour (R,G, B) Background colour of the message.
OPTION ATTRIBUTE DESCRIPTION

Mitel 600/700 DECT Phone Messaging and Alerting Applications
6
•Pre-defined messages: shows the pre-defined messages
list
•Message options: lists message options, including
options to configure ringing melodies and volume for
received messages
The access to some of these lists and entries can be
programmed on a key.
MENU: INFO
You can access new text messages and jobs through the Inbox
/ Jobs lists and also through the Info menu. To open the Info
menu, do one of the following:
• Press the left navigation key (delivery setting)
• Press the key and select Info
• Press the programmed key

7
Receiving Text Messages / Jobs
RECEIVING TEXT MESSAGES /
JOBS
Please note:
• If you have programmed a call diversion, received text
messages and jobs will not be diverted.
• If you have switched on the silent charging feature (in the
Settings > Device options > Silent charging menu),
messages will not be signalled audibly, except the Locating
alert/message (see “Locating Alert” on page 31).
• The Info LED flashes until all messages are read.
MESSAGE POP-UP WINDOW
On message receipt, an information window pops up in the
display. Depending on the message type, the message
delivery is also indicated with an audible tone.
The pop-up window contains information on the message type,
the sender, send date and time, and the message text.
KEY BEHAVIOUR
When a text message or a job is received (pop-up window),
the following keys are activated:
• The left softkey indicates the action you should perform
(e.g., Read).
• The Esc softkey allows you to hide the pop-up window
(e.g., if you are currently in a conversation or if you want
to make a call). The window pops up again after a couple
of seconds (see “Message Window Re-pop-up” on
page 10).
• The key opens the Options menu, which contains all
actions that can be currently performed.

Mitel 600/700 DECT Phone Messaging and Alerting Applications
8
• Pressing the key briefly stops message signaling.
• Long pressing on the key turns the device off.
• The SOS key is also available.
• If there is an incoming call while a pop-up message window
is displayed, the message is hidden automatically for the
duration of the call. You can accept the call by pressing the
call key ( ).
AUDIBLE INDICATORS
Received messages trigger an audible signal as described in
the following table.
MESSAGE TYPE IN IDLE MODE IN CONVERSATION
Information message
(e.g. news ticker)
No tone No tone
Low priority message
(e.g., confirmation
message)
Short beep 1Short beep 1
Normal message/job Melody plays once 2Two beeps
Urgent message/job Melody plays once 2Two beeps
Alarm message/job Melody plays until
DECT phone user
confirms or hides
message 2
Five beeps, melody
plays until DECT
phone use confirms
or hides message 2
Locating alert Increasing special
locating alert
Starts with signaling
tones, then warning
beeps with increasing
volume; vibra call is
turned on
automatically 3
1 The “beep” is signalled only if you have enabled the Confirm tones setting
in the Audio > Attention tones DECT phone menu.
2 Signalled according to the individual melody and volume settings.
3 A locating alert is always be signalled through the loudspeaker, even if you
have deactivated the ringer (Off setting in the in the Audio > Ringer settings
> Device > Headset menu).

9
Receiving Text Messages / Jobs
Notes on using a headset
• If a corded headset is plugged in, an audible signal on
receipt of low priority/normal/urgent messages is played in
the headset, according to the On/Off setting in the Audio
> Ringer settings > Device > Headset menu.
• If a Bluetooth® headset is registered, no melodies or
attention tones are played in the headset. All audible
signals are played only on the DECT phone.
• If the ringer volume is turned off (in the Audio > Ringer
settings > Volume > Ringer menu), there is no audible
signal to indicate incoming calls and receipt of low priority
/ normal / urgent messages (including in the headset).
However, alarm messages and locating alerts are signalled
through the loudspeaker.
VISUAL INDICATORS
New or unread text messages and jobs are indicated by the
following icons in the upper part of the display:
Note: The icon line provides placeholders for up to seven
icons. The icon display is dynamic, and depends on current
device settings, call state and message information. When all
seven icon placeholders are used but there is additional
information to be displayed, the message indication icons are
new/unread normal messages
new/unread urgent messages
new email (dependent on application)
new fax (dependent on application)
new/unread jobs

Mitel 600/700 DECT Phone Messaging and Alerting Applications
10
removed from the icon line. They are displayed again when
there is space in the icon line.
VISUAL INDICATOR WITH INFO BOX
In idle state, new or unread text messages / jobs and pending
jobs are also indicated in an info box in the upper part of the
DECT phone display. You will see one of the following status
messages:
MESSAGE WINDOW RE-POP-UP
You can hide the message window by pressing Esc, (e.g., if
you want to make a call and read the message after the call).
The message will be displayed again later, as described in the
following table.
1 new message Indicates the number of new messages in
your Inbox list.
1 unread message Indicates the number of unread
(unconfirmed) messages in your Inbox list.
New info Indicates that there are several new entries
in your Info menu (e.g., new entries in your
Caller list, new Text messages, or new
Jobs)
1 new job Indicates the number of unread jobs in your
Jobs list.
1 pending job Indicates the number of not accepted or
incomplete jobs in your Jobs list
MESSAGE TYPE POPS UP AFTER ... LIST ENTRY TO ...
Low priority
message (e.g.,
confirmation
message)
None • Text messages >
Inbox
•Info > Text
messages

11
Receiving Text Messages / Jobs
Normal text
messages
60 seconds if DECT
phone is in idle mode
or calling state
•Text messages >
Inbox
•Info > Text
messages
Urgent text
messages
30 seconds if DECT
phone is in idle mode
or calling state
•Text messages >
Inbox
•Info > Text
messages
Alarm text
messages
10 seconds if
• DECT phone is in
idle mode or
calling state
• device menu or
editor is opened
• keyboard is
locked
•Text messages >
Inbox
•Info > Text
messages
Normal jobs 30 seconds if DECT
phone is in idle mode
or calling state
•Text messages >
Jobs
•Info > Jobs
Urgent jobs 20 seconds if DECT
phone is in idle mode
or calling state
•Text messages >
Jobs
•Info > Jobs
Alarm jobs 10 seconds if
• DECT phone is in
idle mode or
calling state
• device menu or
editor is opened
• keyboard is
locked
•Text messages >
Jobs
•Info > Jobs
Locating alert 5 seconds,
independent of
DECT phone state
None
MESSAGE TYPE POPS UP AFTER ... LIST ENTRY TO ...

Mitel 600/700 DECT Phone Messaging and Alerting Applications
12
If the DECT phone receives a new message, a displayed
pop-up window is updated with the new information. The
former message is only visible in the Info > Text messages
or Info > Jobs list and in the Inbox or Jobs lists in the Text
messages menu.
CONFIRMATION OF A TEXT MESSAGE
When receiving a text message, press Read. The message is
saved to your Text messages > Inbox list (see “Menu: Inbox
/ Jobs (Lists)” on page 16). If the message is an urgent
message, the sender receives a “read” confirmation message
(see “Receiving Confirmation Messages” on page 14).
CONFIRMATION OF A JOB
Jobs are messages that contain a task to complete or to accept.
Depending on the job priority (normal or urgent), completing
the job requires several steps.
NORMAL JOB
When receiving a normal job message:
1. Press Read.
The job is saved to your Text messages > Jobs list (see
“Menu: Inbox / Jobs (Lists)” on page 16). The sender
receives a read confirmation message (see “Receiving
Confirmation Messages” on page 14).
2. Press Accept.
You accept the job. The job is thus finished and will be
deleted from your Text messages > Jobs list. The sender
receives an order confirmation message (see “Receiving
Confirmation Messages” on page 14).

13
Receiving Text Messages / Jobs
Using the Options menu
When the message pop-up window is displayed, press to
open the Options menu. Confirm the job message with of the
following:
•Read: to inform the sender that you have read the job.
•Accepted: to inform the sender that you have accepted
the job.
•Reject: to inform the sender that you have rejected the job.
When accepted or rejected, the job is finished and will be
deleted from your Text messages > Jobs list.
URGENT JOB
When receiving an urgent job message:
1. Press Read.
The job is saved to your Text messages > Jobs list (see
“Menu: Inbox / Jobs (Lists)” on page 16). The sender
receives a read confirmation message (see “Receiving
Confirmation Messages” on page 14).
2. Press Accept.
You accept the job. The job is thus finished and will be
deleted from your Text messages > Jobs list. The sender
receives a read confirmation message (see “Receiving
Confirmation Messages” on page 14).
3. Press Done.
You have finished the job. The job will be deleted from your
Text messages > Jobs list. he sender receives a
confirmation message (see “Receiving Confirmation
Messages” on page 14).

Mitel 600/700 DECT Phone Messaging and Alerting Applications
14
Using the Options menu
When the message pop-up window is displayed, press to
open the Options menu. Confirm the job message with of the
following:
•Read: to inform the sender that you have read the job.
•Accepted: to inform the sender that you have accepted
the job.
•Reject: to inform the sender that you have rejected the job.
•Delay: to inform the sender that you have noticed the job.
•Done: to inform the sender that you have finished the job.
•Not done: to inform the sender that the job was not done.
•Failed: to inform the sender that the job failed.
When you have confirmed the job by selecting one of these
options (except the Read and Delay options), the job will be
deleted from your Text messages > Jobs list.
RECEIVING CONFIRMATION MESSAGES
When you have sent a message which requires confirmation,
you receive a confirmation message from the recipient. The
following table summarizes the different confirmation
messages:
ACKNOWLEDGMENT
BY RECIPIENT
CONFIRMATION
TO SENDER MESSAGE TYPE
Read Read confirmation
for the message [...]
Urgent text
message, Normal
/ urgent job
Accept / Accepted Order confirmation
for the message [...]
Normal / urgent
job
Reject Order in the
message [...] was
refused
Normal / urgent
job

15
Receiving Text Messages / Jobs
When you receive a confirmation message, do one of the
following:
• Press Read. The message will be deleted automatically.
• Press Esc. The message will be hidden.
You can read the message in the Text messages > Inbox
menu later. After acknowledgment, the confirmation
message is deleted.
RECEIVING INFORMATION MESSAGES
Information messages that contain general information (e.g.
current company news) can be displayed on your DECT phone.
The window is shown in the lower part of the display. To view
the display information hidden by the window, proceed as
follows:
• When idle: briefly press the key.
The information window is hidden for 10 seconds.
Delay Order in the
message [...] was
recognized
Urgent job
Done Executing
confirmation for the
message [...]
Urgent job
Not done Execution of the
order in the
message [...] not
finished
Urgent job
Failed Execution of the
order in the
message [...] failed
Urgent job
ACKNOWLEDGMENT
BY RECIPIENT
CONFIRMATION
TO SENDER MESSAGE TYPE

Mitel 600/700 DECT Phone Messaging and Alerting Applications
16
• When idle: long press the key.
The information window is removed until the next message
is received.
MENU: INBOX / JOBS (LISTS)
Received text messages and jobs are saved in lists. Up to 15
entries can be saved in your Inbox list and up to 10 entries in
your Jobs list. If the list is full, you receive an information
message in the display. In this case, you should delete entries
in the lists.
You can switch the list behaviour to Overwrite mode. If
Overwrite is enabled, old messages are overwritten if the
buffer is full (see “Menu: Overwrite” on page 27).
You can access the Inbox list or Jobs list through the Info
menu entry, or press a programmed key (see “Message List
Access through Programmed Keys” on page 30). You can also
use the Text messages menu:
• When idle, briefly press . Select the Text messages
> Inbox or Jobs menu entry.
Note: Confirmation messages and the failed message
notifications from the alarm / message server received
(and confirmed with Read) are not saved in your Inbox
list.
